2AVD2-MS62144PORTABLE VOICE AMPLIFIER

快速指南 M23 Model: MS62144 便携式扩音器 请仔细阅读本快速指南并妥善保存以备将来使用 本产品由中国平安保险公司承保 产品概述 TF CARD模式播放 开机时,TF CARD（不包含）插入扩音器后，会以TF CARD为优先播放，届时 如需用蓝牙播放时，短按 “ ” 键来切换音源。 录音 在有TF卡或者U盘插入时，短按“ ”键，扩音器开始录音，再次短按“ ” 键退出录音，并自动播放当前录音（新录入的文件排序最优先，且会重复 播放新录入的录音文件），短按任意键将退出录音播放。 录音回放 在U盘或TF卡播放模式下，双击“ ”键进入录音回放功能，依次播放已存 录音文件;短按“ ”键播放上一个录音,短按“ ”键播放下一个录音;再 次双击“ ”键，退出录音回放。 删除录音 在进入录音回放后，播放当前录音时，长按�秒“ ” 键可删除当前录音。 恢复出厂设置 在开机状态下，同时长按“ ” 和“ ” 键�秒 ，即可恢复出厂设置。 注意 ·不建议未经许可私下更换电池。 ·电池[电池组或电池组合]不得暴露在诸如日照、火烤或类似过热环境中。 开机/关机 在关机模式下，顺时针转动旋钮开启扩音器，可听到开机提示音。 关闭扩音器，逆时针转动旋钮关机，可听到关机提示音。 蓝牙配对 ·首次使用并开机时，扩音器将自动进入配对模式。 ·如已连上蓝牙设备,双击“ ”键，即可断开当前连接,以便与其它设备进 行配对。 ·如没有连上蓝牙设备，扩音器也会自动进入配对模式。 连接时，启用手机的蓝牙功能，搜索“ Monster M�� ”进行连接，连接成功 后你会听到提示音，白色指示灯由闪烁变成长亮 。 音乐控制 短按“ ”键，可播放或暂停音乐。 短按“ ”键，可播放上一首歌。 短按“ ”键，可播放下一首歌。 音量控制 逆时针旋转旋钮调低音量。 顺时针旋转旋钮调高音量。 USB IN (Audio) 模式播放 开机时，USB IN (Audio) 插入扩音器后，会以USB IN (Audio) 为优先播放， 届时如需用蓝牙播放时，短按“ ” 键来切换音源。 12345678 101112 9 ���g双胶���C+K 风琴折 双色印刷 ��x��mm 正 �.多功能旋钮 �.录音 短按：进入录音模式 长按：删除当前播放的录音文件 �.上一曲 短按：上一首歌 �.播放/暂停 短按：播放/暂停 双击：断开/回连蓝牙 长按�秒可清除所有已配对的设备记录 �.下一曲 短按：下一首歌 LED 指示灯/提示音指南 描述 提示音状态 白色指示灯闪烁 开机提示音开机 所有灯熄灭 关机提示音关机 白色指示灯闪烁 -未连接 白色指示灯长亮 连接成功提示音已连接 红色指示灯闪烁 低电提示 指示灯 指示灯 扩音器 充电 低电提示音- 充电中，红色指示灯长亮-- 充满电，红色指示灯熄灭-- 电源/充电 为了更好的使用体验，在使用扩音器前，您需要先为其充满电。 包装中包含了一条USB-C充电线（仅充电，无数据传输功能），使用�V/�A 或以上适配器(不包含)进行充电。 注意：- 其它不兼容的充电线可能会造成损坏。 - 如果连接线或设备潮湿、损坏，请勿充电。 本表格依据SJ /T�����- ����的规定来编制 产品有毒有害物质或元素表 X:表示该有害物质至少 在该部件的某一均质材料中的含量超出G B/T�� ���规定的限量要求。 O: 表示该有害物质在该部件所有均质材料中的含量均在G B/T�� ���规定的限量要求以 下。 ○ ○ ○ 有害物质 铅 (Pb) 汞 (Hg) 镉 (Cd) 六格铬 (Cr(VI)) 多溴联笨 (PBBs) 多溴二笨醚 (PBDEs) 部件名称 外壳线材喇叭主板 电池 其它 ○○○○ ○ ○○○○ ○ ○○○ ○ ○○○ ○ ○○○ ○ ○○○ X ○ ○ ○ ○ ○ ○ ○ �.模式切换 短按：模式切换 �.MIC输入接口 连接到有线话筒 �.USB (Audio)输入接口 连接USB存储设备 �.USB-C充电接口 ��.指示灯 ��.TF CARD输入接口 连接 TF CARD 存储设备 ��.充电指示灯 Model: MS62144 Power On/Off To turn on the Voice Amplifier, rotate the multifunction knob clockwise to power it on. A startup tone will be heard. To turn off the Voice Amplifier, rotate the knob counterclockwise. A shutdown tone will be heard. Bluetooth Connection • When first used and turned on, the Voice Amplifier will automatically enter a waiting mode for connection. • If the Bluetooth device is already connected, double click the " " button to disconnect the current connection so that you can connect to another device. • The Voice Amplifier will automatically enter pairing mode if it is not connected to a Bluetooth device. When connecting, enable the Bluetooth function of the mobile phone, search for "Monster Phonic 20" and connect. Aer the connection is successful, you will hear a prompt tone, the white light of stays on. Music Control Short press " " music can be played or paused. Short press " " to go to the previous song. Short press " " to go to the next song. Product Overview Power/Charging For better enjoyment, fully charge the Voice Amplifier before use. A USB-C charging cable (charge only) is included for standard USB compatible device. Please use a 5V/1A or above power adapter (not included). Caution: - Other incompatible charges may cause damages. - Do not use if the connector or device is wet or damaged. Volume Control Turn counterclockwise to decrease volume. Turn clockwise to increase volume. USB IN (Audio) Playback When Voice Amplifier is on and USB drive is inserted, USB IN (Audio) is the priority playback source. If you want to use Bluetooth function, press the " " button to switch the source. Micro SD Card Playback When Voice Amplifier is on and micro SD card (not included) is inserted, micro SD card is the priority playback source. If you want to use Bluetooth function, press the " " button to switch the source. Recording When a micro SD card or USB drive is inserted, short press the " " button to start recording. Short press the" " button again to stop recording, and the Voice Amplifier will automatically play the current recording (the newly recorded file will be prioritized and looped). Short pressing any button will exit the recording playback. LED indicator/Prompt tone Guide DescribePrompt toneStatus The white light flashingPower on tonePower on All lights offPower off tonePower off The white light flashing- Not connected The white light stays onConnectedConnected tone Low battery Voice Amplifier charging The red light flashingLow battery tone- Charging in progress, the red charging indicator light stays on - - Aer fully charged, the red charging indicator light off -- Indicator Light Indicator Light FCC Statement IC Caution Radio Standards Specification RSS-Gen, issue 5 - English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: This device may not cause interference. This device must accept any interference, including interference that may cause undesired operation of the device. RF exposure statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. - French: Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes: Cet appareil ne doit pas causer d'interférences. Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de provoquer un fonctionnement indésirable de l'appareil. Déclaration d'exposition RF: L'appareil a été évalué pour répondre aux exigences générales d'exposition aux RF. L'appareil peut être utilisé dans des conditions d'exposition portable sans restriction. IC: 28087-MS62144 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against …

Text truncated - open the document above for the full version.

AOGES CO., LIMITED 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Monster Creative Technology Co., Ltd. Address: Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Product Name: BLUETOOTH AUDIO GLASSES FCC ID: 2AVD2-G02A Model(s): MG25004, MG25011, MG25012, G02A 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Monster Creative Technology Co., Ltd.] (“the applicant”) designate [AOGES CO., LIMITED] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. USA Agent Company name: AOGES CO., LIMITED USA Address: 1624 Market St, Ste 226, #30327 Denver CO, 80202 USA FRN Number: 0033947847 Contact Name: XIAOYAN LAl Telephone No: +1 303 623 1940 Email: [email protected] Applicant Company name: Shenzhen Monster Creative Technology Co., Ltd. Address: Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Grantee FRN Number: 0036280543 FCC Grantee Code: 2AVD2 Contact Name: Wang runlong AOGES CO., LIMITED 2.911 (d)(7)USA Agent v1.5 Telephone No: 18925204512 Email: [email protected] Signature: Title: CEO Signature: Title: Mannger Date: 2025.11.25 Date: 2025.11.25 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Shenzhen Monster Creative Technology Co., Ltd. (2025.12.06) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2AVD2-MS62144) [Shenzhen Monster Creative Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Wang runlong Shenzhen Monster Creative Technology Co., Ltd. (2025.12.06) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2AVD2-MS62144) [Shenzhen Monster Creative Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Wang runlong

Differences Description We Shenzhen Monster Creative Technology Co., Ltd. state: Product： PORTABLE VOICE AMPLIFIER Model Name： MS62144, D151 Trade Name: MONSTER FCC ID: 2AVD2-MS62144 PCB board, structure and internal of these model(s) are the same, Only different in model name, So no additional models were tested. Signatory Signature Date: 2025.12.06 Name: Wang runlong Title: R & D Manager Company: Shenzhen Monster Creative Technology Co., Ltd. Address: Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China

Shenzhen Monster Creative Technology Co., Ltd. (2025.12.06) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (PORTABLE VOICE AMPLIFIER / MS62144, D151/ FCC ID: 2AVD2-MS62144) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description required to be submitted with this application be permanently withheld from public review. These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Please contact me if there is any information you may need. Sincerely, Name: Wang runlong

Shenzhen Monster Creative Technology Co., Ltd. (2025.12.06) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Wang runlong

Page 1 of 4 ReportNo.:STS2509185 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 4 ReportNo.:STS2509185 Photo3 Photo4 Page 3 of 4 ReportNo.:STS2509185 Photo5 Photo6 Page 4 of 4 ReportNo.:STS2509185 Photo7 Photo8

型 号/Model No.: MS62144 输入/Input: 5V 1A FCC ID: 2AVD2-MS62144 IC28087-MS62144 CMIIT ID: SN: MS621442580100001 制造商: 深圳市魔声创新技术有限公司 Manufacturer: Shenzhen Monster Creative Technology Co., Ltd 中国制造 Designed in California PORTABLE VOICE AMPLIFIER Made in China 魔声便携式扩音器 镭雕 镭雕颜色：本色 尺寸：38.94x14.58mm 安规信息 38.94mm 14.58mm

Page 1 of 4 ReportNo.:STS2509185 APPENDIX-PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 4 ReportNo.:STS2509185 Photo3 Photo4 Antenna Page 3 of 4 ReportNo.:STS2509185 Photo5 Photo6 Page 4 of 4 ReportNo.:STS2509185 Photo7

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2509185H02 Issued for Shenzhen Monster Creative Technology Co., Ltd. Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Product Name: PORTABLE VOICE AMPLIFIER Brand Name: MONSTER Model Name: MS62144 Series Model(s): D151 FCC ID: 2AVD2-MS62144 Test Standards: FCC 47CFR §2.1093 Page 2 of 9 Report No.: STS2509185H02 TEST REPORT Applicant’s Name ................. : Shenzhen Monster Creative Technology Co., Ltd. Address ................................. : Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Manufacturer's Name ........... : Shenzhen Monster Creative Technology Co., Ltd. Address ................................. : Room 1602, 1601A2, 1601B, 1601C, Building A, Fencheng Zhigu Building, No. 60 Tiezai Road, Xixiang Street, Bao’an District, Shenzhen, China. Product Description Product Name ........................ : PORTABLE VOICE AMPLIFIER Brand Name .......................... : MONSTER Model Name .......................... : MS62144 Series Model(s) ...................... : D151 Test Standards ..................... : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 26 Sept. 2025 Date (s) of performance of tests ............. : 26 Sept. 2025 ~ 09 Oct. 2025 Date of Issue .......................................... : 09 Oct. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2509185H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2509185H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 09 Oct. 2025 STS2509185H02 ALL Initial Issue Page 5 of 9 Report No.: STS2509185H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name PORTABLE VOICE AMPLIFIER Brand Name MONSTER Model Name MS62144 Series Model(s) D151 Model Difference Only the model names are different. Product Description The EUT is PORTABLE VOICE AMPLIFIER Operation Frequency: 2402~2480 MHz Modulation Type: BT BR(1Mbps): GFSK BT EDR(2Mbps): π/4-DQPSK BT EDR(3Mbps): 8DPSK Antenna gain: 1.94dBi Antenna Designation: PCB Power Rating Input: DC 5V 1A Adapter N/A Battery Model: 18650 Brand: N/A Rated Voltage:3.7V Charge Limit Voltage:4.2V Capacity: 1800mAh Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2509185H02 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2509185H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2509185H02 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same…

Text truncated - open the document above for the full version.

D151Antennaereport 1 productmodelnameantennamodel namePCBAntenna TestEquipment:Agilent5071 1、Antennamanufacturers OurBluetoothantennaisdirectlyusedinthePCBonboard mode,theantennaiscopperparkandtininjectionprocess, copperfoilthickness:H/HOZ,theplateisFR-4thickness of1.2mmmaterial; PCBmanufacturer: MEIZHOUCITYHONGLIPRINTEDGIRCUITBOARDCO.LTD 2、Antennaappearance 1.Dimensioneddrawing：14.4*5.5mm 2.Antennaepicture： D151Antennaereport 2 3、ElectricalCharacteristics Theantennanamatchingcircuit: BT Element E1(0402) NC E2(0402) 0ohm E3(0402) 0.7pF AntennaeS11test: Freq （ MHz ） 240024402480 SWR1.41.191.39 LogMag-15.48-21.16-15.61 D151Antennaereport 3 AntennaeGain: Frequency (MHz) Gain (dBi) Efficiency (%) 24000.4538.32 24101.0439.51 24201.5740.66 24301.8641.41 24401.8741.30 24501.9440.57 24601.7340.58 24701.6542.59 24801.8043.18 24901.7242.43 25001.6341.73 Directiondiagramofpassiveantenna: D151Antennaereport 4 AntennaeOTAtest: ChannelsTRPTIS 01.23-79.24 391.16-82.78 781.28-80.18 3.1Testmethodsandteststandards: NameParameterMethodStandardno. Antenna performance RadiationefficiencyIEEEStandard TestProcedures forAntennas ANSI/IEEEStd 149-2021 3.2Instrumentlistandcalibrationdate: EquipmentManufacturerModel No. Serial No. LastCal.DueDate. Network Analyzer AgilentE5071B2024.11..042025.11.04 AntennaRSCMW5002024.11..042025.11.04 ChamberFUTUKEJI4*4*3.52024.11..042025.11.04 D151Antennaereport 5 3.3Antennaemanufacturersreport TestLabName:ShenzhenWorldeliteElectronicCO.,LTD Testlaboratoryaddress:1stFloor,Building4,XiangyuerIndustrialPark, No.8LongshengRoad,LonggangDistrict,Shenzhen Tester:LiYuepeng Testdate:2025.1.20 3.4Testphotos: D151Antennaereport 6 3.5Testconfigurationdiagram:

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2509185W02 Issued for Shenzhen Monster Creative Technology Co., Ltd. Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Product Name: PORTABLE VOICE AMPLIFIER Brand Name: MONSTER Model Name: MS62144 Series Model(s): D151 FCC ID: 2AVD2-MS62144 Test Standards: FCC Part15.247 Page 2 of 94 Report No.: STS2509185W02 TEST REPORT Applicant’s Name ................. : Shenzhen Monster Creative Technology Co., Ltd. Address .................................. : Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Manufacturer's Name ........... : Shenzhen Monster Creative Technology Co., Ltd. Address .................................. : Room 1602, 1601A2, 1601B, 1601C, Building A, Fencheng Zhigu Building, No. 60 Tiezai Road, Xixiang Street, Bao’an District, Shenzhen, China. Product Description Product Name ........................ : PORTABLE VOICE AMPLIFIER Brand Name ........................... : MONSTER Model Name ........................... : MS62144 Series Model(s) .................... : D151 Standards ............................. : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................... : Date of receipt of test item ......... : 26 Sept. 2025 Date (s) of performance of tests : 26 Sept. 2025 ~ 09 Oct. 2025 Date of Issue ............................. : 09 Oct. 2025 Test Result ................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 94 Report No.: STS2509185W02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.6 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.7 EQUIPMENTS LIST 14 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 31 4.1 LIMIT 31 4.2 TEST PROCEDURE 31 4.3 TEST SETUP 31 4.4 EUT OPERATION CONDITIONS 31 4.5 TEST RESULTS 31 5. NUMBER OF HOPPING CHANNEL 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 TEST SETUP 32 5.4 EUT OPERATION CONDITIONS 32 5.5 TEST RESULTS 32 6. AVERAGE TIME OF OCCUPANCY 33 6.1 LIMIT 33 6.2 TEST PROCEDURE 33 6.3 TEST SETUP 33 6.4 EUT OPERATION CONDITIONS 33 6.5 TEST RESULTS 33 7. HOPPING CHANNEL SEPARATION MEASUREMEN 34 7.1 LIMIT 34 Page 4 of 94 Report No.: STS2509185W02 Table of Contents Page 7.2 TEST PROCEDURE 34 7.3 TEST SETUP 34 7.4 EUT OPERATION CONDITIONS 34 7.5 TEST RESULTS 34 8. BANDWIDTH TEST 35 8.1 LIMIT 35 8.2 TEST PROCEDURE 35 8.3 TEST SETUP 35 8.4 EUT OPERATION CONDITIONS 35 8.5 TEST RESULTS 35 9. OUTPUT POWER TEST 36 9.1 LIMIT 36 9.2 TEST PROCEDURE 36 9.3 TEST SETUP 37 9.4 EUT OPERATION CONDITIONS 37 9.5 TEST RESULTS 37 10. ANTENNA REQUIREMENT 38 10.1 STANDARD REQUIREMENT 38 10.2 EUT ANTENNA 38 APPENDIX 1-TEST DATA 39 DWELL TIME 39 MAXIMUM PEAK CONDUCTED OUTPUT POWER 49 -20DB BANDWIDTH 55 CARRIER FREQUENCIES SEPARATION 61 NUMBER OF HOPPING CHANNEL 67 BAND EDGE 70 BAND EDGE(HOPPING) 77 CONDUCTED RF SPURIOUS EMISSION 84 APPENDIX 2-PHOTOS OF TEST SETUP 94 Page 5 of 94 Report No.: STS2509185W02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 09 Oct. 2025 STS2509185W02 ALL Initial Issue Page 6 of 94 Report No.: STS2509185W02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 94 Report No.: STS2509185W02 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.755dB 2 Unwanted Emissions, conducted ±2.874dB 3 All emissions, radiated 9K-30MHz ±3.80dB 4 All emissions, radiated 30M-1GHz ±4.18dB 5 All emissions, radiated 1G-6GHz ±4.90dB 6 All emissions, radiated>6G ±5.24dB 7 Conducted Emission (9KHz-150KHz) ±2.19dB 8 Conducted Emission (150KHz-30MHz) ±2.53dB 9 Occupied Channel Bandwidth ±3.…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AVD2-MS62144 Setup photo AC Conduction RF Conduction Page 2 of 2 FCC ID: 2AVD2-MS62144 RE (Below 1GHz) RE (Above 1GHz)
