2AXA8-PGW-2005PGW

Attention: Application Examiner Re: Covered List, located athttps://www.fcc.gov/supplychain/coveredlistand 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: Trackonomy Systems, Inc. FCC ID: 2AXA8-PGW-2005 To whom it may concern, Trackonomy Systems, Inc. (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant is not identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Eurofins E&E North America if there is any change in the status identified above. ___________________________________ Dr. Saurabh Sanghai Director of Engineering Trackonomy 214 Devcon Drive San Jose, CA 95112, USA Date: August 30, 2023 Trackonomy Systems, Inc. | 214 Devcon Drive, San Jose, CA 95112 | www.trackonomy.com

Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules To whom it may concern, This letter is to certify that Trackonomy Systems, Inc. (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the Applicant for all certification applications to the FCC. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of any commission-related proceeding involving the equipment and agree to immediately notify the FCC and Eurofins E&E North America if there is any change in the status identified above. : Trackonomy Systems, Inc. : Dr. Saurabh Sanghai, Director of Engineering : 214 Devcon Drive San Jose, CA 95112, USA : 1-833-872-2566 : [email protected] : 0029378411 Trackonomy Systems, Inc. | 214 Devcon Drive, San Jose, CA 95112 | www.trackonomy.com Applicant Company Name Cont act Name Address Telephone No Email Applicant FRN Signature : Date: August 30, 2023

Trackonomy Systems, Inc. | 214 Devcon Drive, San Jose, CA 95112 | www.trackonomy.com August 30, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Long-Term Confidentiality Request for Multifunctional IoT platform Device, PGW-2005 with FCC ID# 2AXA8-PGW-2005 To Whom It May Concern: This letter serves as an official request for confidentiality under sections §§ 0.457(d) and 0.459 of CFR 47. Trackonomy has requested that the Block Diagram, Schematics, Internal Photos, Parts List/Tune Up Procedure, User Manual, SDR Software / Security Info and Operational Description required to be submitted with this application be permanently withheld from public review. The above documents are company proprietary information that must never get into open resources online or in the possession of competitors. Circuit board and internal components are not accessible to users because of the permanent bonding/ fusing process at the factory. Requirement to be handled only by professional qualified personnel such as people working on restricted industrial sites or secured industrial plants which do not allow access of the product to any common public. We reviewed confidential information for the long term confidentiality agreement and we met the confidentiality requirements. Please contact me if there is any information you may need. Sincerely, Dr. Saurabh Sanghai Director of Engineering Trackonomy 214 Devcon Drive San Jose, CA 95112, USA

Trackonomy Systems, Inc. | 214 Devcon Drive, San Jose, CA 95112 | www.trackonomy.com August 30, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short-Term Confidentiality Request for Multifunctional IoT platform sensor, PGW-2005 with FCC ID# 2AXA8-PGW-2005 To Whom It May Concern: In accordance with §§ 0.457(d) and 0.459 of CFR 47, Trackonomy. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued: External photos, Test setup photos required to be submitted with this application be withheld from public review. We would like the Short-Term Confidentiality (STC) period of 180 days (max). These documents contain detailed system and equipment descriptions and related information about the product, which Trackonomy considers to be proprietary, confidential, and a custom design and otherwise, would not be released to the general public. Since this design is a basis from which current and future technological products will evolve, Trackonomy feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Dr. Saurabh Sanghai Director of Engineering Trackonomy 214 Devcon Drive San Jose, CA 95112, USA

Trackonomy Systems, Inc. | 214 Devcon Drive, San Jose, CA 95112 | www.trackonomy.com August 30, 2023 Eurofins Electrical and Electronic Testing NA, Inc. 914 W est Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To W hom It May Conc ern: I, the undersigned, hereby a uthorize Gary Chou to act on our behalf in a ll matters relating to application for equipment authorization, including t he signing of all documents relating to these matters. We also hereby certify t hat no pa rty t o the application a uthorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Ac t of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Dr. Saurabh Sanghai Director of Engineering Trackonomy 214 Devcon Drive San Jose, CA 95112, USA

External TopView RearView

SPE-12-8-050-G FXP14 Flexible PCB Cellular Antenna Part No: FXP14.07.0100A Description 5G/4G Cellular Flexible PCB with 100mm 1.13 & IPEX MHFI Connector Features: Flexible PCB Antenna Dimensions: 70x20x0.2mm Connector: I-PEX MHF® I (U.FL Compatible) Cable: 100mm of Ø1.13 Peel and Stick Mounting 3M 467 Adhesive CE Certified RoHS & REACH Compliant 1 www.taoglas.com SPE-12-8-050-G 1. Introduction 2 2. Specification 3 3. Antenna Characteristics 5 4. Radiation Patterns 8 5. Mechanical Drawing 17 6. Packaging 18 Changelog 19 Taoglas makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Taoglas reserves all rights to this document and the information contained herein. Reproduction, use or disclosure to third parties without express permission is strictly prohibited. 2 www.taoglas.com SPE-12-8-050-G 1. Introduction The Taoglas FXP14 Flexible Wideband Cellular Antenna covers all world-wide 5G/4G bands. The antenna has been designed in a flexible material with a rectangular form-factor and cable connection for an easy installation. The antenna works on different plastic materials and thickness. We have selected a piece of ABS with 2 mm of thickness as a baseline for testing. Typical Applications Include: • Security • Remote Monitoring • Connected Health The antenna has been designed using a super thin flexible polymer substrate with a rectangular form-factor and cable connection for ease of installation. The antenna radiates well on different plastic materials and thickness. We have selected ABS plastic mounting with 2 mm of thickness as a baseline for testing. Best in class efficiency on lower and upper bands (above 40%) make it an ideal antenna for devices where space for onboard SMD cellular antennas is not available. The antenna is mounted via automotive quality 3M 467 adhesive and has excellent reliability. The FXP14 has its own ground-plane, therefore it does not need to connect to the ground-plane of the main-board of the device for improved radiation efficiency. For more information or installation instructions, please contact your regional Taoglas customer support team. 3 www.taoglas.com SPE-12-8-050-G 2. Specification Electrical Band Frequency (MHz) Efficiency (%) Average Gain (dB) Peak Gain (dBi) Impedance Polarization Radiation Pattern Input power 5GNR/4G Band71 617-698 36.9 -4.33 -0.06 50 Ω Linear Omni 5W 4G/3G Band 12,13,14,17,28,29 698-806 46.2 -3.36 2.03 4G/3G/NB-IoT/Cat M Band 5,8,18,19,20,26,27 824-960 58.1 -2.36 6.01 5GNR/4G Band 21,32,74,75,76 1427-1518 51.5 -2.88 1.90 4G/3G Band 1,2,3,4,9,23,25,35,39,6 6 1710-2200 70.5 -1.52 4.52 4G/3G Band 7,30,38,40,41 2300-2690 29.5 -5.30 2.75 5GNR/4G Band 22,42,48,77,78,79 3300-5000 52.7 -2.79 3.35 LTE5200/Wi-Fi5800 5150-5925 49.0 -3.10 3.88 Mechanical Dimensions 70 x 20 x 0.2mm Weight 1.5g Cable 100mm 1.13 Black Connector IPEX MHFI Adhesive 3M 467 Environmental Temperature Range 40°C to 85°C Humidity Non-condensing 65°C 95% RH 4 www.taoglas.com SPE-12-8-050-G 5G/4G Bands Band Number 5GNR / FR1 / LTE / LTE-Advanced / WCDMA / HSPA / HSPA+ / TD-SCDMA Uplink Downlink Covered B1 1920 to 1980 2110 to 2170 ✓ B2 1850 to 1910 1930 to 1990 ✓ B3 1710 to 1785 1805 to 1880 ✓ B4 1710 to 1755 2110 to 2155 ✓ B5 824 to 849 869 to 894 ✓ B7 2500 to 2570 2620 to 2690 ✓ B8 880 to 915 925 to 960 ✓ B9* 1749.9 to 1784.9 1844.9 to 1879.9 ✓ B11 1427.9 to 1447.9 1475.9 to 1495.9 ✓ B12 699 to 716 729 to 746 ✓ B13 777 to 787 746 to 756 ✓ B14 788 to 798 758 to 768 ✓ B17 704 to 716 734 to 746 ✓ B18 815 to 830 860 to 875 ✓ B19 830 to 845 875 to 890 ✓ B20 832 to 862 791 to 821 ✓ B21 1447.9 to 1462.9 1495.9 to 1510.9 ✓ B22* 3410 to 3490 3510 to 3590 ✓ B23* 2000 to 2020 2180 to 2200 ✓ B24 1626.5 to 1660.5 1525 to 1559 ✓ B25 1850 to 1915 1930 to 1995 ✓ B26 814 to 849 859 to 894 ✓ B27* 807 to 824 852 to 869 ✓ B28 703 to 748 758 to 803 ✓ B29 717 to 728 ✓ B30 2305 to 2315 2350 to 2360 ✓ B31 452.5 to 457.5 462.5 to 467.5  B32 1452 to 1496 ✓ B34 2010 to 2025 ✓ B35 1850 to 1910 ✓ B36 1930 to 1990 ✓ B37 1910 to 1930 ✓ B38 2570 to 2620 ✓ B39 1880 to 1920 ✓ B40 2300 to 2400 ✓ B41 2496 to 2690 ✓ B42 3400 to 3600 ✓ B43 3600 to 3800 ✓ B45 1447 to 1467 ✓ B46 5150 to 5925 ✓ B47 5855 to 5925 ✓ B48 3550 to 3700 ✓ B49 3550 to 3700 ✓ B50 1432 to 1517 ✓ B51 1427 to 1432 ✓ B52 3300 to 3400 ✓ B53 2483.5 to 2495 ✓ B65 1920 to 2010 2110 to 2200 ✓ B66 1710 to 1780 2110 to 2200 ✓ B68 698 to 728 753 to 783 ✓ B69 2570 to 2620 ✓ B70 1695 to 1710 1995 to 2020 ✓ B71 663 to 698 617 to 652 ✓ B72 451 to 456 461 to 466  B73 450 to 455 460 to 465  B74 1427 to 1470 1475 to 1518 ✓ B75 1432 to 1517 ✓ B76 1427 to 1432 ✓ B77 3300 to 4200 ✓ B78 3300 to 3800 ✓ B79 4400 to 5000 ✓ B85 698 to 716 728 to 746 ✓ B87 410 to 415 420 to 425  B88 412 to 417 422 to 427  5 www.taoglas.com SPE-12-8-050-G 3. Antenna Characteristics 3.1 Return Loss 3.2 VSWR 6 www.taoglas.com SPE-12-8-050-G 3.3 Efficiency 3.4 Average Gain 7 www.taoglas.com SPE-12-8-050-G 3.5 Peak Gain 8 www.taoglas.com SPE-12-8-050-G 4. Radiation Patterns 4.1 Test Setup 9 www.taoglas.com SPE-12-8-050-G 4.2 FXP14.07.0100.A - Patterns at 650 MHz XZ Plane YZ Plane XY Plane 10 www.taoglas.com SPE-12-8-050-G 4.3 FXP14.07.0100.A - Patterns at 750 MHz XZ Plane YZ Plane XY Plane 11 www.taoglas.com SPE-12-8-050-G 4.4 FXP14.07.0100.A - Patterns at 890 MHz XZ Plane YZ Plane XY Plane 12 www.taoglas.com SPE-12-8-050-G 4.5 FXP14.07.0100.A - Patterns at 1475 MHz XZ Plane YZ Plane XY Plane 13 www.taoglas.com SPE-12-8-050-G 4.6 FXP14.07.0100.A - Patterns at 1950 MHz XZ Plane YZ Plane XY Plane 14 www.taoglas.com SPE-12-8-050-G 4.7 FXP14.07.0100.A - Patterns at 2500 MHz XZ Plane YZ Plane XY Plane 15 www.taoglas.com SPE-12-8-050-G 4.8 FXP14.07.0100.A - Patterns at 4150 MHz XZ Plane YZ Plane XY Plane 16 www.taoglas.com SPE-12-8-050-G 4.9 FXP14.07.0100.A - Patterns at 5550 MHz XZ Plane YZ Plane XY Plane 17 www.taoglas.com SPE-12-8-050-G…

Text truncated - open the document above for the full version.

SPE-19-8-001 Page 1 of 13 Specification Part No. : GW.22.5151 Product Name : 5dBi 2.4GHz Rubber Duck Dipole Antenna with RP-SMA(M) Straight Connector Features : 2.4GHz Band Operation UV Resistant, Robust TPEE Housing IP67 Waterproof Rating IK07 Impact Rating Up to 5dBi Peak Gain Connector Mount: RP-SMA(M) Dimension: 235.5mm * 13mm RoHS Compliant SPE-19-8-001 Page 2 of 13 1. Introduction The GW.22 is a dipole antenna designed to provide up to 5dB of gain to 2.4GHz applications such as Bluetooth, BLE, Thread, Wi-Fi, WLAN and ZigBee. The IP67 rated enclosure makes it suitable for both indoor and outdoor applications. The flexible IK07 rated TPEE enclosure is impact resistant and durable and has the added benefit of UV resistance, allowing it to meet the needs of demanding outdoor applications. It has an omnidirectional radiation pattern and excellent efficiency of up to 70%. The GW.22 has up to 5dBi Peak making it a cost-effective, high-performing choice for any indoor or outdoor application operating at 2.4GHz. Many module manufacturers specify peak gain limits for any antennas that are to be connected to that module. Those peak gain limits are based on free-space conditions. In practice, the peak gain of an antenna tested in free-space can degrade by at least 1 or 2dBi when installed. So ideally you should go for a slightly higher peak gain antenna than mentioned on the module specification to compensate for this effect, giving you better performance. Upon testing of any of our antennas with your device and a selection of appropriate layout, integration technique, or cable, Taoglas can make sure any of our antennas’ peak gain will be below the peak gain limits. Taoglas can then issue a specification and/or report for the selected antenna in your device that will clearly show it complying with the peak gain limits, so you can be assured you are meeting regulatory requirements for that module. Choosing a Taoglas antenna with a higher peak gain than what is specified by the module manufacturer and enlisting our help will ensure you are getting the best performance possible without exceeding the peak gain limits. SPE-19-8-001 Page 3 of 13 2. Specification ELECTRICAL Frequency (MHz) 2400 2450 2500 Efficiency (%) 71.25 70.87 69.32 Average Gain(dB) -1.47 -1.50 -1.59 Peak Gain(dBi) 4.64 Return Loss <-10 Radiation Omni-directional Polarization Linear Impedance 50 Ω Input Power 10W MECHANICAL Antenna length 235mm Antenna Diameter 13mm Weight 32.5 grams Casing TPEE Connector RP-SMA(M) Waterproof IP67 Pendulum Hammer Test [IEC62262] IK07 ENVIRONMENTAL Operation Temperature -40°C ~ +85°C Storage Temperature -40°C ~ +85°C Humidity Non-condensing 65°C 95% RH SPE-19-8-001 Page 4 of 13 3. Antenna Characteristics 3.1 Return Loss 3.2 Efficiency SPE-19-8-001 Page 5 of 13 3.3 Average Gain 3.4 Peak Gain SPE-19-8-001 Page 6 of 13 4. Antenna Radiation Patterns The antenna radiation patterns were measured in a CTIA certified ETS Anechoic Chamber. The measurement setup is shown below. Free Space X Y Z SPE-19-8-001 Page 7 of 13 4.1 2D Radiation Pattern (Free Space) XY Plane ZX Plane SPE-19-8-001 Page 8 of 13 ZY Plane SPE-19-8-001 Page 9 of 13 4.4 3D Radiation Pattern (Free Space) 2400MHz 2450MHz SPE-19-8-001 Page 10 of 13 2500MHz SPE-19-8-001 Page 11 of 13 5. Mechanical Drawing SPE-19-8-001 Page 12 of 13 6. Packaging SPE-19-8-001 Page 13 of 13 Taoglas makes no warranties based on the accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Taoglas reserves all rights to this document and the information contained herein. Reproduction, use or disclosure to third parties without express permission is strictly prohibited. Copyright © Taoglas Ltd.

Radiated Emission Test below 1GHz Front View Radiated Emission Test below 1GHz Rear View Radiated Emission Test above 1GHz Front View Radiated Emission Test above 1GHz Rear View
