2BEBP-ACE01Wireless Earbuds

音乐控制 R 触摸区域 L 单击(播放/暂停) 双击(上一首) 单击(播放/暂停) 双击(下一首) 三击（游戏模式） 三击(语音助手) R L 单击：左/右耳机 （接听通话） 双击：左/右耳机 （挂断当前通话） 长按2秒：左/右耳机 （拒接来电） 通话语音控制 长按2秒（通透模式） 长按2秒（降噪开） ON 长按2秒（降噪关） OFF 耳机恢复出厂设置 快速单击5次：左/右耳 耳机在未连接状态下 （恢复出厂设置） R L 蓝牙连接 打开蓝牙搜索连接设备 蓝牙 蓝牙 蓝牙 蓝牙 设备 Netac ACE01 打开机仓盖，(耳机蓝色灯闪烁) 进入配对模式。 打手机蓝牙，寻找蓝牙设备名称：“Netac ACE01”，点击进行连接。 充电描述 耳 机 充 电 机 仓 充 电 机仓绿灯慢闪 （充电中） 耳机电量低时伴有提示音,请及时放入仓内充电。 >30% When the earbud battery is low with warning tone. Please put it into the charge case to charge it in time. 机仓灯灭 （机仓满电量） 100% 机仓红灯慢闪 （电量不足） 30% Bluetooth connectivity Char ging Music Control R Touch area L Single touch Double touch Single touch Double touch Triple touch Triple touch Single touch Double touch Touch for 2s Call control Touch for 2S（Transparency mode） Touch for 2s ON Touch for 2s OFF When the earbuds are not connected. Reset earbuds Befor e connect to any Device ,quick touch left & Right earbuds 5 times R L R L R L R L Open blutoothSear ch device Bluetooth Bluetooth Bluetooth Bluetooth Bluetooth Netac ACE 01 Open the charging case , earbuds will goes into pairing Mode automatically. Open bluetooth from y our phone , search“Netac ACE01”, then click The connect icon Earbuds Charging case Red LED blink （Battery low） 30% Green LED bling （Charging） >30% LED OFF （Fully charged） 100% ACE01尺寸90mm x 533mm 128g铜版纸 规格参数 注意事项 请在常温环境中存放以及使用本产品； 请勿将本产品长期暴露在雨中或潮湿的环境中； 请勿丢掷,避免因跌落造成产品破坏； 请勿自行拆解、修理和改造本产品； 请使用额定电压的电源充电器充电； 擅自拆解将使保修失效。 充电盒及耳机内的电池为不可更换电池 不得暴露在诸如日照、火烤或类似过热的环境中 型号:ACE01 耳机电池:40mAh 充电仓电池:400mAh 播放时间:6H(耳机) +24H(充电仓） 充电时长:1.5H 产品重量:45±5g 扬声器单元:φ10mm 输入:DC5V 450mA ACE01 无线耳机说明书 Wir eless Earbuds Instructions 保修卡 感谢您选择朗科产品。通过正规渠道购买的朗科产品依法享有国家规定的三 包服务。查询具体细则请登录朗科中文网站:http://www.netac.com.cn 自签收之日起，朗科无线蓝牙/有线耳机配件齐全且无人为损坏，享有七天无 理由退货，十五天换货，一年非人为有性能故障保修服务(有线耳机一年半）。 产品名称 产品SN码 顾客姓名 联系电话 联系地址 购买日期 保修日期故障及处理方法 用户资料 保修记录 完成日期顾客签名 延期服务及更多礼遇 敬请关注朗科官方订阅号 北京朗科创新技术发展有限公司 地址：北京市门头沟区石龙经济开发区永安路20号3号楼一层138室 深圳市朗科科技股份有限公司 地址：深圳市南山区高新区南区高新南六道10号朗科大厦 服务电话：400-105-5505 官方网址：www.netac.com.cn Beijing Netac Innovation Technology Development Co.,Ltd. Location:138-1-3 No.20,Yongan Road,Mentougou District,Beijing,China Netac Technology Co.,Ltd. Location:Netac Building,Number 6 High-tech South St,Nanshan District, Shenzhen,P.R.China 518057 Web:www.netac.com matt er s needing attention Please stor e and use this product in normal t emperature environment; Do not expose this product to rain or humid environment for a long time; Do not throw it to av oid product damage caused by falling; Do not disassemble, rep air or transform this product by your self ; Please use the power charger with rated v oltage to charge; Unauthorized disassembly will invalidate the warranty. The batt eries in the charging stand and earphone are non replaceable batt eries Do not expose to such conditions as sunlight, fire or similar overheating Model:ACE01 Earbud Battery:40mAh Charging Case:400mAh Play Time:6H(Earbuds) +24H(Charging Case） Charging Time:1.5H Product Weight:45±5g Speaker Unit:φ10mm Input:DC5V 450mA Specifications FCC Compliance S tatement This device complie s w ith part 15 of the FCC Rule s. Operation i s sub ject to the follo wing two c onditions: (1) This devic e may not c ause harmful interf er enc e. (2) This d evice mu st acce pt any int erf erenc e receiv ed, including int erf er enc e tha t may cause undesired operation. Thi s equipment has been test ed and foun d t o comply with the limits for a Class B digit al devic e, pur suant to p art 15 of the F CC R ules. These limi ts are d esi gned to pr ovide r easona ble prot ection aga ins t harmful interference in a residential ins tallatio n. This equipment gene rate s uses and c an r adiate radio frequency e ner gy and, if not ins talled and used in acco rdan ce with the instru ction s, m ay cause harmful in terf er- enc e to r adio communication s. H owe ver, there is no guarantee tha t interf erenc e wi ll no t oc cur i n a particu lar i nstalla tion. I f t his equipment does c ause harmful interf erence t o r adio or t ele visi on r eception, which can be d etermined by turning the equipment off a nd on, the user is enc our aged to tr y to c orr ect the int erf erence b y one or more of the follo wing measur es: -R eorient or reloc ate the rec eiving antenna. -Incr ease the separ ation betw een the equipment and rec eiv er . -Connect the equipment into an out let on a circuit different fr om t hat to which the rec eiv er is connected. -Consult the dealer or an experienced r adio/TV technician for help. 正面第一页 背面第一页 开关 手动开机 长按左右耳机MFB键3秒 耳机开机并伴有提示音 长按左右耳机MFB键5秒耳机关机 ，态状队组SWT机耳右左（.音示提有伴并 长按任意一边耳机关机，左右耳机同步关机） R L 打开充电盒耳机自动开机 自动开机 手动关机 R L 放入充电盒中关闭充电盒上盖， 耳机自动关机并开始充电 自动关机 长按区域 Power ON/OFF Manual startup Touch & hold both left and right earbud for 3S to P owe on Touch & hold either left or right earbud for 5S to P owe off (When Left and right earbuds are connect, Long press L/R earbud to turn off both of the ear buds) Put e arbuds into charging case and close the case , it will power off aut oma tic ally Open the case , then Earbuds will power on automa tic ally Auto startup Manual shutdo wn Auto shutdown Touch area FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, the…

Text truncated - open the document above for the full version.

U.S.AgentDesignationforServiceofProcess (ApplicantandU.S.AgentareSeparateParties) TO:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ATTENTION:FCCCertification–Section2.911(d)(7)Information DesignatedU.S.Agent CompanyName:HOPEKCORPORATIONINC Address:4358SBANNOCKSTENGLEWOOD,CO80110UnitedStates FRN:0034562900 ContactName:PeterDavis Tel.:561-235-6113 Email:[email protected] Thisletteristoconfirmthatwe(“theDesignatedU.S.Agent)haveacceptedtheresponsibilitytoactasthe DesignatedU.S.AgentforServiceofProcessasrequiredbysection47CFR2.911(d)(7)onbehalfofthe Applicantnotedbelow. U.S.AgentSignature:PeterDavis Date:June11,2024 Signedby(PrintedName/Title): TheApplicantacknowledgesthattheymustmaintainanagentfornolessthanoneyearafterterminatingall marketingandimportationORtheconclusionofanyCommission-relatedproceedinginvolvingthe equipment.TheapplicantfurtheracknowledgestheirresponsibilitytoinformtheFCCwheneverthe DesignatedU.S.Agentinformationabovechanges. Applicant Companyname:BeijingNetacInnovationTechnologyDevelopmentCo.Ltd FRN:0034670349 GranteeCode:2BEBP FCCID:2BEBP-ACE01 ContactName:dongdongxie StreetAddress:138-1-3NO.20YONGANROADMENTOUGOUDISTRICTBEIJINGCHINA TelephoneNo:13612842510 Email:[email protected] ApplicantSignature: Date:June11,2024 Signedby(PrintedName/Title):dongdongxie/M anager

Beijing Netac Innovation Technology Development Co.Ltd 2024.06.11 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BEBP-ACE01 [Beijing Netac Innovation Technology Development Co.Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Dongdong xie Beijing Netac Innovation Technology Development Co.Ltd 2024.06.11 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BEBP-ACE01 [Beijing Netac Innovation Technology Development Co.Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Dongdong xie

Beijing Netac Innovation Technology Development Co.Ltd 2024.06.11 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Wireless Earbuds Trademark: Netac MODEL : ACE01 FCC ID : 2BEBP-ACE01 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Dongdong xie /Manager Contact information / address: 138-1-3 NO.20 YONG AN ROAD MEN TOU GOU DISTRICT BEIJING CHINA

Beijing Netac Innovation Technology Development Co.Ltd 2024.06.11 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : dongdong xie /Manager Contact information / address: 138-1-3 NO.20 YONG AN ROAD MEN TOU GOU DISTRICT BEIJING CHINA

External Photos

Size:10*5mm FCC ID: 2BEBP-ACE01 Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID:2BEBP-ACE01 Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEEC95.1-1992. and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2003. Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT GFSK 2402 0.5 21 GFSK 2441 0.23 21 GFSK 2480 -0.26 21 π/ 4 DQPSK 2402 1.34 21 π/ 4 DQPSK 2441 1.06 21 π/ 4 DQPSK 2480 0.52 21 8DPSK 2402 1.88 21 8DPSK 2441 1.64 21 8DPSK 2480 1.16 21 max possible output power (PK,conducted)：2±1dBm 1.13dBi logarithmic terms convert to numeric result is nearly 1.30 3dBm=2.00mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.00/5*√2.402=0.62≤3.0 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.00/5*√2.441=0.62≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 2.00/5*√2.48=0.63≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

深圳 合立讯科技有限公司 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL ：0755-23591525FAX ：0755-23591525 1 承 认 书 SPECIFICATIONFOR APPROVAL 客户名称 CustomerName 深羽 客户项目名Customer ProjectName YF09 合立讯项目名 HelixunProject Name YF09 客户编码 CustomerP/N 合立讯料号 HelixunP/N HLX0010-YF09-V2 频段 Band 2400MHz-2500MHz 版本号 Version A0 设计人信息/DesignerInformation 射频工程师 RF Engineer 黄亚飞 电子工程师 EE Engineer 时震浩 结构工程师 ME Engineer 黄亚飞 合立讯审批/HelixunApproval客户批准/CustomerApproval 制作 PreparedBy 审核 CheckedBy 批准 ApprovalBy 审核 CheckedBy 批准 ApprovalBy 签章 Signature 朱增圆 日期 Date 2024-5-13 修订履历/ChangeLog 版本 Version 修订内容 ChangeDescription 责任人 Personin Charge 核准 ApprovalBy 日期 Date ManufacturerBeijing Netac Innovation Technology Development Co.Ltd Address:138-1-3 NO.20 YONG AN ROAD MEN TOU GOU DISTRICT BEIJING CHINA 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 2 目录/Catalogue 序号 No. 项目 Item 页码 PageNo. 1 图纸或实物图片 DrawingorProductImage 3 2 尺寸测量报告 DimensionsTestReport 4 3 射频性能测试报告 RFPerformanceTestReport 5-11 4 可靠性测试报告 ReliabilityTestReport1 12 5 包装文件 PackageDocument 13 6 环保要求 Environmentalrequirements 14 7 安装事宜或其它 InstallWizardorOther 14 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 3 产品图纸或实物图片 DrawingorProductImage 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 4 样品尺寸测量报告 SampleDimensionsTestReport 客户名称 CustomerName 深羽 客户料号 CustomerP/N 合立讯料号 HelixunP/N HLX0010-YF09-V2 测试日期 TestDate 2024-5-13 样品数量 SampleQty. 3 测试人 Inspector 朱增圆 尺寸编号 DimensionNo. 标准 Standard 样品1 Sample1 样品2 Sample2 样品3 Sample3 Pass/NG ①长度 27.52±0.2mm27.50mm27.52mm27.51mm Pass ②宽度 4.15±0.2mm4.15mm4.15mm4.16mm Pass ③厚度 0.2±0.05mm0.21mm0.22mm0.20mm Pass 最终结论 Conclusion PASS 测试人&日期 Inspector&Date 朱增圆2024-5-13 批准&日期 Approval&Date 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 5 射频性能测量报告 RFPerformanceTestReport 客户名称 CustomerName 深羽 项目名称 Project Name YF09 合立讯料号 HelixunP/N HLX0010-YF09- V2 频段 Band 2400MHz-2500MHz 测试日期 TestDate 2024-5-13 测试人 Inspector 朱增圆 天线测试设备简介 AntennaTestEquipmentIntroduction 测试天线输入特性使用AgilentE5071CandAgilent5071C矢量网络分析仪；辐射特性利用 ETS三维近场暗室进行测试，并分别使用CMW500和Agilent5071C进行了分析。暗房的测试坐标如 下: TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5071Cvectornetworkanalyzer; TheradiationpatternoftheantennaaretestedusingtheETSstarlab3DnearfieldAnechoicChamber, andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthedarkroom areasfollows: 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 6 TestSystem SequenceNumberTestItemequipment SparameterVSWRAgilent5071C&Agilent5062A OTATestTRP&TISAgilent 8960E5515C&Agilent4438C&CMW500ETS&SATIMO Gain&EfficiencyGain&Efficiency ETS&SATIMO Agilent5071C 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 7 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 8 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 9 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 10 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 11 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 12 可靠性测试报告 ReliabilityTestReport 客户名称 Customer Name 深羽 客户料号 Customer P/N 合立讯料号 HelixunP/N HLX0010-YF09-V2 测试日期 TestDate 2024-5-13 样品数量 Sample Qty. 3 测试人 Inspector 朱增圆 测试项目 TestItem 要求 Requirement 试验设备 testing equipment 样品1 Sample1 样品2 Sample2 样品3 Sample3 判定 PASS/NG 高温存储 在+85°C条件下暴露24H， 恢复2H后进行测试 恒温恒湿箱 OKOKOKPass 低温存储 在-40°C条件下暴露24H， 恢复2H后进行测试 恒温恒湿箱 OKOKOKPass 高温工作 在+60°C条件下通电工作 24H 恒温恒湿箱 OKOKOKPass 低温工作 在-20°C条件下通电工作 24H 恒温恒湿箱 OKOKOKPass 盐雾试验 (5士0．5)氯化钠、pH 值为6.5～7.2，实验箱 温度(35±2)°C ☑24H□48H 盐雾试验机 OKOKOKPass 连接器铆压 拉拔力 1.13线径≥10N 0.81线径≥8N RG174≥60N RG178≥50N 推拉力计/// / 最终结论 Conclusion Pass 测试人& 日期 Inspector &Date 朱增圆2024-5-13 批准&日期 Approval&D ate 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 13 产品包装规范 PACKINGCRITERION 1、单个产品（以实际包装为准） 2、大PE袋包装（整版/单90pcs）（以实际包装为准） 3、封箱，外箱贴我司生产标签和ROHS标签。（以实际包装为准) A 0 地址：深圳市宝安区西乡街道共乐社区铁仔路九方广场2栋1905TEL：0755-23591525FAX：0755-23591525 深圳合立讯科技有限公司 14 6、环保要求 7、安装事宜或其它 InstallWizardorOther 安装过程： 取1PCS产品，用手撕下FPC背面的离型纸，然后将FPC定位孔位置与外壳定位孔位置（定位筋 位或定位线）对齐，平整的贴附与外壳上，具体位置如下图所示： 安装过程注意事项： ☑粘贴天线后保证FPC完整贴附于外壳； ☑定位孔与外壳定位柱位置对齐； ☑FPC边缘与外壳边缘对其 ☐带端子天线在将端子扣合到主板PCBA端时请首先对其端子，然后垂直扣合； ☐ 拆卸天线端子时需使用工具（如专用撬棍）垂直翘起端子，不可直接拽线拆卸。 MSDS（材料安全数据表） ☑ 提供 ☐ 不提供 ☐ N/A COC(环保协议)☑提供☐不提供☐N/A 环保有害物质云仕技术标准☑提供☐不提供☐N/A 具体环保要求 ☑符合ROHS2.0☑符合REACH☑符合无卤素 ☑符合加州65

No.：BCTC/RF-EMC-005 Page: 1 of 79 Edition：B.2 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2405503987E Applicant: Beijing Netac Innovation Technology Development Co.Ltd Product Name: Wireless Earbuds Test Model: ACE01 Tested Date: 2024-05-29 to 2024-06-05 Issued Date: 2024-06-06 Report No.:BCTC2405503987E No.：BCTC/RF-EMC-005 Page: 2 of 79 Edition：B.2 FCC ID:2BEBP-ACE01 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Wireless Earbuds Trademark: Netac Model/Type Reference: ACE01 Prepared For: Beijing Netac Innovation Technology Development Co.Ltd Address: 138-1-3 NO.20 YONG AN ROAD MEN TOU GOU DISTRICT BEIJING CHINA Manufacturer: Beijing Netac Innovation Technology Development Co.Ltd Address: 138-1-3 NO.20 YONG AN ROAD MEN TOU GOU DISTRICT BEIJING CHINA Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2024-05-29 Sample tested Date: 2024-05-29 to 2024-06-05 Issue Date: 2024-06-06 Report No.: BCTC2405503987E Test Standards FCC Part15.247 ANSI C63.10-2013 Test Results PASS Remark: This is Bluetooth Classic radio test report. Tested by: Approved by: Tang Changyu/ Project Handler Zero Zhou/Reviewer Report No.:BCTC2405503987E No.：BCTC/RF-EMC-005 Page: 3 of 79 Edition：B.2 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 8 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List .......................................................................................................... 9 4.5 Test Mode ........................................................................................................... 10 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test procedure .................................................................................................... 13 6.4 EUT operating Conditions ................................................................................... 13 6.5 Test Result .......................................................................................................... 14 7. Radiated emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test procedure .................................................................................................... 18 7.4 EUT operating Conditions ................................................................................... 19 7.5 Test Result .......................................................................................................... 19 8. Radiated Band Emission Measurement And Restricted Bands Of Operation ..... 23 8.1 Block Diagram Of Test Setup .............................................................................. 23 8.2 Limit .................................................................................................................... 23 8.3 Test procedure .................................................................................................... 24 8.4 EUT operating Conditions ................................................................................... 24 8.5 Test Result .......................................................................................................... 25 9. Spurious RF Conducted Emissions ..................................................................... 26 9.1 Block Diagram Of Test Setup .............................................................................. 26 9.2 Limit .................................................................................................................... 26 9.3 Test procedure .................................................................................................... 26 9.4 Test Result ..........................................................................................................…
