2AYYSNSAWCB1Magnetic Charging Cable

FrontBack PACKAGE CONTENTS • Magnetic charging cable • Cable management bumper • Quick Setup Guide COMPATIBILITY Apple® Watch Series 1, 2, 3, 4, and 5 FEATURES The silicone cable management bumper stays in place even if it is bumped. Note: Your magnetic charging cable is slightly larger than the original Apple® Charging Cable for an Apple® Watch magnetic charging cable. QUICK SETUP GUIDE Magnetic Charging Cable WRAPPING THE CABLE 1 Wind the cord around the cable management bumper until the end with the USB connector is sticking out about an inch. Note: Make sure that you wrap it tightly. Before using your new product, please read these instructions to prevent any damage. 2 Flip the cable management bumper over , then insert the USB connector into the notch in the back of the bumper. Cable management bumper Magnetic charger Top view USB connector Back viewSide view Notch USB connector USING YOUR MAGNETIC CHARGING CABLE 1 Pull out the USB connector from the back of the cable management bumper and unwind the cord. 2 Plug the USB connector into your charging source (not included), then set your Apple watch on top of the charger. SPECIFICATIONS • Dimensions (H × D): .7 in. × 2.7 in. (1.8 cm × 6.9 cm) • Cable length: 4 ft. (121.9 cm) LEGAL NOTICE FCC information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer ence, and (2) this device must accept any interfer ence received, including in terfer ence that may cause undesired operation. FCC Caution: compliance could void the user's authority to operate the equipment. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer ence in a residential installation. This equipment generates, uses and can radiate radio fr equency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer ence to radio communications. However , there is no guarantee that interfer ence will not occur in a particular installation. If this equipment does cause harmful interfer ence to radio or and on, the user is encouraged to try to correct the interfer ence by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver . which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontr olled environment. RSS-Gen Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interfer ence. 2. This device must accept any interfer ence, including interfer ence that may cause undesired operation of the device. Ce dispositif contient des émetteurs exonérés de permis(s)/récepteurs)s qui sont conformes aux RSS (s) exemptés de licence du Canada. L’opération est soumise aux deux conditions suivantes : 1. Cet appareil peut ne pas causer d’in terfér ences. 2. Ce dispositif doit accepter toute interfér ence, y compris les interfér ences qui peuvent provoquer un fonctionnement indésirable de l’appareil. This equipment complies with Innovation, Science and Economic Development Canada’s radiation exposure limits set forth for an uncontr olled environment. Cet équipement est conforme aux limites d’exposition aux r ayonnements de Développement économique Canada pour l’innovation, les sciences et le développement économique établies dans un environnement incontr ôlé. " Visit www.insigniaproducts .c om for details. CONTACT INSIGNIA: 1-877-467-4289 (U.S. and Canada) www.insigniaproducts .c om Distributed by Best Buy Purchasing, LLC. ©2021 Best Buy. All rights reserved. CONTENU DE L'EMBALLAGE • Câble de charge magnétique • Dispositif de rangement du câble • Guide d’installation rapide COMPATIBILITÉ Apple MD Watch Série 1, 2, 3, 4 et 5 CARACTÉRISTIQUES Le dispositif en silicone de rangement du câble reste en place même s'il est heurté. Remarque : L e câble magnétique de charge est légèrement plus large que le câble de charge original d'Apple MD et peut ne pas s'adapter à toutes les stations de charge conçues pour un câble de l'Apple MD Watch. GUIDE D’INSTALLATION RAPIDE Câble de charge magnétique ENROULEMENT DU CÂBLE 1 Enrouler le câble autour du dispositif de rangement du câble jusqu'à ce que l' extr émité avec le connecteur USB dépasse d'environ un pouce. Remarque : S'assurer de l'enrouler fermement. Avant l’utilisation de ce produit neuf, lire ces 2 Retourner le dispositif de rangement du câble et insérer le connecteur USB dans l' encoche située à l'arrière du dispositif. Dispositif de rangement du câble Chargeur magnétique Partie supérieure Connecteur USB Panneau arrièreVue latérale Encoche Connecteur USB UTILISATION DU CÂBLE DE CHARGE MAGNÉTIQUE 1 Tir er le connecteur USB de l'arrière du dispositif de rangement du câble et dérouler le câble. 2 Brancher le connecteur USB dans la source de charge (non incluse), puis placer l'Apple Watch sur le dessus du chargeur. SPÉCIFICATIONS • Dimensions (H × P) : 1,8 x 6,9 cm (0,7 po × 2,7 po) • Longueur du câble : 121,9 cm (4 pi) AVIS JURIDIQUES Information de la FCC Cet appareil est conforme à l’article 15 du règlement de la FCC. Operation is subject to the following two conditions: (1) cet appareil ne doit pas provoquer d’interférences préjudiciables, et (2) il doit accepter toute interférence reçue, y compris celles risquant d’engendrer un fonctionnement indésirable. Avertissement FCC : approuvés par les responsables des normes pourraient rendre nul le droit de l’utilisateur d’utiliser cet équipement. Déclaration de la FCC : Cet équipement a été t…

Text truncated - open the document above for the full version.

LEGAL NOTICE FCC information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer ence, and (2) this device must accept any interfer ence received, including in terfer ence that may cause undesired operation. FCC Caution: compliance could void the user's authority to operate the equipment. FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer ence in a residential installation. This equipment generates, uses and can radiate radio fr equency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer ence to radio communications. However , there is no guarantee that interfer ence will not occur in a particular installation. If this equipment does cause harmful interfer ence to radio or and on, the user is encouraged to try to correct the interfer ence by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver . which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontr olled environment. RSS-Gen Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interfer ence. 2. This device must accept any interfer ence, including interfer ence that may cause undesired operation of the device. Ce dispositif contient des émetteurs exonérés de permis(s)/récepteurs)s qui sont conformes aux RSS (s) exemptés de licence du Canada. L’opération est soumise aux deux conditions suivantes : 1. Cet appareil peut ne pas causer d’in terfér ences. 2. Ce dispositif doit accepter toute interfér ence, y compris les interfér ences qui peuvent provoquer un fonctionnement indésirable de l’appareil. This equipment complies with Innovation, Science and Economic Development Canada’s radiation exposure limits set forth for an uncontr olled environment. Cet équipement est conforme aux limites d’exposition aux r ayonnements de Développement économique Canada pour l’innovation, les sciences et le développement économique établies dans un environnement incontr ôlé. " Visit www.insigniaproducts .c om for details. CONTACT INSIGNIA: 1-877-467-4289 (U.S. and Canada) www.insigniaproducts .c om Distributed by Best Buy Purchasing, LLC. ©2021 Best Buy. All rights reserved. EN SP FR AVIS JURIDIQUES Information de la FCC Cet appareil est conforme à l’article 15 du règlement de la FCC. Operation is subject to the following two conditions: (1) cet appareil ne doit pas provoquer d’interférences préjudiciables, et (2) il doit accepter toute interférence reçue, y compris celles risquant d’engendrer un fonctionnement indésirable. Avertissement FCC : approuvés par les responsables des normes pourraient rendre nul le droit de l’utilisateur d’utiliser cet équipement. Déclaration de la FCC : Cet équipement a été testé et déclaré conforme aux limitations prévues dans Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. conforme aux CNR d’Innovation, Sciences et Développement économique This equipment complies with Innovation, Science and Economic Development Canada’s radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme aux limites d’exposition aux rayonnements de Développement économique Canada pour l’innovation, les sciences et le développement économique établies dans un environnement incontrôlé. GARANTIE LIMITÉE D’UN AN Aller sur le site www.insigniaproducts .c om pour plus de détails. POUR CONTACTER INSIGNIA : 1-877-467-4289 (É.-U. et Canada) www.insigniaproducts .c om Distribué par Best Buy Purchasing, LLC. © 2021 Best Buy. Tous droits réservés. AVISOS LEGALES Información de la FCC Este dispositivo satisface la parte 15 del reglamento FCC. Su utilización está sujeta a las siguientes dos condiciones: (1) este dispositivo no puede causar interfer encia dañina, y (2) este dispositivo debe aceptar cualquier in terfer encia recibida incluyendo interfer encias que puedan causar una operación no deseada. Advertencia de la FCC: la parte responsable por el cumplimiento puede anular la autoridad del usuario para operar el equipo. Declaración de la FCC: Este dispositivo ha sido sometido a prueba y se ha determinado que digital de Clase B, de acuerdo con la Parte 15 del reglamento FCC. Estos límites están diseñados para proporcionar una protección razonable contr a interfer encias dañinas en un ambiente residencial. Este dispositivo genera, utiliza y puede irradiar energía de radiofrecuencia y, si no es instalado y utilizado de acuerdo a las instrucciones, puede causar du règlement de la FCC. Ces limites ont été établies pour fournir une protection raisonnable contre les interférences préjudiciables lors d’une radio et s’il n’est pas installé et utilisé conformément aux instructions en vigueur, il peut provoquer des interférences préjudiciables aux communications radio. Cependant, il n'est pas possible de garantir qu’aucune interférence ne se produira pour une installation particulière. Si cet équipement produit des interférences préjudiciables lors de réceptions radio ou télévisées, qui peuvent être détect ées en éteignant puis en rallumant l’appareil, essayer de corriger l’interférence au moyen de l’une ou de plusieurs des mesures suivant…

Text truncated - open the document above for the full version.

Date: 2020-12-1 1 TUY Rheinland Group 762 Park Avenue Youngsville, NC 27596 To Whom It May Concern: Authority to Act as A�ent I oint TUV Rheinland (Shenzhen) Co., Ltd. to act app as our agent m the preparation of this app � ication for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also ce巾fy that each unit manufactured, imported or marketed, as defined in the FCC or Industry Canada's regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by TUY Rheinland Group, still resides with Luxshare Precision Industry Co., Ltd. / Fl9or 2, Block A Sanvo New Industrial Area We t Hao i Communit I Sha"in Subdistrict ffice Bao'an District Shenzhen P.R. China For TCB applications, We certify that we are not subject to denial offederal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 12 months By Title On behalf of QF094234 趴＼ 灼 (Signature) Product Design Telephone Engineer Luxshare Precision Industry Co., Ltd (Company Name) Page 1 of 1 Bin Lin (Print Name) 15197269372 Revision 0

Difference Declaration FCC US Model No.: NS-AWCB1, NS-AWCB1W, NS-AWCB4CM, NS- AWCPLG, NS-AWCxxxxxxxxxx,DX-AWCxxxxxxxxxx, MD-AWCxxxxxxxxxx IC Canada Model No.: NS-AWCB1-C, NS-AWCB1W-C, NS-AWCB4CM-C, NS-AWCPLG-C, NS-AWCxxxxxxxxxx, DX- AWCxxxxxxxxxx, MD-AWCxxxxxxxxxx (x can be A-Z, a-z, 0-9, - or blank) To whom it may concern, We, Luxshare Precision Industry Co., Ltd. would like to declare above models are identical in electrical circuit design and PCB layout.The only difference are model number, colour and cable length: Sincerely yours, Applicant:Luxshare Precision Industry Co., Ltd. Address: Floor 2, Block A, Sanyo New Industrial Area, West Haoyi Community, Shajing Subdistrict Office, Bao'an District, Shenzhen, P. R. China Signature: Name and title:Bin Lin / Product Design Engineer Email:[email protected] Tel.:15197269372

Wireless Charging Adapter NS-AWCPLG NS-AWCPLG-C F C C I D : 2 A Y Y S N S A W C B 1 I C : 2 7 0 8 3 - N A A W C B 1 C Wireless Charging Cable NS-AWCB6W NS-AWCB6W-C F C C I D : 2 A Y Y S N S A W C B 1 I C : 2 7 0 8 3 - N A A W C B 1 C Wireless Charging Cable NS-AWCB1 NS-AWCB1-C F C C I D : 2 A Y Y S N S A W C B 1 I C : 2 7 0 8 3 - N A A W C B 1 C Wireless Charging Cable NS-AWCB1W NS-AWCB1W-C F C C I D : 2 A Y Y S N S A W C B 1 I C : 2 7 0 8 3 - N A A W C B 1 C Wireless Charging Cable NS-AWCB4CM NS-AWCB4CM-C F C C I D : 2 A Y Y S N S A W C B 1 I C : 2 7 0 8 3 - N A A W C B 1 C

Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21XHCT 001 Seite 27 von 29 Page 27 of 29 6Safety Human Exposure 6.1Radio Frequency Exposure Compliance 6.1.1Electromagnetic Fields RESULT:Pass Test Specification Test standard: CFR47 FCC Part 2: Subpart J Section 1.1310 FCC CFR 47 Part 1(1.1310) KDB 680106 D01 v03 According to the table 1 of FCC Part 2.1310, the reference limit as below: Test Setup: Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21XHCT 001 Seite 28 von 29 Page 28 of 29 Test Result: Table: H-Field Strength at 15 cm from the edges surrounding the EUT and 20cm from the top surface of the EUT Measured H-Field Strength Values (A/m) EUT Test Mode Test Position Top Test Position front Test Position rear Test Position left Test Position right 50% Limit (A/m) Limit (A/m)Result 10% Battery Level 0.1830.1820.1820.1840.1820.8151.63Pass 50% Battery Level 0.1710.1750.1650.1760.1760.8151.63Pass 90% Battery Level 0.1520.1650.1460.1690.1690.8151.63Pass

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN21XHCT 001 Auftrags-Nr.: Order no.: 168307761 Seite 1 von 29 Page 1 of 29 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2021-03-01 Auftraggeber: Client: Luxshare Precision Industry Co., Ltd. Floor 2, Block A, Sanyo New Industrial Area, West Haoyi Community, Shajing Subdistrict Office, Bao'an District, Shenzhen, P. R. China Prüfgegenstand: Test item: Magnetic Charging Cable Bezeichnung / Typ-Nr.: Identification / Type no.: NS-AWCB1, NS-AWCB1W, NS-AWCB4CM, NS-AWCPLG, NS-AWCxxxxxxxxxx,DX- AWCxxxxxxxxxx, MD-AWCxxxxxxxxxx(x can be A-Z, a-z, 0-9, - or blank) (Trademark: INSIGNIA) Auftrags-Inhalt: Order content: Type test Prüfgrundlage: Test specification: CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 CFR47 FCC Part 15: Subpart C Section 15.215 CFR47 FCC Part 2: Subpart J Section 1.1310 Wareneingangsdatum: Date of sample receipt: 2021-03-01 Refer to photos document Prüfmuster-Nr.: Test sample no.: A003005501-001 to 006 Prüfzeitraum: Testing period: 2021-03-02 – 2021-03-15 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Alex Lan genehmigt von: authorized by: X Signed by: Sam Lin Datum: Date: 2021-06-01 Ausstellungsdatum: Issue date: 2021-06-01 Stellung / Position Senior Project Engineer Stellung / Position Department Manager Sonstiges / Other: FCC ID: 2AYYSNSAWCB1 Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged: * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhalt P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specifications(s) F(ail) = failed a.m. test specifications(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be V05 duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21XHCT 001 Seite 2 von 29 Page 2 of 29 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 20DB BANDWIDTH RESULT: Pass 5.1.3 RADIATED SPURIOUS EMISSION RESULT: Pass 5.1.4 CONDUCTED EMISSIONS RESULT: Pass 5.1.5 RADIATED EMISSION RESULT: Pass 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No. CN21XHCT 001 Seite 3 von 29 Page 3 of 29 Contents 1 GENERAL REMARKS ........................................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................................ 4 2 TEST SITES ........................................................................................................................................ 5 2.1 TEST FACILITIES ................................................................................................................................. 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS................................................................................. 5 2.3 TRACEABILITY .................................................................................................................................... 7 2.4 CALIBRATION ..................................................................................................................................... 7 2.5 MEASUREMENT UNCERTAINTY............................................................................................................. 7 2.6 LOCATION OF ORIGINAL DATA ............................................................................................................. 7 2.7 STATUS OF FACILITY USED FOR TESTING ............................................................................................. 7 3 GENERAL PRODUCT INFORMATION ...................................................................................................... 8 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................................................. 8 3.2 RATINGS AND SYSTEM DETAILS .......................................................................................................... 8 3.3 INDEPENDENT OPERATION MODES ...................................................................................................... 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ......................................................................... 9 3.5 SUBMITTED DOCUMENTS..................................................................................................................... 9 4 TEST SET-UP AND OPERATION MODES ..............................................................................................10 4.1 PRINCIPLE OF CONFIGURATION SELECTION .......................................................................................10 4.2 TEST OPERATION AND TEST SOFTWARE ............................................................................................10 4.3…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A CN21XHCT 001 Page 1 of 4 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP.......................................................................................................1 PHOTOGRAPH 1: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 9KHZ - 30MHZ.......................................................................2 PHOTOGRAPH 2: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, 30MHZ - 1GHZ......................................................................2 PHOTOGRAPH 3: SET-UP PHOTO FOR CONDUCTED EMISSION.........................................................................................................3 PHOTOGRAPH 4: SET-UP PHOTO FOR RADIATED EMISSION.............................................................................................................3 PHOTOGRAPH 4: SET-UP PHOTO FOR RF EXPOSURE......................................................................................................................4 Prüfbericht - Produkte Test Report - Products Appendix A CN21XHCT 001 Page 2 of 4 Photograph 1: Set-up photo for Radiated Spurious Emission, 9KHz - 30MHz Photograph 2: Set-up photo for Radiated Spurious Emission, 30MHz - 1GHz Prüfbericht - Produkte Test Report - Products Appendix A CN21XHCT 001 Page 3 of 4 Photograph 3: Set-up photo for Conducted Emission Photograph 4: Set-up photo for Radiated Emission Prüfbericht - Produkte Test Report - Products Appendix A CN21XHCT 001 Page 4 of 4 Photograph 5: Set-up photo for RF Exposure
