Page 1 of 80 Report No.: S22041203505001 FCC SAR EVALUATION REPORT In accordance with the requirements of FCC 47 CFR Part 2(2.1093), ANSI/IEEE C95.1-1992 and IEEE Std 1528-2013 Product Name： Tablet PC Trademark： G-TiDE Model Name： H2 Family Model： N/A Report No.： S22041203505001 FCC ID： 2AZUR-H2 Prepared for ShenZhenTelconn Technology Co.,Ltd. 41A Building 301C Room The 5th district of huaidecuigang industrial park ,fuyong town, Baoan district, Shenzhen, Guangdong,China. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao'an District, Shenzhen 518126 P.R.China. Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Page 2 of 80 Report No.: S22041203505001 TEST RESULT CERTIFICATION Applicant’s name.................. : ShenZhenTelconn Technology Co.,Ltd. Address .................................. : 41A Building 301C Room The 5th district of huaidecuigang industrial park ,fuyong town, Baoan district, Shenzhen, Guangdong,China. Manufacturer's Name ........... : ShenZhenTelconn Technology Co.,Ltd. Address .................................. : 41A Building 301C Room The 5th district of huaidecuigang industrial park ,fuyong town, Baoan district, Shenzhen, Guangdong,China. Product description Product name ......................... : Tablet PC Trademark ............................ : G-TiDE Model Name ......................... : H2 Family Model .......................... : N/A Standards.............................. : FCC 47 CFR Part 2(2.1093) ANSI/IEEE C95.1-1992 IEEE Std 1528-2013 Published RF exposure KDB procedures This device described above has been tested by Shenzhen NTEK. In accordance with the measurement methods and procedures specified in IEEE Std 1528-2013 and KDB 865664 D01. Testing has shown that this device is capable of compliance with localized specific absorption rate (SAR) specified in FCC 47 CFR Part 2(2.1093) and ANSI/IEEE C95.1-1992. The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. This report shall not be reproduced except in full, without the written approval of Shenzhen NTEK, this document may be altered or revised by Shenzhen NTEK, personal only, and shall be noted in the revision of the document. Date of Test Date (s) of performance of tests............. : May 08, 2022 ~ May 13, 2022 Date of Issue ......................................... : May 17, 2022 Test Result ............................................. : Pass Prepared By (Test Engineer) : (Jacob Chen) Approved By (Lab Manager) : (Alex Li) Page 3 of 80 Report No.: S22041203505001 ※ ※ Revision History ※ ※ REV. DESCRIPTION ISSUED DATE REMARK Rev.1.0 Initial Test Report Release May 17, 2022 Jacob Chen Page 4 of 80 Report No.: S22041203505001 TABLE OF CONTENTS 1. General Information .......................................................................................... 6 1.1. RF exposure limits .................................................................................. 6 1.2. Statement of Compliance ....................................................................... 7 1.3. EUT Description ..................................................................................... 7 1.4. Test specification(s) ................................................................................ 8 1.5. Ambient Condition ................................................................................. 8 2. SAR Measurement System ................................................................................. 9 2.1. SATIMO SAR Measurement Set-up Diagram ........................................... 9 2.2. Robot ................................................................................................... 10 2.3. E-Field Probe ........................................................................................ 11 2.3.1. E-Field Probe Calibration ................................................................ 11 2.4. SAM phantoms .................................................................................... 12 2.4.1. Technical Data ................................................................................ 13 2.5. Device Holder ...................................................................................... 14 2.6. Test Equipment List .............................................................................. 15 3. SAR Measurement Procedures ........................................................................ 17 3.1. Power Reference.................................................................................. 17 3.2. Area scan & Zoom scan ........................................................................ 17 3.3. Description of interpolation/extrapolation scheme ............................. 19 3.4. Volumetric Scan ................................................................................... 19 3.5. Power Drift .......................................................................................... 19 4. System Verification Procedure ......................................................................... 20 4.1. Tissue Verification ................................................................................ 20 4.1.1. Tissue Dielectric Parameter Check Results ..................................... 21 4.2. System Verification Procedure ............................................................. 22 4.2.1. System Verification Results ............................................................ 23 5. SAR Measurement variability and uncertainty ................................................. 24 5.1. SAR measurement variability ............................................................... 24 5.2. SAR measurement uncertainty ............................................................. 24…

Text truncated - open the document above for the full version.

Report No.: S22041203503004 Version.1.2 Page 114 of 181 5.8G 10.7 DUTY CYCLE Condition Mode Frequency (MHz) Duty Cycle (%) Correction Factor (dB) NVNT 802.11a 5745 99.7 0.01 NVNT 802.11a 5785 100 0 NVNT 802.11a 5825 100 0 NVNT 802.11ac20 5745 100 0 NVNT 802.11ac20 5785 99.1 0.04 NVNT 802.11ac20 5825 100 0 NVNT 802.11ac40 5755 99.7 0.01 NVNT 802.11ac40 5795 100 0 NVNT 802.11ax20 5745 100 0 NVNT 802.11ax20 5785 100 0 NVNT 802.11ax20 5825 100 0 NVNT 802.11ax40 5755 100 0 NVNT 802.11ax40 5795 100 0 NVNT 802.11n(HT20) 5745 99.5 0.02 NVNT 802.11n(HT20) 5785 100 0 NVNT 802.11n(HT20) 5825 100 0 NVNT 802.11n(HT40) 5755 100 0 NVNT 802.11n(HT40) 5795 99.4 0.03 Duty Cycle NVNT 802.11a 5745MHz Report No.: S22041203503004 Version.1.2 Page 115 of 181 Duty Cycle NVNT 802.11a 5785MHz Duty Cycle NVNT 802.11a 5825MHz Report No.: S22041203503004 Version.1.2 Page 116 of 181 Duty Cycle NVNT 802.11ac20 5745MHz Duty Cycle NVNT 802.11ac20 5785MHz Report No.: S22041203503004 Version.1.2 Page 117 of 181 Duty Cycle NVNT 802.11ac20 5825MHz Duty Cycle NVNT 802.11ac40 5755MHz Report No.: S22041203503004 Version.1.2 Page 118 of 181 Duty Cycle NVNT 802.11ac40 5795MHz Duty Cycle NVNT 802.11ax20 5745MHz Report No.: S22041203503004 Version.1.2 Page 119 of 181 Duty Cycle NVNT 802.11ax20 5785MHz Duty Cycle NVNT 802.11ax20 5825MHz Report No.: S22041203503004 Version.1.2 Page 120 of 181 Duty Cycle NVNT 802.11ax40 5755MHz Duty Cycle NVNT 802.11ax40 5795MHz Report No.: S22041203503004 Version.1.2 Page 121 of 181 Duty Cycle NVNT 802.11n(HT20) 5745MHz Duty Cycle NVNT 802.11n(HT20) 5785MHz Report No.: S22041203503004 Version.1.2 Page 122 of 181 Duty Cycle NVNT 802.11n(HT20) 5825MHz Duty Cycle NVNT 802.11n(HT40) 5755MHz Report No.: S22041203503004 Version.1.2 Page 123 of 181 Duty Cycle NVNT 802.11n(HT40) 5795MHz Report No.: S22041203503004 Version.1.2 Page 124 of 181 10.8 MAXIMUM CONDUCTED OUTPUT POWER Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Duty Factor (dB) Total Power (dBm) Limit (dBm) Verdict NVNT 802.11a 5745 Ant 1 9.79 0.01 9.8 30 Pass NVNT 802.11a 5785 Ant 1 10.5 0 10.5 30 Pass NVNT 802.11a 5825 Ant 1 9.83 0 9.83 30 Pass NVNT 802.11ac20 5745 Ant 1 9.87 0 9.87 30 Pass NVNT 802.11ac20 5785 Ant 1 9.75 0.04 9.79 30 Pass NVNT 802.11ac20 5825 Ant 1 8.89 0 8.89 30 Pass NVNT 802.11ac40 5755 Ant 1 10.27 0.01 10.28 30 Pass NVNT 802.11ac40 5795 Ant 1 9.34 0 9.34 30 Pass NVNT 802.11ax20 5745 Ant 1 9.76 0 9.76 30 Pass NVNT 802.11ax20 5785 Ant 1 9.62 0 9.62 30 Pass NVNT 802.11ax20 5825 Ant 1 8.83 0 8.83 30 Pass NVNT 802.11ax40 5755 Ant 1 10.22 0 10.22 30 Pass NVNT 802.11ax40 5795 Ant 1 9.59 0 9.59 30 Pass NVNT 802.11n(HT20) 5745 Ant 1 9.59 0.02 9.61 30 Pass NVNT 802.11n(HT20) 5785 Ant 1 9.82 0 9.82 30 Pass NVNT 802.11n(HT20) 5825 Ant 1 9.02 0 9.02 30 Pass NVNT 802.11n(HT40) 5755 Ant 1 9.66 0 9.66 30 Pass NVNT 802.11n(HT40) 5795 Ant 1 9.65 0.03 9.68 30 Pass Report No.: S22041203503004 Version.1.2 Page 125 of 181 10.9 -6DB EMISSION BANDWIDTH Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT 802.11a 5745 Ant 1 16.36 0.5 Pass NVNT 802.11a 5785 Ant 1 16.32 0.5 Pass NVNT 802.11a 5825 Ant 1 16.32 0.5 Pass NVNT 802.11ac20 5745 Ant 1 17.56 0.5 Pass NVNT 802.11ac20 5785 Ant 1 17.56 0.5 Pass NVNT 802.11ac20 5825 Ant 1 17.56 0.5 Pass NVNT 802.11ac40 5755 Ant 1 36.32 0.5 Pass NVNT 802.11ac40 5795 Ant 1 36.32 0.5 Pass NVNT 802.11ax20 5745 Ant 1 18.96 0.5 Pass NVNT 802.11ax20 5785 Ant 1 19.08 0.5 Pass NVNT 802.11ax20 5825 Ant 1 19.12 0.5 Pass NVNT 802.11ax40 5755 Ant 1 35.92 0.5 Pass NVNT 802.11ax40 5795 Ant 1 37.52 0.5 Pass NVNT 802.11n(HT20) 5745 Ant 1 16.64 0.5 Pass NVNT 802.11n(HT20) 5785 Ant 1 17.52 0.5 Pass NVNT 802.11n(HT20) 5825 Ant 1 16.92 0.5 Pass NVNT 802.11n(HT40) 5755 Ant 1 36.32 0.5 Pass NVNT 802.11n(HT40) 5795 Ant 1 36.32 0.5 Pass EBW NVNT 802.11a 5745MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 126 of 181 EBW NVNT 802.11a 5785MHz Ant1 EBW NVNT 802.11a 5825MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 127 of 181 EBW NVNT 802.11ac20 5745MHz Ant1 EBW NVNT 802.11ac20 5785MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 128 of 181 EBW NVNT 802.11ac20 5825MHz Ant1 EBW NVNT 802.11ac40 5755MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 129 of 181 EBW NVNT 802.11ac40 5795MHz Ant1 EBW NVNT 802.11ax20 5745MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 130 of 181 EBW NVNT 802.11ax20 5785MHz Ant1 EBW NVNT 802.11ax20 5825MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 131 of 181 EBW NVNT 802.11ax40 5755MHz Ant1 EBW NVNT 802.11ax40 5795MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 132 of 181 EBW NVNT 802.11n(HT20) 5745MHz Ant1 EBW NVNT 802.11n(HT20) 5785MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 133 of 181 EBW NVNT 802.11n(HT20) 5825MHz Ant1 EBW NVNT 802.11n(HT40) 5755MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 134 of 181 EBW NVNT 802.11n(HT40) 5795MHz Ant1 Report No.: S22041203503004 Version.1.2 Page 135 of 181 10.10 OCCUPIED CHANNEL BANDWIDTH Condition Mode Frequency (MHz) Antenna 99% OBW (MHz) -26 dB Bandwidth (MHz) Verdict NVNT 802.11a 5745 Ant 1 18.3417 22.64 Pass NVNT 802.11a 5785 Ant 1 18.5814 23.52 Pass NVNT 802.11a 5825 Ant 1 18.6214 23.52 Pass NVNT 802.11ac20 5745 Ant 1 20.1399 22.68 Pass NVNT 802.11ac20 5785 Ant 1 19.5005 24.8 Pass NVNT 802.11ac20 5825 Ant 1 20.7792 25.08 Pass NVNT 802.11ac40 5755 Ant 1 37.8821 48.16 Pass NVNT 802.11ac40 5795 Ant 1 37.8022 49.68 Pass NVNT 802.11ax20 5745 Ant 1 18.981 20.68 Pass NVNT 802.11ax20 5785 Ant 1 18.981 21.52 Pass NVNT 802.11ax20 5825 Ant 1 19.1741 24.008 Pass NVNT 802.11ax40 5755 Ant 1 37.962 45.12 Pass NVNT 802.11ax40 5795 Ant 1 38.042 45.6 Pass NVNT 802.11n(HT20) 5745 Ant 1 20.2997 25.08 Pass NVNT 802.11n(HT20) 5785 Ant 1 21.0989 24.24 Pass NVNT 802.11n(HT20) 5825 Ant 1 20.9391 24.24 Pass NVNT 802.11n(HT40) 5755 Ant 1 39.0809 47.84 Pass NVNT 802.11n(HT40) 5795 Ant 1 37.8821 48.24 Pass OBW NVNT 802.11a 5745MHz Ant1 Report No.: S22041203503004 Version.1.2 Page…

Text truncated - open the document above for the full version.

Report No.: S22041203503004 Version.1.2 Page 1 of 181 FCC RADIO TEST REPORT FCC ID: 2AZUR-H2 Product: Tablet PC Trade Mark: G-TiDE Model No.: H2 Family Model: N/A Report No.: S22041203503004 Issue Date: May 13. 2022 Prepared for ShenZhenTelconn Technology Co.,Ltd. 41A Building 301C Room The 5th district of huaidecuigang industrial park ,fuyong town, Baoan district, Shenzhen, Guangdong,China. Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S22041203503004 Version.1.2 Page 2 of 181 TEST RESULT CERTIFICATION Applicant’s name ...................... : ShenZhenTelconn Technology Co.,Ltd. Address ....................................... : 41A Building 301C Room The 5th district of huaidecuigang industrial park ,fuyong town, Baoan district, Shenzhen, Guangdong,China. Manufacturer's Name ................ : ShenZhenTelconn Technology Co.,Ltd. Address ....................................... : 41A Building 301C Room The 5th district of huaidecuigang industrial park ,fuyong town, Baoan district, Shenzhen, Guangdong,China. Product description Product name .............................. : Tablet PC Model and/or type reference ..... : H2 Family Model ............................... : N/A Standards ................................... : FCC Part15.407 Test procedure ................................. : ANSI C63.10-2013 and KDB 789033 D02 General UNII Test Procedures New Rules v02r01 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ................................................... : Date (s) of performance of tests .................... : Apr 12, 2022 ~ May 13, 2022 Date of Issue .................................................. : May 13, 2022 Test Result ...................................................... : Pass Testing Engineer : (Mary Hu) Authorized Signatory : (Alex Li) Report No.: S22041203503004 Version.1.2 Page 3 of 181 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 FACILITIES AND ACCREDITATIONS 7 1.2 MEASUREMENT UNCERTAINTY 7 1 . GENERAL INFORMATION 8 1.1 GENERAL DESCRIPTION OF EUT 8 1.2 DESCRIPTION OF TEST MODES 10 1.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 1.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 12 1.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 2 . EMC EMISSION TEST 15 2.1 CONDUCTED EMISSION MEASUREMENT 15 2.1.1 APPLICABLE STANDARD 15 2.1.2 CONFORMANCE LIMIT 15 2.1.3 TEST CONFIGURATION 15 2.1.4 TEST PROCEDURE 15 2.2 RADIATED EMISSION MEASUREMENT 20 2.2.1 APPLICABLE STANDARD 20 2.2.2 CONFORMANCE LIMIT 20 2.2.3 MEASURING INSTRUMENTS 20 2.2.4 TEST CONFIGURATION 21 2.2.5 TEST PROCEDURE 22 2.2.6 TEST RESULTS (9KHZ – 30 MHZ) 23 2.2.7 TEST RESULTS (30MHZ – 1GHZ) 24 2.2.8 TEST RESULTS (1GHZ-18GHZ) 28 2.2.10 TEST RESULTS (18GHZ-40GHZ) 30 3 . POWER SPECTRAL DENSITY TEST 35 3.1 APPLIED PROCEDURES / LIMIT 35 3.2 TEST PROCEDURE 36 3.3 DEVIATION FROM STANDARD 36 3.4 TEST SETUP 36 3.5 EUT OPERATION CONDITIONS 36 3.6 TEST RESULTS 37 4 . 26DB & 99% EMISSION BANDWIDTH 38 4.1 APPLIED PROCEDURES / LIMIT 38 4.2 TEST PROCEDURE 38 4.3 EUT OPERATION CONDITIONS 39 4.4 TEST RESULTS 39 Report No.: S22041203503004 Version.1.2 Page 4 of 181 Table of Contents Page 5 . MINIMUM 6 DB BANDWIDTH 40 5.1 APPLIED PROCEDURES / LIMIT 40 5.2 TEST PROCEDURE 40 5.3 DEVIATION FROM STANDARD 40 5.4 TEST SETUP 40 5.5 EUT OPERATION CONDITIONS 40 5.6 TEST RESULTS 41 6 . MAXIMUM CONDUCTED OUTPUT POWER 42 6.1 PPLIED PROCEDURES / LIMIT 42 6.2 TEST RESULTS 44 7 . OUT OF BAND EMISSIONS 45 7.1 APPLICABLE STANDARD 45 7.2 TEST PROCEDURE 46 7.3 DEVIATION FROM STANDARD 46 7.4 TEST SETUP 46 7.5 EUT OPERATION CONDITIONS 46 7.6 TEST RESULTS 47 8. FREQUENCY STABILITY MEASUREMENT 48 8.1 LIMIT 48 8.2 TEST PROCEDURES 48 8.3 TEST SETUP LAYOUT 48 8.4 EUT OPERATION DURING TEST 48 8.5 TEST RESULTS 49 9. ANTENNA REQUIREMENT 55 9.1 STANDARD REQUIREMENT 55 9.2 EUT ANTENNA 55 Report No.: S22041203503004 Version.1.2 Page 5 of 181 Revision History Report No. Version Description Issued Date S22041203503004 Rev.01 Initial issue of report May 13, 2022 Report No.: S22041203503004 Version.1.2 Page 6 of 181 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark 15.207 AC Power Line Conducted Emissions PASS 15.209(a), 15.407 (b)(1) 15.407 (b)(4) Spurious Radiated Emissions PASS 15.407 (a)(1) 15.407 (a)(3) 26 dB and 99% Emission Bandwidth PASS 15.407(e) Minimum 6 dB bandwidth PASS 15.407 (a)(1) 15.407 (a)(3) Maximum Conducted Output Power PASS 15.407(b)(1) 15.407(b)(4) Band Edge PASS 15.407 (a)(1) 15.407 (a)(3) Power Spectral Density PASS 15.407(b) Spurious Emissions at Antenna Terminals PASS 15.203 Antenna Requirement PASS 15.407(c) Automatically discontinue transmission PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Report No.: S22041203503004 Version.1.2 Page 7 of 181 1.1 FACILITIES AND ACCREDITATIONS FACILITIES All measurement facilities used to collect the measurement data are located at 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District Shenzhen, Guangdong, China The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.10 and CISPR Publication 22. LABORATORY ACCREDITATIONS AND LISTINGS Site Description CNAS-Lab. : The Certificate Registration Number is L5516. IC-Registration The Certificate Registration Number is 9270A. CAB identifier:CN0074 FCC- Accredited Tes…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos

Test Positions Front Side (Separation distance of 0mm) Back Side (Separation distance of 0mm) Left side (Separation distance of 0mm) Right side (Separation distance of 0mm) Top side (Separation distance of 0mm) Bottom side (Separation distance of 0mm) END
