2AXFW-ES-F300DDigital Door Lock

EPIC SYSTEMS CO., LTD.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 05, 2020
Application Purpose: Original Equipment
Date of Application: Nov 05, 2020
Equipment Note: Digital Door Lock
Frequency Range: 2402.00000000 - 2480.00000000
Company: EPIC SYSTEMS CO., LTD.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Pin Number Registration Please perform while door is open Default Pin Number is [1, 2, 3, 4]. Don’t forget your Pin Number. If you forgot your Pin Number , New registration of Pin Number, RFID Card, Fingerprint, Guest Pin Number and Remote Control is not possible. 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [1] button. 4. Enter 4~12 digits New User Pin Number and press the [#] button. 5. Re-Enter the New User Pin Number and press the [Registration] button to complete the process. Only 1 user Pin Number can be saved. When error occur during registration [2] will be lighted together with an error sound. During each process, when [Registration] button is pressed, the registration process will end. When the registration process has completed, a completion sound will be heard. Note Product Line-Up EPIC product lineup. Check main features of each product carefully. Note Registration Deletion The number pad lighting is as follows, during registration and deletion, the numbers that are lighted when the number pad is touched are as follows, products containing each function will all be lighted. [1] Pin Number Registration & Deletion [2] RFID Card Registration & Deletion [3] Fingerprint Registration & Deletion [4] Guest Pin Number Registration & Deletion [5] Remote Control Registration & Deletion [0] User Registered Information & Settings Reset This is a unified manual of EPIC products. Products features may change for improvement purposes. Contents of this manual may be modified without prior notice. ES-100D ES-S100D ES-300D ES-500D ES-500H ES-700G ES-F300D ES-F500D ES-F500H ES-F500HK ES-F700G ES-FF730G ES-7000K ES-9000K ES-F9000K EF-P8800K MODELLIGHTINGFUNCTION Pin Number Pin Number + RFID Card Pin Number + RFID Card Pin Number + RFID Card Pin Number + RFID Card Pin Number + RFID Card + Fingerprint Pin Number + RFID Card + Fingerprint Pin Number + RFID Card + Fingerprint Pin Number + RFID Card + Fingerprint + Mechanical Key Pin Number + RFID Card + Mechanical Key Pin Number + RFID Card + Mechanical Key Pin Number + RFID Card + Fingerprint + Mechanical Key Pin Number + RFID Card + Fingerprint + Mechanical Key R D [1],[4],[5] [1],[4],[5],[0] R D [1],[2],[4],[5] [1],[2],[4],[5],[0] R D [1],[2],[3],[4],[5] [1],[2],[3],[4],[5],[0] R D [1],[2],[4],[5] [1],[2],[4],[5],[0] R D [1],[2],[3],[4],[5] [1],[2],[3],[4],[5],[0] RD RegistrationDeletion Pin Number + RFID Card + Fingerprint (Outer / Inner body) + Mechanical Key Pin Number + RFID Card (Outer / Inner body) + Mechanical Key Pin Number + RFID Card (Outer / Inner body) + Fingerprint + Mechanical Key User RFID Card Registration (all-at-once) 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [2] button. 4. Place the Card to be registered on the card reader . When the Card has been successfully registered, the 3 digits Card Placement Number will be displayed on the number pad and registration is complete. (If you want to register additional Card, repeat step 4.) 5. When registration of all Card is done, press the [Registration] button to complete the process. User RFID Card Registration (one-by-one) 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [2] button. 4. Enter the Card Placement Number from 001~200 on the number pad followed by the [#] button. (When the selected Card Placement Number is already in use, the error sound will be heard and [7] button will be lighted on the number pad.) 5. Place the Card to be registered on the card reader. When the Card has been successfully registered, the 3 digits Card Placement Number will be displayed on the number pad and registration is complete. (If you want to register additional Card, repeat step 4.) 6. When registration of all Card is done, press the [Registration] button to complete the process. Up to 200 cards can be registered. New registration will not delete previously registered card in the system. Note User Fingerprint Registration (all-at-once) 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [3] button. 4. Check the total number of the registered Fingerprint displayed on the number pad, then enter the Fingerprint to be registered for 4 times. When the Fingerprint has been successfully registered, the 3 digits Fingerprint Placement Number will be displayed on the number pad and registration is complete. (If you want to register additional Fingerprint, repeat step 4.) 5. When registration of all Fingerprint is done, press the [Registration] button to complete the process. Up to 100 Fingerprints can be registered. Y ou can also re-register registered Fingerprints. When error occur during registration LED [2] will be blinking. Note User Guest Pin Number Registration 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [4] button. 4. Enter 4~12 digits User Guest Pin Number and press the [#] button. 5. Re-Enter the User Guest Pin Number and press the [Registration] button to complete the process. If you register a new guest Pin Number, the old one will be deleted. Only 1 Guest Pin Number can be saved. It will be deleted after 1 usage. Note User…

Text truncated - open the document above for the full version.

Attestation Statements

Cover Letter(s)

October 27, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Cover letter FCC ID : 2AXFW-ES-F300D Gentlemen: 1. The only reason for the variant model name is the color difference. 2. We use existing originally approved modules and meet the requirements in accordance with KDB 996369. 3. The original module usage voltage is applied by the regulator and there is no circuit and component change. 4. The orginal identification is FCC ID : SH6MDBT42Q 5. The original identification grant date is 08/19/2016 Sincerely, Wanseob Lee /CEO EPIC SYSTEMS CO., LTD. EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea

Cover Letter(s)

EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean- ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea October 27, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : EPIC SYSTEMS CO., LTD. FCC ID : 2AXFW-ES-F300D Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), EPIC SYSTEMS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give EPIC SYSTEMS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX 2AXFW-ES-F300D SCH DIA.pdf Parts list CONF APPENDIX 2AXFW-ES-F300D PL.pdf Block diagram CONF APPENDIX 2AXFW-ES-F300D BLK DIA.pdf Operational description CONF APPENDIX 2AXFW-ES-F300D OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF 2AXFW-ES-F300DEXT Photo.pdf Internal Photos SHORT-TERM CONF 2AXFW-ES-F300D INT Photo.pdf Te s t-Setup Photos SHORT-TERM CONF 2AXFW-ES-F300D Test Photo.pdf User’s Manual SHORT-TERM CONF 2AXFW-ES-F300D Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Wanseob Lee/CEO EPIC SYSTEMS CO., LTD.

Cover Letter(s)

November 02, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Cover Letter for Reused Test Teport FCC ID : 2AXFW-ES-F300D To Whom It May Concern: We, EPIC SYSTEMS CO., LTD., hereby declare our product (Digital Door Lock) Model Number : ES- F300D (FCC ID : 2AXFW-ES-F300D) will reuse test reports of product (BT BLE Module) Model Number : MDBT42Q (FCC ID : SH6MDBT42Q) as difference declaration as follow ; 1. Our product integrated BT BLE Module (FCC ID : SH6MDBT42Q), so conducted test data re-used; 2. Radiation emission re-tested and reported in Report (Number : LR500112010M) ; 3. RF exposure no need to evaluated as the same intended condition ; 4. BLE module is identical and in the same configuration as in the original test. The output power has been tested and verified in test report. We reuse test reports information as follows: Test Report Description Test Report Number BT BLE Test Report ER/2016/70009-03 Should you have any qusetions or comments regarding this matter, please have any best attention. Sincerely, Wanseob Lee /CEO EPIC SYSTEMS CO., LTD. EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea

External Photos

FCC ID: 2AXFW-ES-F300D Front Rear Copyright ○ c 2020, LTA Co., Ltd .Page 1 of 4 FCC ID: 2AXFW-ES-F300D To p Bottom Copyright ○ c 2020, LTA Co., Ltd .Page 2 of 4 FCC ID: 2AXFW-ES-F300D Left Right Copyright ○ c 2020, LTA Co., Ltd .Page 3 of 4 FCC ID: 2AXFW-ES-F300D ANTENNA Label Position Copyright ○ c 2020, LTA Co., Ltd .Page 4 of 4

ID Label/Location Info

Internal Photos

FCC ID: 2AXFW-ES-F300D MainBoard–Front MainBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 4 FCC ID: 2AXFW-ES-F300D SubBoard–Front SubBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 4 FCC ID: 2AXFW-ES-F300D Module–Front Module –Rear Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 4 FCC ID: 2AXFW-ES-F300D Total internal Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 4

RF Exposure Info

FCC ID: 2AXFW-ES-F300D ATTACHMENT RF EXPOSURE EVULATION 1.1 Limit According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength Magnetic field Strength Power density Averaging time 1.34 - 30....................................... 824/f 2.19/f *(180/ f²) 30 30 - 300....................................... 27.5 0.073 0.2 30 300 - 1500.................................... ............... ............... f/1500 30 1500 - 100.000................................. ............... ............... 1.0 30 F = frequency in MHz * = Plane-wave equivalent power density 1.2 MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Power density at the specific separation: S = PG/(4R 2 π) Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20 cm = limit for MPE) S = (1.66 * 0.69) / (4 * 5 2 * π) S = 0.003 mW/cm 2 FCC ID: 2AXFW-ES-F300D ATTACHMENT 1.3 MAXIMUM PERMISSIBLE EXPOSURE Prediction - Calculated under the worst-case conditions of each mode. (Measured power 2.19 dBm ± 0.5dB) 3-1. 2.4 GHz Mode Max Peak output Power at antenna input terminal 2.19 dBm Max Peak output Power at antenna input terminal 1.66 mW Prediction distance 5 mm Prediction frequency 2,442 MHz Antenna Gain(typical) -1.61 dBi Antenna Gain(numeric) 0.69 - Power density at prediction frequency( S) 0.05 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.016 mW/cm 2 SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm = Used [(max.power of channel, including tune-up torelance, mW)/(min. test separation distance, mm)] * [√f(GHz)] = [1.66 / 5 ] * [ √2.442 ] = 0.44 ≤ 3.0, for 1g SAR Thus, SAR for this device is not required.

Test Report

Report No.: ER/2016/70009-03 Page 1 of 68 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Product Name: BT 4.2 Module Brand Name: Raytac Model No.: MDBT42Q, MDBT42Q-P Model Difference: MDBT42Q with Chip antenna, MDBT42Q-P with PCB antenna FCC ID: SH6MDBT42Q Report No.: ER/2016/70009-03 Issue Date: Sep. 02, 2019 FCC Rule Part: §15.247, Cat: DTS Prepared for: Raytac Corporation 5F, No.3, Jiankang Rd., Zhonghe Dist., New Taipei City , 23586, Taiwan Prepared by: SGS Taiwan Ltd. Electronics & Communication Laboratory No.134, Wu Kung Road, New Taipei Indus- trial Park, Wuku District, New Taipei City, Taiwan 24803 Note: This report shall not be reproduced except in full, without the written approval of SGS Taiwan Ltd. This document may be altered or revised by SGS Taiwan Ltd. personnel only, and shall be noted in the revision section of the document. Report No.: ER/2016/70009-03 Page 2 of 68 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or ap- pearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. SGS Taiwan Ltd. No.134,WuKungRoad,NewTaipeiIndustrialPark,WukuDistrict,NewTaipeiCity,Taiwan24803/北北路134 t (8862) 22993279 f (8862) 22980488 www.tw.sgs.com Member of SGS Group VERIFICATION OF COMPLIANCE Applicant: Raytac Corporation 5F, No.3, Jiankang Rd., Zhonghe Dist., New Taipei City , 23586, Taiwan Product Name: BT 4.2 Module Brand Name: Raytac Model No.: MDBT42Q, MDBT42Q-P Model Difference: MDBT42Q with Chip antenna, MDBT42Q-P with PCB antenna FCC ID: SH6MDBT42Q Report Number: ER/2016/70009-03 Date of test: Jul. 04, 2016 ~ Jul. 22, 2016 Date of EUT Received: Jul. 04, 2016 We hereby certify that: The above equipment was tested by SGS Taiwan Ltd. Electronics & Communication Laboratory The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10:2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emis- sion limits. The test results of this report relate only to the tested sample identified in this report. Test By: Date Sep. 02, 2019 Cooper Hsu / Engineer Prepared By: Date Sep. 02, 2019 Yuri Tsai / Clerk Approved By: Date Sep. 02, 2019 Jim Chang / Asst. Manager Report No.: ER/2016/70009-03 Page 3 of 68 Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 說留不 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for elec- tronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm. Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized…

Text truncated - open the document above for the full version.

Test Report

Ref. No.: LR500112010M 243 Jubug-Ri,Yangji-Myeon, Yongin-Si, Gyeonggi-Do, Korea 17159 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: Oct 15, 2020 ~ Oct 27, 2020 Test Report S/N: LR500112010M Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT Equipment Class : Digital Transmission System (DTS) Manufacturing Description : Digital Door Lock Manufacturer : EPIC SYSTEMS CO., LTD. Model name : ES-F300D Module FCCID : SH6MDBT42Q Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15.247 Subpart C ; ANSI C63.10 - 2013 Frequency Range : 2402 ~ 2480 MHz Max. Output Power : Max 1.98 mW - Conducted Data of issue : October 28, 2020 This test report is issued under the authority of: The test was supervised by: Ja-Beom Koo, Manager Eun-Hwan Jung, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. NVLAP LAB Code.: 200723-0 2AXFW- ES-F300D EPIC SYSTEMS CO., LTD. Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 13 Ref. No.: LR500112010M TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT ------------------------------------------------------------------------------------------ 3.1 SUMMARY OF TESTS ---------------------------------------------------------------------------- 3.2 TECHNICAL CHARACTERISTICS TEST ---------------------------------------------------- 3.2.2 Peak Output Power Measurement ------------------------------------------------------------------ 3.2.1 RADIATED SPURIOUS EMISSIONS------------------------------------------------------------ APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 7 13 Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 13 Ref. No.: LR500112010M 1. General information 1- 1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 17159 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1- 2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2021-09-30 ECT accredited Lab. RRA KOREA KR0049 - EMC accredited Lab. FCC U.S.A 649054 2021-04-11 FCC CAB VCCI JAPAN C-4948, 2023-09-10 VCCI registration VCCI JAPAN T-2416, 2023-09-1 0 VCCI registration VCCI JAPAN R-4483(10 m), 2023-08-1 5 VCCI registration VCCI JAPAN G-847 2021-12-13 VCCI registration IC CANADA 5799A-1 2021-06-16 IC filing KOLAS KOREA NO.551 2021-08-20 KOLAS accredited Lab. Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 13 Ref. No.: LR500112010M 2. Information about test item 2-1 Client & Manufacturer Client Company name : EPIC SYSTEMS CO., LTD. Address : Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax : + 82-070-4741-1025 / + 82-031-481-8116 Manufacturer EPIC SYSTEMS CO., LTD. Address Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax + 82-070-4741-1025 / + 82-031-481-8116 2- 2 Equipment Under Test (EUT) Model name : ES-F300D Variant Model name : ES-F300D Gold, ES-F300 24K Gold plating Serial number : Identical prototype Date of receipt : Oct 13, 2020 EUT condition : Pre-production, not damaged Antenna type : PCB Antenna (Max Gain : -1.61 dBi) Frequency Range : 2402 ~ 2480 MHz Type of Modulation : GFSK Power Source : DC 6 V 2- 3 Tested frequency LOW MID HIGH Frequency (MHz) 2402 2442 2480 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer - - - - Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 13 Ref. No.: LR500112010M 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Test Condition Status (note 1) 15.247(a) 6 dB Bandwidth Conducted N/A 1) 15.247(b) Transmitter Peak Output Power C 15.247(e) Transmitter Power Spectral Density N/A 1) 15.247(d) Band Edge & Conducted Spurious emission N/A 1) 15.209 Transmitter emission Radiated C 15.207 AC Conducted Emissions Conducted N/A 1) 15.203 Antenna requirement - C N/A 1) : The product replaces this test with a certificate using an authenticated module. The above equipment was tested by LTA Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. The tests were performed according to the method of measurements prescribed in KDB No.558074.  Antenna Requirement EPIC SYSTEMS CO., LTD. FCC ID: 2AXFW-ES-F300D unit complies with the requirement of §15.203. The antenna type is FPCB Antenna Copyright ○ c 2020, LTA Co., Ltd. Page 5 of 13 Ref. No.: LR500112010M 3.2 Technical Characteristics Test 3.2.1 Peak Output Power Measurement Procedure: The following procedure can be used when the maximum available RBW of the instrument is less than the DTS bandwidth : The spectrum analyzer is set to: Center frequency = the highest, middle and the lowest channels RBW ≥ DTS Bandwidth Span ≥ 3 X RBW VBW = 3 X RBW Sweep = auto Detector function = peak Measurement Data : Complies BLE Mode Frequency (MH…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: 2AXFW-ES-F300D Radiate Emission Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 3 FCC ID: 2AXFW-ES-F300D Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 3 FCC ID: 2AXFW-ES-F300D Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 3
