2BDJ8-IG10Wireless Game Controller

User Manual Product Overview Technical Specifications Compatibility: PS5/IOS/Android/PC Steam Connectivity: Bluetooth V5.3/Wired Type-C Total Number of Buttons: 19 digital buttons (△, ○, ╳, □, Up, Down, Left, Right, L3, R3, Share button, Option button, HOME button, Touch button, L1/R1 ( L2 /R2 with trigger function), a Mute button), plus ML/ MR mapping programming buttons on the back and two analog 3D components. Functionality: 1. It features a 6-axis sensor (3-axis accelerator and 3-axis gyroscope) with a 125hz return rate for precise game operations. 2. The front has a dual-point capacitive sensing touchpad and supports dual-motor vibration. 3. It has several built-in output ports, including a 3.5mm TRRS stereo jack for headphone and microphone connection, and an independent speaker output with RGB LED color channel indication for user and role distinction. (The controller doesn't have a built-in microphone) Programmable Buttons: with specific programming methods for back buttons ML and MR. Input Voltage: 5V, 500mA Working Voltage: 5V, 120mA Battery Capacity: 1000mAh Product Size: 160*106.6*68.1 mm Product Weight: 250+10g Product Material: ABS What included in packaging 1*controller 1*user manual 1*charging cable Operation Instructions PS5 Connection method: 1. Use the included Type-C cable to connect the controller to the PS5 console. And then pressing the HOME button on gamepad. The LED will turn solid to indicate successful connection. 2. Remove the Type-C cable and press Home button briefly to reconnect in wireless. 3. Re-connection: Press and hold the Home button on the controller until the light bar starts flashing. PC Connection method: Wired Connection Plug game controller into PC through the USB cable. The default mode is PS5 mode, recognized by PC for "DualSense Wireless Controller". Indicator LED will be on. Under this mode, PC STEAM platform and headphone function are available. Press Share+Options for 5s to switch modes between PS5 mode and Xinput Mode. Mode Device Name LED Indicator Color PS5 Mode DualSenes Wireless Controller Blue X-input Mode Xbox 360 Controller for Windows Green Bluetooth Connection 1. Open computer settings, choose "Bluetooth & devices" 2. Press and hold the [Share] + [Home] button of the controller for 5s. 3. Select [DualSense Wireless Controller]. (There are stay-on LED light when connected successfully). IOS Connection Method: The controller supports Apple devices with iOS 13.0 and higher version, allowing compatibility with games available on the Apple Store. Press and hold Share + HOME buttons for 3s, the LED will flash. Connect to the game controller via the Bluetooth settings on your device, recognized by Bluetooth name for " DualSense Wireless Controller".when connected, the LED indicator will be on. Note:Bluetooth devices work with limited functionality. For example, buttons and some games may not work as expected. Android Devices Connection Method: Press and hold Share + HOME buttons for 3s. The controller will enter pairing mode and LED indicator will flash. Search for the Bluetooth name "DualSense Wireless Controller" on android device and tap to connect. The light on the controller will turn to on when connected. Mute Function * Short press Mute button to turn on/ off micro on headphone, LED under Mute button will light on * Press and hold Mute button for 2s to turn off all audio function, LED under Mute button will blink in breath style. Press Mute button again to turn on audio function. LED will be off. LED Setting Light Mode Change:Hold [Options]+press [Left and Right of Dpad] to change light mode. Mode sequence: Ice Blue→Blue→Purple→Red→Orange→Yellow→Green→White→Breathing Light Mode→Colorful Rainbow →Turn off Light Brightness Change: Hold[Options]+[Up and Down of Dpad] Programming Start Marco:Press the TouchKey + ML/MR button simultaneously for 3s until the controller LED flashes with vibration feedback. Set Macro:Press the action button which you need to set in turn, the macro will record the button press intervals. (Up to 24 buttons can be programmed in a macro.) Complete Macro:After setting up, press MR/ML once to com plete the macro setting. Clean Macro:Hold [Touchkey+ML/MR ] for 5s; the LED will flash and with vibration feedback. * Touchkey is the function of pressing down of touchpad FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

(Targetever (GuangDong) Technology Co.Ltd.) (2026.1.9) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID:2BDJ8-IG10) [Targetever (GuangDong) Technology Co.Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, (Applicant signature) (Applicant printed name) CHAO CHEN (Targetever (GuangDong) Technology Co.Ltd.) (2026.1.9) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID:2BDJ8-IG10) [Targetever (GuangDong) Technology Co.Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) CHAO CHEN

Targetever (GuangDong) Technology Co.Ltd. 2026.1.9 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Wireless Game Controller Trademark: ASRVA MODEL : IG10 G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 FCC ID : 2BDJ8-IG10 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the -Block Diagram -Schematics -Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : CHAO CHEN /Manager Contact information / address: Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou.

Targetever (GuangDong) Technology Co.Ltd. 2026/1/13 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : CHAO CHEN / Manager Contact information / address: Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou.

Targetever (GuangDong) Technology Co.Ltd. Model Difference 2026.01.09 EUT NAME: Wireless Game Controller Trademark: ASRVA MODEL : IG10 G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 FCC ID : 2BDJ8-IG10 All models are identical except for the model name. Regards Sincerely Client’s signature: Client’s name / title : CHAO CHEN /Manager Contact information / address: Building 10, Floors 2-11th, and Building 11, Floors 1- 11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou.

FCC ID: 2BDJ8-IG10 External Photos FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10

Size:10*5mm FCC ID: 2BDJ8-IG10 Label location

FCC ID: 2BDJ8-IG10 Internal Photos Antenna FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10 FCC ID: 2BDJ8-IG10

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2512491H01 Issued for Targetever (GuangDong) Technology Co.Ltd. Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou. Product Name: Wireless Game Controller Brand Name: ASRVA Model Name: IG10 Series Model(s): G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 FCC ID: 2BDJ8-IG10 Test Standards: FCC 47CFR §2.1093 Page 2 of 7 Report No.: STS2512491H01 TEST REPORT Applicant’s Name ................. : Targetever (GuangDong) Technology Co.Ltd. Address ................................. : Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou. Manufacturer's Name ........... : Targetever (GuangDong) Technology Co.Ltd. Address ................................. : Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou. Product Description Product Name ........................ : Wireless Game Controller Brand Name .......................... : ASRVA Model Name .......................... : IG10 Series Model(s) ...................... : G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 Test Standards ..................... : FCC 47CFR §2.1093 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ...................... : 22 Dec. 2025 Date (s) of performance of tests ............. : 22 Dec. 2025 to 30 Dec. 2025 Date of Issue .......................................... : 30 Dec. 2025 Test Result .............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 7 Report No.: STS2512491H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 7 Page 4 of 7 Report No.: STS2512491H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Dec. 2025 STS2512491H01 ALL Initial Issue Page 5 of 7 Report No.: STS2512491H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Wireless Game Controller Brand Name ASRVA Model Name IG10 Series Model(s) G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 Model Difference All the model are the same circuit and RF module, except model names, the test model is IG10. Product Description The EUT is Wireless Game Controller Operation Frequency: 2402 – 2480 MHz Modulation Type: GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps) Antenna gain: 0 dBi Antenna Designation: Internal antenna Power Rating Input: DC 5V Adapter N/A Battery Rated Voltage:3.7V Capacity:1000mAh Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 7 Report No.: STS2512491H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Page 7 of 7 Report No.: STS2512491H01 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 2.3 TEST RESULT Maximum measured transmitter power. Worst Case Mode frequency Maximum Output Power Tune up tolerance Max Tune up GHz dBm dBm dBm GFSK 2.402 0.71 1±1 2 Evaluation Result Mode Frequency Antenna Distance RF output power including tune up (dBm) SAR Test Exclusion Threshold SAR Test Exclusion Estimated SAR GHz mm dBm mw GFSK 2.402 5 2 1.58 0.49 Yes / Note: 1. Remark: The worst case gain of the antenna is 0dBi. 2. Threshold at which no SAR required is 0.49≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm. ※※※※※END OF THE REPORT※※※※※

Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 1/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. Antenna specification Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 2/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. Antenna model: MP341 V1.0 APPlications ※Bluetooth Home RF ※ISM band 2.4GHz applications 1.Dimensions 2.Specifications number Item Specifications 1 Working Central Frequency 2441 MHz 2 Band Width (2402-2480)MHz 3 Gain 0dBi 4 VSWR ≤2.0 5 Antenna type PCB antenna 6 Azimuth Beam width Omni‐directional 7 Impedance 50ohm 8 Modulation mode GFSK ‣Company Name Shenzhen Innosystem Technology Ltd ‣Company address F2 Building 3 Shenzhen Software Park Technology Middle 2 Rd Gao Xin Science & Technology Park North, S.Z Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 3/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. 3.simulation parameter ① VSWR Mkr1: 2397MHz 1.47 Mkr2: 2450MHz 1.51 Mkr3: 2482 MHz 1.59 Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 4/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. ②Smith Char Mkr1: 2397MHz 73.4 Mkr2: 2450MHz 62.7 Mkr3: 2482MHz 66.8 Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 5/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. ③Return Loss Mkr1: 2397MHz -15 Mkr2: 2450MHz -18 Mkr3: 2482 MHz -16 Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 6/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. ④Smith Char Mkr1: 2400MHz 1.234 Mkr2: 2500MHz 1.051Mkr3: 2600MHz 1.322 Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 7/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. ⑤Return Loss Mkr1: 2400MHz -19.59 Mkr2: 2450MHz -27.70Mkr3: 2500MHz -31.97 Mkr4: 2550MHz -21.83 ` Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 8/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. ⑥Phase Mkr1: 2400MHz -54.89 Mkr2: 2500MHz -82.03 Mkr3: 2600MHz -102.6 Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 9/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved. 4. Radiation Pattems XY-plane XZ-plane YZ-plane Antenna specification Doc No. IS-QR-PD-010 Rev. V1.0 Page 10/10 2013/05/22 Copyright 2013© Shenzhen InnosystemTechnologyLimited All rights reserved.  3DRadiation pattern

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512491W01 Issued for Targetever (GuangDong) Technology Co.Ltd. Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou. Product Name: Wireless Game Controller Brand Name: ASRVA Model Name: IG10 Series Model(s): G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 FCC ID: 2BDJ8-IG10 Test Standards: FCC Part15.247 Page 2 of 98 Report No.: STS2512491W01 TEST REPORT Applicant’s Name ................. : Targetever (GuangDong) Technology Co.Ltd. Address .................................. : Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou. Manufacturer's Name ........... : Targetever (GuangDong) Technology Co.Ltd. Address .................................. : Building 10, Floors 2-11th, and Building 11, Floors 1-11th, Lang Yuan, 16 Chenghai Avenue, Chenjiang Street, Zhongkai High-Tech Zone, Huizhou. Product Description Product Name ........................ : Wireless Game Controller Brand Name ........................... : ASRVA Model Name ........................... : IG10 Series Model(s) .................... : G831, G832, G833, IG14B, JG11, JG13, JG14, JG15, JG16, JG17, JG18, GG01, FG07A, HG04G, HG04K, HG04I, IG10AMZ01 Standards ............................. : FCC Part15.247 Test Procedure ....................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ............................... : Date of receipt of test item ......... : 22 Dec. 2025 Date (s) of performance of tests : 22 Dec. 2025 to 30 Dec. 2025 Date of Issue ............................. : 30 Dec. 2025 Test Result ................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : Page 3 of 98 Report No.: STS2512491W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 FREQUENCY HOPPING SYSTEM REQUIREMENTS 10 2.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 12 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 12 2.6 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 13 2.7 EQUIPMENTS LIST 14 3. EMC EMISSION TEST 15 3.1 CONDUCTED EMISSION MEASUREMENT 15 3.2 RADIATED EMISSION MEASUREMENT 19 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 34 4.1 LIMIT 34 4.2 TEST PROCEDURE 34 4.3 TEST SETUP 35 4.4 EUT OPERATION CONDITIONS 35 4.5 TEST RESULTS 35 5. NUMBER OF HOPPING CHANNEL 36 5.1 LIMIT 36 5.2 TEST PROCEDURE 36 5.3 TEST SETUP 36 5.4 EUT OPERATION CONDITIONS 36 5.5 TEST RESULTS 36 6. AVERAGE TIME OF OCCUPANCY 37 6.1 LIMIT 37 6.2 TEST PROCEDURE 37 6.3 TEST SETUP 37 6.4 EUT OPERATION CONDITIONS 37 6.5 TEST RESULTS 37 7. HOPPING CHANNEL SEPARATION MEASUREMEN 38 Page 4 of 98 Report No.: STS2512491W01 Table of Contents Page 7.1 LIMIT 38 7.2 TEST PROCEDURE 38 7.3 TEST SETUP 38 7.4 EUT OPERATION CONDITIONS 38 7.5 TEST RESULTS 38 8. BANDWIDTH TEST 39 8.1 LIMIT 39 8.2 TEST PROCEDURE 39 8.3 TEST SETUP 39 8.4 EUT OPERATION CONDITIONS 39 8.5 TEST RESULTS 39 9. OUTPUT POWER TEST 40 9.1 LIMIT 40 9.2 TEST PROCEDURE 40 9.3 TEST SETUP 41 9.4 EUT OPERATION CONDITIONS 41 9.5 TEST RESULTS 41 10. ANTENNA REQUIREMENT 42 10.1 STANDARD REQUIREMENT 42 10.2 EUT ANTENNA 42 APPENDIX 1-TEST DATA 43 APPENDIX 2-PHOTOS OF TEST SETUP 98 Page 5 of 98 Report No.: STS2512491W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Dec. 2025 STS2512491W01 ALL Initial Issue Page 6 of 98 Report No.: STS2512491W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247(a)(1) Hopping Channel Separation PASS -- 15.247(a)(1)&(b)(1) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247(d) Conducted Spurious & Band Edge Emission PASS -- 15.247(a)(1)(iii) Number of Hopping Frequency PASS -- 15.247(a)(1)(iii) Dwell Time PASS -- 15.247(a)(1) Bandwidth PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Page 7 of 98 Report No.: STS2512491W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz)…

Text truncated - open the document above for the full version.

Page 69 of 98 Report No.: STS2512491W01 CFS NVNT 3-DH5 2402MHz CFS NVNT 3-DH5 2441MHz Page 70 of 98 Report No.: STS2512491W01 CFS NVNT 3-DH5 2480MHz Page 71 of 98 Report No.: STS2512491W01 Band Edge Condition Mode Frequency (MHz) Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH5 2402 No-Hopping -39.46 -20 Pass NVNT 1-DH5 2480 No-Hopping -39.08 -20 Pass NVNT 2-DH5 2402 No-Hopping -38.61 -20 Pass NVNT 2-DH5 2480 No-Hopping -38.39 -20 Pass NVNT 3-DH5 2402 No-Hopping -40.63 -20 Pass NVNT 3-DH5 2480 No-Hopping -37.45 -20 Pass Page 72 of 98 Report No.: STS2512491W01 Test Graphs Band Edge NVNT 1-DH5 2402MHz No-Hopping Ref Band Edge NVNT 1-DH5 2402MHz No-Hopping Emission Page 73 of 98 Report No.: STS2512491W01 Band Edge NVNT 1-DH5 2480MHz No-Hopping Ref Band Edge NVNT 1-DH5 2480MHz No-Hopping Emission Page 74 of 98 Report No.: STS2512491W01 Band Edge NVNT 2-DH5 2402MHz No-Hopping Ref Band Edge NVNT 2-DH5 2402MHz No-Hopping Emission Page 75 of 98 Report No.: STS2512491W01 Band Edge NVNT 2-DH5 2480MHz No-Hopping Ref Band Edge NVNT 2-DH5 2480MHz No-Hopping Emission Page 76 of 98 Report No.: STS2512491W01 Band Edge NVNT 3-DH5 2402MHz No-Hopping Ref Band Edge NVNT 3-DH5 2402MHz No-Hopping Emission Page 77 of 98 Report No.: STS2512491W01 Band Edge NVNT 3-DH5 2480MHz No-Hopping Ref Band Edge NVNT 3-DH5 2480MHz No-Hopping Emission Page 78 of 98 Report No.: STS2512491W01 Band Edge(Hopping) Condition Mode Frequency (MHz) Hopping Mode Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH5 2402 Hopping -38.76 -20 Pass NVNT 1-DH5 2480 Hopping -38.74 -20 Pass NVNT 2-DH5 2402 Hopping -37.5 -20 Pass NVNT 2-DH5 2480 Hopping -37.87 -20 Pass NVNT 3-DH5 2402 Hopping -38.55 -20 Pass NVNT 3-DH5 2480 Hopping -36.26 -20 Pass Page 79 of 98 Report No.: STS2512491W01 Test Graphs Band Edge(Hopping) NVNT 1-DH5 2402MHz Hopping Ref Band Edge(Hopping) NVNT 1-DH5 2402MHz Hopping Emission Page 80 of 98 Report No.: STS2512491W01 Band Edge(Hopping) NVNT 1-DH5 2480MHz Hopping Ref Band Edge(Hopping) NVNT 1-DH5 2480MHz Hopping Emission Page 81 of 98 Report No.: STS2512491W01 Band Edge(Hopping) NVNT 2-DH5 2402MHz Hopping Ref Band Edge(Hopping) NVNT 2-DH5 2402MHz Hopping Emission Page 82 of 98 Report No.: STS2512491W01 Band Edge(Hopping) NVNT 2-DH5 2480MHz Hopping Ref Band Edge(Hopping) NVNT 2-DH5 2480MHz Hopping Emission Page 83 of 98 Report No.: STS2512491W01 Band Edge(Hopping) NVNT 3-DH5 2402MHz Hopping Ref Band Edge(Hopping) NVNT 3-DH5 2402MHz Hopping Emission Page 84 of 98 Report No.: STS2512491W01 Band Edge(Hopping) NVNT 3-DH5 2480MHz Hopping Ref Band Edge(Hopping) NVNT 3-DH5 2480MHz Hopping Emission Page 85 of 98 Report No.: STS2512491W01 Conducted RF Spurious Emission Condition Mode Frequency (MHz) Max Value (dBc) Limit (dBc) Verdict NVNT 1-DH5 2402 -43.52 -20 Pass NVNT 1-DH5 2441 -42.67 -20 Pass NVNT 1-DH5 2480 -42.71 -20 Pass NVNT 2-DH5 2402 -42.71 -20 Pass NVNT 2-DH5 2441 -42.18 -20 Pass NVNT 2-DH5 2480 -42.11 -20 Pass NVNT 3-DH5 2402 -42.19 -20 Pass NVNT 3-DH5 2441 -36.02 -20 Pass NVNT 3-DH5 2480 -41.31 -20 Pass Page 86 of 98 Report No.: STS2512491W01 Test Graphs Tx. Spurious NVNT 1-DH5 2402MHz Ref Tx. Spurious NVNT 1-DH5 2402MHz Emission Page 87 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 1-DH5 2441MHz Ref Tx. Spurious NVNT 1-DH5 2441MHz Emission Page 88 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 1-DH5 2480MHz Ref Tx. Spurious NVNT 1-DH5 2480MHz Emission Page 89 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 2-DH5 2402MHz Ref Tx. Spurious NVNT 2-DH5 2402MHz Emission Page 90 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 2-DH5 2441MHz Ref Tx. Spurious NVNT 2-DH5 2441MHz Emission Page 91 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 2-DH5 2480MHz Ref Tx. Spurious NVNT 2-DH5 2480MHz Emission Page 92 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 3-DH5 2402MHz Ref Tx. Spurious NVNT 3-DH5 2402MHz Emission Page 93 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 3-DH5 2441MHz Ref Tx. Spurious NVNT 3-DH5 2441MHz Emission Page 94 of 98 Report No.: STS2512491W01 Tx. Spurious NVNT 3-DH5 2480MHz Ref Tx. Spurious NVNT 3-DH5 2480MHz Emission Page 95 of 98 Report No.: STS2512491W01 Number of Hopping Channel Condition Mode Hopping Number Limit Verdict NVNT 1-DH5 79 15 Pass NVNT 2-DH5 79 15 Pass NVNT 3-DH5 79 15 Pass Page 96 of 98 Report No.: STS2512491W01 Test Graphs Hopping No. NVNT 1-DH5 2441MHz Hopping No. NVNT 2-DH5 2441MHz Page 97 of 98 Report No.: STS2512491W01 Hopping No. NVNT 3-DH5 2441MHz Page 98 of 98 Report No.: STS2512491W01 APPENDIX 2-PHOTOS OF TEST SETUP Note: See test photos in setup photo document for the actual connections between Product and support equipment. ※※※※※END OF THE REPORT※※※※※

Page 1 of 2 FCC ID: 2BDJ8-IG10 Conducted emissions 30MHz-1GHz Page 2 of 2 FCC ID: 2BDJ8-IG10 Spurious emissions
