2AVD2-MH22280BLUETOOTH HEADPHONE

Charging Before using the "Monster Sleep Ear100" , please connect the USB-C cable to a power adapter to begin charging. Fully charge the earphones and the charging case before the first use. Power On/Off Open the charging case cover and remove the earphones, which will automatically turn on. If you want to turn off the earphones, please put the earphones into the charging case and close the cover,the earphones will power off and charge at the same time. Pairing Open the charging case and remove the earphones, which will automatically turn on.For new device connection, turn on the 75X95MM 105G双胶+K+186C印刷+风琴折 封面 Please read this Quick Start Guide carefully and keep it for future use. QUICK START GUIDE Bluetooth in your device and choose "Monster Sleep Ear100" from the Bluetooth list to connect. You will hear system prompts aer the earphones are connected to the device. If the earphones have been connected before, they will connect to the last connected device automatically aer being turned on. Wearing Put the "Monster Sleep Ear100" onto your ears and rotate to fit comfortably to get the best wearing and sound quality experience. 充电 请在使用此设备前先给耳机和充电仓充满电，此设备可以通过USB-C 接口进行充电。 电源开、关 打开充电盒盖，取出耳机，耳机将自动开机。如果想要关闭耳机，请将耳 机放入充电盒，耳机会关机同时进行充电。 配对 打开充电盒，取出耳机，耳机将自动开机。对于新设备连接，请打 开蓝牙设备并搜索 “Monster Sleep Ear100”进行连接，配对成功 后，您会听到系统提示音。如果耳机之前已配对过，开机就会尝试连接上 一次的设备。 佩戴 拿出耳机，将 “ Monster Sleep Ear100 ” 放入耳中，并轻轻旋转至 舒适位置，以确保获得最佳的佩戴效果和音质体验。 恢复出厂设置 开机状态下连续�击耳机触控键（双耳同时），耳机将自动关机，恢复出厂 设置。耳机放入充电盒再取出，耳机重新开机，进入配对模式。 注意 *不建议未经许可私下更换电池。 *电池[电池组或电池组合]不得暴露在照明，烘烤或类似过热的环境中。 *耳机充电仓在外接电源充电时，输入电压电流标准 Attention *Private replacement of batteries without permission is not recommended. *Batteries [battery packs or battery combinations] should not be exposed to lighting, baking or similar overheating environments. *The input voltage and current standard ≤ 5V/1A when charging the headset charging compartment from an external power source; 按键操作 Additional Operation Answer call End call Reject call LED indicator (earphone) Power on Power off Pairing is successful Pairing timed out Disconnect the phone Low battery LED indicator (charging case) Charging Discharge Low battery Press L or R twice Press L or R twice Press MFB on the le or right earphone for 2 seconds White flashes The white light on 2s and then turn off The white light on 1s and then turn off The white light on 2s and then turn off White flashes White light flashes slowly The white light continues to flash slowly, and the red light is full and on When the charging case charges the earphones, the white light stays on and turns off when it is full White flashes USB-C 接口处 USB-C Port MFB Operation 更多操作 接听 挂断 拒接 LED 指示灯（耳机） 开机 关机 配对成功 配对超时 断开手机连接 低电提醒 LED 指示灯（充电盒） 充电 放电 低电提醒 双击左或右耳 双击左或右耳 长按左或右耳MFB键�秒 白灯快闪 白灯长亮�S熄灭 白灯长亮�S熄灭 白灯长亮�S熄灭 白灯快闪 白灯慢闪 白灯持续慢闪,充满红灯长亮 仓给耳机充电时白灯长亮，充满熄灭 白灯闪烁 Reset In the power on state, press the MFB of the earphones 5 times (two earphones at the same time), and the earphones will automatically shut down to reset. Put the earphones in the charging case and then take them out, the earphones will turn on automatically, and enter the pairing mode. L/R L R L/RL L/R R L � � � � �s �s �� 快速指南 Model No: MH22280 Sleep Ear100 请仔细阅读快速指南并妥善保存以备将来使用 本产品由中国平安保险公司承保 Model No: MH22280 Sleep Ear100 ≤ �V/�A； 1 2 3 4 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. lf this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and the receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio / TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received. Including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. FCC ID: 2AVD2-MH22280 FCC STATEMENT 1 2 3 4 L/R L R L/RL L/R R L � � �� �s �s � � IC CAUTION Radio Standards Specification RSS-Gen, issue 5 - English: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: This device may not cause interference. This device must accept any interference, including interference that may cause undesired operation of the device. RF exposure statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. - French: Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes: Cet appareil ne doit …

Text truncated - open the document above for the full version.

AOGES CO., LIMITED 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Monster Creative Technology Co., Ltd. Address: Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Product Name: BLUETOOTH HEADPHONE FCC ID: 2AVD2- MH22280 Model(s): MH22280, W57, FY005 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Monster Creative Technology Co., Ltd.] (“the applicant”) designate [AOGES CO., LIMITED] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. USA Agent Company name: AOGES CO., LIMITED USA Address: 1624 Market St, Ste 226, #30327 Denver CO, 80202 USA FRN Number: 0033947847 Contact Name: XIAOYAN LAl Telephone No: +1 303 623 1940 Email: [email protected] Applicant Company name: Shenzhen Monster Creative Technology Co., Ltd. Address: Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Grantee FRN Number: 0036280543 FCC Grantee Code: 2AVD2 Contact Name: Wang runlong AOGES CO., LIMITED 2.911 (d)(7)USA Agent v1.5 Telephone No: 18925204512 Email: [email protected] Signature: Title: CEO Signature: Title: Mannger Date: 2025.12.15 Date: 2025.12.15 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

(Shenzhen Monster Creative Technology Co., Ltd.) (2025.12.15) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (2AVD2- MH22280) [Shenzhen Monster Creative Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Wang run long (Shenzhen Monster Creative Technology Co., Ltd.) (2025.12.15) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (2AVD2- MH22280) [Shenzhen Monster Creative Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Wang run long

Shenzhen Monster Creative Technology Co., Ltd. Product Similarity Declaration Product name: BLUETOOTH HEADPHONE Model name: MH22280, W57, FY005 FCC ID: 2AVD2-MH22280 We (Shenzhen Monster Creative Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only the appearance color and naming are different. Signature: Name: Wang run long Title: R & D Manager China, 2025.12.15

Shenzhen Monster Creative Technology Co., Ltd. 2025.12.15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (BLUETOOTH HEADPHONE / MH22280, W57, FY005/ FCC ID: 2AVD2- MH22280) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the • Schematics • Block diagram • Operation description required to be submitted with this application be permanently withheld from public review. These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Please contact me if there is any information you may need. Sincerely, Name: Wang run long

Shenzhen Monster Creative Technology Co., Ltd. 2025.12.15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen STS Test Services Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Name: Wang run long

Page 1 of 4 Report No.: STS2509001 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 4 Report No.: STS2509001 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2509001 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2509001 Photo 7 Photo 8

FCC ID Label Location The product does not have enough space to place the label, and FCC ID label is reflected in the user manual and package, as below: User Manual: Package:

Page 1 of 4 Report No.: STS2509001 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Page 2 of 4 Report No.: STS2509001 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2509001 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2509001 Photo 7

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2509001H02 Issued for Shenzhen Monster Creative Technology Co., Ltd. Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Product Name: BLUETOOTH HEADPHONE Brand Name: Monster, FVYAO Model Name: MH22280 Series Model(s): W57, FY005 FCC ID: 2AVD2-MH22280 Test Standards: FCC 47CFR §2.1093 Page 2 of 9 Report No.: STS2509001H02 TEST REPORT Applicant’s Name ................. : Shenzhen Monster Creative Technology Co., Ltd. Address ................................. : Room 1602, Building A, Fencheng Zhigu Building, Xixiang Street, Bao 'an District, Shenzhen, Guangdong, China Manufacturer's Name ........... : Shenzhen Monster Creative Technology Co., Ltd. Address ................................. : Room 1602, 1601A2, 1601B, 1601C, Building A, Fencheng Zhigu Building, No. 60 Tiezai Road, Xixiang Street, Bao’an District, Shenzhen, China. Product Description Product Name ........................ : BLUETOOTH HEADPHONE Brand Name .......................... : Monster, FVYAO Model Name .......................... : MH22280 Series Model(s) ...................... : W57, FY005 Test Standards ..................... : FCC 47CFR §2.1093 447498 D04 Interim General RF Exposure Guidance v01 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 01 Sept. 2025 Date (s) of performance of tests ............. : 01 Sept. 2025 ~ 06 Sept. 2025 Date of Issue .......................................... : 06 Sept. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2509001H02 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2509001H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 06 Sept. 2025 STS2509001H02 ALL Initial Issue Page 5 of 9 Report No.: STS2509001H02 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name BLUETOOTH HEADPHONE Brand Name Monster, FVYAO Model Name MH22280 Series Model(s) W57, FY005 Model Difference Only the appearance color and naming are different Product Description The EUT is BLUETOOTH HEADPHONE Operation Frequency: 2402 – 2480 MHz Modulation Type: BT BR(1Mbps): GFSK BT EDR(2Mbps): π/4-DQPSK BT EDR(3Mbps): 8DPSK Antenna gain: 2.78dBi Antenna Designation: Chip Antenna Power Rating Input: DC 5V 05A Adapter N/A Battery EAR: Model: 401012 Brand: N/A Rated Voltage: 3.7 V Charge Limit Voltage: 4.2 V Capacity: 30mAh BOX: Model: 602030 Brand: N/A Rated Voltage: 3.7 V Charge Limit Voltage: 4.2 V Capacity: 300mAh Hardware Version V1.0 Software Version V6.0 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2509001H02 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2509001H02 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2509001H02 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separat…
