2AXA8-GBP-2007Mesh Pro

Certification Designating Applicant as FCC US Agent To: Federal Communications CommissionDate: 07-29-2024 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2AXA8-GBP-2007 Trackonomy (“the applicant”) as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC ID. The applicant acknowledge the applicant’s consent and the designated agent for service of process’s obligation to accept service of process. The applicant acknowledge the applicant’s acceptance to maintain an agent for service of process for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledge the responsibility to inform the FCC whenever the agent information changes. Designated U.S. Agent from Applicant Company Company Name: Trackonomy Contact Person: Nivedita Manohar Address: 214 Devcon Drive, San Jose, California, United States Tel.: 1-315-708-9739 Email: [email protected] FCC FRN: 0029378411 Sincerely yours, Signature Printed Name: Nivedita Manohar Title:Certification Manager

Attestation Statements Not Covered Entity Applicant To: Federal Communications CommissionDate: 07-29-2024 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(ii) filing FCC ID: 2AXA8-GBP-2007 [Trackonomy] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely yours, Applicant Signature Printed Name: Nivedita Manohar Title: Certification Manager Address: 214 Devcon Drive, San Jose, California, United States Tel.: 1-315-708-9739 Email: [email protected]

Attestation Statements Not Covered Equipment To: Federal Communications CommissionDate: 07-29-2024 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) filing FCC ID: 2AXA8-GBP-2007 [Trackonomy] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section§ 2.903of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Nivedita Manohar Title: Certification Manager Address: 214 Devcon Drive, San Jose, California, United States Tel.: 1-315-708-9739 Email: [email protected]

Authority to Act as Agent Date: 2024-07-29 TUV Rheinland of North America, Inc. 1279 Quarry Lane., Suite. A Pleasanton, CA 94566 To Whom It May Concern: I appoint __________ TUV Rheinland (Shenzhen) Co., Ltd. _______ to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUV Rheinland Group, still resides with ___ Trackonomy__214 Devcon Drive, San Jose, California, United States ___. For TCB applications, We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b),to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Date: ________12 Months_______ Agreement is valid for 12 months from the above date. By: ________________________________ (Signature) Nivedita Manohar (Print name) Certification Manager (Title) 1-315-708-9739 (Telephone) On behalf of: Trackonomy Systems, Inc. (Company Name) Page 1 of 1

Page 1 of 1 uncontrolled when printed out Confidentiality Letter Date: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, USA Subject: Confidentiality Request for Pursuant to FCC 47 CRF 0.457(d), the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term n/a External Photo Short Term Permanent Internal Photos *** Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Schematics Short Term Permanent Test Setup*** Short Term Permanent Tune-Up Procedure Short Term Permanent User’s Manual*** Short Term Permanent Part List has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. (*** Exceptional case for Permanent Confidentiality for these Exhibits by PAG only) Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: _______________________________________________ ____________ ____________ (Signature/Title) (Print name) Tel: Email: 2024-07-30 FCC ID: 2AXA8-GBP-2007 Trackonomy Nivedita Manohar 1-315-708-9739 [email protected]

<Above information located on surface of device>

RAK5146 WisLink LPWAN Concentrator RAK634 Wi-Fi Module RAK3401 WisDuo EG95-NA LTE Module RAK5148 WisLink LPWAN Concentrator LTE ANT WIFI ANT BLE ANT GNSS ANT

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN240SIF 002 Auftrags-Nr.: Order no.: 168492755 Seite 1 von 3 Page 1 of 3 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2024-06-27 Auftraggeber: Client: Trackonomy Systems, Inc. 214 Devcon Drive, San Jose CA 95112, USA. Prüfgegenstand: Test item: Mesh Pro Bezeichnung / Typ-Nr.: Identification / Type no.: GBP-2007 (Trademark: ) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart B Section 15.107 CFR47 FCC Part 15: Subpart B Section 15.109 Wareneingangsdatum: Date of sample receipt: 2023-09-26 Refer to photos documents Prüfmuster-Nr.: Test sample no: A003562972-001~002 Prüfzeitraum: Testing period: 2023-09-26 - 2024-03-03 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X genehmigt von: authorized by: X Datum: Date: 2024-10-08 Ausstellungsdatum: Issue date: 2024-10-08 Stellung / Position: Sachverständige(r)/Expert Stellung / Position: Sachverständige(r)/Expert Sonstiges / Other: FCC ID: 2AXA8-GBP-2007 This report based on previous report CN24VFE4 001 for changing applicant information and product information, also the FCC ID of the HOST without additional testing because the product is not changed, refer to page 3 for details. Contains FCC ID: XMR201807EG95NA, 2AXA8-MBD-0634, 2AXA8-MGD-5148, 2AXA8-MGD-5146, 2AXA8-MWD-3401. Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Details im vorherigen Abschnitt Details in the previous section * Legende: P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the above mentioned test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland (Shenzhen) Co., Ltd., 1601-1604, 17-18F, Tower A Building 2, Shenzhen International Innovation Valley, Dashi 1st Road, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P. R. China Mail: [email protected] · Web: www.tuv.com V101023GCNSR Hardy Suo Lin Lin Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: CN240SIF 002 Test report no.: Seite 2 von 3 Page 2 of 3 Anmerkungen Remarks 1 Alle eingesetzten Prüfmittel waren zum angegebenen Prüfzeitraum gemäß eines festgelegten Kalibrierungsprogramms unseres Prüfhauses kalibriert. Sie entsprechen den in den Prüfprogrammen hinterlegten Anforderungen. Die Rückverfolgbarkeit der eingesetzten Prüfmittel ist durch die Einhaltung der Regelungen unseres Managementsystems gegeben. Detaillierte Informationen bezüglich Prüfkonditionen, Prüfequipment und Messunsicherheiten sind im Prüflabor vorhanden und können auf Wunsch bereitgestellt werden. The equipment used during the specified testing period was calibrated according to our test laboratory calibration program. The equipment fulfils the requirements included in the relevant standards. The traceability of the test equipment used is ensured by compliance with the regulations of our management system. Detailed information regarding test conditions, equipment and measurement uncertainty is available in the test laboratory and could be provided on request. 2 Wie vertraglich vereinbart, wurde dieses Dokument nur digital unterzeichnet. Der TÜV Rheinland hat nicht überprüft, welche rechtlichen oder sonstigen diesbezüglichen Anforderungen für dieses Dokument gelten. Diese Überprüfung liegt in der Verantwortung des Benutzers dieses Dokuments. Auf Verlangen des Kunden kann der TÜV Rheinland die Gültigkeit der digitalen Signatur durch ein gesondertes Dokument bestätigen. Diese Anfrage ist an unseren Vertrieb zu richten. Eine Umweltgebühr für einen solchen zusätzlichen Service wird erhoben. As contractually agreed, this document has been signed digitally only. TUV Rheinland has not verified and unable to verify which legal or other pertaining requirements are applicable for this document. Such verification is within the responsibility of the user of this document. Upon request by its client, TUV Rheinland can confirm the validity of the digital signature by a separate document. Such request shall be addressed to our Sales department. An environmental fee for such additional service will be charged. 3 Prüfklausel mit der Note * wurden an qualifizierte Unterauftragnehmer vergeben und sind unter der jeweiligen Prüfklausel des Berichts beschrieben. Abweichungen von Prüfspezifikation(en) oder Kundenanforderungen sind in der jeweiligen Prüfklausel im Bericht aufgeführt. Test clauses with remark of * are subcontracted to qualified subcontractors and descripted under the respective test clause in the report. Deviations of testing specification(s) or customer requirements are listed in specific test clause in the report. 4 Die Entscheidungsregel für Konformitätserklärungen basierend auf numerischen Messergebnisen in diesem Prüfbericht basiert auf der "Null-Grenzwert-Regel" und der "Einfachen Akzeptanz" gemäß ILAC G8:2019 und IEC Guide 115:2021, es sei denn, in der auf Seite 1 dieses Berichts genannten angewandten Norm ist etwas anderes festgelegt oder vom Kunden gewünscht. Dies bedeutet, dass die Messunsicherheit nicht berücksichtigt wird und daher auch nicht im Prüfbericht angegeben wird. Zu weiteren Informationen bezueglich des Risikos durch diese Entscheidungsregel siehe ILAC G8:2019. The decision rule for statements of…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN24VFE4 001 Auftrags-Nr.: Order no.: 168444032 Seite 1 von 13 Page 1 of 13 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2023-09-26 Auftraggeber: Client: Shenzhen RAKwireless Technology Co.,Ltd. Room 506, Building B, New Compark, Pingshan First Road, Taoyuan Street, Nanshan District, Shenzhen, Guangdong, P.R. China Prüfgegenstand: Test item: WisGate Edge Pro Bezeichnung / Typ-Nr.: Identification / Type no.: RAK7229CV2 (Trademark: ) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart B Section 15.107 CFR47 FCC Part 15: Subpart B Section 15.109 ICES-003 Issue 7 October 2020 Wareneingangsdatum: Date of sample receipt: 2023-09-26 Refer to photos documents Prüfmuster-Nr.: Test sample no: A003562972-001~002 Prüfzeitraum: Testing period: 2023-09-26 - 2024-03-03 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X genehmigt von: authorized by: X Datum: Date: 2024-03-12 Ausstellungsdatum: Issue date: 2024-03-12 Stellung / Position Sachverständige(r)/Expert Stellung / Position Sachverständige(r)/Expert Sonstiges / Other: FCC ID: 2AF6B-RAK7229CV2 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. TUV Rheinland (Shenzhen) Co., Ltd., 1601-1604, 17-18F, Tower A Building 2, Shenzhen International Innovation Valley, Dashi 1st Road, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P. R. China Mail: [email protected] · Web: www.tuv.com Hardy Suo Lin Lin Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: CN24VFE4 001 Test report no.: Seite 2 von 13 Page 2 of 13 Anmerkungen Remarks 1 Alle eingesetzten Prüfmittel waren zum angegebenen Prüfzeitraum gemäß eines festgelegten Kalibrierungsprogramms unseres Prüfhauses kalibriert. Sie entsprechen den in den Prüfprogrammen hinterlegten Anforderungen. Die Rückverfolgbarkeit der eingesetzten Prüfmittel ist durch die Einhaltung der Regelungen unseres Managementsystems gegeben. Detaillierte Informationen bezüglich Prüfkonditionen, Prüfequipment und Messunsicherheiten sind im Prüflabor vorhanden und können auf Wunsch bereitgestellt werden. The equipment used during the specified testing period was calibrated according to our test laboratory calibration program. The equipment fulfils the requirements included in the relevant standards. The traceability of the test equipment used is ensured by compliance with the regulations of our management system. Detailed information regarding test conditions, equipment and measurement uncertainty is available in the test laboratory and could be provided on request. 2 Wie vertraglich vereinbart, wurde dieses Dokument nur digital unterzeichnet. Der TÜV Rheinland hat nicht überprüft, welche rechtlichen oder sonstigen diesbezüglichen Anforderungen für dieses Dokument gelten. Diese Überprüfung liegt in der Verantwortung des Benutzers dieses Dokuments. Auf Verlangen des Kunden kann der TÜV Rheinland die Gültigkeit der digitalen Signatur durch ein gesondertes Dokument bestätigen. Diese Anfrage ist an unseren Vertrieb zu richten. Eine Umweltgebühr für einen solchen zusätzlichen Service wird erhoben. As contractually agreed, this document has been signed digitally only. TUV Rheinland has not verified and unable to verify which legal or other pertaining requirements are applicable for this document. Such verification is within the responsibility of the user of this document. Upon request by its client, TUV Rheinland can confirm the validity of the digital signature by a separate document. Such request shall be addressed to our Sales department. An environmental fee for such additional service will be charged. 3 Prüfklausel mit der Note * wurden an qualifizierte Unterauftragnehmer vergeben und sind unter der jeweiligen Prüfklausel des Berichts beschrieben. Abweichungen von Prüfspezifikation(en) oder Kundenanforderungen sind in der jeweiligen Prüfklausel im Bericht aufgeführt. Test clauses with remark of * are subcontracted to qualified subcontractors and descripted under the respective test clause in the report. Deviations of testing specification(s) or customer requirements are listed in specific test clause in the report. 4 Die Entscheidungsregel für Konformitätserklärungen basierend auf numerischen Messergebnisen in diesem Prüfbericht basiert auf der "Null-Grenzwert-Regel" und der "Einfachen Akzeptanz" gemäß ILAC G8:2019 und IEC Guide 115:2021, es sei denn, in der auf Seite 1 dieses Berichts genannten angewandten Norm ist etwas anderes festgelegt oder vom Kunden gewünscht. Dies bedeutet, dass die Messunsicherheit nicht berücksichtigt wird und daher auch nicht im Prüfbericht angegeben wird. Zu weiteren Informationen bezueglich des Risikos durch diese Entscheidungsregel siehe ILAC G8:2019. The decision rule for statements of conformity, based on numerical measurement results, in…

Text truncated - open the document above for the full version.

1. Radio Frequency Exposure RESULT: Pass Test standard : FCC Part 2: Section 2.1091 KDB 447498 D01 General RF Exposure Guidance v06 RSS-102 Issue 6, December 2023 1.1 Product Technical Information The EUT is a Mesh Pro which supports Lora+GNSS, 2.4GHz Wi-Fi, BLE and WCDMA/LTE wireless technologies. For details refer to the User Manual, Technical Description and Circuit Diagram. General Information of EUT Description Kind of Equipment: Mesh Pro Type Designation: GBP-2007 FCC ID: 2AXA8-MWD-3401 IC: 27299-MWD3401 HMN: GBP-2007 Operating Voltage: DC 12V via DC Source or DC 37 ~ 57V via POE adapter Testing Voltage: AC 230V, 50Hz or DC 12V Operating Temperature Range: -30 °C ~ +55 °C Remark: This product assemblies multi-transmitter modules: - LTE Module (FCC ID: XMR201807EG95NA, IC ID: 10224A-2018EG95NA) - Wi-Fi Module (FCC ID: 2AXA8-MBD-0634, IC ID: 27299-MBD0634) - WisLink LPWAN Concentrator*2 (FCC ID: 2AXA8-MGD-5148, FCC ID: 2AXA8-MGD-5146, IC ID: 27299-MGD5148, IC ID: 27299-MGD5146) - WisDuo (FCC ID: 2AXA8-MWD-3401, IC ID: 27299-MWD3401) The LTE module, BLE module, Wi-Fi module and Lora module are combination in a new host, the EMF is arrange re-assessment (CIIPC and C4PC for FCC ID: 2AXA8-MWD-3401, IC: 27299-MWD3401). Technical Specification of LTE Module Characteristic Description Operating Frequency WCDMA Band: II, IV, V LTE Band: 2, 4, 5, 12, 13 Type of Modulation QPSK, 16QAM Power Class 4 Antenna Number: 2 Antenna Gain: 5.1dBi for Ant0 (declared by client) 4.3dBi for Ant1 (declared by client) Technical Specification of Wi-Fi Module Characteristic Description Operating Frequency 2412 - 2462 MHz for 802.11b/g/n(HT20) 2422 - 2452 MHz for 802.11n(HT40) Type of Modulation DSSS(DBPSK/DQPSK/CCK) OFDM(BPSK/QPSK/16QAM/64QAM) Data Rate: 1/2/5.5/11 Mbps for 802.11b 6/9/12/18/24/36/48/54 Mbps for 802.11g MCS0 ~ MCS7 for 802.11n Channel Number: 11 channels for 802.11b/g/n(HT20) 7 channels for 802.11n(HT40) Antenna Number: 2412 - 2462 MHz for 802.11b/g/n(HT20) 2422 - 2452 MHz for 802.11n(HT40) Antenna Gain: 4.5dBi for Ant0 (declared by client) 4.5dBi for Ant1 (declared by client) Technical Specification of WisLink LPWAN Concentrator Characteristic Description Operating Frequency 2403 MHz- 2479 MHz for 2.4GHz DTS LoRa 1559 MHz to 1610 MHz (receiver) for GPS L1 Type of Modulation Chirp Spread Spectrum Data Rate: DR0-DR7 Antenna Number: 1 Antenna Gain: 8.00 dBi (declared by client) for Omni antenna Technical Specification of WisLink LPWAN Concentrator Characteristic Description Operating Frequency 1. 923.3 - 927.5MHz for DTS LoRa 2. 903.9MHz - 905.3MHz for Hybrid LoRa 3. GNSS receiver: 1) GLONASS G1: 1559 to 1610 MHz (Operating Frequency: 1597-1607MHz) 2) GPS L1: 1559 to 1610 MHz (Operating Frequency: 1575.42MHz) Type of Modulation FSK/Lora Data Rate: Lora: SF7 – SF12 / DR8 – DR13, SF7 – SF10 / DR0 –DR3 Antenna Number: 1 Antenna Gain: 5.10 dBi (declared by client) for Fiber Glass Antenna Technical Specification of WisDuo Characteristic Description Operating Frequency 2402 - 2480 MHz Type of Modulation GFSK Data Rate: 1Mbps, 2Mbps Antenna Number: 1 Antenna Gain: 3.4 dBi (declared by client) for Fiber Glass Antenna Information of LTE Module Product Name LTE Module Model Number EG95-NA FCC ID XMR201807EG95NA IC ID 10224A-2018EG95NA Information of Wi-Fi Module Product Name Wi-Fi Module Model Number MBD-0634 FCC ID 2AXA8-MBD-0634 IC ID 27299-MBD0634 Information of WisLink LPWAN Concentrator Product Name WisLink LPWAN Concentrator Model Number MGD-5148 FCC ID 2AXA8-MGD-5148 IC ID 27299-MGD5148 Information of WisLink LPWAN Concentrator Product Name WisLink LPWAN Concentrator Model Number MGD-5146 FCC ID 2AXA8-MGD-5146 IC ID 27299-MGD5146 Information of module WisDuo Product Name WisDuo Model Number MWD-3401 FCC ID 2AXA8-MWD-3401 IC ID 27299-MWD3401 1.2 Product Classification This device defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at 20 cm is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. 1.3 Radio Frequency Exposure Limit For FCC: Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm²) Average Time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 *100 <6 3.0-30 1842/f 4.89/f *(900/f²) <6 30-300 61.4 0.163 1.0 <6 300-1,500 -- -- f/300 <6 1,500-100,000 -- -- 1.0 <6 (B) Limits for General Population/Uncontrolled Exposure 0.3-3.0 614 1.63 *100 <30 3.0-30 824/f 2.19/f *(180/f²) <30 30-300 27.5 0.073 0.2 <30 300-1,500 -- -- f/1500 <30 1,500-100,000 -- -- 1.0 <30 f = frequency in MHz. * = Plane-wave equivalent power density. For IC: 1.4 Radio Frequency Exposure Calculation Formula 1.5 Calculation Result 1.5.1 Stand-alone transmission MPE Mode Band PG (dBm) PG (W) Power Density (mW/cm²) FCC Limit (mW/cm²) Lora (RAK5146) 902-928MHz 30.49 1.11944 0.070 0.601 Lora (RAK5148) 2.4GHz 25.97 0.39537 0.025 1.0 BLE 2.4GHz 7.88 0.0061 0.0002 1.0 WIFI 2.4GHz 31.74 0.77983 0.094 1.0 WCDMA II 29.0 0.79433 0.040 1.0 VI 29.0 0.79433 0.040 1.0 V 29.0 0.79433 0.040 0.55 LTE 2 29.0 0.79433 0.040 1.0 4 29.0 0.79433 0.040 1.0 5 29.0 0.79433 0.040 0.55 12 29.0 0.79433 0.040 0.47 13 29.0 0.79433 0.040 0.52 Mode Band PG (dBm) PG (W) Power Density (W/m²) IC Limit (W/m²) Lora (RAK5146) 902-928MHz 30.49 1.11944 0.701 2.74 Lora (RAK5148) 2.4GHz 25.97 0.39537 0.247 5.35 BLE 2.4GHz 7.88 0.0061 0 5.35 WIFI 2.4GHz 31.74 0.77983 0.935 5.35 WCDMA II 28.0 0.63096 0.314 4.48 VI 28.0 0.63096 0.314 4.24 V 28.0 0.63096 0.314 2.58 LTE 2 28.5 0.70795 0.352 4.48 4 28.5 0.70795 0.352 4.24 5 28.5 0.70795 0.352 2.58 12 28.5 0.70795 0.352 2.30 13 28.5 0.70795 0.352 2.47 1.5.2 Simultaneous transmission MPE FCC Operating Mode Lora RAK5146 Lora RAK5148 BLE WIFI WCDMA /LTE Sum Ratio Limit Verdict Lora + 2.4GHz LoRa + BLE + WIFI + WCDMA/LTE 0.12 0.025 0.0002 0.094 0.085 0.324 <1 Pass IC Operating Mode Lora RAK5146 Lora R…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix B CN24VFE4 001 Page 1 of 3 Appendix B: Photographs of the Test Set-Up Photos Appendix B: Photographs of the Test Set-Up Photos ................................................................................ 1 Photograph 1: Set-up for Conducted Emissions, AC Mains.......................................................................... 2 Photograph 2: Set-up for Radiated Emissions, below 1GHz......................................................................... 2 Photograph 3: Set-up for Radiated Emissions, above 1GHz ........................................................................ 3 Prüfbericht - Produkte Test Report - Products Appendix B CN24VFE4 001 Page 2 of 3 Photograph 1: Set-up for Conducted Emissions, AC Mains Photograph 2: Set-up for Radiated Emissions, below 1GHz Prüfbericht - Produkte Test Report - Products Appendix B CN24VFE4 001 Page 3 of 3 Photograph 3: Set-up for Radiated Emissions, above 1GHz
