2AZUX-L1Security Camera

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: swinway inc FRN: 0033427451 Contact Name: Karl Xie Address: 123 South 16th Avenue suite A,Brighton, Co 80601,US Telephone No: 1-866-958-6988 Email: [email protected] This letter is to confirm that the US Agent for Service of Process accepts responsibility to act as a local representative on behalf of (Shenzhen Anran Security Technology Co., Ltd). The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Applicant: Company name: Shenzhen Anran Security Technology Co., Ltd Product Description: Security Camera Grantee code: 2AZUX FCC ID: 2AZUX-L1 Contact Name: Hans Yi Address: No.290, Jihua Road, Jihua street, Longgang District, Shenzhen, No.112 Telephone No: 18826978584 Email: [email protected] The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. This Agreement is valid until (product lifetime). Date: 2.22.2023 Applicant’s Name: Hans Yi US Agent for Service of Process’s Name: Karl Xie Title: Title: Compliance Manager Signature Signature

C5266091_X24_Ed.1 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Anran Security Technology Co., Ltd Grantee code: 2AZUX FCC ID: 2AZUX-L1 Contact Name: Hans Yi Address: No.290, Jihua Road, Jihua street, Longgang District, Shenzhen, No.112 Telephone No: 18826978584 Fax No: 18826978584 Email: [email protected] i. [Shenzhen Anran Security Technology Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Anran Security Technology Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Date: 2.22.2023 Applicant’s Name: Hans Yi Title: Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Shenzhen Anran Security Technology Co., Ltd Model difference statement Product Name: Security Camera Model N o.: L1, L1 Pro, L1 Max, L2, L2 Pro, L2 Max, L3, L3 Pro, L3 Max, L5, L6, C1 We (Shenzhen Anran Security Technology Co., Ltd. No.290, Jihua Road, Jihua street, Longgang District, Shenzhen, No.112) hereby state that all the models are the same circuit and module, except the model name. Signature: Name: Hans Yi Title: Tel: 18826978584 Email: [email protected] Date: 2.3.2023

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Anran Security Technology Co., Ltd Address: No.290, Jihua Road, Jihua street, Longgang District, Shenzhen, No.112 Product Name: Security Camera Model Number: L1, L1 Pro, L1 Max, L2, L2 Pro, L2 Max, L3, L3 Pro, L3 Max, L5, L6, C1 FCC Identifier: 2AZUX-L1 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Hans Yi Date: 2/3/2023 Title: Signature of applicant:

C5266091_X10_Ed.1 1/1 Shenzhen Anran Security Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2/3/2023 Subject: Request for Confidentiality FCC ID: 2AZUX-L1 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Hans Yi Date: 2/3/2023 Title:

Page 1 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Appendix - Ext Photos Model: L1 Photo 1 Photo 2 Page 2 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 3 Photo 4 Page 3 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 5 Photo 6 Page 4 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 7 ----End of Report----

Label Size：25*15mm Location

Page 1 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: L1 Photo 1 Photo 2 Page 2 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 3 Photo 4 Page 3 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 5 Photo 6 Page 4 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 7 Photo 8 ANT Page 5 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 9 Photo 10 ----End of Report----

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi221117003-01E2 Date of issue: 2023-01-14 Applicant: Shenzhen Anran Security Technology Co., Ltd Product: Security Camera Model(s): L1, L1 Pro, L1 Max, L2, L2 Pro, L2 Max, L3, L3 Pro, L3 Max, L5, L6, C1 FCC ID: 2AZUX-L1 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 5 - Report No.: MTi221117003-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 5 - Report No.: MTi221117003-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Shenzhen Anran Security Technology Co., Ltd Address: No.290, Jihua Road, Jihua street, Longgang District, Shenzhen, No.112 Manufacturer: Shenzhen Anran Security Technology Co., Ltd Address: No.290, Jihua Road, Jihua street, Longgang District, Shenzhen, No.112 Product description Product name: Security Camera Trademark: N/A Model name: L1 Serial Model: L1 Pro, L1 Max, L2, L2 Pro, L2 Max, L3, L3 Pro, L3 Max, L5, L6, C1 Standards: N/A Test procedure: KDB 447498 D01 v06 Date of Test Date of test: 2022-12-15 ~ 2023-01-14 Test result: Pass Test Engineer : (David Lee) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) - Page 4 of 5 - Report No.: MTi221117003-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b) Limits for Maximum Permissible Exposure (MPE) MPE Calculation Method Friis transmission formula: Pd= (Pout*G)\ (4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in mW G= Numeric gain of the antenna relative to isotropic antenna Pi=3.1415926 R= distance between observation point and center of the radiator in cm(20cm) Pd the limit of MPE, 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. - Page 5 of 5 - Report No.: MTi221117003-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Measurement Result 2.4GWiFi: Operation Frequency: WIFI 802.11b/g/n HT20: 2412-2462MHz, 802.11n HT40: 2422-2452MHz, Power density limited: 1mW/ cm 2 Antenna Type: PCB Antenna; WIFI antenna gain: 2.26dBi R=20cm mW=10^(dBm/10) antenna gain Numeric=10^(dBi/10)= 10^(2.26/10)=1.68 2.4GWiFi: Channel Freq. (MHz) modulation conducted power Tune- up power Max Antenna Evaluation result at 20cm Power density Limits (dBm) (dBm) tune-up power Gain Power density(mW/cm 2 ) (mW/cm 2 ) (dBm) (mW) Numeric 2412 802.11b 17.35 17±1 18 63.096 1.68 0.02109 1 2437 17.45 17±1 18 63.096 1.68 0.02109 1 2462 16.95 17±1 18 63.096 1.68 0.02109 1 2412 802.11g 15.67 15±1 16 39.811 1.68 0.01331 1 2437 15.14 15±1 16 39.811 1.68 0.01331 1 2462 15.58 15±1 16 39.811 1.68 0.01331 1 2412 802.11n H20 15.5 15±1 16 39.811 1.68 0.01331 1 2437 14.67 15±1 16 39.811 1.68 0.01331 1 2462 14.4 15±1 16 39.811 1.68 0.01331 1 2422 802.11n H40 21.66 21±1 22 158.489 1.68 0.05297 1 2437 20.89 20±1 21 125.893 1.68 0.04208 1 2452 19.91 20±1 21 125.893 1.68 0.04208 1 Conclusion: For the max result: 0.05297≤ 1.0 SAR, No SAR is required. ----END OF REPORT----

'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP   ᢯䇔Җ $33529$/ 6+((7 ᇒᡧ਽〠 &86720(5 1$0( ޹ᆹ ӗ૱਽〠 352'8&7 1$0( * )3& ޵㖞ཙ㓯 / PP,3(; ᇒᡧᯉਧ &86720(5 31 Ո∄⭥ᆀᯉਧ <RXEL31 8%&)'$5(9 $ 00$18)$&785(5 6,*1$785( &86720(5 6,*1$785( &+(&.('%< (GG\ $33529('%<&KDQJ[LQJ/LX '$7(  'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP   00RGLILFDWLRQ+LVWRU\ 9HUVLRQ&RQWHQW5HYLVLRQ,VVXHGE\'DWH $2ULJLQDO YHUVLRQ(GG\ 'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP   &RQWHQW OWHP'HVFULSWLRQ (OHFWULFDO6SHFLILFDWLRQ 7HVW,WHPVDQG(TXLSPHQW 63DUDPHWHU (IILFLHQF\DQG*DLQ 5DGLDWLRQ3DWWHUQ 0HFKDQLFDO6SHFLILFDWLRQ 'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP    (OHFWULFDO 6SHFLILFDWLRQ 7HVW ,WHPV DQG (TXLSPHQW &KDUDFWHULVWLFV6SHFLILFDWLRQV8QLW 2XWOLQH 'LPHQVLRQV[/PP )UHTXHQF\  0+] ,PSHGDQFHŸ 5HWXUQ /RVV G% 3RODUL]DWLRQ/LQHDU 3RODUL]DWLRQ *DLQ“ G%L (IILFLHQF\!  &RQQHFWRU 7\SH0+)3OXJ 2SHUDWLQJ WHPSHUDWXUHćać 6WRUDJH 7HPSćać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˖ZZZXEXDQWFRP   63DUDPHWHU 9ROWDJH 6WDQGLQJ :DYH 5DWLR 96:5 5HWXUQ /RVV 5/ 5/  ORJ> 96:5  96:5 (IILFLHQF\DQG*DLQ )UHTXHQF\ 0+] 5HWXUQ /RVV G%    )UHTXHQF\ 0+]  (IILFLHQF\   *DLQ G%L  'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP   5DGLDWLRQ3DWWHUQ 0+= 'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP   0HFKDQLFDO6SHFLILFDWLRQ 'RQJJXDQ <RXEL (OHFWURQLFV &R/7'+DQJ]KRX <RXELJH (OHFWURQLFV &R/7'6KHQ]KHQ <RXEL (OHFWURQLFV &R/7' 5RRP %XLOGLQJ 1R5RRP %XLOGLQJ /HWRQJ 6FLHQFH 3DUN 5RRP %XLOGLQJ $;LQ]KHQJ ,QGXVWULDO 3DUN ;LQID 5RDG/LQ 9LOODJH7DQJ[LD 7RZQ1R 4LX\L 5RDG%LQMLDQJ 'LVWULFW /LX[LDQ 5RDG %DR DQ 'LVWULFW 6KHQ]KHQ 7HO:HEVLWH˖ZZZXEXDQWFRP

Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 We b : www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi221117003-01E1 Date of issue: 2023-01-31 Applicant: Shenzhen Anran Security Technology Co., Ltd Product: Security Camera Model(s): L1, L1 Pro, L1 Max, L2, L2 Pro, L2 Max, L3, L3 Pro, L3 Max, L5, L6, C1 FCC ID: 2AZUX-L1 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 63 Report No.: MTi221117003-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 63 Report No.: MTi221117003-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT .................................................................................................................................. 5 1.2 Description of test modes ............................................................................................................................. 6 1.3 Environmental conditions for testing ............................................................................................................. 7 1.4 Description of support units .......................................................................................................................... 7 2 Measurement uncertainty ............................................................................................................... 8 3 Summary of Test Result ................................................................................................................. 9 4 Test Laboratory ............................................................................................................................. 10 5 Equipment List .............................................................................................................................. 11 6 Test Result ..................................................................................................................................... 12 6.1 Antenna requirement .................................................................................................................................. 12 6.2 AC power line conducted emissions ........................................................................................................... 13 6.3 Radiated spurious emission ........................................................................................................................ 18 6.4 DTS bandwidth ........................................................................................................................................... 27 6.5 Maximum conducted output power ............................................................................................................. 28 6.6 Power spectral density ................................................................................................................................ 29 6.7 Band edge (Conducted) .............................................................................................................................. 30 6.8 Conducted spurious emissions ................................................................................................................... 31 6.9 Duty Cycle ................................................................................................................................................... 32 Appendix A: DTS Bandwidth ............................................................................................................... 33 Appendix B: Maximum conducted output power ............................................................................... 38 Appendix C: Maximum power spectral density .................................................................................. 39 Appendix D: Band edge measurements ............................................................................................. 44 Appendix E: Conducted Spurious Emission ...................................................................................... 47 Appendix F: Duty Cycle ....................................................................................................................... 59 Photographs of the Test Setup............................................................................................................ 62 Photographs of the EUT....................................................................................................................... 63 Page 4 of 63 Report No.: MTi221117003-01E1 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Shenzhen Anran Security Technology Co., Ltd Address: No.290, Jihua Road, Ji…
