2AXFW-ES-9000KDigital Door Lock

EPIC SYSTEMS CO., LTD.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 12, 2020
Application Purpose: Original Equipment
Date of Application: Nov 12, 2020
Equipment Note: Digital Door Lock
Frequency Range: 13.56000000 - 13.56000000
Company: EPIC SYSTEMS CO., LTD.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help Rule Part 15.19(a)(3): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Rule Part 15.21: The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital

Attestation Statements

Cover Letter(s)

November 11, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Cover letter FCC ID : 2AXFW-ES-9000K Gentlemen: 1. Variant Model name : ES-9000K(B) 2. The only reason for the variant model name is the color difference. Sincerely, Wanseob Lee/CEO EPIC SYSTEMS CO., LTD. EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea

Cover Letter(s)

EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean- ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea November 11, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : EPIC SYSTEMS CO., LTD. FCC ID : 2AXFW-ES-9000K Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), EPIC SYSTEMS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give EPIC SYSTEMS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX 2AXFW-ES-9000K SCH DIA.pdf Parts list CONF APPENDIX 2AXFW-ES-9000K PL.pdf Block diagram CONF APPENDIX 2AXFW-ES-9000K BLK DIA.pdf Operational description CONF APPENDIX 2AXFW-ES-9000K OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF 2AXFW-ES-9000KEXT Photo.pdf Internal Photos SHORT-TERM CONF 2AXFW-ES-9000K INT Photo.pdf Te s t-Setup Photos SHORT-TERM CONF 2AXFW-ES-9000K Test Photo.pdf User’s Manual SHORT-TERM CONF 2AXFW-ES-9000K Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Wanseob Lee/CEO EPIC SYSTEMS CO., LTD.

Cover Letter(s)

External Photos

FCC ID: 2AXFW-ES-9000K Front Rear Copyright ○ c 2020, LTA Co., Ltd .Page 1 of 6 FCC ID: 2AXFW-ES-9000K To p Bottom Copyright ○ c 2020, LTA Co., Ltd .Page 2 of 6 FCC ID: 2AXFW-ES-9000K Left Right Label Positio Copyright ○ c 2020, LTA Co., Ltd .Page 3 of 6 FCC ID: 2AXFW-ES-9000K ANTENNA Copyright ○ c 2020, LTA Co., Ltd .Page 4 of 6 FCC ID: 2AXFW-ES-9000K Contain Module Position Contain Module Position Copyright ○ c 2020, LTA Co., Ltd .Page 5 of 6 FCC ID: 2AXFW-ES-9000K Contain Module Copyright ○ c 2020, LTA Co., Ltd .Page 6 of 6

ID Label/Location Info

FCC ID: 2AXFW-ES-9000K SAMPLE LABEL & LOCATION EUT Side position EPIC SYSTEMS CO., LTD. Model : ES-9000K Rated Voltage : 6 V FCC ID : 2AXFW-ES-9000K Contains FCC ID: 2AXFW-MDBT42Q Made in Korea Copyright Ⓒ 2020, LTA Co., Ltd.

Internal Photos

FCC ID: 2AXFW-ES-9000K MainBoard–Front MainBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 4 FCC ID: 2AXFW-ES-9000K SubBoard–Front SubBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 4 FCC ID: 2AXFW-ES-9000K Contain Module–Front Contain Module –Rear Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 4 FCC ID: 2AXFW-ES-9000K Total internal Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 4

Parts List/Tune Up Info

ProductES-9000K KEYAss'yDrawingCheckApproval TypeRFID+BLECode Rev.Page No.ItemTypeDescriptionQ'tyRemarks 1CAPACITOR CERAMIC1UF2 C103 105 2CAPACITOR CERAMIC100NF5 C101 104 106 108 111 3CAPACITOR CERAMIC1NF1 C125 4CAPACITOR CERAMIC10NF1 C109 5CAPACITOR CERAMIC47NF1 C114 6CAPACITOR CERAMIC100PF3 C110 121 123 7CAPACITOR CERAMIC68PF4 C115 116 117 118 8CAPACITOR CERAMIC43PF2 C122 124 9CAPACITOR CERAMIC33PF1 C120 10CAPACITOR CERAMIC51PF1 C119 11CAPACITOR CERAMIC10PF2 C112 113 12 13CAPACITOR TANTAL22UF 16V (B-CASE)1 C102 14CAPACITOR TANTAL100UF/6.3V(B-CASE)1 C107 15 16DIODE SWITCHINGSDS28361 D102 17DIODE SWITCHINGSDS28381 D103 18DIODE SWITCHINGSDS70001 D101 19DIODE ZENER15V 1/2W3 ZD 101 102 103 20 21CHIP BEAD1K AT 100MHz2 BD 101 102 22VARISTOR14V5 V101 102 103 104 105 23 24RESISTOR1.5K ΩJ1 R129 25RESISTOR120 ΩJ4 R113 114 115 132 26RESISTOR220 ΩJ1 R119 1 2 3 4 5 6 7 8 9 10 11 12 101 102 103 104 105 106 107 108 109 110 111 112 29RESISTOR820 ΩJ1 R127 27RESISTOR510 ΩJ12 RX 28RESISTOR100 ΩJ Note SymbolVender 12 R 1 / 2 PARTS LIST KEY PCB EPIC ProductES-9000K KEYAss'yDrawingCheckApproval TypeRFID+BLECode Rev.0Page No.ItemTypeDescriptionQ'tyRemarks 30RESISTOR1K ΩJ1 R124 31RESISTOR2.2K ΩJ1 R128 32RESISTOR4.7K ΩJ2 R121 122 33RESISTOR10K ΩJ1 R123 34RESISTOR100K ΩJ1 R126 35RESISTOR1M ΩJ2 R120 125 36RESISTOR68 ΩJ3 R116 117 118 37 38INDUCTOR MLFC1NH1 L101 39INDUCTOR MLFC22NH1 L102 40INDUCTOR WIREWOUND1UH2 L103 104 41 42LED GREENPMC1608ZGAC3 LED 113 114 115 43LED REDPMC1608CRC4 LED 116 117 118 119 101 102 103 104 105 106 107 108 109 110 111 112 45 46TRANSISTOR PNPSRA2205S2 Q101 102 47IC TOUCH SENSORBS66F3501 U101 48IC LDOBL8064-331 U103 49IC RFID READERTNR-1001 U102 50IC LDOAIC1731-33GV1 U104 51 52CRYSTAL13.560MHz1 X101 53 54WIRE ASS'YYDH200-12XYBH200-11X250mm1 JH 101 55 56PCB, ES-9000K KEYFR4-GOLD, t1.6X55.5x1261 57 58 59 LED44LED WHITEPST-1608H233W-LVR5-0412 Note SymbolVender PARTS LIST KEY PCB 2 / 2 ProductES-9000K MAINAss'yDrawingCheckApproval TypeRFID+VOICE+BLE+H/ACode Rev.0Page No.ItemTypeDescriptionQ'tyRemarks 1 2 3 4 5 8 12 13 16 17 20 21 22 2CAPACITOR CERAMIC1UF2 C14 18 3CAPACITOR CERAMIC10NF1 C9 4CAPACITOR CERAMIC4.7UF1 C19 5CAPACITOR TANTAL100UF 10V (B-CASE)1 C6 6CAPACITOR TANTAL100UF 6.3V (B-CASE)3 C7 11 15 7CAPACITOR TANTAL22UF 16V (B-CASE)1 C10 8 9VARISTOR18V2 V8 9 10VARISTOR5.6V5 V2 5 6 7 10 11VARISTOR14V4 V1 3 4 11 12 13DIODE SCHOTTKYSDB05402 D1 3 14DIODE SWITCHINGSDS28382 D2 4 15DIODE ZENER6.8V 1/2W1 ZD 1 16 17THERMISTER10K AT 25deg1 TH 1 18PHOTO COUPLERSPC817M1 ISO 1 19 20IC MCUSTM8L151R81 U1 21IC LDOBL8604-332 U2 5 22IC VOICEISD-38001 U3 23IC FLASH MEMORYW25Q32JVSSIQ1 U4 24 25TRANSISTOR NPNSRC1205S3 Q2 4 6 26TRANSISTOR NPNSTD1664Y2 Q8 9 27TRANSISTOR PNPSRA2205S2 Q1 3 28TRANSISTOR PNPSTB1132Y2 Q5 7 29 1/2 PARTS LIST MAIN PCB Note SymbolVender C1CAPACITOR CERAMIC100NF13 ProductES-9000K MAINAss'yDrawingCheckApproval TypeRFID+VOICE+BLE+H/ACode Rev.0Page No.ItemTypeDescriptionQ'tyRemarks 30RESISTOR000 ΩJ1 R9 31RESISTOR120 ΩJ3 R8 10 11 32RESISTOR180 ΩJ2 R25 26 33RESISTOR1K ΩJ8 R12 13 15 16 18 19 23 27 34RESISTOR6.8K ΩF1 R4 35RESISTOR10K ΩJ3 R14 17 21 36RESISTOR100K ΩF6 R1 2 3 5 20 24 37RESISTOR470K ΩJ1 R22 38RESISTOR1M ΩJ1 R6 39 40SWITCH TACTIT-7050R-SMD2 SW 1 2 41BUZZERA12P-5E1 BZ 1 42 43WAFER RIGHT ANGLE20017WR-022 JW4 6 44WAFER RIGHT ANGLE20017WR-081 JW2 45WAFER RIGHT ANGLEYDAW200-121 JW1 46 47 CONNECTOR, 2.0mm Pitch Dual Socket 22002-4045-061 JW3 48 CONNECTOR, 2.0mm Pitch Dual Socket 22002-4045-061 JW5 49 50BATTERY TEMINALG-9F SPRING(+)2 51BATTERY TEMINALG-9F SPRING(-)2 52 53SPEAKER ASS'Y8ohm, 0.5W, A13081 SPK 1 54BLE MODULEPBM-3001 55PCB, ES-9000Kb MAINFR4-HASL, t1.6X61X63.31 56 57 PARTS LIST MAIN PCB 0 2/2 Note SymbolVender G-9KFDate.작 성검 토승 인 ES-9000KRev. G9CK-E010-EOWRITER NoLevelPart NameDescriptionFinishMakerQuantityPriceAmountRemarks PL DRAWING EX.D PRODUCT -11ES-9000K FRONT ASSY ES-9000K FRONT ASSY -1-12FRONT PCB0.00 -1-220.00 -1-320 -1-42FRONT CABINETAlDCSPRAY / BLACK1.00 -1-52FRONT HANDLEAlDC SPRAY / DARK GRAY 1.00 -1-62HANDLE COVERABSBLACK1.00 -1-72BUTTON HOUSINGABS BLACK1.00 -1-82OTP-8008-E000TOUCH PLATEACRYLSILK / EPIC1.00 -1-92OMO-8007-000ADECORATION RINGABSCr plating1.00 -1-102KEY COVERABSBLACK1.00 -1-112OMO-8012-0060HANDLE BUSHINGPOM1.00 -1-122OPR-8006-0000 HANDLE STOPPERSUS4301.00 -1-132OPR-8007-0000 STOPPER BRACKETGALVE t=1.51.00 -1-142ODI-8006-000EEM CONTACTZnDC2.00 -1-152OZA-8029-0000EMI GASKET11 x 11 x 5.0 (t)12.00 -1-162OSC-8001-000BMOUNTING SHAFTSUM24LZn plating4.00 -1-17 2ORB-8005-0000FRONT PADEPDM1.00 -1-182OSP-8008-0000HANDLE SPRINGSUS304 1.00 -1-192OSP-8009-0000STOPPER SPRINGSUS304 1.00 -1-202OSP-8010-0000HANDLE SHAFT SPRINGSUS304 1.00 -1-212OSP-8024-0000GROUND SPRINGSUS304 2.0 -1-222SNAP RING #181.00 -1-232KEY CYLINDERL=47mm1.00 -1-242SENSOR BRACKETABSBLACK1.00 -1-252OSW-201-200402SCREW PH TTB 2_42.00 -1-262OSW-401-260502SCREW BH TTB 2.6_58.00 -1-272OSW-201-300602SCREW PH TTB 3_68.00 -1-282OSW-501-300602SCREW FH TTB 3_61.00 -1-292OSW-301-300601SCREW PHW TTB 3_6washer (Ø10) Type1.00 -1-302OSW-512-300506SCREW FH M3_5 BLACK2.00 297x210mm(A4) OMO-8028-0030 5 POINT CHECK Part No EBOM FRONT ASS'Y OMO-8026-0030 OZA-8020-0000 OZA-8022-0000 A1AF-G9CKF-E010 EFP-8009-0000 ODI-8013-003C ODI-8009-005C OMO-8011-0030 OMO-8013-0030 Basic Model Bill Of Material (BOM) 결 재 MODEL1.0 MODEL CODE

RF Exposure Info

FCC ID: 2AXFW-ES-9 000K ATTACHMENT RF EXPOSURE EVULATION 1.1 Limit According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength Magnetic field Strength Power density Averaging time 1.34 - 30....................................... 824/f 2.19/f *(180/ f²) 30 30 - 300....................................... 27.5 0.073 0.2 30 300 - 1500.................................... ............... ............... f/1500 30 1500 - 100.000................................. ............... ............... 1.0 30 F = frequency in MHz * = Plane-wave equivalent power density 1.2 MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Power density at the specific separation: S = PG/(4R 2 π) Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20 cm = limit for MPE) S = (1.66 * 0.69) / (4 * 5 2 * π) S = 0.003 mW/cm 2 FCC ID: 2AXFW-ES-9 000K ATTACHMENT 1.3 MAXIMUM PERMISSIBLE EXPOSURE Prediction - Calculated under the worst-case conditions of each mode. (Measured power 2.19 dBm ± 0.5dB) 3-1. 2.4 GHz Mode Max Peak output Power at antenna input terminal 2.19 dBm Max Peak output Power at antenna input terminal 1.66 mW Prediction distance 5 mm Prediction frequency 2,442 MHz Antenna Gain(typical) -1.61 dBi Antenna Gain(numeric) 0.69 - Power density at prediction frequency( S) 0.05 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.016 mW/cm 2 SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm = Used [(max.power of channel, including tune-up torelance, mW)/(min. test separation distance, mm)] * [√f(GHz)] = [1.66 / 5 ] * [ √2.442 ] = 0.44 ≤ 3.0, for 1g SAR Thus, SAR for this device is not required.

Test Report

Ref. No.: LR500112010F 4, Songjuro236Beon-gil, Yangji-myeon, Cheoin-gu Yong-in-si, Gyeonggi-do, Korea 17159 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: Sep 23, 2020 ~ Oct 12, 2020 Test Report S/N: LR500112010F Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT Manufacturing Description : Digital Door Lock Manufacturer : EPIC SYSTEMS CO., LTD. Model name : ES-9000K Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15 Subpart C ; ANSI C63.10 - 2013 Frequency Range : 13.56 MHz Data of issue : October 05, 2020 This test report is issued under the authority of: The test was supervised by: Ja-Beom Koo, Manager Eun-Hwan Jung, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. NVLAP LAB Code.: 200723-0 2AXFW- ES-9000K EPIC SYSTEMS CO., LTD. Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 15 Ref. No.: LR500112010F TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT ------------------------------------------------------------------------------------------ 3.1 SUMMARY OF TESTS ---------------------------------------------------------------------------- 3.2 TECHNICAL CHARACTERISTICS TEST ---------------------------------------------------- 3.2.1 Radiated Emission ------------------------------------------------------------------------------- 3.2.2 Frequency Tolerance ------------------------------------------------------------------------------ 3.2.3 20dB Bandwidth ------------------------------------------------------------------------------ 3.2.4 AC Conducted Emissions --------------------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 11 12 14 15 Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 15 Ref. No.: LR500112010F 1. General information 1- 1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 17159 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1- 2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2021-09-30 ECT accredited Lab. RRA KOREA KR0049 - EMC accredited Lab. FCC U.S.A 649054 2021-04-11 FCC CAB VCCI JAPAN C-4948, 2023-09-10 VCCI registration VCCI JAPAN T-2416, 2023-09-1 0 VCCI registration VCCI JAPAN R-4483(10 m), 2023-08-1 5 VCCI registration VCCI JAPAN G-847 2021-12-13 VCCI registration IC CANADA 5799A-1 2021-06-16 IC filing KOLAS KOREA NO.551 2021-08-20 KOLAS accredited Lab. Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 15 Ref. No.: LR500112010F 2. Information about test item 2-1 Client & Manufacturer Client Company name : EPIC SYSTEMS CO., LTD. Address : Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax : + 82-070-4741-1025 / + 82-031-481-8116 Manufacturer EPIC SYSTEMS CO., LTD. Address Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax + 82-070-4741-1025 / + 82-031-481-8116 2- 2 Equipment Under Test (EUT) Model name : ES-9000K Variant Model name : ES-9000K(B) Serial number : Identical prototype Date of receipt : Sep 23, 2020 EUT condition : Pre-production, not damaged Antenna type : Pattern Antenna Frequency Range : 13.56 MHz Type of Modulation : FSK Power Source : DC 6 V 2- 3 Tested frequency LOW MID HIGH Frequency (MHz) BLE 13.56 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer - - - - Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 15 Ref. No.: LR500112010F 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Test Condition Status (note 1) 15.209 15.225(a)(b)(c)(d) Radiated Emission Radiated C 15.225(e) Frequency Tolerance C 15.215(c) 20dB Bandwidth C 15.207 AC Conducted Emissions Conducted N/A 15.203 Antenna requirement - C N/A : This product is battery-enabled and excludes the test. The above equipment was tested by LTA Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. The tests were performed according to the method of measurements prescribed in KDB No.558074.  Antenna Requirement EPIC SYSTEMS CO., LTD. FCC ID: 2AXFW-ES-9000K unit complies with the requirement of §15.203. The antenna type is FPCB Antenna Copyright ○ c 2020, LTA Co., Ltd. Page 5 of 15 Ref. No.: LR500112010F 3.2 Technical Characteristics Test 3.2.1 Radiated Spurious Emissions Procedure: Radiated emissions from 30 MHz to 25 GHz were measured according to the methods defines in ANSI C63.10-2013. The EUT is a placed on as turn table. For emissions testing at or below 1 GHz, the table height shall be 0.8 m above the reference ground plane. For emission measurements above 1 GHz, the table height shall be 1.5 m. The turn table shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3m away from the r…
