2BCGV0006Wireless charger speaker

MADE IN CHINA 90mm 55mm 1. Wireless Charging Pad 2. Vol-/Previous Track 3. Play/Pause/ON/OFF 4. Light button 5. Vol +/Next Track 6. Wireless Charging LED Indicator 1 7. Charging/Buletooth LED Indicator 8. Wireless Charging LED Indicator 2 9. TYPE-C charging port Overview 1. Power On: Hold the " " button for 3 seconds to turn on the speaker. The indicator light will turn blue and you will hear a tone. 2. Pairing: Once speaker is turned on, using your mobile device, search for Bluetooth devices and select Bluetooth ID ‘256002’. It will pair automatically. 3. Power Off: Hold the " " button for more than 3 seconds to turn off the speaker. 4. Play/Pause: Tap the " " button once to pause/play music Operation Instructions Specifications: 1. Model: SL525-10W 2. Item256002 3. Wireless Output Power : 5W / 10W 4. Input: DC 5V / 2A 9V / 2A 5. Battery capacity: 3.7V/1800mAh 6.66Wh 6. Speaker output power:3W Attention: 1. Prolonged or repeated exposure to sounds in excess of 85dBA can cause hearing loss. 2. To prevent damage to the speaker, do not drop or bump. Avoid exposure to water, high temperature and high humidity. 3. Keep away from children. 4. Music volume decreasing, distorting, slowing or silencing may indicate low power level. The battery will need to charge. 5. Please do not disassemble the speaker. 6. When not in use the device will turn off automatically. Please disconnect from power source. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. FCC STATEMENT FCC ID: 2BCGV0006 Bluetooth Listing Declaration ID:D063501 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by (ShenZhen C-Star Electronic Tech. Co., Ltd.) is under license. Other trademarks and trade names are those of their respective owners. ® Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. • This device complies with Part 18 of the FCC Rules. • The interference potential of the device or system. • Maintenance of the system. • Simple measures that can be taken by the user to correct interference. • For RF lighting devices, provide an advisory statement, either on the product packaging or with other user documentation, similar to the following: This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30 MHz. 1 2 3 68 7 9 5 4 5. Next track/Vol+: Tap the " + " button once to switch to next track. Hold the " " for 3 seconds to increase music volume. 6. Previous Track/Vol-: Tap the " - " button once to return to previous track. Hold the " " for 3 seconds to decrease music volume. 7. Light: Tap the " " button to cycle between 3 brightness settings: "High," "Low," and "Off." 8. Charging Speaker: Use the USB cable included to connect the speaker to an adaptor. The LED indicator will display a solid red light. When the speaker is fully charged, the red light will turn off. 9. Wireless charging: Use the USB cable included to connect the speaker to a certified adaptor. The wireless LED indicator 1 will display a solid red light. Place a Qi enabled mobile device on top of the charging pad. The wireless LED indicator 1 will turn off, the wireless LED indicator 2 will display a solid green light. The mobile device will begin to charge automatically. - + FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. RF Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Rev1/26/2023 (NINGBOCSTARIMPRINTE-COMMERCECO.,LTD) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:06-27-2024 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID：2BCGV0006 [NINGBOCSTARIMPRINTE-COMMERCECO.,LTD](“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. Sincerely, (Applicantsignature) (FosterLi) Rev1/26/2023 (NINGBOCSTARIMPRINTE-COMMERCECO.,LTD) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:06-27-2024 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID：2BCGV0006 [NINGBOCSTARIMPRINTE-COMMERCECO.,LTD](“theapplicant”)certifiesthat,asofthedateofthe filingoftheapplication,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentity oranyofitssubsidiariesoraffiliates)asanentityproducing“covered” equipment. Sincerely, (Applicantsignature) (FosterLi)

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:06-27-2024 SUBJECT:FCCID:2BCGV0006 ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheclassB computerperipheralportionofthiscompositedevice.IunderstandthefollowingFCC requirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, NINGBOCSTARIMPRINTE-COMMERCECO.,LTD ------------------------------- （ FosterLi ）

2.911 (d)(7)USA Agent v1.2 Company name: NINGBO CSTAR IMPRINT E-COMMERCE CO., LTD. Address: B46, BUILDING B, INDUSTRIAL BLOCK, QIAOTOUHU STREET, NINGHAI COUNTY, NINGBO CITY, ZHEJIANG PROVINCE, CHINA GC: NINGBO CSTAR IMPRINT E-COMMERCE CO.,LTD Section 2.911(d)(7) USAAgent for Service of Process 2BCGV FRN: 0034122457 2.911(d)(7) USA Designated Agent for Service of Process We, [NINGBO CSTAR IMPRINT E-COMMERCE CO., LTD.] (“the applicant”) designate [PROSTOCK LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: PROSTOCK LLC Address: 10 Pines Lake Drive East Wayne, NJ.07470, USA FRN：0033411935 Contact Name: Marc Puglisi Telephone No: 973-865-8262 Email: [email protected] Applicant Company name: NINGBO CSTAR IMPRINT E-COMMERCE CO., LTD. Address: B46, BUILDING B, INDUSTRIAL BLOCK, QIAOTOUHU STREET, NINGHAI COUNTY, NINGBO CITY, ZHEJIANG PROVINCE, CHINA Contact Name: Foster Li Telephone No: +86-755-29063393 Email: [email protected] Signature: Title: General Manager Signature: Title: Compliance Manager 2.911 (d)(7)USA Agent v1.2 Date: Sep 13, 2023 Date: Sep 13, 2023 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Rev11/20/07 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2BCGV0006 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName Sincerely, FosterLi 06-27-2024

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethesame RFmodule,PCBlayout,Antenna,schematicsandcomponent.Onlydifferentonmodelnameand color. ProductionnameTrademarkFCCModelno. Wirelesscharger speaker N/A2BCGV0006256002,SL525-10W Confirmedby: FosterLi NINGBOCSTARIMPRINTE-COMMERCECO.,LTD 06-27-2024

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:06-27-2024 SUBJECT:FCCApplicationforFCCID:2BCGV0006 ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLv.atEMTEK(DONGGUAN)CO.,LTD.on ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(DONGGUAN)CO.,LTD.onourbehalfshallhave thesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Sincerely, FosterLi 06-27-2024

ReportNo.EDG2406060050E003Page1of5Ver.1.0 FCCID:2BCGV0006 ReportNo.EDG2406060050E003Page2of5Ver.1.0 ReportNo.EDG2406060050E003Page3of5Ver.1.0 ReportNo.EDG2406060050E003Page4of5Ver.1.0 ReportNo.EDG2406060050E003Page5of5Ver.1.0

3mm 14mm 14mm 37.6mm 20mm 687359687359

ReportNo.EDG2406060050E003Page1of5Ver.1.0 FCCID:2BCGV0006 ReportNo.EDG2406060050E003Page2of5Ver.1.0 ReportNo.EDG2406060050E003Page3of5Ver.1.0 ReportNo.EDG2406060050E003Page4of5Ver.1.0 BTANT ReportNo.EDG2406060050E003Page5of5Ver.1.0

ReportNo.EDG2406060050E00302RPage1of7Ver.1.0 TESTREPORT ProductName：Wirelesschargerspeaker ModelNumber：256002,SL525-10W FCCID：2BCGV0006 Preparedfor:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address:B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHU STREET,NINGHAICOUNTY,NINGBOCITY,ZHEJIANG PROVINCE Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2406060050E00302R Date(s)ofTests:Jun06,2024toJun24,2024 Dateofissue:Jun25,2024 $二维码$ ReportNo.EDG2406060050E00302RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT................................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.EDG2406060050E00302RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address: B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHUSTREET,NINGHAI COUNTY,NINGBOCITY,ZHEJIANGPROVINCE Manufacturer:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address: B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHUSTREET,NINGHAI COUNTY,NINGBOCITY,ZHEJIANGPROVINCE EUT:Wirelesschargerspeaker ModelName:256002,SL525-10W Trademark:N/A MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.247(i),§2.1093 PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRulesFCC§15.247(i),§2.1093. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest: Jun06,2024toJun24,2024 Preparedby: WarrenDeng/Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2406060050E00302RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2406060050E00302R/OriginalReport ReportNo.EDG2406060050E00302RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:Wirelesschargerspeaker ModelNumber: 256002,SL525-10W Allproductsareidenticalexceptthemodelnumberandcolor.Herewe selected256002forallthetest. Sample:1# DataRate: 1MbpsforGFSKmodulation 2Mbpsforπ/4-DQPSKmodulation 3Mbpsfor8DPSKmodulation Modulation: GFSK,π/4-DQPSK,8DPSK OperatingFrequency Range(s): 2402-2480MHz NumberofChannels: 79channels TransmitPowerMax: 1.76dBm(0.001500W) AntennaGain:-0.58dBi Rating: Input:DC5V/2A9V/2A Batterycapacity:3.7V/1800mAh6.66Wh WirelessOutputPower:5W/10W Speakeroutputpower:3W Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.EDG2406060050E00302RPage6of7Ver.1.0 3. TestRequirement SAREvaluation Accordingto447498D01V06,systemsoperatingundertheprovisionsofthissectionshallbeoperatedina mannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurementsorcomputer simulation.WhenroutineSARevaluationisnotrequired,portabletransmitterswithoutputpowergreaterthan theapplicablelowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis5mm. ReportNo.EDG2406060050E00302RPage7of7Ver.1.0 4. MeasurementResult Antennagain:-0.58dBi Transmit Frequency (MHz) Mode Measured Power (dBm) Tune upPower (dBm) Maxtuneup power (dBm) Calculation Result 1-gSAR 2402GFSK0.670±110.39023 2441GFSK0.440±110.39343 2480GFSK-0.030±110.39653 2402Π/4-DQPSK1.321±120.49133 2441Π/4-DQPSK1.061±120.49523 2480Π/4-DQPSK0.711±120.49923 24028DPSK1.682±130.61853 24418DPSK1.762±130.62353 24808DPSK1.071±120.49923 AccordingtoKDB447498D01V06,nostand-alonerequiredforBTantenna,andnosimultaneousSAR measurementisrequired. ***EndofReport***

ReportNo.EDG2406060050E00301RPage1of75Ver.1.0 $二维码$ TESTREPORT ProductName：Wirelesschargerspeaker ModelNumber：256002,SL525-10W FCCID：2BCGV0006 Preparedfor:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address:B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHU STREET,NINGHAICOUNTY,NINGBOCITY,ZHEJIANG PROVINCE Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2406060050E00301R Date(s)ofTests:Jun06,2024toJun24,2024 Dateofissue:Jun25,2024 ReportNo.EDG2406060050E00301RPage2of75Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION..................................................................................................................................................3 2EUTTECHNICALDESCRIPTION.................................................................................................................................................5 3SUMMARYOFTESTRESULT.....................................................................................................................................................6 4TESTMETHODOLOGY.................................................................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS......................................................................................................7 4.2MEASUREMENTEQUIPMENTUSED..................................................................................................................................7 4.3DESCRIPTIONOFTESTMODES..........................................................................................................................................8 5FACILITIESANDACCREDITATIONS........................................................................................................................................9 5.1FACILITIES..............................................................................................................................................................................9 5.2EQUIPMENT............................................................................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS.........................................................................................................9 6TESTSYSTEMUNCERTAINTY.................................................................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST.....................................................................................................................................11 7.1RADIOFREQUENCYTESTSETUP1.................................................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2.................................................................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP.............................................................................................................................13 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.............................................................................................14 7.5SUPPORTEQUIPMENT........................................................................................................................................................14 8FREQUENCYHOPPINGSYSTEMREQUIREMENTS...............................................................................................................15 8.1StandardApplicable.................................................................................................................................................................15 8.2EUTPseudorandomFrequencyHoppingSequence................................................................................................................15 8.3EqualHoppingFrequencyUse................................................................................................................................................16 8.4FrequencyHoppingSystem.....................................................................................................................................................16 9TESTREQUIREMENTS...............................................................................................................................................................17 9.120DB&99%BANDWIDTH.....................................................................................................................................................17 9.2CARRIERFREQUENCYSEPARATION..............................................................................................................................29 9.3NUMBEROFHOPPINGFREQUENCIES............................................................................................................................32 9.4AVERAGETIMEOFOCCUPANCY(DWELLTIME)........................................................................................................35 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER.........................................................................................................45 9.6CONDUCTEDSUPRIOUSEMISSION.................................................................................................................................51 9.7RADIATEDSPURIOUSEMISSION.....................................................................................................................................61 9.8CONDUCTEDEMISSIONTEST...........................................................................................................................................70 9.9ANTENNAAPPLICATION..........................…

Text truncated - open the document above for the full version.

ReportNo.EDG2406060050E00301RPage41of75Ver.1.0 2DH5-Ant1-Hop-PASS ReportNo.EDG2406060050E00301RPage42of75Ver.1.0 3DH1-Ant1-Hop-PASS ReportNo.EDG2406060050E00301RPage43of75Ver.1.0 3DH3-Ant1-Hop-PASS ReportNo.EDG2406060050E00301RPage44of75Ver.1.0 3DH5-Ant1-Hop-PASS ReportNo.EDG2406060050E00301RPage45of75Ver.1.0 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER 9.5.1ApplicableStandard AccordingtoFCCPart15.247(b)(1)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-247.5.4andRSS-Gen6.12 9.5.2ConformanceLimit ThemaxForfrequencyhoppingsystemsoperatinginthe2400-2483.5MHzbandemployingatleast75 non-overlappinghoppingchannels:1watt.Forallotherfrequencyhoppingsystemsinthe2400-2483.5MHzband: 0.125watts. 9.5.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.5.4TestProcedure Asanalternativetoapeakpowermeasurement,compliancewiththelimitcanbebasedonameasurementofthe maximumconductedoutputpower. Usethefollowingspectrumanalyzersettings: SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel(about8MHz) SetRBW>the20dBbandwidthoftheemissionbeingmeasured(about3MHz) SetVBW  RBW SetSweep=auto SetDetectorfunction=peak SetTrace=maxhold Allowthetracetostabilize.Usethemarker-to-peakfunctiontosetthemarkertothepeakoftheemissionto determinethepeakamplitudelevel. TestResults Temperature: 25 ̊C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Test Mode AntennaFrequency[MHz] ConductedPeak Powert[dBm] Conducted Limit[dBm] Verdict DH5Ant124020.67≤20.97PASS DH5Ant124410.44≤20.97PASS DH5Ant12480-0.03≤20.97PASS 2DH5Ant124021.32≤20.97PASS 2DH5Ant124411.06≤20.97PASS 2DH5Ant124800.71≤20.97PASS 3DH5Ant124021.68≤20.97PASS 3DH5Ant124411.76≤20.97PASS 3DH5Ant124801.07≤20.97PASS ReportNo.EDG2406060050E00301RPage46of75Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS ReportNo.EDG2406060050E00301RPage47of75Ver.1.0 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS ReportNo.EDG2406060050E00301RPage48of75Ver.1.0 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS ReportNo.EDG2406060050E00301RPage49of75Ver.1.0 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS ReportNo.EDG2406060050E00301RPage50of75Ver.1.0 3DH5-Ant1-2480-PASS ReportNo.EDG2406060050E00301RPage51of75Ver.1.0 9.6CONDUCTEDSUPRIOUSEMISSION 9.6.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-2475.5 9.6.2ConformanceLimit Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumintentionalradiatoris operating,theradiofrequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dBbelowthat inthe100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,basedoneitheran RFconducted,providedthetransmitterdemonstratescompliancewiththepeakconductedpowerlimits. 9.6.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.6.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDSSchannelcenterfrequency. SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel. SettheRBW=100kHz.SettheVBW≥3xRBW. SetDetector=peak.SetSweeptime=autocouple. SetTracemode=maxhold.Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumMaximumconducetedlevel. Notethatthechannelfoundtocontainthemaximumconducetedlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttotheband-edge, aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW  1%ofthespan=100kHzSetVBW  3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighestmodulation productoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethemarker-deltafunction, thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthein-bandemission.Themarker-delta valuenowdisplayedmustcomplywiththelimitspecifiedinthisSection. Now,usingthesameinstrumentsettings,enablethehoppingfunctionoftheEUT.Allowthetracetostabilize. Followthesameprocedurelistedabovetodetermineifanyspuriousemissionscausedbythehoppingfunction alsocomplywiththespecifiedlimit. Emissionlevelmeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeaklevelofthein-bandemissionandallspuriousemissions(e.g.,harmonics) fromthelowestfrequencygeneratedintheEUTupthroughthe10thharmonic.(30MHzto25GHz).SetRBW= 100kHzSetVBW  RBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkeronthepeakofanyspuriousemissionrecorded.Theleveldisplayed mustcomplywiththelimitspecifiedinthisSection. ReportNo.EDG2406060050E00301RPage52of75Ver.1.0 9.6.5TestResults Temperature: 25 ̊ C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Alltheantennaandmodesmodehavebeentested,andtheworstresultrecordedwasreportasbelow: Bandedgemeasurements TestModeAntennaChNameFrequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1Low2402-0.19-43.52≤-20.19PASS DH5Ant1High2480-0.76-46.07≤-20.76PASS DH5Ant1LowHop_2402-0.55-45.57≤-20.55PASS DH5Ant1HighHop_2480-0.86-45.31≤-20.86PASS ReportNo.EDG2406060050E00301RPage53of75Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS ReportNo.EDG2406060050E00301RPage54of75Ver.1.0 DH5-Ant1-Hop_2402-PASS DH5-Ant1-Hop_2480-PASS ReportNo.EDG2406060050E00301RPage55of75Ver.1.0 ConductedSpuriousEmission TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant124020~Reference-0.66-0.66---PASS DH5Ant1240230~1000-0.66-50.57≤-20.66PASS DH5Ant124021000~26500-0.66-44.19≤-20.66PASS DH5Ant124410~Reference-0.49-0.49---PASS DH5Ant1244130~1000-0.49-51.5≤-20.49PASS DH5Ant124411000~26500-0.49-43.54≤-20.49PASS DH5Ant124800~Reference-1.17-1.17---PASS DH5Ant1248030~1000-1.17-50.87≤-21.17PASS DH5Ant124801000~26500-1.17-41.06≤-21.17PASS ReportNo.EDG2406060050E00301RPage56of75Ver.1.0 DH5-Ant1-2402-0~Reference-PASS DH5-Ant1-2402-30~1000-PASS …

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEM ANT SPEC Model Name 2.4G ANT Horizontal Vertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26 -0.76 -0.58 -5.25 -2.46 -1.86 MAX. Gain -0.58dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50 Ohm Antenna Length 35.965mm Manu…
