2AVD2-MH72002RMonster Bluetooth Headphones

MonsterBluetoothHeadphones Model: MH72002 Quick Start Guide Please read this Quick Start Guide carefully and keep it for future use. Product Overview:  Earphones (Left & Right)  Charging Case  Eartips x 3 Pairs (S, M & L)  USB-C Charging Cable  Quick Start Guide & Warranty letter 1. Multi Function Button (MFB） 2. LED Indicator 3. Earphone - Charging Contacts 4. Eartip 5. Charging Case - Charging Pins 6. Charging Case - Battery LED Indicator 7. USB-C Charging Port 8. Reset Button 8 7 1 4 2 3 5 6 Power On/Off The earphones will automatically turn on after removing from the charging case. To turn off the earphones, put back to the charging case. Earphone’s light indicator is on and starts charging, the earphones will automatically turn off. When the LED indicator is off, it is fully charged. Experiment with the different sizes of ear tip to find your perfect fit. Pairing Remove earphones from the charging case, the earphones will turn on automatically. Left and right earphones will be connected automatically. Wait for a few seconds, “pairing” voice prompt will be heard. For new device connection, go to the Bluetooth settings on your mobile device and set it to search for new devices (new Monster device). Once the earphone is paired, you will hear “connected”. Volume Control To decrease/increase the volume level, quickly double press the MFB on the left/right earphone during music streaming. Calling Short press the MFB to answer/end a phone call, long press the MFB about 2 seconds to reject a phone call. Music Short press the MFB once to play/pause music. To play the previous/next song, press and hold left/right MFB for around 2 seconds Voice Control After connecting to the phone, quickly press the MFB three times on the left earphone to activate the voice assistant. Game and music modes Music is the default mode. Quickly press the MFB three times on the right earphone, to switch between game and music modes, corresponding voice prompt “game mode” or “music mode” will be heard. Reset Put the earphones back to the charging case, both LED indicators will be turned on to indicate earphones are charging. Then long press the reset button for around 3 seconds, The LED indicators flash three times. Earphones reset successfully, remove earphones from the charging case, the earphones will turn on automatically. Left and right earphones will be connected automatically. Wait for a few seconds, “pairing” voice prompt will be heard. LED Indicator Guide StatusDescriptionVoice Prompt Power OnBlue LED indicator stays on about 1 second “Power On” Power OffBlue LED indicator stays on about 1 second “Power Off” PairingBlue LED indicator flashes continuously“Pairing” Music Mode (Connected)LED indicator is off“Connected” Game Mode (Connected)Blue LED indicator flashes every 6 seconds - Charging – EarphonesBlue LED indicator stays on- Charging – Charging Case Battery LED Indicator flashes while charging. When battery LED indicator is off, it is fully charged. - Charging Case Battery Low Battery LED Indicator flashes five times when battery case is activated. - FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Shenzhen Monster Creative Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021-05-21 Subject; Request for Long Term Confidentiality FCC ID: 2AVD2-MH72002R To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: run long wang Title: R & D Manager

Shenzhen Monster Creative Technology Co., Ltd. Agent Authorization Company: Shenzhen Monster Creative Technology Co., Ltd. Address: Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, 518126 China Product Name: Monster Bluetooth Headphones Model Number(s): MH72002 Product Description: Monster Bluetooth Headphones We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2021-05-21 Name: run long wang Title: R & D Manager Company: Shenzhen Monster Creative Technology Co., Ltd.

Page 1 of 4 Appendix B: Photographs of EUT Product: Monster Bluetooth Headphones Model: MH72002 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: MH72002 Label: Size: L*W=10*3.5mm FCC ID: 2AVD2-MH72002R Location

Page 1 of 3 Appendix B: Photographs of EUT Product: Monster Bluetooth Headphones Model: MH72002 Internal Photos Page 2 of 3 Antenna Page 3 of 3

RF exposure evaluation FCC ID: 2AVD2-MH72002R §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  For EDR+BDR: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 0 2.402 5.88 5±1 6 3.98 5 1.23 3.0 Result: Base on the calculation value, No SAR measurement is required.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AVD2-MH72002R Product: Monster Bluetooth Headphones Model No.: MH72002 Additional Model No.: N/A Trade Mark: MONSTER Report No.: TCT210419E075 Issued Date: May 17, 2021 Issued for: Shenzhen Monster Creative Technology Co., Ltd. Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, 518126 China Issued By: Shenzhen Tongce Testing Lab TCT Testing Industrial Park, Fuqiao 5th Industrial Zone, Fuhai Street, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT210419E075 Page 2 of 65 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification....................................................................................... 3 2. Test Result Summary ............................................................................... 4 3. EUT Description ........................................................................................ 5 4. General Information .................................................................................. 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations ................................................................... 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ...................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. 20dB Occupy Bandwidth .................................................................................... 18 6.5. Carrier Frequencies Separation ......................................................................... 23 6.6. Hopping Channel Number .................................................................................. 28 6.7. Dwell Time ............................................................................................................ 31 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 36 6.9. Conducted Band Edge Measurement ................................................................ 37 6.10.Conducted Spurious Emission Measurement .................................................. 41 6.11.Radiated Spurious Emission Measurement ..................................................... 45 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT210419E075 Page 3 of 65 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Monster Bluetooth Headphones Model No.: MH72002 Additional Model: N/A Trade Mark: MONSTER Applicant: Shenzhen Monster Creative Technology Co., Ltd. Address: Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, 518126 China Manufacturer: Shenzhen Monster Creative Technology Co., Ltd. Address: Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, 518126 China Date of Test: Apr. 21, 2021 – May 14, 2021 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: May 14, 2021 Rleo Reviewed By: Date: May 17, 2021 Beryl Zhao Approved By: Date: May 17, 2021 Tomsin Report No.: TCT210419E075 Page 4 of 65 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT210419E075 Page 5 of 65 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product Name: Monster Bluetooth Headphones Model : MH72002 Additional Model: N/A Trade Mark: MONSTER Blu…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Monster Bluetooth Headphones Model: MH72002 Radiated Emission Page 2 of 2 Conducted Emission
