2BCGV0019Bluetooth speaker with RGB light

USER MANUAL What’s in the box? 1. Speaker*1 2. Type-C cable*1 Overview 1.Previous track/Vol – 2.Power ON/OFF/Play/Pause 3.Light button 4.Next track/Vol+ 5.Lamp 6.Type-C input 7.Charging LED indicator 8.Wireless LED indicator Specifications: 1.Model: SL549-H 2.Item: 25249 3.Input: DC 5V/1A 4.Speaker output power: 3W 5.Battery capacity: 3.7V/1200mAh, 4.44Wh Operation Instructions 1. Power On: Long press the power button to turn on the speaker and will hear a tone. 2. Pairing: Once the speaker is turned on, use the mobile device to search for Bluetooth ID '25249'. It will pair automatically. The wireless LED indicator will flash blue and turn into solid once paired successfully. 3. Play/Pause: Short press the button to play or pause the music. 4. Next track/Vol+: Short press to next track, long press to increase volume 5. Previous track/Vol -: Short press to previous track, long press to decrease volume 6. Lamp: Tap the light button sequentially to switch different color mode and turn off the lamp. 1 2 3 4 6 5 7. Power Off: Long press the power button to turn off the speaker. 8. Charging: Use the Type-C cable included to connect the speaker to a computer or adaptor, the Charging LED indicator will display a solid red light. When the speaker is fully charged, the red light will be turned off. 9. The speaker will be turned off automatically after disconnected and no other operation for 10 minutes. FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio Caution: 1. Listen to the music at an appropriate volume to avoid the risk of damaging your hearing and sound system. 2. Avoid the exposure to rain, water droplets, and prolonged exposure to high temperature and high humidity environment. 3. When in use, keep the product away from heat and high pressure and do not let children play with it unattended. 4. Do not drop or bump and apply heavy pressure to the product to avoid damage. communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: RF Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure conditions without restriction. Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. 7 8 MADE IN CHINA FCC ID: 2BCGV0019 Bluetooth Listing Declaration ID: D063501 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by (ShenZhen SHD Electronic Tech. Co., Ltd.) is under license. Other trademarks and trade names are those of their respective owners.
