2BDJ8-FG02AWireless Gamepad

Product Overview Technical Specifications Input Voltage: 5V, 350mA Working Voltage: 3.7V Battery Capacity: 600mAh Product Size: 154*59*111mm Product Weight: 250±10g Product Material: ABS Package Included 1 x Gamepad 1 x User Manual 1 x Type-C Charging Cable Wireless Connection Please Note: Please make sure that airplane mode on the console is turned off before use. First-T ime Pairing: Step 1: Find Controllers Option Step 2: Click Change Grip/Order Step 3: Press the SYNC Button (on the back of the controller) for about 5 seconds, until the 4 Led lights flash quickly, then release your finger and wait for the connection to complete. * NOTE: Enter the Change Grip/Order page, please complete the connection within 30 seconds as soon as possible. If you stay on this page for too long, you may not be able to connect to the switch console Console Wake Up and Wireless Re-connection Once the controller has paired with the console: . If the console is in SLEEP mode, the HOME button on the controller is able to wake up both the controller and the console. . If the console screen is on, any button can wake up the controller, which will allow the controller to reconnect to the console. . If re-connection failed, please follow the three steps: 1.Turn off Airplane mode on the console 2.Remove the controller's information on the NS console (System Setting> Controllers and Sensors> Disconnect Controllers) 3.Follow the steps in First-T ime Pairing Wired Connection 1. Turn on the "Pro Controller Wired Communication" in the console: System Settings > Controllers and Sensors > Pro Controller Wired Communication>On Please Note: The "Pro Controller Wired Communication" must be turned on before connecting the controller and the Dock with the cable. 2. Set the Switch on the dock to activate TV mode. Connect the Switch Dock and the controller directly via the USB Type C cable. Audio Function The controller has a 3.5mm audio port, supports 3.5mm wired headset and microphone. Please note: The audio function will ONLY work in Wired Connection Mode with a NS console. It will not work in wireless connection or PC platform. Please Note: The "Pro Controller Wired Communication" must be turned on BEFORE connecting the controller and the Dock with the cable. ① System settings > Controllers and Sensors > Pro Controller Wired Communication > On ② Set the Switch console on the dock to TV mode. ③ Connect the Switch Dock and the controller with the USB cable. ④ The icon with "USB" displayed indicates the wired connection is successful. ⑤ Plug the 3.5mm audio jack into the audio port on the bottom of the controller. Turbo and Auto-Fire Buttons Available to Set the Turbo Function: A/B/X/Y/L/ZL/R/ZR button Enable/disable the manual and auto turbo speed function: Step1: Press the TURBO button and one of the function button simultaneously, to enable the manual turbo speed function. Step2: Repeat the step 1, to enable the auto turbo speed function Step3: Repeat the step 1 again, to disable the manual and auto turbo speed function of this button. There are 3 levels of turbo speed: Minimum 5 shoots per-second, the corresponding channel light flash slowly. Moderate 12 shoots per-second, the corresponding channel light flash at a moderate rate. Maximum 20 shoots per-second, the corresponding channel light flash quickly. How to increase the turbo speed: When the manual turbo function is on, upward the right joystick meanwhile press and hold the TURBO button, which can increase one level of turbo speed. How to decrease the turbo speed: When the manual turbo function is on, downward the right joystick meanwhile press and hold the TURBO button, which can decrease one level of turbo speed. Turn Off All the Turbo Functions for All Buttons: Press and hold the Turbo button for 6 seconds until the controller vibrates, which will turn off the turbo functions of all buttons. Adjust Vibration Intensity There are 4 levels of vibration intensity: 100%-70%-30%-0%(no vibration) How to increase the vibration intensity: upward the left joystick meanwhile press the TURBO button, which can increase one level of vibration intensity. How to decrease the vibration intensity: downward the left joystick meanwhile press the TURBO button, which can decrease one level of vibration intensity. Macro Function There are two macro-enabled programmable buttons "ML/MR" on the back of the controller. Macro buttons can be programmed into function buttons or button sequences respectively. Macro Buttons Can Be Programmed to: A/B/X/Y/L/ZL/R/ZR/up/down/left/right buttons. The default mapping buttons of ML&MR are A&B. Enter the Macro Definition Mode and Set Up the Button(s): 1.Press and hold the "Turbo" + "ML" / "MR" together for 2 seconds, LED2-LED3 will stay lighting. The controller is ready to record the macro setting. 2.Press the function buttons that need to be set sequentially, the controller will record the button with the time interval between each button pressed. 3.Press macro button ML or MR shortly to save, the corresponding player LED light will stay lighting. The macro definition setting has been saved. When the controller re-connects to the console, it will automatically apply the last macro definition setting. Clear the Macro Definition Settings: Press the "Turbo" + "ML"/"MR" together for 2 seconds to enter settings mode, the LED2-LED3 will stay lit, then directly exit setting mode by pressing the same ML/MR buttons. The corresponding player LED will light up again. The macro definition setting within the current slot will be removed. RGB Lights ON/OFF Turn on/off ABXY button lights: Hold down the "L1+L2" together for 6 seconds Turn on/off Joystick lights: Hold down the "ZL+ZR" together for 6 seconds RGB Brightness Settings Hold the "-" then press the Up of the D-Pad to increase the light brightness Hold the "-" then press the Down of the D-Pad to decrease the light brightness Color Breathing Mode The color automatically breathes and changes every second followin…

Text truncated - open the document above for the full version.

Targetever (GuangDong) Technology Co.Ltd. 2023.11.28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BDJ8-FG02A [Targetever (GuangDong) Technology Co.Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) CHAO CHEN Targetever (GuangDong) Technology Co.Ltd. 2023.11.28 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BDJ8-FG02A [Targetever (GuangDong) Technology Co.Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) CHAO CHEN

Targetever (GuangDong) Technology Co.Ltd. 2023.11.28 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Wireless Gamepad Trademark: N/A MODEL : FG02A GG04, GG06, HG02, HG01, G808, G808-PRO, FG07, HG04, T-TGP802, T- TGP802W, MTNSPC-S01, MTNSPC-B01, MTNSPC-M01, NSPC-B02, NSPC- P01, NSPC-G01, WGP14,WGP15, WGP16, EG-3059W, EG-C3071W, EG08, EG10, G818 FCC ID : 2BDJ8-FG02A To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : CHAO CHEN /Manager Contact information / address: Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou, China

Targetever (GuangDong) Technology Co.Ltd. 2023.11.28 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : CHAO CHEN /Manager Contact information / address: Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou, China

Targetever (GuangDong) Technology Co.Ltd. Model Difference 2023/11/28 EUT NAME: Wireless Gamepad FCC ID: 2BDJ8-FG02A MODEL: FG02A GG04, GG06, HG02, HG01, G808, G808-PRO, FG07, HG04, T-TGP802, T- TGP802W, MTNSPC-S01, MTNSPC-B01, MTNSPC-M01, NSPC-B02, NSPC-P01, NSPC-G01, WGP14,WGP15, WGP16, EG-3059W, EG-C3071W, EG08, EG10, G818 All the model are the same circuit and RF module, except model names and appearance color. Regards Sincerely Client’s signature: Client’s name / title: CHAO CHEN /Manager Contact information / address: Building 10, Floors 2-11th, and Building 11, Floors 1- 11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou, China

External Photos

Size:10*5mm FCC ID: 2BDJ8-FG02A Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID: 2BDJ8-FG02A Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEEC95.1-1992. and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2003. Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT Modulation Test Channel Output Power (dBm) Limit (dBm) GFSK Low -5.60 21 GFSK Middle -4.40 21 GFSK High -3.79 21 π/4DQPSK Low -5.20 21 π/4DQPSK Middle -4.19 21 π/4DQPSK High -3.58 21 8DPSK Low -4.91 21 8DPSK Middle -4.01 21 8DPSK High -3.42 21 max possible output power (PK,conducted)：-3±1dBm -6.17dBi logarithmic terms convert to numeric result is nearly 0.242 -2dBm=0.63mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.63/5*√2.402=0.20≤3.0 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.63/5*√2.441=0.20≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 0.63/5*√2.48=0.20≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

3 1. Product Overview & Dimension 2mm2mm 1mm1mm 4.7mm4.7mm 2.8mm2.8mm 9mm9mm Targetever (GuangDong) Technology Co.Ltd. Address: Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou, China 4 2.1 VSWR 2. Test Result 2.69VSWR 2500 Frequency (MHz) 2400 4.08 2450 3.32 www.inpaq.com.tw 5 2.2SMISH 2. Test Result 18.68SMISH 2500 Frequency (MHz) 2400 13.39 2450 15.20 6 2.3GAIN & Efficiency 2. Test Result -6.17-12.255.96 2500 -6.67-12.795.26 2450 -8.84-13.644.33 2400 Peak GAIN (dBi) Average GAIN(dB)Efficiency (%)Frequency(MHz) 7 2.43D DATE 2. Test Result www.inpaq.com.tw 8 2. Test Result

Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 69 of 80 Edition：B.0 Hopping No. NVNT 3-DH1 2441MHz Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 70 of 80 Edition：B.0 14. Dwell Time 14.1 Block Diagram Of Test Setup 14.2 Limit Frequency hopping systems in the 2400-2483.5 MHz band shall use at least 15 channels. The average time of occupancy on any channel shall not be greater than 0.4 seconds within a period of 0.4 seconds multiplied by the number of hopping channels employed. Frequency hopping systems may avoid or suppress transmissions on a particular hopping frequency provided that a minimum of 15 channels are used. 14.3 Test procedure 1. Remove the antenna from the EUT and then connect a low RF cable from the antenna port to the spectrum. 2. Set spectrum analyzer span = 0. Centred on a hopping channel; 3. Set RBW = 1MHz and VBW = 3MHz.Sweep = as necessary to capture the entire dwell time per hopping channel. Set the EUT for DH5, DH3 and DH1 packet transmitting. 4. Use the marker-delta function to determine the dwell time. If this value varies with different modes of operation (e.g.. data rate. modulation format. etc.). repeat this test for each variation. The limit is specified in one of the subparagraphs of this Section. Submit this plot(s). 14.4 Test Result DH5 Packet permit maximum 1600 / 79 / 6 hops per second in each channel (5 time slots RX, 1 time slot TX). DH3 Packet permit maximum 1600 / 79 / 4 hops per second in each channel (3 time slots RX, 1 time slot TX). DH1 Packet permit maximum 1600 / 79 /2 hops per second in each channel (1 time slot RX, 1 time slot TX). So, the Dwell Time can be calculated as follows: DH5:1600/79/6*0.4*79*(MkrDelta)/1000 DH3:1600/79/4*0.4*79*(MkrDelta)/1000 DH1:1600/79/2*0.4*79*(MkrDelta)/1000 Remark: Mkr Delta is once pulse time. Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 71 of 80 Edition：B.0 Modulation Channel Data Packet pulse time(ms) Dwell Time(s) Limits(s) GFSK Middle 1DH1 0.376 0.120 0.4 1DH3 1.631 0.261 0.4 1DH5 2.880 0.307 0.4 π/ 4 DQPSK Middle 2DH1 0.386 0.124 0.4 2DH3 1.636 0.262 0.4 2DH5 2.887 0.308 0.4 8DPSK Middle 3DH1 0.387 0.124 0.4 3DH3 1.636 0.262 0.4 3DH5 2.887 0.308 0.4 Test Graphs Dwell NVNT 1-DH1 2441MHz One Burst Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 72 of 80 Edition：B.0 Dwell NVNT 1-DH3 2441MHz One Burst Dwell NVNT 1-DH5 2441MHz One Burst Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 73 of 80 Edition：B.0 Dwell NVNT 2-DH1 2441MHz One Burst Dwell NVNT 2-DH3 2441MHz One Burst Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 74 of 80 Edition：B.0 Dwell NVNT 2-DH5 2441MHz One Burst Dwell NVNT 3-DH1 2441MHz One Burst Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 75 of 80 Edition：B.0 Dwell NVNT 3-DH3 2441MHz One Burst Dwell NVNT 3-DH5 2441MHz One Burst Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 76 of 80 Edition：B.0 15. Antenna Requirement 15.1 Limit 15.203 requirement: For intentional device, according to 15.203: an intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. 15.2 Test Result The EUT antenna is Internal antenna, fulfill the requirement of this section. Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 77 of 80 Edition：B.0 16. EUT Photographs EUT Photo NOTE: Appendix-Photographs Of EUT Constructional Details Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 78 of 80 Edition：B.0 17. EUT Test Setup Photographs Conducted emissions Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 79 of 80 Edition：B.0 Radiated Measurement Photos Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 80 of 80 Edition：B.0 STATEMENT 1. The equipment lists are traceable to the national reference standards. 2. The test report can not be partially copied unless prior written approval is issued from our lab. 3. The test report is invalid without the "special seal for inspection and testing". 4. The test report is invalid without the signature of the approver. 5. The test process and test result is only related to the Unit Under Test. 6. Sample information is provided by the client and the laboratory is not responsible for its authenticity. 7. The quality system of our laboratory is in accordance with ISO/IEC17025. 8. If there is any objection to this test report, the client should inform issuing laboratory within 15 days from the date of receiving test report. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China TEL: 400-788-9558 P. C.: 518103 FAX: 0755-33229357 Website: http://www.chnbctc.com E-Mail: [email protected] ※※※※※ END ※※※※※

Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 78 of 80 Edition：B.0 17. EUT Test Setup Photographs Conducted emissions Report No.: BCTC2307142113E No.：BCTC/RF-EMC-007 Page: 79 of 80 Edition：B.0 Radiated Measurement Photos
