2AXFW-ES-7000KDigital Door Lock

EPIC SYSTEMS CO., LTD.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 11, 2020
Application Purpose: Original Equipment
Date of Application: Nov 11, 2020
Equipment Note: Digital Door Lock
Frequency Range: 13.56000000 - 13.56000000
Company: EPIC SYSTEMS CO., LTD.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help Rule Part 15.19(a)(3): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Rule Part 15.21: The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital

Attestation Statements

Cover Letter(s)

November 11, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Cover letter FCC ID : 2AXFW-ES-7000K Gentlemen: Variant Model name : ES-7000K(B) The only reason for the variant model name is the color difference. Sincerely, Wanseob Lee /CEO EPIC SYSTEMS CO., LTD. EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea

Cover Letter(s)

EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean- ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea October 05, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : EPIC SYSTEMS CO., LTD. FCC ID : 2AXFW-ES-7000K Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), EPIC SYSTEMS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give EPIC SYSTEMS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX 2AXFW-ES-7000K SCH DIA.pdf Parts list CONF APPENDIX 2AXFW-ES-7000K PL.pdf Block diagram CONF APPENDIX 2AXFW-ES-7000K BLK DIA.pdf Operational description CONF APPENDIX 2AXFW-ES-7000K OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF 2AXFW-ES-7000KEXT Photo.pdf Internal Photos SHORT-TERM CONF 2AXFW-ES-7000K INT Photo.pdf Te s t-Setup Photos SHORT-TERM CONF 2AXFW-ES-7000K Test Photo.pdf User’s Manual SHORT-TERM CONF 2AXFW-ES-7000K Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Wansub Lee/CEO EPIC SYSTEMS CO., LTD.

External Photos

FCC ID: 2AXFW-ES-7000K Front Rear Label position Copyright ○ c 2020, LTA Co., Ltd .Page 1 of 4 FCC ID: 2AXFW-ES-7000K To p Bottom Copyright ○ c 2020, LTA Co., Ltd .Page 2 of 4 FCC ID: 2AXFW-ES-7000K Left Right Copyright ○ c 2020, LTA Co., Ltd .Page 3 of 4 FCC ID: 2AXFW-ES-7000K ANTENNA Copyright ○ c 2020, LTA Co., Ltd .Page 4 of 4

ID Label/Location Info

FCC ID: 2AXFW-ES-7000K SAMPLE LABEL & LOCATION EUT Front EPIC SYSTEMS CO., LTD. Model : ES-7000K Rated Voltage : 6 V FCC ID : 2AXFW-ES-7000K Contains FCC ID: 2AXFW-MDBT42Q Made in Korea Copyright Ⓒ 2020, LTA Co., Ltd.

Internal Photos

FCC ID: 2AXFW-ES-7000K MainBoard–Front MainBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 4 FCC ID: 2AXFW-ES-7000K SubBoard–Front SubBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 4 FCC ID: 2AXFW-ES-7000K Contain Module–Front Contain Module –Rear Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 4 FCC ID: 2AXFW-ES-7000K Total internal Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 4

Test Report

Ref. No.: LR500112010E 4, Songjuro236Beon-gil, Yangji-myeon, Cheoin-gu Yong-in-si, Gyeonggi-do, Korea 17159 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: Sep 23, 2019 ~ Oct 12, 2020 Test Report S/N: LR500112010E Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT Manufacturing Description : Digital Door Lock Manufacturer : EPIC SYSTEMS CO., LTD. Model name : ES-7000K Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15 Subpart C ; ANSI C63.10 - 2013 Frequency Range : 13.56 MHz Data of issue : October 05, 2020 This test report is issued under the authority of: The test was supervised by: Ja-Beom Koo, Manager Eun-Hwan Jung, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. NVLAP LAB Code.: 200723-0 2AXFW- ES-7000K EPIC SYSTEMS CO., LTD. Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 15 Ref. No.: LR500112010E TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT ------------------------------------------------------------------------------------------ 3.1 SUMMARY OF TESTS ---------------------------------------------------------------------------- 3.2 TECHNICAL CHARACTERISTICS TEST ---------------------------------------------------- 3.2.1 Radiated Emission ------------------------------------------------------------------------------- 3.2.2 Frequency Tolerance ------------------------------------------------------------------------------ 3.2.3 20dB Bandwidth ------------------------------------------------------------------------------ 3.2.4 AC Conducted Emissions --------------------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 11 12 14 15 Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 15 Ref. No.: LR500112010E 1. General information 1- 1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 17159 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1- 2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2021-09-30 ECT accredited Lab. RRA KOREA KR0049 - EMC accredited Lab. FCC U.S.A 649054 2021-04-11 FCC CAB VCCI JAPAN C-4948, 2023-09-10 VCCI registration VCCI JAPAN T-2416, 2023-09-1 0 VCCI registration VCCI JAPAN R-4483(10 m), 2023-08-1 5 VCCI registration VCCI JAPAN G-847 2021-12-13 VCCI registration IC CANADA 5799A-1 2021-06-16 IC filing KOLAS KOREA NO.551 2021-08-20 KOLAS accredited Lab. Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 15 Ref. No.: LR500112010E 2. Information about test item 2-1 Client & Manufacturer Client Company name : EPIC SYSTEMS CO., LTD. Address : Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax : + 82-070-4741-1025 / + 82-031-481-8116 Manufacturer EPIC SYSTEMS CO., LTD. Address Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax + 82-070-4741-1025 / + 82-031-481-8116 2- 2 Equipment Under Test (EUT) Model name : ES-7000K Variant Model name : ES-7000K(B) Serial number : Identical prototype Date of receipt : Sep 23, 2020 EUT condition : Pre-production, not damaged Antenna type : Pattern Antenna Frequency Range : 13.56 MHz Type of Modulation : FSK Power Source : DC 6 V 2- 3 Tested frequency LOW MID HIGH Frequency (MHz) BLE 13.56 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer - - - - Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 15 Ref. No.: LR500112010E 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Test Condition Status (note 1) 15.209 15.225(a)(b)(c)(d) Radiated Emission Radiated C 15.225(e) Frequency Tolerance C 15.215(c) 20dB Bandwidth C 15.207 AC Conducted Emissions Conducted N/A 15.203 Antenna requirement - C N/A : This product is battery-enabled and excludes the test. The above equipment was tested by LTA Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. The tests were performed according to the method of measurements prescribed in KDB No.558074.  Antenna Requirement EPIC SYSTEMS CO., LTD. FCC ID: 2AXFW-ES-7000K unit complies with the requirement of §15.203. The antenna type is FPCB Antenna Copyright ○ c 2020, LTA Co., Ltd. Page 5 of 15 Ref. No.: LR500112010E 3.2 Technical Characteristics Test 3.2.1 Radiated Spurious Emissions Procedure: Radiated emissions from 30 MHz to 25 GHz were measured according to the methods defines in ANSI C63.10-2013. The EUT is a placed on as turn table. For emissions testing at or below 1 GHz, the table height shall be 0.8 m above the reference ground plane. For emission measurements above 1 GHz, the table height shall be 1.5 m. The turn table shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3m away from the r…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: 2AXFW-ES-7000K Radiate Emission Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 3 FCC ID: 2AXFW-ES-7000K Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 3 FCC ID: 2AXFW-ES-7000K Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 3
