2AVD2-MH41902Monster Bluetooth Headphone

MONSTER CLARITY 700 dB Model No.: MH41902 FCC ID: 2AVD2‐MH41902 Quick Start Guide Please read this Quick Start Guide carefully and keep it for future use. Product Overview z Earphones (Left & Right) z Charging Case z Eartips x 3 Pairs (S, M & L, M size installed) z USB-C Charging Cable z Quick Start Guide & Warranty letter ② ① ③ ④ ⑦ ⑥ ⑤ Multi Function Button (MFB） 1. LED Indicator 2. Earphone - Charging Contacts 3. Eartip 4. Charging Case - Charging Contacts 5. Charging Case - Battery level LED Indicator 6. USB-C charging port Power On/Off The earphones will automatically turn on after removing from the charging case. To turn off the earphones, put back to the charging case. Earphone’s light indicator is on and start charging. When the LED indicator is off, it is fully charged. Experiment with the different sizes of ear tip to find your perfect fit. Pairing Remove earphones from charging case, the earphones will turn on automatically. Left and right earphones will be connected automatically. Wait for a few seconds, “pairing” voice prompt will be heard. For new device connection, go to the Bluetooth settings on your mobile device and set it to search for new devices (new Monster device). Once the earphone is paired, you will hear “connected”. Volume Control Volume down: quickly double press the MFB on the left earphone during music streaming Volume up: quickly double press the MFB on the right earphone during music streaming Calling Answer/End Call: short press MFB button to answer/end the phone call Reject Call: long press MFB button about 2 seconds to reject phone call Music Play/Pause: press MFB once to play/pause music Track forward: press and hold MFB on right earphone for about 2 seconds Track backward: press and hold MFB on left earphone for about 2 seconds Voice Control After connecting to the phone, quickly double press the MFB to activate the voice assistant. Reset to Factory Settings When both left and right earphones are in off state, press and hold both MFB for about 5 seconds at the same time. Sound effect will be heard, both left and right earphones are reset successfully. Earphones will power on and connect left and right sides automatically, and “pairing” voice prompt will be heard for device connection. LED Indicator Guide Status Description Voice Prompt Power On LED indicator stays on about 1 second. “Power On” Power Off LED indicator stays on about 1 second. “Power Off” Pairing LED indicator flashes continuously. “Pairing” Connected LED indicator will be turned off. “Connected” Charging – Earphones LED indicator stays On. - Charging – Charging Case Battery level LED Indicator flashes while charging. When battery level LED indicator is off, it is fully charged. - Caution ONLY use computer USB output or standard 5 volt only (500mA minimum) power adapter for charging. Damage may occur if non-standard USB power adapter is used for charging. Do not charge if connector and/or device is wet or damaged. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction

Declaration Monster Bluetooth Headphone Model Number: MH41902 FCC ID: 2AVD2-MH41902 The device have left and right earphones ，the left and right earphones are electrically identical. <Signature> Name: Qingyun He Title: R & D Manager Company: Shenzhen Monster Creative Technology Co., Ltd.

DATE:2020.11.05 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID:2AVD2-MH41902 ProductName:MonsterBluetoothHeadphone RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommissionsrules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: (Listherethedocumentsforwhichyouareseekingconfidentiality–forexample...)  Schematics Blockdiagram Operationdescription Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. <Signature> Name:QingyunHe Title:R&DManager Company:ShenzhenMonsterCreativeTechnologyCo.,Ltd.

DATE:2020.11.05 FederalCommunicationsCommission Authorization&EvaluationDivision 7345OaklandMillsRoad Columbia,Maryland21046 AuthoritytoActasAgent Onourbehalf,IappointESTTechnologyCo.,Ltd.Address:Chilingxiang,Qishantou,Santun, Houjie,Dongguan,Guangdong,China (NameofAgentcompanynameandaddress)toact asouragentinthepreparationofthisapplicationforequipmentcertification.Icertifythat submitteddocumentsproperlydescribethedeviceorsystemforwhichequipment certificationissought.Ialsocertifythateachunitmanufactured,importedormarketed,as definedintheFederalCommunicationsCommission’sregulationswillhaveaffixedtoita labelidenticaltothatsubmittedforapprovalwiththisapplication. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,I acknowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforcertification, stillresideswithShenzhenMonsterCreativeTechnologyCo.,Ltd.Address: FlatG,3/F,BuildingD, TheCentralAvenue,XixiangStreet,Bao'anDistrict,Shenzhen,Guangdong,China (ApplicantNameandaddress) <Signature> Name:QingyunHe Title:R&DManager Company:ShenzhenMonsterCreativeTechnologyCo.,Ltd.

External Photos M/N: MH41902 External Photos M/N: MH41902 External Photos M/N: MH41902 External Photos M/N: MH41902 External Photos M/N: MH41902 External Photos M/N: MH41902 External Photos M/N: MH41902

Internal Photos M/N: MH41902 Internal Photos M/N: MH41902 Internal Photos M/N: MH41902 Internal Photos M/N: MH41902 Internal Photos M/N: MH41902 Internal Photos M/N: MH41902

FCC ID: 2AVD2-MH41902 EST Technology Co., Ltd Report No. ESTE-R2011037 Page 1 of 3 FCC RF EXPOSURE REPORT Shenzhen Monster Creative Technology Co., Ltd. Monster Bluetooth Headphone Model Number: MH41902 FCC ID: 2AVD2-MH41902 Prepared for: Shenzhen Monster Creative Technology Co., Ltd. Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2011037 Date of Test: Sep. 18~Nov. 02, 2020 Date of Report: Nov. 05, 2020 FCC ID: 2AVD2-MH41902 EST Technology Co., Ltd Report No. ESTE-R2011037 Page 2 of 3 1. Applicable Standards FCC Part 2(Section 2.1093) FCC KD B447498 D01 General RF Exposure Guidance v06 2. Exposure Evaluation of Portable or Mobile Devices Human exposure to RF emissions from portable devices (47 CFR §2.1093), as defined by the FCC, must be evaluated with respect to the FCC-adopted limits for SAR. Evaluation of mobile devices, as defined by the FCC, may also be performed with respect to SAR limits, but in such cases it is usually simpler and more cost-effective to evaluate compliance with respect to field strength or power density limits. For certain devices that are designed to be used in both mobile and portable configurations similar to those described in 47 CFR §2.1091(d)(4), such as certain desktop phones and wireless modem modules, compliance for mobile configurations is also satisfied when the same device is evaluated for SAR compliance in portable configurations. SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: 2AVD2-MH41902 EST Technology Co., Ltd Report No. ESTE-R2011037 Page 3 of 3 3. Evaluation Results Mode Frequency (MHz) Peak output Power (dBm) Peak output Power (mW) Target power (dBm) Results GFSK 2402 -3.64 0.433 -3±1 0.196 2441 -2.76 0.530 -2±1 0.248 2480 -3.32 0.466 -3±1 0.199 8-DPSK 2402 2.12 1.629 2±1 0.618 2441 2.92 1.959 2±1 0.623 2480 2.70 1.862 2±1 0.628 BLE GFSK 1M 2402 -3.95 0.403 -3±1 0.196 2440 -3.38 0.459 -3±1 0.197 2480 -3.86 0.411 -3±1 0.199 BLE GFSK 2M 2402 -3.99 0.399 -3±1 0.196 2440 -3.39 0.458 -3±1 0.197 2480 -4.00 0.398 -4±1 0.158 Note: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required. End of Test Report

FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011036 Page 1 of 74 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Shenzhen Monster Creative Technology Co., Ltd. Monster Bluetooth Headphone Model Number: MH41902 FCC ID: 2AVD2-MH41902 Prepared for: Shenzhen Monster Creative Technology Co., Ltd. Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2011036 Date of Test: Sep. 18~Nov. 02, 2020 Date of Report: Nov. 05, 2020 FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011036 Page 2 of 74 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION......................................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................. 5 1.1. Description of Device (EUT) ........................................................................................................... 5 1.2. Antenna Information ........................................................................................................................ 5 2. SUMMARY OF TEST ......................................................................................................................... 6 2.1. Summary of test result ...................................................................................................................... 6 2.2. Test Facilities ................................................................................................................................... 7 2.3. Measurement uncertainty ................................................................................................................. 8 2.4. Assistant equipment used for test ..................................................................................................... 8 2.5. Block Diagram ................................................................................................................................. 8 2.6. Test Mode ......................................................................................................................................... 9 2.7. Power Setting of Test Software ........................................................................................................ 9 2.8. Duty Cycle ...................................................................................................................................... 10 2.9. Channel List ................................................................................................................................... 12 2.10. Test Equipment List ....................................................................................................................... 13 3. 6DB BANDWIDTH .......................................................................................................................... 14 3.1. Limit ............................................................................................................................................... 14 3.2. Test Setup ....................................................................................................................................... 14 3.3. Spectrum Analyzer Setting ............................................................................................................. 14 3.4. Test Procedure ................................................................................................................................ 14 3.5. Test Result ...................................................................................................................................... 15 4. MAXIMUM PEAK OUTPUT POWER ................................................................................................. 19 4.1. Limit ............................................................................................................................................... 19 4.2. Test Setup ....................................................................................................................................... 19 4.3. Spectrum Analyzer Setting ............................................................................................................. 19 4.4. Test Procedure ................................................................................................................................ 19 4.5. Test Result ...................................................................................................................................... 20 5. POWER SPECTRAL DENSITY .......................................................................................................... 24 5.1. Limit ............................................................................................................................................... 24 5.2. Test Setup ....................................................................................................................................... 24 5.3. Spectrum Analyzer Setting ............................................................................................................. 24 5.4. Test Procedure ................................................................................................................................ 24 5.5. Test Result ...................................................................................................................................... 25 6. CONDUCTED BAND EDGE ............................................................................................................. 29 6.1. Limit ............................................................................................................................................... 29 6.2. Test Setup .…

Text truncated - open the document above for the full version.

Conducted Test Radiated Test (Below 1GHz) Radiated Test (Above 1GHz)
