2BCGV0017IPX5 Bluetooth speaker

MADE IN CHINA FCC ID: 2BCGV0017 90mm 55mm 1. Next track/Vol+ 2. Power ON/OFF/Play/Pause 3. Previous track/Vol – 4. TF slot 5. Type-C input 6. LED Indicator Overview 1. Speaker*1 2. User manual*1 3. Type-C cable*1 What’s in the box? 1. Power On: Long press the power button to turn on the speaker, you will hear a tone. The LED indicator will flash blue. 2. Pairing: Once speaker is turned on, open your mobile device, search the wireless device and select wireless ID ‘25241’, It will pair automatically. The LED indicator will turn into solid blue after paired successfully. 3. Play/Pause: Short press the button to play or pause the music, the LED indicator will flash blue during playing music. 4. Next track/Vol+: Long press to next track, short press to increase volume 5. Previous track/Vol -: Long press to last track, short press to decrease volume 6. TF card play: Plug the TF card into TF slot, it will automatically play the music. 7. Charging: Use the Type-C cable included to connect the speaker to a certified adaptor, the LED indicator will illuminate red in charging and turn off when fully charged. 9. Power Off: Long press the power button to turn off the speaker. Operation Instructions Specifications: 1. Model: CT02106 2. Item: 25241 3. Input: DC 5V/0.4A 4. Speaker output power: 3W 5. Battery capacity:3.7V/500mAh 1.85Wh Caution: 1. Please enjoy music with an appropriate volume, which will avoid to damage your hearing and sound system. 2. Please avoid exposure, rain, water droplets, avoid prolonged exposure to high temperature, high humidity environment. 3. During use, please make it away from heat, high pressure, and prevent children from playing with this product. 4. Please use the power which meets the requirements. 5. Do not drop or bump and applied heavy pressure to avoid damage to the product. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. FCC STATEMENT Bluetooth Listing Declaration ID: D063501 Warning: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. RF Statement The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by (ShenZhen SHD Electronic Tech. Co., Ltd.) is under license. Other trademarks and trade names are those of their respective owners. 1 45 6 2 3

Rev1/26/2023 (NINGBOCSTARIMPRINTE-COMMERCECO.,LTD) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:06-27-2024 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID：2BCGV0017 [NINGBOCSTARIMPRINTE-COMMERCECO.,LTD](“theapplicant”)certifiesthattheequipmentfor whichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceivinganequipment authorizationpursuanttosection2.903oftheFCCrules. Sincerely, (Applicantsignature) (FosterLi) Rev1/26/2023 (NINGBOCSTARIMPRINTE-COMMERCECO.,LTD) FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:06-27-2024 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID：2BCGV0017 [NINGBOCSTARIMPRINTE-COMMERCECO.,LTD](“theapplicant”)certifiesthat,asofthedateofthe filingoftheapplication,theapplicantisnotidentifiedontheCoveredList(asaspecificallynamedentity oranyofitssubsidiariesoraffiliates)asanentityproducing“covered” equipment. Sincerely, (Applicantsignature) (FosterLi)

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:06-27-2024 SUBJECT:FCCID:2BCGV0017 ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheclassB computerperipheralportionofthiscompositedevice.IunderstandthefollowingFCC requirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, NINGBOCSTARIMPRINTE-COMMERCECO.,LTD ------------------------------- （ FosterLi ）

2.911 (d)(7)USA Agent v1.2 Company name: NINGBO CSTAR IMPRINT E-COMMERCE CO., LTD. Address: B46, BUILDING B, INDUSTRIAL BLOCK, QIAOTOUHU STREET, NINGHAI COUNTY, NINGBO CITY, ZHEJIANG PROVINCE, CHINA GC: NINGBO CSTAR IMPRINT E-COMMERCE CO.,LTD Section 2.911(d)(7) USAAgent for Service of Process 2BCGV FRN: 0034122457 2.911(d)(7) USA Designated Agent for Service of Process We, [NINGBO CSTAR IMPRINT E-COMMERCE CO., LTD.] (“the applicant”) designate [PROSTOCK LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: PROSTOCK LLC Address: 10 Pines Lake Drive East Wayne, NJ.07470, USA FRN：0033411935 Contact Name: Marc Puglisi Telephone No: 973-865-8262 Email: [email protected] Applicant Company name: NINGBO CSTAR IMPRINT E-COMMERCE CO., LTD. Address: B46, BUILDING B, INDUSTRIAL BLOCK, QIAOTOUHU STREET, NINGHAI COUNTY, NINGBO CITY, ZHEJIANG PROVINCE, CHINA Contact Name: Foster Li Telephone No: +86-755-29063393 Email: [email protected] Signature: Title: General Manager Signature: Title: Compliance Manager 2.911 (d)(7)USA Agent v1.2 Date: Sep 13, 2023 Date: Sep 13, 2023 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Rev11/20/07 FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2BCGV0017 PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName BlockDiagram Schematics OperationalDescription BlockDiagram Schematics OperationalDescription Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,Wealsorequestingthe commissiontograntshort-termconfidentialityrequestonthefollowingattachmentsuntil180 daysaftertheGrantDateofEquipmentAuthorizations. ExhibitTypeFileName Sincerely, FosterLi 06-27-2024

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Declarationonmodeldifference Wetheundersignedherebyconfirmthatthesemodelsareidentical,andallmodelshavethesame RFmodule,PCBlayout,Antenna,schematicsandcomponent.Onlydifferentonmodelnameand color. ProductionnameTrademarkFCCModelno. IPX5BluetoothspeakerN/A2BCGV0017CT02106,25241 Confirmedby: FosterLi NINGBOCSTARIMPRINTE-COMMERCECO.,LTD 06-27-2024

NINGBOCSTARIMPRINTE-COMMERCECO.,LTD FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:06-27-2024 SUBJECT:FCCApplicationforFCCID:2BCGV0017 ToWhomItMayConcern: We,theundersigned,herebyauthorizeSamLv.atEMTEK(DONGGUAN)CO.,LTD.on ourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment.Any andallactscarriedoutbyEMTEK(DONGGUAN)CO.,LTD.onourbehalfshallhave thesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards, Sincerely, FosterLi 06-27-2024

ReportNo.EDG2406060050E007Page1of5Ver.1.0 FCCID:2BCGV0017 ReportNo.EDG2406060050E007Page2of5Ver.1.0 ReportNo.EDG2406060050E007Page3of5Ver.1.0 ReportNo.EDG2406060050E007Page4of5Ver.1.0 ReportNo.EDG2406060050E007Page5of5Ver.1.0

55mm 20mm

ReportNo.EDG2406060050E007Page1of2Ver.1.0 FCCID:2BCGV0017 ReportNo.EDG2406060050E007Page2of2Ver.1.0 BTANT

ReportNo.EDG2406060050E00702RPage1of7Ver.1.0 TESTREPORT ProductName：IPX5Bluetoothspeaker ModelNumber：CT02106,25241 FCCID：2BCGV0017 Preparedfor:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address:B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHU STREET,NINGHAICOUNTY,NINGBOCITY,ZHEJIANG PROVINCE Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2406060050E00702R Date(s)ofTests:Jun06,2024toJun24,2024 Dateofissue:Jun25,2024 $二维码$ ReportNo.EDG2406060050E00702RPage2of7Ver.1.0 TableofContents 1.TESTRESULTCERTIFICATION...............................................................................................................................................3 2.EUTSPECIFICATION.................................................................................................................................................................5 3.TESTREQUIREMENT................................................................................................................................................................6 4.MEASUREMENTRESULT.........................................................................................................................................................7 ReportNo.EDG2406060050E00702RPage3of7Ver.1.0 1.TESTRESULTCERTIFICATION Applicant:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address: B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHUSTREET,NINGHAI COUNTY,NINGBOCITY,ZHEJIANGPROVINCE Manufacturer:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address: B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHUSTREET,NINGHAI COUNTY,NINGBOCITY,ZHEJIANGPROVINCE EUT:IPX5Bluetoothspeaker ModelName:CT02106,25241 Trademark:N/A MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT §15.247(i),§2.1093 PASS TheaboveequipmentwastestedbyEMTEK(DONGGUAN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththeprocedures giveninANSIC63.10(2013)andtheenergyemittedbythesampleEUTtestedasdescribedinthisreportisin compliancewiththerequirementsofFCCRulesFCC§15.247(i),§2.1093. Thetestresultsofthisreportrelateonlytothetestedsampleidentifiedinthisreport DateofTest: Jun06,2024toJun24,2024 Preparedby: WarrenDeng/Editor Reviewer: TimDong/Supervisor Approve&AuthorizedSigner: SamLv/Manager ReportNo.EDG2406060050E00702RPage4of7Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary EDG2406060050E00702R/OriginalReport ReportNo.EDG2406060050E00702RPage5of7Ver.1.0 2. EUTSpecification CharacteristicsDescription Product:IPX5Bluetoothspeaker ModelNumber: CT02106,25241 Allproductsareidenticalexceptthemodelnumberandcolor.Herewe selectedCT02106forallthetest. Sample:1# DataRate: 1MbpsforGFSKmodulation 2Mbpsforπ/4-DQPSKmodulation 3Mbpsfor8DPSKmodulation Modulation: GFSK,π/4-DQPSK,8DPSK OperatingFrequency Range(s): 2402-2480MHz NumberofChannels: 79channels TransmitPowerMax: -2.44dBm(0.000570W) AntennaGain:-0.58dBi Powersupply: DC5VfromUSB DC3.7Vfrombattery Evaluationapplied:MPEEvaluation SAREvaluation ReportNo.EDG2406060050E00702RPage6of7Ver.1.0 3. TestRequirement SAREvaluation Accordingto447498D01V06,systemsoperatingundertheprovisionsofthissectionshallbeoperatedina mannerthatensuresthatthepublicisnotexposedtoradiofrequencyenergylevelinexcessofthe Commission’sguidelines. RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,usingmeasurementsorcomputer simulation.WhenroutineSARevaluationisnotrequired,portabletransmitterswithoutputpowergreaterthan theapplicablelowthresholdrequireSARevaluationtoqualityforTCBapproval. OneantennaisavailablefortheEUT.Theminimumseparationdistanceis5mm. ReportNo.EDG2406060050E00702RPage7of7Ver.1.0 4. MeasurementResult Antennagain:-0.58dBi Transmit Frequency (MHz) Mode Measured Power (dBm) Tune upPower (dBm) Maxtuneup power (dBm) Calculation Result 1-gSAR 2402GFSK-3.98-3±1-20.19563 2441GFSK-3.54-3±1-20.19723 2480GFSK-3.34-3±1-20.19873 2402Π/4-DQPSK-3.36-3±1-20.19563 2441Π/4-DQPSK-2.87-2±1-10.24823 2480Π/4-DQPSK-2.84-2±1-10.25023 24028DPSK-3.04-3±1-20.19563 24418DPSK-2.44-2±1-10.24823 24808DPSK-2.52-2±1-10.25023 AccordingtoKDB447498D01V06,nostand-alonerequiredforBTantenna,andnosimultaneousSAR measurementisrequired. ***EndofReport***

ANT SPECITEM 2.4G ANTModel Name VerticalHorizontal 2500MHz2400MHz2500MHz2400MHz Center Frequency -0.58dBi MAX. Gain Horizontal and VerticalPolarization Azimuth Beam Pattern Omni-directional 50 OhmImpedance 38.20mmAntenna Length Manufacture Antenna Photo & Length (mm) Antenna Specification Summary 2450MHz2450MHz -5.25dBi -1.86dBi -1.26dBi -0.76dBi -0.58dBi -2.46dBi ZHUHAI JIELI TECHNOLOGY CO.,LTD7th floor, Fuhua Science and Technology Building, North Ring Avenue, Xili Street, NanshanDistrict, Shenzhen Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Frequency (MHz) AvgMinMax -7.18716-30.0801-1.261742400 -7.48023-36.5604-0.7658022450 -6.59127-22.0315-0.5855822500 Gain(dBi) Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Frequency (MHz) AvgMinMax -12.4294-22.1424-5.25372400 -10.4702-24.5837-2.46522450 -9.20432-29.5214-1.861202500 ANT Test Labs：Attestation of Global Compliance Co., Ltd. Gain(dBi)

ReportNo.EDG2406060050E00701RPage1of75Ver.1.0 $二维码$ TESTREPORT ProductName：IPX5Bluetoothspeaker ModelNumber：CT02106,25241 FCCID：2BCGV0017 Preparedfor:NINGBOCSTARIMPRINTE-COMMERCECO.,LTD Address:B46,BUILDINGB,INDUSTRIALBLOCK,QIAOTOUHU STREET,NINGHAICOUNTY,NINGBOCITY,ZHEJIANG PROVINCE Preparedby:EMTEK(DONGGUAN)CO.,LTD. Address:-1&2/F.,Building2,ZoneA,ZhongdaMarineBiotechnology ResearchandDevelopmentBase,No.9,XinchengAvenue, SongshanhuHigh-technologyIndustrialDevelopmentZone, Dongguan,Guangdong,China TEL:+86-0769-22807078 FAX:+86-0769-22807079 ReportNumber:EDG2406060050E00701R Date(s)ofTests:Jun06,2024toJun24,2024 Dateofissue:Jun25,2024 ReportNo.EDG2406060050E00701RPage2of75Ver.1.0 TableofContents 1TESTRESULTCERTIFICATION..................................................................................................................................................3 2EUTTECHNICALDESCRIPTION.................................................................................................................................................5 3SUMMARYOFTESTRESULT.....................................................................................................................................................6 4TESTMETHODOLOGY.................................................................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS......................................................................................................7 4.2MEASUREMENTEQUIPMENTUSED..................................................................................................................................7 4.3DESCRIPTIONOFTESTMODES..........................................................................................................................................8 5FACILITIESANDACCREDITATIONS........................................................................................................................................9 5.1FACILITIES..............................................................................................................................................................................9 5.2EQUIPMENT............................................................................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS.........................................................................................................9 6TESTSYSTEMUNCERTAINTY.................................................................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST.....................................................................................................................................11 7.1RADIOFREQUENCYTESTSETUP1.................................................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2.................................................................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP.............................................................................................................................13 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM.............................................................................................14 7.5SUPPORTEQUIPMENT........................................................................................................................................................14 8FREQUENCYHOPPINGSYSTEMREQUIREMENTS...............................................................................................................15 8.1StandardApplicable.................................................................................................................................................................15 8.2EUTPseudorandomFrequencyHoppingSequence................................................................................................................15 8.3EqualHoppingFrequencyUse................................................................................................................................................16 8.4FrequencyHoppingSystem.....................................................................................................................................................16 9TESTREQUIREMENTS...............................................................................................................................................................17 9.120DB&99%BANDWIDTH.....................................................................................................................................................17 9.2CARRIERFREQUENCYSEPARATION..............................................................................................................................29 9.3NUMBEROFHOPPINGFREQUENCIES............................................................................................................................32 9.4AVERAGETIMEOFOCCUPANCY(DWELLTIME)........................................................................................................35 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER.........................................................................................................45 9.6CONDUCTEDSUPRIOUSEMISSION.................................................................................................................................51 9.7RADIATEDSPURIOUSEMISSION.....................................................................................................................................61 9.8CONDUCTEDEMISSIONTEST...........................................................................................................................................70 9.9ANTENNAAPPLICATION...............................…

Text truncated - open the document above for the full version.

ReportNo.EDG2406060050E00701RPage41of75Ver.1.0 2DH5-Ant1-Hop-PASS ReportNo.EDG2406060050E00701RPage42of75Ver.1.0 3DH1-Ant1-Hop-PASS ReportNo.EDG2406060050E00701RPage43of75Ver.1.0 3DH3-Ant1-Hop-PASS ReportNo.EDG2406060050E00701RPage44of75Ver.1.0 3DH5-Ant1-Hop-PASS ReportNo.EDG2406060050E00701RPage45of75Ver.1.0 9.5MAXIMUMPEAKCONDUCTEDOUTPUTPOWER 9.5.1ApplicableStandard AccordingtoFCCPart15.247(b)(1)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-247.5.4andRSS-Gen6.12 9.5.2ConformanceLimit ThemaxForfrequencyhoppingsystemsoperatinginthe2400-2483.5MHzbandemployingatleast75 non-overlappinghoppingchannels:1watt.Forallotherfrequencyhoppingsystemsinthe2400-2483.5MHzband: 0.125watts. 9.5.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.5.4TestProcedure Asanalternativetoapeakpowermeasurement,compliancewiththelimitcanbebasedonameasurementofthe maximumconductedoutputpower. Usethefollowingspectrumanalyzersettings: SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel(about8MHz) SetRBW>the20dBbandwidthoftheemissionbeingmeasured(about3MHz) SetVBW  RBW SetSweep=auto SetDetectorfunction=peak SetTrace=maxhold Allowthetracetostabilize.Usethemarker-to-peakfunctiontosetthemarkertothepeakoftheemissionto determinethepeakamplitudelevel. TestResults Temperature: 25 ̊C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Test Mode AntennaFrequency[MHz] ConductedPeak Powert[dBm] Conducted Limit[dBm] Verdict DH5Ant12402-3.98≤20.97PASS DH5Ant12441-3.54≤20.97PASS DH5Ant12480-3.34≤20.97PASS 2DH5Ant12402-3.36≤20.97PASS 2DH5Ant12441-2.87≤20.97PASS 2DH5Ant12480-2.84≤20.97PASS 3DH5Ant12402-3.04≤20.97PASS 3DH5Ant12441-2.44≤20.97PASS 3DH5Ant12480-2.52≤20.97PASS ReportNo.EDG2406060050E00701RPage46of75Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2441-PASS ReportNo.EDG2406060050E00701RPage47of75Ver.1.0 DH5-Ant1-2480-PASS 2DH5-Ant1-2402-PASS ReportNo.EDG2406060050E00701RPage48of75Ver.1.0 2DH5-Ant1-2441-PASS 2DH5-Ant1-2480-PASS ReportNo.EDG2406060050E00701RPage49of75Ver.1.0 3DH5-Ant1-2402-PASS 3DH5-Ant1-2441-PASS ReportNo.EDG2406060050E00701RPage50of75Ver.1.0 3DH5-Ant1-2480-PASS ReportNo.EDG2406060050E00701RPage51of75Ver.1.0 9.6CONDUCTEDSUPRIOUSEMISSION 9.6.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MEASGUIDANCEv05r02 AccordingtoICRSS-2475.5 9.6.2ConformanceLimit Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumintentionalradiatoris operating,theradiofrequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dBbelowthat inthe100kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,basedoneitheran RFconducted,providedthetransmitterdemonstratescompliancewiththepeakconductedpowerlimits. 9.6.3TestConfiguration Testaccordingtoclause7.1radiofrequencytestsetup1 9.6.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDSSchannelcenterfrequency. SetSpan=approximately5timesthe20dBbandwidth,centeredonahoppingchannel. SettheRBW=100kHz.SettheVBW≥3xRBW. SetDetector=peak.SetSweeptime=autocouple. SetTracemode=maxhold.Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumMaximumconducetedlevel. Notethatthechannelfoundtocontainthemaximumconducetedlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttotheband-edge, aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW  1%ofthespan=100kHzSetVBW  3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighestmodulation productoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethemarker-deltafunction, thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthein-bandemission.Themarker-delta valuenowdisplayedmustcomplywiththelimitspecifiedinthisSection. Now,usingthesameinstrumentsettings,enablethehoppingfunctionoftheEUT.Allowthetracetostabilize. Followthesameprocedurelistedabovetodetermineifanyspuriousemissionscausedbythehoppingfunction alsocomplywiththespecifiedlimit. Emissionlevelmeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeaklevelofthein-bandemissionandallspuriousemissions(e.g.,harmonics) fromthelowestfrequencygeneratedintheEUTupthroughthe10thharmonic.(30MHzto25GHz).SetRBW= 100kHzSetVBW  RBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkeronthepeakofanyspuriousemissionrecorded.Theleveldisplayed mustcomplywiththelimitspecifiedinthisSection. ReportNo.EDG2406060050E00701RPage52of75Ver.1.0 9.6.5TestResults Temperature: 25 ̊ C RelativeHumidity:45% ATMPressure:1011mbar Note:N/A Alltheantennaandmodesmodehavebeentested,andtheworstresultrecordedwasreportasbelow: Bandedgemeasurements TestModeAntennaChNameFrequency[MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant1Low2402-5.33-37.44≤-25.33PASS DH5Ant1High2480-4.14-39.96≤-24.14PASS DH5Ant1LowHop_2402-4.89-47.4≤-24.89PASS DH5Ant1HighHop_2480-4.56-33.41≤-24.56PASS ReportNo.EDG2406060050E00701RPage53of75Ver.1.0 DH5-Ant1-2402-PASS DH5-Ant1-2480-PASS ReportNo.EDG2406060050E00701RPage54of75Ver.1.0 DH5-Ant1-Hop_2402-PASS DH5-Ant1-Hop_2480-PASS ReportNo.EDG2406060050E00701RPage55of75Ver.1.0 ConductedSpuriousEmission TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict DH5Ant124020~Reference-4.75-4.75---PASS DH5Ant1240230~1000-4.75-55.28≤-24.75PASS DH5Ant124021000~26500-4.75-49.26≤-24.75PASS DH5Ant124410~Reference-4.87-4.87---PASS DH5Ant1244130~1000-4.87-56.08≤-24.87PASS DH5Ant124411000~26500-4.87-49.26≤-24.87PASS DH5Ant124800~Reference-4.84-4.84---PASS DH5Ant1248030~1000-4.84-54.62≤-24.84PASS DH5Ant124801000~26500-4.84-48.76≤-24.84PASS ReportNo.EDG2406060050E00701RPage56of75Ver.1.0 DH5-Ant1-2402-0~Reference-PASS DH5-Ant1-2402-30~10…
