2AXFW-ES-FF730GDigital Door Lock

EPIC SYSTEMS CO., LTD.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 15, 2020
Application Purpose: Original Equipment
Date of Application: Nov 15, 2020
Equipment Note: Digital Door Lock
Frequency Range: 13.56000000 - 13.56000000
Company: EPIC SYSTEMS CO., LTD.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

User Pin Number Registration Please perform while door is open Default Pin Number is [1, 2, 3, 4]. Don’t forget your Pin Number . If you forgot your Pin Number, New registration of Pin Number, RFID Card, Fingerprint, Guest Pin Number and Remote Control is not possible. 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [1] button. 4. Enter 4~12 digits New User Pin Number and press the [#] button. 5. Re-Enter the New User Pin Number and press the [Registration] button to complete the process. Only 1 user Pin Number can be saved. When error occur during registration [2] will be lighted together with an error sound. During each process, when [Registration] button is pressed, the registration process will end. When the registration process has completed, a completion sound will be heard. Note Product Line-Up EPIC product lineup. Check main features of each product carefully. Note Registration Deletion The number pad lighting is as follows, during registration and deletion, the numbers that are lighted when the number pad is touched are as follows, products containing each function will all be lighted. [1] Pin Number Registration & Deletion [2] RFID Card Registration & Deletion [3] Fingerprint Registration & Deletion [4] Guest Pin Number Registration & Deletion [5] Remote Control Registration & Deletion [0] User Registered Information & Settings Reset This is a unified manual of EPIC products. Products features may change for improvement purposes. Contents of this manual may be modified without prior notice. ES-100D ES-S100D ES-300D ES-500D ES-500H ES-700G ES-F300D ES-F500D ES-F500H ES-F500HK ES-F700G ES-FF730G ES-7000K ES-9000K ES-F9000K EF-P8800K MODELLIGHTINGFUNCTION Pin Number Pin Number + RFID Card Pin Number + RFID Card Pin Number + RFID Card Pin Number + RFID Card Pin Number + RFID Card + Fingerprint Pin Number + RFID Card + Fingerprint Pin Number + RFID Card + Fingerprint Pin Number + RFID Card + Fingerprint + Mechanical Key Pin Number + RFID Card + Mechanical Key Pin Number + RFID Card + Mechanical Key Pin Number + RFID Card + Fingerprint + Mechanical Key Pin Number + RFID Card + Fingerprint + Mechanical Key R D [1],[4],[5] [1],[4],[5],[0] R D [1],[2],[4],[5] [1],[2],[4],[5],[0] R D [1],[2],[3],[4],[5] [1],[2],[3],[4],[5],[0] R D [1],[2],[4],[5] [1],[2],[4],[5],[0] R D [1],[2],[3],[4],[5] [1],[2],[3],[4],[5],[0] RD RegistrationDeletion Pin Number + RFID Card + Fingerprint (Outer / Inner body) + Mechanical Key Pin Number + RFID Card (Outer / Inner body) + Mechanical Key Pin Number + RFID Card (Outer / Inner body) + Fingerprint + Mechanical Key User RFID Card Registration (all-at-once) 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [2] button. 4. Place the Card to be registered on the card reader. When the Card has been successfully registered, the 3 digits Card Placement Number will be displayed on the number pad and registration is complete. (If you want to register additional Card, repeat step 4.) 5. When registration of all Card is done, press the [Registration] button to complete the process. User RFID Card Registration (one-by-one) 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [2] button. 4. Enter the Card Placement Number from 001~200 on the number pad followed by the [#] button. (When the selected Card Placement Number is already in use, the error sound will be heard and [7] button will be lighted on the number pad.) 5. Place the Card to be registered on the card reader. When the Card has been successfully registered, the 3 digits Card Placement Number will be displayed on the number pad and registration is complete. (If you want to register additional Card, repeat step 4.) 6. When registration of all Card is done, press the [Registration] button to complete the process. Up to 200 cards can be registered. New registration will not delete previously registered card in the system. Note User Fingerprint Registration (all-at-once) 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [3] button. 4. Check the total number of the registered Fingerprint displayed on the number pad, then enter the Fingerprint to be registered for 4 times. When the Fingerprint has been successfully registered, the 3 digits Fingerprint Placement Number will be displayed on the number pad and registration is complete. (If you want to register additional Fingerprint, repeat step 4.) 5. When registration of all Fingerprint is done, press the [Registration] button to complete the process. Up to 100 Fingerprints can be registered. Y ou can also re-register registered Fingerprints. When error occur during registration LED [2] will be blinking. Note User Guest Pin Number Registration 1. Open the battery cover and press the [Registration] button. 2. Enter the User Pin Number followed by the [#] button. (First registration: Initial User Pin Number [1, 2, 3, 4] + [#] button.) 3. After entering the Registration Mode, press the [4] button. 4. Enter 4~12 digits User Guest Pin Number and press the [#] button. 5. Re-Enter the User Guest Pin Number and press the [Registration] button to complete the process. If you register a new guest Pin Number , the old one will be deleted. Only 1 Guest Pin Number can be saved. It will be deleted after 1 usage. Note User…

Text truncated - open the document above for the full version.

Attestation Statements

Cover Letter(s)

October 27, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Cover letter FCC ID : 2AXFW-ES-FF730G Gentlemen: Variant Model name : ES-FF730 Gold. ES-FF730 24K Gold plating The only reason for the variant model name is the color difference. Sincerely, Wanseob Lee /CEO EPIC SYSTEMS CO., LTD. EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea

Cover Letter(s)

EPIC SYSTEMS CO., LTD. Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean- ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea October 27, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re : EPIC SYSTEMS CO., LTD. FCC ID : 2AXFW-ES-FF730G Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), EPIC SYSTEMS CO., LTD. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give EPIC SYSTEMS CO., LTD. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: Exhibit Type File Name CONFIDENTIAL Schematics CONF APPENDIX 2AXFW-ES-FF730G SCH DIA.pdf Parts list CONF APPENDIX 2AXFW-ES-FF730G PL.pdf Block diagram CONF APPENDIX 2AXFW-ES-FF730G BLK DIA.pdf Operational description CONF APPENDIX 2AXFW-ES-FF730G OpDes.pdf SHORT-TERM CONFIDENTIAL External Photos SHORT-TERM CONF 2AXFW-ES-FF730G EXT Photo.pdf Internal Photos SHORT-TERM CONF 2AXFW-ES-FF730G INT Photo.pdf Te s t-Setup Photos SHORT-TERM CONF 2AXFW-ES-FF730G Test Photo.pdf User’s Manual SHORT-TERM CONF 2AXFW-ES-FF730G Manual.pdf The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Wanseob Lee/CEO EPIC SYSTEMS CO., LTD.

External Photos

FCC ID: 2AXFW-ES-FF730G Front Rear Copyright ○ c 2020, LTA Co., Ltd .Page 1 of 4 FCC ID: 2AXFW-ES-FF730G To p Bottom Copyright ○ c 2020, LTA Co., Ltd .Page 2 of 4 FCC ID: 2AXFW-ES-FF730G Left Right Copyright ○ c 2020, LTA Co., Ltd .Page 3 of 4 FCC ID: 2AXFW-ES-FF730G ANTENNA Label Position Copyright ○ c 2020, LTA Co., Ltd .Page 4 of 4

ID Label/Location Info

FCC ID: 2AXFW-ES-FF730G SAMPLE LABEL & LOCATION EUT Side position EPIC SYSTEMS CO., LTD. Model : ES-FF730G Rated Voltage : 6 V FCC ID : 2AXFW-ES-FF730G Contains FCC ID: 2AXFW-MDBT42Q Made in Korea Copyright Ⓒ 2020, LTA Co., Ltd.

Internal Photos

FCC ID: 2AXFW-ES-FF730G MainBoard–Front MainBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 5 FCC ID: 2AXFW-ES-FF730G SubBoard–Front SubBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 5 FCC ID: 2AXFW-ES-FF730G SubBoard–Front SubBoard–Rear Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 5 FCC ID: 2AXFW-ES-FF730G Module–Front Module –Rear Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 5 FCC ID: 2AXFW-ES-FF730G Total internal Copyright ○ c 2020, LTA Co., Ltd. Page 5 of 5

RF Exposure Info

FCC ID: 2AXFW-ES-FF730G ATTACHMENT RF EXPOSURE EVULATION 1.1 Limit According to §1.1310 and §2.1091 RF exposure is calculated. (B) Limits for General Population/Uncontrolled Exposures Frequency range (MHz) Electric field Strength Magnetic field Strength Power density Averaging time 1.34 - 30....................................... 824/f 2.19/f *(180/ f²) 30 30 - 300....................................... 27.5 0.073 0.2 30 300 - 1500.................................... ............... ............... f/1500 30 1500 - 100.000................................. ............... ............... 1.0 30 F = frequency in MHz * = Plane-wave equivalent power density 1.2 MAXIMUM PERMISSIBLE EXPOSURE Prediction Prediction of MPE limit at a given distance Power density at the specific separation: S = PG/(4R 2 π) Where, S = Maximum power density (mW/cm 2 ) P = Power input to the antenna (mW) G = Numeric power gain of the antenna R = Distance to the center of the radiation of the antenna (20 cm = limit for MPE) S = (6.67 * 0.32) / (4 * 5 2 * π) S = 0.07 mW/cm 2 FCC ID: 2AXFW-ES-FF730G ATTACHMENT 1.3 MAXIMUM PERMISSIBLE EXPOSURE Prediction - Calculated under the worst-case conditions of each mode. (Measured power 2.19 dBm ± 0.5dB) 3-1. 2.4 GHz Mode Max Peak output Power at antenna input terminal 2.19 dBm Max Peak output Power at antenna input terminal 1.66 mW Prediction distance 5 mm Prediction frequency 2,442 MHz Antenna Gain(typical) -1.61 dBi Antenna Gain(numeric) 0.69 - Power density at prediction frequency( S) 0.05 mW/cm 2 MPE limit for uncontrolled exposure at prediction frequency 0.016 mW/cm 2 SAR Test exclusion thresholds for 100MHz to 6GHz at test separation distance ≤ 50 mm = Used [(max.power of channel, including tune-up torelance, mW)/(min. test separation distance, mm)] * [√f(GHz)] = [1.66 / 5 ] * [ √2.442 ] = 0.44 ≤ 3.0, for 1g SAR Thus, SAR for this device is not required.

Test Report

Ref. No.: LR500112010T 4, Songjuro236Beon-gil, Yangji-myeon, Cheoin-gu Yong-in-si, Gyeonggi-do, Korea 17159 Tel: +82-31-323-6008 Fax: +82-31-323-6010 http://www.ltalab.com Dates of Tests: Oct 15, 2020 ~ Oct 27, 2020 Test Report S/N: LR500112010T Test Site : LTA CO., LTD. CERTIFICATION OF COMPLIANCE FCC ID. APPLICANT Manufacturing Description : Digital Door Lock Manufacturer : EPIC SYSTEMS CO., LTD. Model name : ES-FF730G Test Device Serial No.: : Identical prototype Rule Part(s) : FCC Part 15 Subpart C ; ANSI C63.10 - 2013 Frequency Range : 13.56 MHz Data of issue : October 28, 2020 This test report is issued under the authority of: The test was supervised by: Ja-Beom Koo, Manager Eun-Hwan Jung, Test Engineer This test result only responds to the tested sample. It is not allowed to copy this report even partly without the allowance of the test laboratory. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. NVLAP LAB Code.: 200723-0 2AXFW-ES-FF730G EPIC SYSTEMS CO., LTD. Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 15 Ref. No.: LR500112010T TABLE OF CONTENTS 1. GENERAL INFORMATION -------------------------------------------------------------------------- 2. INFORMATION ABOUT TEST ITEM ------------------------------------------------------------- 3. TEST REPORT ------------------------------------------------------------------------------------------ 3.1 SUMMARY OF TESTS ---------------------------------------------------------------------------- 3.2 TECHNICAL CHARACTERISTICS TEST ---------------------------------------------------- 3.2.1 Radiated Emission ------------------------------------------------------------------------------- 3.2.2 Frequency Tolerance ------------------------------------------------------------------------------ 3.2.3 20dB Bandwidth ------------------------------------------------------------------------------ 3.2.4 AC Conducted Emissions --------------------------------------------------------------------------- APPENDIX APPENDIX TEST EQUIPMENT USED FOR TESTS -------------------------------------------- 3 4 5 5 6 6 11 12 14 15 Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 15 Ref. No.: LR500112010T 1. General information 1- 1 Test Performed Company name : LTA Co., Ltd. Address : 243, Jubug-ri,Yangji-Myeon,Youngin-Si, Kyunggi-Do, Korea. 17159 Web site : http://www.ltalab.com E-mail : [email protected] Telephone : +82-31-323-6008 Facsimile +82-31-323-6010 Quality control in the testing laboratory is implemented as per ISO/IEC 17025 which is the “General requirements for the competents of calibration and testing laboratory”. 1- 2 Accredited agencies LTA Co., Ltd. is approved to perform EMC testing by the following agencies: Agency Country Accreditation No. Validity Reference NVLAP U.S.A 200723-0 2021-09-30 ECT accredited Lab. RRA KOREA KR0049 - EMC accredited Lab. FCC U.S.A 649054 2021-04-11 FCC CAB VCCI JAPAN C-4948, 2023-09-10 VCCI registration VCCI JAPAN T-2416, 2023-09-1 0 VCCI registration VCCI JAPAN R-4483(10 m), 2023-08-1 5 VCCI registration VCCI JAPAN G-847 2021-12-13 VCCI registration IC CANADA 5799A-1 2021-06-16 IC filing KOLAS KOREA NO.551 2021-08-20 KOLAS accredited Lab. Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 15 Ref. No.: LR500112010T 2. Information about test item 2-1 Client & Manufacturer Client Company name : EPIC SYSTEMS CO., LTD. Address : Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax : + 82-070-4741-1025 / + 82-031-481-8116 Manufacturer EPIC SYSTEMS CO., LTD. Address Technology Development Center RM. 406, Gyeonggi Technopark, 705, Haean-ro, Sangnok-gu, Ansan-si, Gyeonggi-do, Republic Of Korea Tel / Fax + 82-070-4741-1025 / + 82-031-481-8116 2- 2 Equipment Under Test (EUT) Model name : ES-FF730G Variant Model name : ES-FF730 Gold. ES-FF730 24K Gold plating Serial number : Identical prototype Date of receipt : Oct 13, 2020 EUT condition : Pre-production, not damaged Antenna type : Pattern Antenna Frequency Range : 13.56 MHz Type of Modulation : FSK Power Source : DC 6 V 2- 3 Tested frequency LOW MID HIGH Frequency (MHz) BLE 13.56 2-4 Ancillary Equipment Equipment Model No. Serial No. Manufacturer - - - - Copyright ○ c 2020, LTA Co., Ltd. Page 4 of 15 Ref. No.: LR500112010T 3. Test Report 3.1 Summary of tests FCC Part Section(s) Parameter Test Condition Status (note 1) 15.209 15.225(a)(b)(c)(d) Radiated Emission Radiated C 15.225(e) Frequency Tolerance C 15.215(c) 20dB Bandwidth C 15.207 AC Conducted Emissions Conducted N/A 15.203 Antenna requirement - C N/A : This product is battery-enabled and excludes the test. The above equipment was tested by LTA Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. The tests were performed according to the method of measurements prescribed in KDB No.558074.  Antenna Requirement EPIC SYSTEMS CO., LTD. FCC ID: 2AXFW-ES-FF730G unit complies with the requirement of §15.203. The antenna type is FPCB Antenna Copyright ○ c 2020, LTA Co., Ltd. Page 5 of 15 Ref. No.: LR500112010T 3.2 Technical Characteristics Test 3.2.1 Radiated Spurious Emissions Procedure: Radiated emissions from 30 MHz to 25 GHz were measured according to the methods defines in ANSI C63.10-2013. The EUT is a placed on as turn table. For emissions testing at or below 1 GHz, the table height shall be 0.8 m above the reference ground plane. For emission measurements above 1 GHz, the table height shall be 1.5 m. The turn table shall rotate 360 degrees to determine the position of maximum emission leve…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID: 2AXFW-ES-FF730G Radiate Emission Copyright ○ c 2020, LTA Co., Ltd. Page 1 of 3 FCC ID: 2AXFW-ES-FF730G Copyright ○ c 2020, LTA Co., Ltd. Page 2 of 3 FCC ID: 2AXFW-ES-FF730G Copyright ○ c 2020, LTA Co., Ltd. Page 3 of 3
