P10/Adventurer 1000 型号:MS22141 / Model No:MS22141 快速指南/ Quick Start Guide 请仔细阅读此快速指南并妥善保存以备将来使用。 Please read this Quick Start Guide carefully and keep it for future use. 产品概述/ Product Overview • 音箱 • 充电直播一体线 • AUX IN线 • 无线话筒 • 快速指南&保修卡 • Speaker Unit • AUX IN Cable • USB-C Charging Cable • Quick Start Guide & Warranty Letter 1. Guitar volume adjustment 2. Reverberation adjustment 3. Microphone volume adjustment 4. Accompaniment Vocal switch 5. Previous song 6. Multi-function button Press to play or pause music. 7. Next song 8. Master volume adjustment Turn clockwise/counterclockwise to increase/decrease the master volume. 9. Treble adjustment Rotate clockwise/counterclockwise to increase/decrease the treble. 10. Bass adjustment Rotate clockwise/counterclockwise to increase/decrease the bass. 11. Sound mode Press this button to switch between sound modes. 12. Bluetooth Press the button to enter Bluetooth pairing mode. Press and hold for 5 seconds to clear all paired devices. 13. Power on/off Press and hold for 2 seconds to turn on or off. 14. Light effect Press this button to switch between different lighting modes. Press and hold for 2 seconds to turn the light on or off. 1.吉他音量调节 2.混响调节 3.话筒音量调节 4.伴唱/原唱切换 5.上一曲 6.多功能键 短按可以播放或暂停音乐。 7.下一曲 8.主音量调节 顺时针/逆时针旋转以增加/减小主音量。 9.高音调节 顺时针/逆时针旋转以增加/减少高音。 10.低音调节 顺时针/逆时针旋转以增加/减少低音。 11.音效模式 短按切换不同音效模式。 12.蓝牙 短按一下可以进入蓝牙配对模式。 按住 5 秒可清除所有已配对的设备。 13.电源开/关 按住2秒可开机或关机。 14.灯效键 短按切换不同灯光模式。 按住 2 秒打开或关闭灯效。 1. MIC IN Connect to microphone (not included). 2. MONITOR Listening interface, connected to headphones (not included). 3. AUX IN External audio devices can be connected using audio cables (not included). 4.RESET Reset button 5.TF CARD Connect TF Card (not included) storage device. 6. USB-C/LIVE USB-C charging port Live broadcast port connects live broadcast devices. 7. USB Connect a USB storage device. 8.GUITAR IN Connect to guitar (not included). 1.MIC IN 连接到有线话筒（不包含）。 2.MONITOR 监听接口，连接到耳机（不包含）。 3.AUX IN 使用音频电缆可以连接外接音频设备。 4.RESET 复位键 5.TF CARD 连接 TF Card（不包含） 存储设备。 6.USB-C/LIVE USB-C充电接口 OTG直播接口,连接直播设备。 7.USB 连接 USB 存储设备。 8.GUITAR 连接到吉他（不包含）。 LED 指示灯/语音提示指南 描述 语音提示 状态 ○白色LED灯亮 开机提示音 开机 ●白色LED灯灭 关机提示音 关机 ★白色LED闪烁 蓝牙等待连接 未连接 ○白色LED长亮 蓝牙已连接 已连接 ○白色LED灯亮 - - ●白色LED灯暗 - - ●白色LED灯灭 - - 低电提示 - 电量低请充电 - 音响充电 充电中，红色指示灯亮， 充满后，红色指示灯灭 - - 说明：○表示指示灯亮；●表示LED灯变暗 ●表示指示灯灭；★表示指示灯闪烁. LED Indicator Guide Description Voice/Tone Status ○White LED light Opening Tone Power On ●The white LED is off Goodbye Power Off ★White LED lights flashing Discovering Not connected ○White LED light Your device is connected Connected ○White LED light is white - - ●White LED light dark white - - ●The white LED is off - - Battery low - Battery low - Charging While charging, the red indicator lights up,When full, the red light goes off - - Description：○Indicator light；●Indicates that the LED lights dim；●Indicate that the light is off；★Indication flash. 使用遥控器 要使用遥控器，请将其指向音箱前面的遥控传感器。 如果遥控器的路径被阻塞，遥控器将无法运行。遥 控器与音箱的距离最远约为 6 米，与传感器的任一侧最多成30 度角，如下图所示。 遥控器概览 电源/充电 为了更好的使用体验，在使用音响前，您需要先为其充满电。 包装中包含了一条USB-C充电线（仅充电，无数据传输功能），可以与其它兼容USB的标准 充电设备。使用5V/2A或以上适配器(不包含)进行充电。 注意：如果连接线或设备潮湿、损坏，请勿充电。 Power/Charging For better enjoyment, fully charge the speaker before use. A USB-C charging cable (charge only) is included for standard USB compatible device. Please use a 5V/2A or above power adapter (not included). Caution: - Other incompatible charges may cause damages. - Do not use if the connector or device is wet or damaged. 开机/关机 在关机模式下，按住电源开/关按键大约2秒以开启音响，可听到开机提示音。 关闭音响，请再次按住电源开/关按键大约2秒，可听到关机提示音。 注意：开机后如没有连接到蓝牙设备，音响大约在15分钟内关闭。 Power On/Off To turn on the speaker, press and hold the Power On/Off Button for 2 seconds, you will hear a power on tone. To turn off the speaker, press and hold the Power On/Off Button for 2 seconds, you will hear a power off tone. Caution: If no Bluetooth device is connected, the speaker will turn off in 15 minutes. 蓝牙连接 • 首次使用并开机时，音响将自动进入等待连接模式。 • 如已连上蓝牙设备，按住2秒“ ”键，即可断开当前连接，以便与其他设备进 行连接。 • 如沒有连上蓝牙设备，音响也会自动进入配对模式。 配对时，启用手机的蓝牙功能，搜索“Monster P10”进行连接，连接成功后你会听到提示 音，蓝牙指示灯从闪烁变成长亮。 Bluetooth Connection Monster Party GO • When first used and turned on, the speaker will automatically enter a waiting mode for connection. • If the Bluetooth device is already connected, press " " button to disconnect the current connection and connect with other devices. • The speaker will automatically enter pairing mode if it is not connected to a Bluetooth device. When pairing, enable the Bluetooth function of the phone and search for "Monster Adventurer 1000" to connect. When the connection is successful, you will hear a prompt tone and the Bluetooth indicator will turn from blinking to long on. 音乐控制 按一次“ ”可播放或暂停音乐。 按一次“ ”可转至上一首歌曲。 按一次“ ”可转至下一首歌曲。 Music control Press " " once to play or pause music. Press " " once to go to the previous song. Press " " once to go to the next song. USB IN (Audio) 模式播放 开机时，USB IN (Audio) 插入音响后，会以USB IN (Audio) 为优先播放，届时如需用蓝牙 播放时，可以通过 “ ” 按键来切换音源。 USB IN (Audio) Playback When speaker is on and USB drive is inserted, USB IN (Audio) is the priority playback source. If you want to use Bluetooth function, press the “ ” Button to switch the source. Micro SD 卡播放 开机时，micro SD卡（不包含）插入音响后，会以micro SD卡为优先播放，届时如需用蓝 牙播放时，可以通过 “ ” 按键来切换音源。 Micro SD Card Playback When speaker is on and micro SD card（Not included） is inserted, micro SD card is the priority playback source. If you want to use Bluetooth function, press the “ ” Button to switch the source. AUX IN模式播放 开机时，外接AUX IN音源输入后，会以外接AUX IN音源为优先播放，届时如需用蓝牙播 放时，可以通过 “ ” 按键来切换音源。 AUX IN Playback When speaker is on and audio source is inserted via AUX IN, AUX IN is the priority playback source. If you want to use Bluetooth function, press the “ ” Button to switch the source. 直播功能 将音响与直播设备连接，一端连接直播设备，另一端连接音响直播口，使用另一台移动设备 连接到音响的蓝牙或AUXIN播放伴奏，音响端所有声音（音乐/话筒声音）都可以通过直播 线（不包含）上传到直播设备。 Live broadcast function Connect the speaker to the live broadcasting device, one end of which is connected to the live broadcasting device, and the other end is connected to the live bro…
