Disco Light Up Bluetooth Speaker Instruction Manual 29062 1 x Bluetooth Speaker 1 x USB to Type-C Charging Cable 1 x Instruction Manual 1 x Lanyard (Be sure to fully charge the speaker before Charging the Speaker Connect the provided charging cable to a power source and to the Type-C port on the speaker (3). The LED indicator light will glow red when charging and turn off when fully charged. Bluetooth Setup: Press and hold the ON/OFF Button to turn ON the device. Turn on the Bluetooth function on mobile device, Select “29062” pairing name. Speaker will automatically pair if the mobile device has been paired before. Press and hold the ON/OFF Button to turn OFF the device. DISCO LIGHT: To turn OFF/ON the disco light function, double press the ON/OFF button. Do not use the device if damaged or explosion or risk of injury. Do not disassemble the device. For professional. Incorrect reassembly may or temperatures above 104°F may cause explosion. use only identical replacement parts to ensure product safety WARNING-When using this product, basic precautions should always be followed: Read all the instructions before use. Never store or use this product in temperatures below 32°F(0°C) or above 115°F(45°C). The unit’s full performance is achieved only after 2 or 3 completed charge and discharge cycles. To reduce the risk of injury, close supervision is necessary when the product is used near children. Do not expose the device to moisture. Do not use the device in excess of its output rating. Overload outputs above 1. • 2. • • * • 3. • 7. 8. 9. 10. 11. • 1. 2. 3. 4. 5. 6. 1. 2. 3. 4. ON/OFF Button LED Indicator Type-C input port Disco Light What’s included: Functions: Instructions: SAFETY PRECAUTIONS: MADE IN CHINA FCC Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by (ShenZhen SHD Electronic Tech. Co., Ltd.) is under license. Other trademarks and trade names are those of their respective owners. FCC ID : 2BCGV0008 Bluetooth Listing Declaration ID: D063501 Model: CT02103 Item No.: 29062 Input: DC 5V/ 500mA Battery capacity: 200 mAh Speaker output power: 3W FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. RF Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
