2AWY6-ELMT7663BUNTWiFi Module

Module EL.MT7663BUN-WFT Datasheet IEEE 802.11 2x2 WiFi 5 Wireless LAN and Bluetooth 5.1 USB Combo Module [SoC MT7663BEN] for 802.11a/b/g/n/ac + Bluetooth 5.1 Version： 0.4 For Private Preview — 1 /4 — EL.MT7663BUN-WFT 1.Features 1.1 Module overview EL.MT7663BUN-WFT module design is based on Mediatek MT7663BUN solution, The MT7663BUN is a highly integrated single chip which has built in a 2x2 dual-band wireless LAN radio and Bluetooth radio. It includes Bluetooth EDR and LE radio which complies with Bluetooth v2.1+EDR, v4.2, and v5.1. The Module is a highly integrated MAC/BBP and 2.4/5GHz PA/LNA single chip which supports a 866.7Mbps PHY rate. The Module is designed to support standard-based features in the areas of security, quality of service, and international regulations, giving end users the greatest performance anytime and in any circumstance. This documentation describes the engineering requirements specification. 1.2 system function This WLAN Module design is based on Mediatek MT7663BUN. It is a highly integrated single-chip MIMO(Multiple In Multiple Out) Wireless LAN (WLAN) network interface controller complying with the 802.11 specification and Bluetooth over USB interface. It combines a MAC, a 2T2R capable baseband, and RF in a single chip. An intelligent Wi-Fi/Bluetooth coexistence algorithm is implemented to provide the best harmonized Wi-Fi and Bluetooth radio performance. 1.3 System characteristics Module Size Typical:25.0mmx 30.0mm x 6.0mm Main chip Mediatek MT7663BUN frequency band 2.4G/5G Antenna External Antennas Design voltage 3.3V +/-10% input PCB information 4-layers design (1+/-0.15mm) Peripheral interface USB 2.0 working temperature -10°C to +70°C Storage temperature -40°C to +85°C power waste Power Consumption（WIFI TX）：700mA@5V 5G TX NSS=2 HT20 MCS0 Power Consumption（WIFI RX）：150mA@5V 5G RX NSS=2 VHT80 MCS9 Power Consumption（BT TX）：82mA@5V Power Consumption（BT RX）29mA@5V Antistatic index HBM 2 kV（Class 1 B） ESD ：±4 kV — 2 /4 — EL.MT7663BUN-WFT 1.4 Logic block diagram 2.mechanical properties 2.1 size Typical size (W x L x T): 25.0mmx 30.0mm x 6.0mm PCB thickness: 1.0mm (+/-0.15mm) TOP View BOT View — 3 /4 — EL.MT7663BUN-WFT 2.2 Pin definition NO. definition function 1 GND Module grounding 2 DP+ USB D+ 3 DM- USB D- 4 VCC 3.3V INPUT 5 CHIP_EN Module enable 6 WIFI_WAKE WIFI WAKE Host 7 GND Module grounding 8 SYNC NC 9 BT_WAKE GPIO port of wake-up TV 10 GND Module grounding 11 GND Module grounding 12 BT_RF BT RF 13 GND Module grounding 2.3 Information identification TOP VIEW BOTTOM VIEW — 4 /4 — EL.MT7663BUN-WFT 3.RF characteristics 3.1 Wi-Fi RF characteristics Items Contents WLAN Standard IEEE 802.11a/b/g/n/ac Frequency Range 5.1GHz~5.9GHz(5GHz, excluding 5500~5720MHz) 2.412GHz~2.462GHz(Wifi) Channels CH1 to CH11 @ 2.4G CH36 to CH165 @ 5G(excluding CH100~144) Modulation Mode 11b: DBPSK, DQPSK and CCK and DSSS 11a/g: BPSK, QPSK, 16QAM, 64QAM and OFDM 11n: BPSK, QPSK, 16QAM, 64QAM and OFDM 11ac: BPSK, QPSK, 16QAM, 64QAM,256QAM and OFDM Output Power 802.11b /1Mbps-11Mbps: 15dBm ± 2dBm 802.11g /6Mbps-48 Mbps：13dBm ± 2dBm 802.11g /54Mbps: 13dBm ± 2dBm 802.11a /6Mbps-48 Mbps：14dBm ± 2dBm 8 02.11a /54Mbps: 14dBm ± 2dB m 2.4G 802.11n HT20 / MCS0-MCS6: 15dBm ± 2dBm 2.4G 802.11n HT20 /MCS7: 15dBm ± 2dBm 5G 802.11n HT20 / MCS0-MCS6: 16dBm ± 2dBm 5G 802.11n HT20 /MCS7: 16dBm ± 2dBm 2.4G 802.11n HT40 / MCS0-MCS6: 12dBm ± 2dBm 2.4G 802.11n HT40 /MCS7: 12dBm ± 2dBm 5G 802.11n HT40 / MCS0-MCS6: 16dBm ± 2dBm 5G 802.11n HT40 /MCS7: 16dBm ± 2dBm 5G 802.11ac VHT20/VHT40/VHT80 MCS0-MCS6: 16dBm ± 2dBm 5G 802.11ac VHT20/VHT40/VHT80 MCS7: 16dBm ± 2dBm 5G 802.11ac VHT20/VHT40/VHT80 MCS8-MCS9: 16dBm ± 2dBm EVM 802.11b /11Mbps : ≤ -15dBm 802.11g /54Mbps : ≤ -28dBm 802.11n HT20 /MCS7: ≤ -30dBm 802.11n HT40 /MCS7 : ≤ -30dBm Receive Sensitivity 11b,20MHz error rate≤8% 1Mbps ≤-76dBm 11Mbps ≤-76dBm Receive Sensitivity 11g,20MHz error rate≤10% 6Mbps ≤-82dBm 54Mbps ≤-65dBm Receive Sensitivity 11n,20MHz 误包率≤10% MCS0 ≤-82dBm MCS7 ≤-64dBm Receive Sensitivity 11n,40MHz error rate≤10% MCS0 ≤-79dBm MCS7 ≤-61dBm — 5 /4 — EL.MT7663BUN-WFT Receive Sensitivity 11ac,20MHz error rate≤10% MCS0 ≤-82dBm MCS7 ≤-64dBm Receive Sensitivity 11ac,40MHzerror rat≤10% MCS7 ≤-79dBm MCS7 ≤-56dBm Receive Sensitivity 11ac,80MHzerror rat≤10% MCS7 ≤-76dBm MCS7 ≤-51dBm 3.2 BT RF characteristics Items Contents Channel BR,EDR:CH0 toCH78 LE:CH0 to CH39 Modulation GFSK、π/4-DQPSK 、8PSK TX Power BR: 9dBm± 2dBm EDR: 9dBm± 2d Bm LE: 4dBm± 2d Bm RX Characteristics / 1.Receiver Sensitivity (BER<0.1%,PER<30.8%) BR: -92dBm EDR: -91dBm LE: -95dBm 2. Maximum usable signal BR: -5dBm EDR: -5dBm LE: -5dBm FCC regulatory compliance statement §15.19 Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. §15.21 Information to user Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. #List of applicable FCC Rules: 47 CFR Part 15, Subpart C 15.247 47 CFR Part 15, Subpart E 15.407 #Summarize the specific operational use conditions The module can be used in teleconference machine. After installing this module, the telephone can be connected to the router through a wireless network. In WIFI coverage, users can send various instructions through smart phones or PCs, which is very convenient. The input voltage of the module is nominally 3.3V, and other antennas of the same type with less than the original gain can be replaced. — 6 /4 — EL.MT7663BUN-WFT RF Exposure compliance statement This Module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-locate…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 2 External Photos for FYCR2204000058AT Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 2 EUT Constructional Details (EUT Photos)

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 3 Internal Photos for FYCR2204000058AT Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 3 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 3

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005806 Page: 1 of 10 Kidd Yang EMC Laboratory Manager 1 Cover Page RF Exposure Report Application No.: FYCR2204000058AT Applicant: EXPRESS LUCK INDUSTRIAL (SHENZHEN) LIMITED Address of Applicant: Floor1, Workshop1, NO.88, SOUTH BAOTONG ROAD, XIKENG COMMUNITY, YUANSHAN STREET, LONGGANG DISTRICT, Shenzhen 518115 China Manufacturer: EXPRESS LUCK INDUSTRIAL (SHENZHEN) LIMITED Address of Manufacturer: Floor1, Workshop1, No.88, SOUTH BAOTONG ROAD, XIKENG COMMUNITY, YUANSHAN STREET, LONGGANG DISTRICT, Shenzhen GUANGDONG China Factory: Sichuan AI-Link Technology Co., Ltd. Address of Factory: Anzhou Industrial Park, Mianyang, Sichuan, P.R.C Equipment Under Test (EUT): EUT Name: WiFi Module Model No.: EL.MT7663BUN-WFT FCC ID: 2AWY6-ELMT7663BUNT Standard(s) : 47 CFR Part 1.1307 47 CFR Part 1.1310 47 CFR Part 2.1091 Date of Receipt: 2022-04-06 Date of Test: 2022-04-07 to 2022-05-19 Date of Issue: 2022-05-20 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005806 Page: 2 of 10 Revision Record Version Chapter Date Modifier Remark 01 2022-04-28 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005806 Page: 3 of 10 2 Contents Page 1 COVER PAGE .................................................................................................................................... 1 2 CONTENTS ........................................................................................................................................ 3 3 GENERAL INFORMATION ................................................................................................................ 4 3.1 GENERAL DESCRIPTION OF E.U.T. ................................................................................................ 4 3.2 DETAILS OF E.U.T. ....................................................................................................................... 4 3.3 SEPARATION DISTANCE ................................................................................................................ 6 3.4 TEST LOCATION ............................................................................................................................ 6 3.5 TEST FACILITY .............................................................................................................................. 6 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS .......................................................... 7 4.1 BLANKET 1 MW BLANKET EXEMPTION ........................................................................................... 7 4.2 MPE-BASED EXEMPTION .............................................................................................................. 7 4.3 SAR-BASED EXEMPTION ............................................................................................................... 8 5 MEASUREMENT AND CALCULATION .......................................................................................... 10 5.1 MAXIMUM TRANSMIT POWER ....................................................................................................... 10 5.2 RF EXPOSURE CALCULATION ...................................................................................................... 10 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005806 Page: 4 of 10 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power Supply: DC 5V For BT: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.1 Dual mode Modulation Type: GFSK, pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Antenna Type: integral antenna Antenna Gain: 1.99dBi EIRP: 12.58dBm(18.11mW) * * The EIRP data refer to the report FYCR220400005802. For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.1 Dual mode Modulation Type: GFSK Data Rate: 1Mbps, 2Mbps Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: integral antenna Antenna Gain: 1.99dBi EIRP: 6.63dBm(4.6mW) * * The EIRP data refer to the report FYCR220400005803. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005806 Page: 5 of 10 For 2.4G WiFi Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz 802.11n(HT40): 2422MHz to 2452MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK) 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) 802.11n (HT20/HT40): OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/11n(HT20): 11 Channels 802.11n(HT40): 7 Channels Channel Spacing: 5MHz Sample Type: Fixed production Antenna Type: Metal Antenna Antenna Gain: ANT1:1.2dBi; ANT2:1.76dBi Note: The two antennas can simultaneous transmission(MIMO for 802.11n). EIRP: 17.41dBm(55.08mW) * * The EIRP data refer to the report FYCR220400005804. For 5G WiFi Operation Frequency: Band Mode Frequency Range(MHz) Number of channels UNII Band I 802.11a/n(HT20)/ac(HT20) 5180-5240 4 802.11n(HT40)/ac(HT40) 5190-5230 2 802.11ac(HT80) 5210 1 UNII Band II-A 802.11a/n(HT20)/ac(HT20) 5260-5320 4 802.11n(HT40)/ac(HT40) 5270-5310 2 802.11ac(HT80) 5290 1 UNII Band III 802.11a/n(HT20)/ac(HT20) 5745-5825 5 802.11n(HT40)/ac(HT40) 5755-5795 2 802.11ac(HT80) 5775 1 Modulation Type: 802.11a: OFDM(64QAM, 16QAM, QPSK, BPSK) 802.11n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) DFS Function: Slave without radar detection Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005806 Page: 6 of 10 TPC Function: Not support Sample Type: Fixed devices Antenna Type: Metal Antenna Antenna Gain: ANT1:3.25dBi; ANT2:3.55dBi…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunsha n) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 1 of 442 Kidd Yang EMC Laboratory Manager TEST REPORT Application No.: FYCR2204000058AT Applicant: EXPRESS LUCK INDUSTRIAL (SHENZHEN) LIMITED Address of Applicant: Floor1, Workshop1, NO.88, SOUTH BAOTONG ROAD, XIKENG COMMUNITY, YUANSHAN STREET, LONGGANG DISTRICT, Shenzhen 518115 China Manufacturer: EXPRESS LUCK INDUSTRIAL (SHENZHEN) LIMITED Address of Manufacturer: Floor1, Workshop1, No.88, SOUTH BAOTONG ROAD, XIKENG COMMUNITY, YUANSHAN STREET, LONGGANG DISTRICT, Shenzhen GUANGDONG China Factory: Sichuan AI-Link Technology Co.,Ltd. Address of Factory: Anzhou Industrial Park, Mianyang, Sichuan, P.R.C Equipment Under Test (EUT): EUT Name: WiFi Module Model No.: EL.MT7663BUN-WFT FCC ID 2AWY6-ELMT7663BUNT Standard(s) : 47 CFR Part 15, Subpart E 15.407 Date of Receipt: 2022-04-06 Date of Test: 2022-04-07 to 2022-05-19 Date of Issue: 2022-05-20 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 2 of 442 Revision Record Version Chapter Date Modifier Remark 01 2022-05-20 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 3 of 442 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart E 15.407 N/A 47 CFR Part 15, Subpart C 15.203 Pass Transmission in the Absence of Data N/A 47 CFR Part 15, Subpart C 15.407 (c) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Duty Cycle 47 CFR Part 15, Subpart E 15.407 KDB 789033 II B 1 KDB 789033 D02 II B 1 Pass 99% Bandwidth KDB 789033 II D N/A Pass 26dB Emission bandwidth KDB 789033 D02 II C 1 47 CFR Part 15, Subpart C 15.407 (a) Pass Minimum 6 dB bandwidth (5.725- 5.85 GHz band ) KDB 789033 D02 II C 2 47 CFR Part 15, Subpart C 15.407 (e) Pass Maximum Conducted output power KDB 789033 D02 II E 47 CFR Part 15, Subpart C 15.407 (a) Pass Peak Power spectrum density KDB 789033 D02 II F 47 CFR Part 15, Subpart C 15.407 (a) Pass Radiated Emissions which fall in the restricted bands KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & 15.407(b) Pass Conducted Emissions at AC Power Line (150kHz-30MHz) ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions (Below 1GHz) KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & 15.407(b) Pass Radiated Emissions (Above 1GHz) KDB 789033 D02 II G 47 CFR Part 15, Subpart C 15.209 & 15.407(b) Pass Frequency Stability ANSI C63.10 (2013) Section 6.8 47 CFR Part 15, Subpart C 15.407 (g) Pass Non-occupancy period KDB 905462 D02 Section 7.8.3 KDB 905462 D02 Section 5.1 Pass Channel Move Time KDB 905462 D02 Section 7.8.3 KDB 905462 D02 Section 5.1 Pass Channel Closing Transmission Time KDB 905462 D02 Section 7.8.3 KDB 905462 D02 Section 5.1 Pass Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 4 of 442 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 澳TEST SUMMARY ....................................................................................................................................... 3澳 3澳CONTENTS ................................................................................................................................................ 4澳 4澳GENERAL INFORMATION ........................................................................................................................ 7澳 4.1澳DETAILS OF E.U.T. ............................................................................................................................... 7澳 4.2澳DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 7澳 4.3澳MEASUREMENT UNCERTAINTY .............................................................................................................. 8澳 4.4澳TEST LOCATION .................................................................................................................................... 9澳 4.5澳TEST FACILITY ...................................................................................................................................... 9澳 4.6澳DEVIATION FROM STANDARDS ............................................................................................................... 9澳 4.7澳ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 9澳 5澳EQUIPMENT LIST .................................................................................................................................... 10澳 6澳RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 18澳 6.1澳ANTENNA REQUIREMENT .................................................................................................................... 18澳 6.1.1澳Test Requirement: ....................................................................................................................... 18澳 6.1.2澳Conclusion ................................................................................................................................... 18澳 6.2澳TRANSMISSION IN THE ABSENCE OF DATA ............................................................................................ 19澳 6.2.1澳Test Requirement: ....................................................................................................................... 19澳 6.2.2澳Conclusion ................................................................................................................................... 19澳 7澳RADI…

Text truncated - open the document above for the full version.

Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 252 of 442 10 Appendix 1. Duty Cycle 1.1 Ant1 1.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 802.11a SISO 5180 1.395 1.464 95.29 0.21 0.03 5200 1.395 1.464 95.29 0.21 0.03 5240 1.395 1.464 95.29 0.21 0.03 5260 1.395 1.465 95.22 0.21 0.03 5300 1.395 1.463 95.35 0.21 0.03 5320 1.395 1.464 95.29 0.21 0.03 5745 1.395 1.464 95.29 0.21 0.03 5785 1.395 1.464 95.29 0.21 0.03 5825 1.395 1.464 95.29 0.21 0.03 802.11n (HT20) MIMO 5180 1.303 1.371 95.04 0.22 0.00 5200 1.303 1.371 95.04 0.22 0.00 5240 1.303 1.371 95.04 0.22 0.00 5260 1.303 1.372 94.97 0.22 0.00 5300 1.303 1.372 94.97 0.22 0.03 5320 1.303 1.372 94.97 0.22 0.03 5745 1.303 1.372 94.97 0.22 0.03 5785 1.303 1.372 94.97 0.22 0.03 5825 1.303 1.372 94.97 0.22 0.03 802.11n (HT40) MIMO 5190 0.650 0.719 90.40 0.44 0.03 5230 0.650 0.719 90.40 0.44 0.03 5270 0.650 0.719 90.40 0.44 0.03 5310 0.650 0.719 90.40 0.44 0.03 5755 0.651 0.720 90.42 0.44 0.06 5795 0.650 0.719 90.40 0.44 0.03 802.11ac (VHT20) MIMO 5180 0.683 0.752 90.82 0.42 0.04 5200 0.683 0.752 90.82 0.42 0.03 5240 0.683 0.752 90.82 0.42 0.07 5260 0.683 0.752 90.82 0.42 0.04 Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 253 of 442 5300 0.683 0.752 90.82 0.42 0.04 5320 0.683 0.752 90.82 0.42 0.04 5745 0.683 0.752 90.82 0.42 0.03 5785 0.683 0.752 90.82 0.42 0.04 5825 0.683 0.752 90.82 0.42 0.03 802.11ac (VHT40) MIMO 5190 0.354 0.423 83.69 0.77 0.03 5230 0.354 0.423 83.69 0.77 0.03 5270 0.354 0.423 83.69 0.77 0.03 5310 0.354 0.423 83.69 0.77 0.03 5755 0.354 0.423 83.69 0.77 0.03 5795 0.354 0.423 83.69 0.77 0.03 802.11ac (VHT80) MIMO 5210 0.190 0.259 73.36 1.35 0.07 5290 0.190 0.258 73.64 1.33 0.08 5775 0.190 0.259 73.36 1.35 0.08 Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 254 of 442 1.1.2 Test Graph 802.11a_LCH_5180MHz_Ant1_NTNV 802.11a_MCH_5200MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 255 of 442 802.11a_HCH_5240MHz_Ant1_NTNV 802.11a_LCH_5260MHz_Ant1_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 256 of 442 802.11a_MCH_5300MHz_Ant1_NTNV 802.11a_HCH_5320MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 257 of 442 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_MCH_5785MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 258 of 442 802.11a_HCH_5825MHz_Ant1_NTNV 802.11n(HT20)_LCH_5180MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 259 of 442 802.11n(HT20)_MCH_5200MHz_Ant1_NTNV 802.11n(HT20)_HCH_5240MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 260 of 442 802.11n(HT20)_LCH_5260MHz_Ant1_NTNV 802.11n(HT20)_MCH_5300MHz_Ant1_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 261 of 442 802.11n(HT20)_HCH_5320MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 262 of 442 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_HCH_5825MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 263 of 442 802.11n(HT40)_LCH_5190MHz_Ant1_NTNV 802.11n(HT40)_HCH_5230MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 264 of 442 802.11n(HT40)_LCH_5270MHz_Ant1_NTNV 802.11n(HT40)_HCH_5310MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 265 of 442 802.11n(HT40)_LCH_5755MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 266 of 442 802.11ac(VHT20)_LCH_5180MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5200MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 267 of 442 802.11ac(VHT20)_HCH_5240MHz_Ant1_NTNV 802.11ac(VHT20)_LCH_5260MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 268 of 442 802.11ac(VHT20)_MCH_5300MHz_Ant1_NTNV 802.11ac(VHT20)_HCH_5320MHz_Ant1_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 269 of 442 802.11ac(VHT20)_LCH_5745MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant1_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 270 of 442 802.11ac(VHT20)_HCH_5825MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5190MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 271 of 442 802.11ac(VHT40)_HCH_5230MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5270MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 272 of 442 802.11ac(VHT40)_HCH_5310MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 273 of 442 802.11ac(VHT40)_HCH_5795MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5210MHz_Ant1_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 274 of 442 802.11ac(VHT80)_MCH_5290MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant1_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 275 of 442 2. Bandwidth 2.1 OBW 2.1.1 Test Result Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result 802.1…

Text truncated - open the document above for the full version.

Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 301 of 442 802.11n(HT40)_HCH_5795MHz_Ant1_NTNV 802.11n(HT40)_HCH_5795MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 302 of 442 802.11ac(VHT20)_LCH_5180MHz_Ant1_NTNV 802.11ac(VHT20)_LCH_5180MHz_Ant2_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 303 of 442 802.11ac(VHT20)_MCH_5200MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5200MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 304 of 442 802.11ac(VHT20)_HCH_5240MHz_Ant1_NTNV 802.11ac(VHT20)_HCH_5240MHz_Ant2_NTNV Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 305 of 442 802.11ac(VHT20)_LCH_5260MHz_Ant1_NTNV 802.11ac(VHT20)_LCH_5260MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 306 of 442 802.11ac(VHT20)_MCH_5300MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5300MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 307 of 442 802.11ac(VHT20)_HCH_5320MHz_Ant1_NTNV 802.11ac(VHT20)_HCH_5320MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 308 of 442 802.11ac(VHT20)_LCH_5745MHz_Ant1_NTNV 802.11ac(VHT20)_LCH_5745MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 309 of 442 802.11ac(VHT20)_MCH_5785MHz_Ant1_NTNV 802.11ac(VHT20)_MCH_5785MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 310 of 442 802.11ac(VHT20)_HCH_5825MHz_Ant1_NTNV 802.11ac(VHT20)_HCH_5825MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 311 of 442 802.11ac(VHT40)_LCH_5190MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5190MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 312 of 442 802.11ac(VHT40)_HCH_5230MHz_Ant1_NTNV 802.11ac(VHT40)_HCH_5230MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 313 of 442 802.11ac(VHT40)_LCH_5270MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5270MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 314 of 442 802.11ac(VHT40)_HCH_5310MHz_Ant1_NTNV 802.11ac(VHT40)_HCH_5310MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 315 of 442 802.11ac(VHT40)_LCH_5755MHz_Ant1_NTNV 802.11ac(VHT40)_LCH_5755MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 316 of 442 802.11ac(VHT40)_HCH_5795MHz_Ant1_NTNV 802.11ac(VHT40)_HCH_5795MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 317 of 442 802.11ac(VHT80)_MCH_5210MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5210MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 318 of 442 802.11ac(VHT80)_MCH_5290MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5290MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 319 of 442 802.11ac(VHT80)_MCH_5775MHz_Ant1_NTNV 802.11ac(VHT80)_MCH_5775MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 320 of 442 2.2 6dB BW 2.2.1 Test Result Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 802.11a SISO 5745 1 15.140 >=0.5 Pass 2 15.144 >=0.5 Pass 5785 1 15.137 >=0.5 Pass 2 15.084 >=0.5 Pass 5825 1 15.141 >=0.5 Pass 2 15.154 >=0.5 Pass 802.11n (HT20) MIMO 5745 1 15.188 >=0.5 Pass 2 15.134 >=0.5 Pass 5785 1 15.138 >=0.5 Pass 2 15.123 >=0.5 Pass 5825 1 15.135 >=0.5 Pass 2 15.719 >=0.5 Pass 802.11n (HT40) MIMO 5755 1 35.165 >=0.5 Pass 2 35.152 >=0.5 Pass 5795 1 35.149 >=0.5 Pass 2 35.138 >=0.5 Pass 802.11ac (VHT20) MIMO 5745 1 15.169 >=0.5 Pass 2 15.112 >=0.5 Pass 5785 1 15.160 >=0.5 Pass 2 15.149 >=0.5 Pass 5825 1 15.142 >=0.5 Pass 2 15.145 >=0.5 Pass 802.11ac (VHT40) MIMO 5755 1 35.158 >=0.5 Pass 2 35.145 >=0.5 Pass 5795 1 35.145 >=0.5 Pass 2 35.149 >=0.5 Pass 802.11ac (VHT80) MIMO 5775 1 75.193 >=0.5 Pass 2 75.148 >=0.5 Pass Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 321 of 442 2.2.2 Test Graph 802.11a_LCH_5745MHz_Ant1_NTNV 802.11a_LCH_5745MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 322 of 442 802.11a_MCH_5785MHz_Ant1_NTNV 802.11a_MCH_5785MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 323 of 442 802.11a_HCH_5825MHz_Ant1_NTNV 802.11a_HCH_5825MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 324 of 442 802.11n(HT20)_LCH_5745MHz_Ant1_NTNV 802.11n(HT20)_LCH_5745MHz_Ant2_NTNV Com pliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005805 Page: 325 of 442 802.11n(HT20)_MCH_5785MHz_Ant1_NTNV 802.11n(HT20)_MCH_5785MHz_Ant2_NTNV Com pliance Certification S…

Text truncated - open the document above for the full version.
