23 5.2.1 Cleaning the Propeller Follow these steps to clean the propeller safely and effectively: 1. Open the top shell. Use a flathead screwdriver to carefully pry open the drain cover.   5.2 Accessory Maintenance (When Necessary) 2. Remove any debris from the propeller area. Once cleaned, reassemble all parts in reverse order, ensuring everything is securely fastened.  5.2.2 Cleaning the Camera and Sensors To maintain the device's optimal performance, use a soft, dry cloth to gently wipe away any dirt from the camera and sensors. 24 5.2.3 Replacing the Caterpillar Tread 2. Remove the two screws and guide sleeves from the rear wheel to access the tread. 1. Remove the side cover plate: • Lay the device on its side. • Press the four side clips inward. • Pry and lift the cover plate upward to remove it. 3. Gently pull to remove the rear wheel and caterpillar tread from the device. 1 2 25 4. Align the gears on the replacement caterpillar tread with those on the rear wheel. Reinstall both components, ensuring the tread fits securely along the tread sleeves. 6. Tighten the screws and reinstall the side cover plate. Repeat these steps for the opposite tread to complete the replacement. 5. Insert the rear wheel guide sleeve, then rotate the clip until the two bumps align with the designated holes in the device. Rear Wheel Front Wheel 1 2 1 2 26 2. Align the replacement roller brush with the designated slots. Press the silicone buckles firmly into place to secure the new brush. Repeat this process for other roller brushes. 5.2.4 Replacing the Roller Brush 1. Remove all silicone buckles from the current roller brush. 5.3 Powering Off and Storing Your Aiper When storing your Aiper device during the off-season (e.g., winter or extended periods of non-use), follow these steps to maintain optimal condition: 1. Fully charge the device before storing. Ensure the device is powered off and disconnected from the charger during storage. 2. Thoroughly clean the entire device, including the top and bottom shells, wheels, and brushes, to remove any dirt or debris. 3. Use a soft cloth or tissue to dry the device completely. Ensure the charging port cover is securely closed. 4. Store the device in its original packaging in a cool, dry, and well-ventilated environment. 5. Recharge the battery every six months to preserve battery health. 27 6 Specifications Model: PRX30SE Rated Input: 25.2V ⎓ 3.0A Charger Model: GM95-252300-1FGN, GM95-252300-4FGN Charger Input: 100–240V~, 50/60Hz, 2.5A Charger Output: 25.2V ⎓ 3.0A Charging Dock Model: CH02 Charging Dock Input: 25.2V ⎓ 3.0A Battery Pack Voltage: 21.6V ⎓ Charging Dock Output: 25.2V ⎓ 3.0A Water Protection Rating: IPX8 Charging Time: 4.5 Hours Min Water Depth: 0.82 ft (0.25m) Suction Power: 8000 GPH (30283 LPH) Max Water Depth: 10 ft (3m) Battery Pack Life: Up to 240 min - Floor Battery Pack Mode: C1264D2-04 Battery Pack Capacity: 10300mAh (222.48Wh) Direct current. Short-circuit-proof safety isolating transformer. Alternating current. Switch mode power supply. Class III equipment. Read the user manual. Polarity of d.c. power connector. For indoor use only. Maximum operating depth. 3m 28 7 LED Indicator LED Status Indicator Wi-Fi Indicator Indicator Type Indicator StatusStatus Description Solid Green Solid Blue Solid Yellow Flowing Green Flowing Blue Flowing Yellow Solid Green Pulsing Green Off Flashing Green (Duration: 2 min, Interval: 30 min) Pulsing Yellow Flashing Red Operating: battery 31-100%. Charging: charging complete. Operating: battery 13–30%. Low battery: battery 0–12%. Charging: battery 31–99%. Charging: battery 13–30%. Charging: battery 0–12%. Device malfunction. Please follow the app's instructions for troubleshooting. Resetting the device. Firmware updating. Wi-Fi connected. Wi-Fi connection available. Wi-Fi disconnected. Camera in operation. 29 8 Troubleshooting 1 2 3 Device fails to power on. Device fails to charge. Device fails to avoid obstacles. MalfunctionNO.Possible CausesSolutions Insufficient battery level. Device not in place. Charger damaged or not powered. Sensor lens is dirty. Sensor is faulty. Camera not enabled. Battery in high or low temperature protection. Battery over- discharge caused by extended non- use. Battery in high or low temperature protection. Fully charge the device before use. Only operate the device in an environment between 41°F (5°C) and 104°F (40°C). Re-locate the device. Ensure the bump is inserted in inlet. Check if the charger is plugged in securely and if there’s a beep after powering on. If connected but no beep , the charger may be faulty. Contact Aiper customer service. Clean with a soft, dry cloth. Contact Aiper customer service. Enable camera in the app via path: Settings - Cleaning Settings - Camera. Only charge the device in an environment between 38°F (3°C) and 113°F (45°C). Follow Section 5.3 Powering Off and Storing Your Aiper for proper storage. If the device won’t charge after non-use, contact Aiper customer service. 30 4 5 Device stuck in a loop at a certain position. Device stuck at waterline while cleaning the waterline. MalfunctionNO.Possible CausesSolutions Sensor lens is dirty. Sensor is faulty. Device caught by pool drain. Protrusion at waterline not detected by sensor. Pool layout is relatively complex. Clean with a soft, dry cloth. Contact Aiper customer service. No action is required. Device will automatically sink to the bottom within 1 minute, then clean after avoiding the bump. Use device with pool drain closed. If stuck, it will free itself. Switch to another entry point to submerge the device and retry. Switch to another mode and retry. 31 6 7 Device tilts or shows decreased cleaning performance in water. Device's battery life is shorter than expected. MalfunctionNO.Possible CausesSolutions Filter box is full. LED flashing red: propeller may be jammed or faulty. Battery not fully charged. Different suction modes consume different amounts of power. Natural battery degradation. No acti…

Text truncated - open the document above for the full version.

Cordless Robotic Pool Cleaner Robot de piscine sans fil User Manual / Manuel d’utilisation Aiper Scuba V3 Pro EN User Manual --------------------------------1 LANGUAGE LANGUE FR Manuel d’utilisation --------------------------34 ES Manual de usuario ---------------------------68 1 Thank you for choosing Aiper. You've now joined millions who have already trusted Aiper to care for their pools and are enjoying the convenience of a pristinely clean pool. This user manual will help you maintain your device and ensure it performs at its maximum efficiency for years to come. Please take a moment to read through it. If you have any questions, please visit our website at www.aiper.com and contact our customer service team for assistance or more information. EN Aiper Customer Service: Email: [email protected] Scan for Video Guide Scan the QR Code to Access Customer Support CountryToll Free NumberLanguage United States Canada Australia +1 8668500666 +1 8338849230 +61 1800497023 English English English 2 Please read this manual carefully and follow all warnings and instructions when using your Aiper Cordless Robotic Pool Cleaner (hereinafter referred to as device ). Failure to comply may result in electric shock, fire, or serious injury. Aiper is not liable for any losses or injuries caused by improper use of this device. For your safety and the optimal performance of this device, please read and follow these instructions: 2. This device can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the device in a safe way and understand the hazards involved. 3. Children shall not play with the device. This device shall not be used by children. Cleaning and user maintenance shall not be carried out by children. 4. WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. 5. Ensure that children do not attempt to touch the device while it is operating. 6. Do not allow children to ride the device under any circumstance. 7. While operational, do not place your hands into any part of the device as this may result in injury. 1 IMPORTANT SAFETY INSTRUCTIONS 1. READ AND FOLLOW ALL INSTRUCTIONS 3 8. Prevent unintentional starting. Ensure the power button is off before connecting to the battery pack, picking up, or carrying the device. Carrying the device with your finger on the power button or energizing the device with the power button on invites accidents. 9. CAUTION: This pump is for use with permanently-installed pools. Do not use with storable pools. A permanently- installed pool is constructed in or on the ground or in a building such that it cannot be readily disassembled for storage. A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled to its original integrity. 10. Do not run your device out of the water as it may lead to over-heating. 11. The device can only be charged with the specific charging dock (model: CH02), which is powered by the specific charger (model: GM95-252300-1FGN, GM95-252300-4FGN). 12. Do not place any objects between the device and the charging dock. The device may fail to charge properly or overheat and get damaged as a result. 13. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. 14. This device can only be used with C1264D2-04 model lithium battery packs. 15. This device contains batteries that are non-replaceable. When the battery is at end of life, the device shall be properly disposed of. 16. In the event a damaged device produces an unfamiliar liquid, avoid contact with the liquid. If coming into contact with a foreign liquid, especially the eyes or other sensitive parts, immediately flush with water. Liquid ejected from a damaged battery may cause skin irritation or burns. 4 17. Do not use a battery pack or device that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion, or risk of injury. 18. Do not expose a battery pack or device to fire or excessive temperature. Exposure to fire or temperature above 158°F (70°C) may cause explosion. 19. Follow all charging instructions and do not charge the battery pack or device outside of the temperature range specified in the instructions. Charging improperly or at temperatures outside of the specified range may damage the battery and increase the risk of fire. 20. WARNING : Risk of Electric Shock. Connect only to a grounding type receptacle. If replacement of the plug or cord is needed, use only identical replacement parts. 21. CAUTION: To reduce the risk of electric shock, the pool must be installed no closer than 6 feet (1.8 m) from any electrical outlet. Do not place portable devices closer than 5 feet (1.5 m) from the pool. 22. Ensure the charging port is dry before charging with the charger. While charging, your device should be kept in a cool, well-ventilated area. Do not cover your device while charging, as this may cause components to overheat. 23. WARNING: To reduce the risk of electric shock, do not use an extension cord to charge your device and instead only charge it via a dedicated wall outlet. 24. WARNING: To reduce the risk of electric shock, replace damaged cord immediately. 25. Only certified professionals should disassemble the sealed drive kit of your device. 5 26. Do not operate your device simultaneously with any other pool equipment, such as a pool filter, cleaner, or skimmer. 27. Operate the device when the pool's water pump is off to prevent it from getting stuck in the drain. 28. When putting your device into the water, the top of the device must face upwards and should never be placed upside down or thrown into the swimming pool. 29. Do not drop, pierce the shell, or intentionally damage…
