2AXD8-BLET8WTLED tube

Suzhou EICCOMM Technology CO., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Sep 23, 2022
Application Purpose: Original Equipment
Date of Application: Sep 23, 2022
Equipment Note: LED tube
Frequency Range: 2402.00000000 - 2480.00000000
Company: Suzhou EICCOMM Technology CO., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Hello Product Features Wireless control from your mobile device Tunable White 2700K-6500K Wireless remote control Create custom scenes Activity Mode Sensor compatible SmartShift™ automated circadian schedule Schedules and automations Wire directly to Line Voltage, bypass the ballast Direct Connect LED, No Gateway or Hub required Catalog Number: LCBT8-18-48P-8TW-SD-BYP-SS Model Number: LCBT8-18-48P-8TW-SD-BYP-SS Electrical: Construction: Lamp Base: G13 18W, 2200lm 120-277Vac 50/60Hz Lightcloud Blue is a Bluetooth mesh wireless lighting control system that allows you to control RAB’s various compatible devices. With RAB’s patent-pending Rapid Provisioning technology, devices can be quickly and easily commissioned for residential and large commercial applications using the Lightcloud Blue mobile app. Each device in a system can communicate with any other device, eliminating the need for a Gateway or Hub and maximizing the control system’s reach. Retrofit application includes these items: Installation Instructions, LED Lamps, Luminaire Marking Labels. Safety Information installation requires knowledge of luminaires electrical in luminaires that have the construction features and dimensions shown in the photographs and/or drawings exceed the input rating of the luminaire. • WARNING - To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects. lampholders. Note: Shunted lamp holders are found only "Instant Start" or "I.S." marked on the ballast. This designation may be in the form of a statement pertaining to the ballast itself, or may be combined with the marking for the lamps with which the ballast is intended to be used, for example F40T12/IS. For more information, contact the • Not suitable for use with dimmers and sensors unless • This device is not intended for use with emergency exits. Safety Information instructions to control this lamp. This lamp will not operate properly when connected to a standard (Incandescent) dimmer or dimming control. • Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation. • Installers should not disconnect existing wires from lampholder terminals to make new connections at lampholder terminals. Instead installers should cut existing lampholder leads away from the lampholder and make new electrical connections to lampholder lead wires by employing applicable connectors. where the suitability of the combination shall be determined by authorities having jurisdiction. Product with the applicable and appropriate electrical codes. The installation guide does not supersede local or national regulations for electrical installations. • Installers should examine all parts that are not intended to • Only dimmed by wireless control. Instructions, LED Lamps (Max. 4), Luminaire Marking Labels. (cont’d) Functionality tcloud Blue products may be performed using the Lightcloud Blue app. WE’RE HERE TO HELP: 1 (844) LIGHTCLOUD 1 (844) 544-4825 [email protected] Emergency default lamps on. FCC Information: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This device has been tested and found to comply with the limits for Class B digital devices pursuant to Part 15 Subpart B, of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential environ - ment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that inter ference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Consult the dealer or an experienced radio/TV technician for help. To comply with the FCC’s RF exposure limits for general population / uncontrolled exposure, this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. to operate this equipment. ±1MM ±2% CMYK 180° 810x180mm 80g 2022-06-221 ≥10N/M 年份每年要变 The rapid reset process must be done by professional electricians quali!ed by RAB. Reach out to your RAB sales manager to request a Rapid Reset Tool. The tool simply needs to be placed directly on the small Lightcloud Blue logo for 2 seconds. The lamp will "ash 3 times, then reset to 100% brightness at default CCT. Method 3: Rapid Reset Tool

Cover Letter(s)

ConfidentialityRequestLetter ForCertificationServiceintheUSA FederalCommunicationCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 Towhomitmayconcern PursuanttoParagraphs§0.457and0.459oftheCommission’sRules(47C.F.R.)andSection §552(b)(4)oftheFreedomofInformationAct,werequestconfidentialityforthe documentationofthefollowingproducts: FCCIDModelname 2AXD8-BLET8WT LCBT8-18-48P-8TW-SD-BYP-SS Fortheproductslistedabove,werequestpermanentconfidentialityforallapplicable exhibitsasthereare: theOperationalDescription  theBlockDiagram  theSchematics thePartsLists  theTuneUpInformation Theabovelistedexhibitscontaintradesecretsandproprietaryinformationthatcouldbeof benefittoourcompetitors. Ifyouhaveanyquestions,pleasefeelfreetocontactusattheaddressshownbelow. Sincerely, 2022.8.31 PrintedNameofSignee:JINGJINGWU Company:SuzhouEICCOMMTechnologyCO.,Ltd. Address:Room304,Building4,ZhuyuanRoad209,GAOXINDistrict,Suzhou,JiangsuProvince, China Phone:18662211697 Fax:18662211697Email:[email protected]

External Photos

Page 1 of 2 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. PHOTOGRAPHSOFTHEEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 2 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. ※※※※※ENDOFTHEREPORT※※※※※ Photo3 Photo4

ID Label/Location Info

2MM 技术要求： 1,垃圾桶标志高度大于7mm, CE标志高度大于5mm. 2,核对参数(彩盒、彩卡、不干胶、唛头等包装材料参数统一) 3,图案及字体清晰，位置正确，不歪斜，不偏移、不翻转。 4,附着力测试，无尘棉纱布蘸清水来回擦试15秒，正己烷来回擦试15秒，每秒一次，压力10N,图案及内容无掉色。 5,灯丝灯移印为保证附着力，打印完之后必须过烘道,烘道 90-100°C，时间5-20分钟（视油墨及设备决定，具体时间参照工艺SOP文件） RAB 1 2022-06-22 11 1:1 LCBT8-18-48P-8TW-SD-BYP-SS FCC ID2AXD8-BLET8WT 蓝色字体丝印，其余内容激光打印蓝色色号：PMS306 21X22.3mm LCBT8-18-48P-8TW-SD-BYP-SS FCC ID2AXD8-BLET8WT 21mm 9X8mm7X8.7mm 21x22mm5x5mm31x16.7mm FXXX每批要变 Lable location(on the product back side)

Internal Photos

Page 1 of 6 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. PHOTOGRAPHSOFTHEEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 6 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. Photo3 Photo4 Page 3 of 6 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. Photo5 Photo6 Page 4 of 6 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. Photo7 Photo8 Page 5 of 6 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. Photo9 Photo10 Page 6 of 6 ReportNo.: ShanghaiATBLTechnologyCo.,Ltd. Photo11 BLE ANT

RF Exposure Info

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2208111H01 Issued for Suzhou EICCOMM Technology CO., Ltd. Room 304, Building 4,Zhuyuan Road 209, GAOXIN District, Suzhou, Jiangsu Province, China Product Name: LED tube Brand Name: RAB Model Name: LCBT8-18-48P-8TW-SD-BYP-SS Series Model: T8-12-48G-8xx-SD-BYP-DIM/LCB FCC ID: 2AXD8-BLET8WT Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 9 Report No.: STS2208111W01 Test Report Certification Applicant’s Name ................. : Suzhou EICCOMM Technology CO., Ltd. Address ................................. : Room 304, Building 4,Zhuyuan Road 209, GAOXIN District, Suzhou, Jiangsu Province, China Manufacturer's Name .......... : RAB lighting INC Address ................................. : No. 9, Jiaozhou Road, Jingan District, Shanghai, China Product Description Product Name ........................ : LED tube Brand Name ......................... : RAB Model Name .......................... : ... : LCBT8-18-48P-8TW-SD-BYP-SS Series Model .......................... : T8-12-48G-8xx-SD-BYP-DIM/LCB Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 19 Aug. 2022 Date (s) of performance of tests ............. : 19 Aug. 2022 ~25 Aug. 2022 Date of Issue .......................................... : 25 Aug. 2022 Test Result.............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2208111W01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2208111W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 25 Aug. 2022 STS2208111W01 ALL Initial Issue Page 5 of 9 Report No.: STS2208111W01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name LED tube Brand Name RAB Model Name LCBT8-18-48P-8TW-SD-BYP-SS Series Model T8-12-48G-8xx-SD-BYP-DIM/LCB Model Difference The color temperature is different Product Description The EUT is LED tube Operation Frequency: BLE: 2402-2480 MHz Modulation Type: GFSK Antenna gain: -1.8dBi Antenna Designation: Single-stage Rating 120-277V, 18W Hardware Version V2.0 Software Version V1.0.1 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2208111W01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2208111W01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2208111W01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structur…

Text truncated - open the document above for the full version.

Test Report

"Shanghai ATBL Technology Co., Ltd." hereby certifies that according to actual testing conditions. The test results or observations are provided in accordance with measured value, without taking risks caused by uncertainty into account. Without explicit stipulation in special agreements, standards or regulations, ATBL shall not assume any responsibility. The test results or observations are applicable only to tested sample. Client shall be responsible for representativeness of the sample and authenticity of the material. This report will be void without authorized signature or special seal for testing report. Do not copied without authorization. Tel:+86(0)21-51298625 Web:www.atbl-lab.com Email:[email protected] RADIO TEST REPORT Report No.: SHATBL2208018W01 Applicant: Suzhou EICCOMM Technology CO., Ltd. Address: Room 304, Building 4,Zhuyuan Road 209, GAOXIN District, Suzhou, Jiangsu Province, China Product Name : LED tube Brand Name : RAB Model Name : LCBT8-18-48P-8TW-SD-BYP-SS Series Model : N/A Test Standard : FCC Part15.247 FCC ID : 2AXD8-BLET8W T Page 2 of 52 Report No.: SHATBL2208018W01 Shanghai ATBL Technology Co., Ltd. Number:SHATBL-W-05 Release date:2022-03-01 Version No.A/1 GENERAL DESCRIPTION Applicant’s Name................. : Suzhou EICCOMM Technology CO., Ltd. Address ................................. : Room 304, Building 4,Zhuyuan Road 209, GAOXIN District, Suzhou, Jiangsu Province, China Manufacture's Name ............ : RAB lighting INC Address ................................. : No. 9, Jiaozhou Road, Jingan District, Shanghai,China Product Description Product Name ....................... : LED tube Brand Name .......................... : RAB Model Name .......................... : LCBT8-18-48P-8TW-SD-BYP-SS SeriesModel .......................... : N/A Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2013 This device described above has been tested by ATB L, the test results show that the equipment under test (EUT) is in compliance with the FCCrequirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ATBL, this document may be altered or revised by ATBL, personal only, and shall be noted in the revision of the document. Date of receipt of test item ..................... : 16 Aug. 2022 Date (s) of performance of tests ............ : 16 Aug. 2022 ~ 20 Aug. 2022 Date of Issue ........................................ : 20 Aug. 2022 Test Result ............................................ : Pass Report Prepared by : (Roean Wei) Report Approved by : (Ghost Li) Authorized Signatory : (Terry Yang) Page 3 of 52 Report No.: SHATBL2208018W01 Shanghai ATBL Technology Co., Ltd. Number:SHATBL-W-05 Release date:2022-03-01 Version No.A/1 Table of Contents 1. SUMMARY OF TEST RESULT S 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF THE EUT 7 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.6 LABORATORY INFORMATION 11 2.7 MEASUREMENT UNCERTAINTY 12 2.8 EQUIPMENTS LIST 13 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 TEST PROCEDURE 15 3.3 TEST SETUP 16 3.4 EUT OPERATING CONDITIONS 16 3.5TEST RESULTS 16 4. RADIATED EMISSION MEASUREMENT 18 4.1 RADIATED EMISSION LIMITS 18 4.2 TEST PROCEDURE 20 4.3 TEST SETUP 21 4.4 EUT OPERATING CONDITIONS 21 4.5 FIELD STRENGTH CALCULATION 22 4.6 TEST RESULTS 23 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 36 5.1 LIMIT 36 5.2 TEST PROCEDURE 36 5.3 TEST SETUP 36 5.4 EUT OPERATION CONDITIONS 36 5.5 TEST RESULTS 37 6. POWER SPECTRAL DENSITY TEST 40 6.1 LIMIT 40 6.2 TEST PROCEDURE 40 6.3 TEST SETUP 40 Page 4 of 52 Report No.: SHATBL2208018W01 Shanghai ATBL Technology Co., Ltd. Number:SHATBL-W-05 Release date:2022-03-01 Version No.A/1 Table of Contents 6.4 EUT OPERATION CONDITIONS 40 6.5 TEST RESULTS 41 7. BANDWIDTH TEST 43 7.1 LIMIT 43 7.2 TEST PROCEDURE 43 7.3 TEST SETUP 43 7.4 EUT OPERATION CONDITIONS 43 7.5 TEST RESULTS 44 8. PEAK OUTPUT POWER TEST 46 8.1 LIMIT 46 8.2 TEST PROCEDURE 46 8.3 TEST SETUP 46 8.4 EUT OPERATION CONDITIONS 46 8.5 TEST RESULTS 46 9. ANTENNA REQUIREMENT 49 9.1 STANDARD REQUIREMENT 49 9.2 EUT ANTENNA 49 APPENDIX-PHOTOS OF TEST SETUP 50 Page 5 of 52 Report No.: SHATBL2208018W01 Shanghai ATBL Technology Co., Ltd. Number:SHATBL-W-05 Release date:2022-03-01 Version No.A/1 Rev. Revision History Issue Date Report NO. Effect Page Contents 00 20 Aug. 2022 SHATBL2208018W01 ALL Initial Issue Page 6 of 52 Report No.: SHATBL2208018W01 Shanghai ATBL Technology Co., Ltd. Number:SHATBL-W-05 Release date:2022-03-01 Version No.A/1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB&99% Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.247(d) & 15.209 & 15.205 Radiated Spurious Emission PASS -- 15.247(d) & 15.205 Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2)All tests are according to ANSI C63.10-2013. Page 7 of 52 Report No.: SHATBL2208018W01 Shanghai ATBL Technology Co., Ltd. Number:SHATBL-W-05 Release date:2022-03-01 Version No.A/1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name LED tube Trade Name RAB Model Name LCBT8-18-48P-8TW-SD-BYP-SS Series Model T8-12-48G-8xx-SD-BYP-DIM/LCB Model Difference The color temperature is different Product Description The EUT is a LED tube Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Version: 5.0 Bluetooth Configuration: LE(Support…

Text truncated - open the document above for the full version.

Test Setup Photos
