2BEBP-TW03GTW03G Wireless Earbuds

(耳机在未连接状态下) Light off 灯灭 耳机电量低时伴有提示音，请及时放入仓内充电。 When the earbud batter y is low with warning tone. Ple ase put it into the charge c ase t o charge it in time. (When the earbuds are no t c onnected) 128g铜版纸 Auto startup Auto shutdown Press and hold the MFB button on the left and right headphones for about 5 seconds to turn off the device, accompanied by a beep. (When Left and right earbuds are connect, Long press L/R earbud to turn off the related earbud, the another earbud still works normally) 手动开机 长按左右耳机MFB键3秒 耳机开机并伴有提示音 打开充电盒耳机自动开机 自动开机自动关机 长按左右耳机MFB键5秒耳机关机 并伴有提示音.（左右耳机TWS组队状态， 长按任意一边仅单耳关机，另一边耳机仍正常工作） 放入充电盒中关闭充电盒上盖， 耳机自动关机并开始充电 手动关机 按键区域 同时长按左右耳5秒 Hold on left and right ear buds 5s FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

U.S.AgentDesignationforServiceofProcess (ApplicantandU.S.AgentareSeparateParties) TO:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ATTENTION:FCCCertification–Section2.911(d)(7)Information DesignatedU.S.Agent CompanyName:HOPEKCORPORATIONINC Address:4358SBANNOCKSTENGLEWOOD,CO80110UnitedStates FRN:0034562900 ContactName:PeterDavis Tel.:561-235-6113 Email:[email protected] Thisletteristoconfirmthatwe(“theDesignatedU.S.Agent)haveacceptedtheresponsibilitytoactasthe DesignatedU.S.AgentforServiceofProcessasrequiredbysection47CFR2.911(d)(7)onbehalfofthe Applicantnotedbelow. U.S.AgentSignature:PeterDavis Date:June11,2024 Signedby(PrintedName/Title): TheApplicantacknowledgesthattheymustmaintainanagentfornolessthanoneyearafterterminatingall marketingandimportationORtheconclusionofanyCommission-relatedproceedinginvolvingthe equipment.TheapplicantfurtheracknowledgestheirresponsibilitytoinformtheFCCwheneverthe DesignatedU.S.Agentinformationabovechanges. Applicant Companyname:BeijingNetacInnovationTechnologyDevelopmentCo.Ltd FRN:0034670349 GranteeCode:2BEBP FCCID:2BEBP-TW03G ContactName:dongdongxie StreetAddress:138-1-3NO.20YONGANROADMENTOUGOUDISTRICTBEIJINGCHINA TelephoneNo:13612842510 Email:[email protected] ApplicantSignature: Date:June11,2024 Signedby(PrintedName/Title):dongdongxie/Manager

Beijing Netac Innovation Technology Development Co.Ltd 2024.06.25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2BEBP-TW03G [Beijing Netac Innovation Technology Development Co.Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Dongdong xie Beijing Netac Innovation Technology Development Co.Ltd 2024.06.25 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2BEBP-TW03G [Beijing Netac Innovation Technology Development Co.Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Dongdong xie

Beijing Netac Innovation Technology Development Co.Ltd 2024.06.25 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: TW03G Wireless Earbuds Trademark: Netac MODEL : TW03G FCC ID : 2BEBP-TW03G To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Dongdong xie /Manager Contact information / address: 138-1-3 NO.20 YONG AN ROAD MEN TOU GOU DISTRICT BEIJING CHINA

External Photos

Size:10*5mm FCC ID: 2BEBP-TW03G Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID:2BEBP-TW03G Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEEC95.1-1992. and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2003. Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT GFSK 2402 2.05 21 GFSK 2441 1.42 21 GFSK 2480 0.21 21 π/ 4 DQPSK 2402 2.85 21 π/ 4 DQPSK 2441 2.11 21 π/ 4 DQPSK 2480 0.94 21 8DPSK 2402 3.21 21 8DPSK 2441 2.7 21 8DPSK 2480 1.47 21 max possible output power (PK,conducted)：4±1dBm 4.11 dBi logarithmic terms convert to numeric result is nearly 2.58 5dBm=3.16mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.16/5*√2.402=0.98≤3.0 2441MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.16/5*√2.441=0.99≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 3.16/5*√2.48=1.0≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

深圳市和鸣微科技有限公司 Shenzhen HamyWe Technology Co., Ltd. HM3216ANT2450-HM01_V1.0 Page1 of 8 SPECIFICATION Ceramic Antenna 3216 Size 2400-2500 MHz P/N: HM3216ANT2450-HM01 HM3216ANT2450-HM01_V1.0 1. Frequency 2400-2500 MHz 2. Applications For Miniaturized Bluetooth System 3. Dimensions (Unit : mm) 1). Over View : 2). PCB Layout (Unit : mm) 深圳市和鸣微科技有限公司 Shenzhen HamyWe For Miniaturized Bluetooth System mm) (Unit : mm) : 深圳市和鸣微科技有限公司 Technology Co., Ltd. Page2 of 8 mm) 深圳市和鸣微科技有限公司 Shenzhen HamyWe Technology Co., Ltd. HM3216ANT2450-HM01_V1.0 Page3 of 8 4. Evaluation Board Size and Matching Circuits 5. Electrical Characteristics Part Number HM3216ANT2450-HM01 Central Frequency 2450 MHz Bandwidth 100(typ.) MHz V.S.W.R ≤2.0 Peak Gain 4.11 dBi Impedance 50 Ohm Polarization Linear Azimuth Beamwidth Omni-directional 5.6 nH 0.8 pF 深圳市和鸣微科技有限公司 Shenzhen HamyWe Technology Co., Ltd. HM3216ANT2450-HM01_V1.0 Page4 of 8 6. Return Loss (S11) 7. Radiation Pattern & Efficiency Frequency (MHz) 2400 2450 2500 Efficiency (dB) -2.08-1.94-2.15 Efficiency (%) 62 64 61 Gain (dBi) 3.43 4.11 3.67 深圳市和鸣微科技有限公司 Shenzhen HamyWe Technology Co., Ltd. HM3216ANT2450-HM01_V1.0 Page5 of 8 8. Reflow Soldering Standard Condition 9. Packaging and Dimensions
Plastic Tape HM3216ANT2450-HM01_V1.0
Remarks for Package Reserve a length of 150~200mm for the trailer of the carrier and 250~300 mm for the leader of the carrier and further 250mm of cover tape at the leading part of the carrier.
Reel (6000 pcs/Reel)
Storage Period Oxidizable Material, 12 months in vacuum sealed bag, please repack within 168 hours by re-seal the package treatment after using. Storage Temperature Range : <30 degree C, Humidity : <60%RH 深圳市和鸣微科技有限公司 Shenzhen HamyWe Reserve a length of 150~200mm for the trailer of the carrier and 250~300 mm for the leader of the carrier and further 250mm of cover tape at the leading part of the Oxidizable Material, 12 months in vacuum sealed bag, please repack within 168 seal the package treatment after using. Storage Temperature Range : <30 degree C, Humidity : <60%RH 深圳市和鸣微科技有限公司 Technology Co., Ltd. Page6 of 8 Reserve a length of 150~200mm for the trailer of the carrier and 250~300 mm for the leader of the carrier and further 250mm of cover tape at the leading part of the Oxidizable Material, 12 months in vacuum sealed bag, please repack within 168 深圳市和鸣微科技有限公司 Shenzhen HamyWe Technology Co., Ltd. HM3216ANT2450-HM01_V1.0 Page7 of 8 10. Dependability Test Test item Test condition / Test method Specification Solderability IEC 60068-2-58 GB/T2423.28 *Solder bath temperature：240±5°C *Immersion time：2±0.5 sec Solder：Sn96.5Ag3.0Gu0.5 for lead-free. At least 95% of a surface of each terminal electrode must be covered by fresh solder. Leaching (Resistance to dissolution of metallization) JIS C5101 *Solder bath temperature：260±5°C *Leaching immersion time：10±1 sec Solder : Sn96.5 Ag3.0 Gu0.5 for lead-free. Loss of metallization on the edges of each electrode shall not exceed 25%. Resistance to soldering heat IEC 60068-2-58 GB/T2423.28 *Preheating temperature：120~150°C, 1 minute. *Solder temperature：260±5°C *Immersion time：10±1 sec Solder：Sn96.5Ag3.0Gu0.5 for lead-free Measurement to be made after keeping at room temperature for 24±2 hrs. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics at the room temperature. Loss of metallization on the edges of each electrode shall not exceed 25%. Drop Test IEC 60068-2-32 GB/T2423.8 Customer’s specification. *Height：50 cm *Test Surface: Rigid surface of concrete or steel. *Times：6 surfaces for each units；2 times for each side. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics at the room temperature. Vibration IEC 60068-2-6 GB/T 2423.10 *Frequency：10Hz~55Hz~10Hz(1min) *Total amplitude：1.5mm *Test times：6hrs.(Two hrs each in three mutually perpendicular directions) No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics at the room temperature. Adhesive Strength of Termination IEC60068-2-21 GB/T 2423.6 *Pressurizing force： 5N(≦0603)；10N(>0603) *Test time:10±1 sec No remarkable damage or removal of the termination. 深圳市和鸣微科技有限公司 Shenzhen HamyWe Technology Co., Ltd. HM3216ANT2450-HM01_V1.0 Page8 of 8 Bending test IEC 60068-2-21 GB/T 2423.29 The middle part of substrate shall be pressurized by means of the pressurizing rod at a rate of about 1 mm/s per second until the deflection becomes 2mm and then pressure shall be maintained for 10±1 sec. Measurement to be made after keeping at room temperature for 24±2 hours. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics at the room temperature. Temperature cycle IEC60068-2-14 GB/T 2423.22 30 minutes at-40°C±2°C. 10~15 minutes at room temperature. 30minutes at +85°C±2°C. 10~15 minutes at room temperature. Total 100 continuous cycles Measurement to be made after keeping at room temperature for 24±2 hrs. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics at the room temperature. High temperature IEC 60068-2-2 GB/T2423.2 *Temperature：85±2°C. *Test duration：500+24/-0 hours. Measurement to be made after keeping at room temperature for 24±2 hrs. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics. Humidity (steady conditions) IEC60068-2-3 GB/T 2423.3 *Humidity：85±5%R.H. *Temperature：85±2°C. *Time：500+24/-0 hrs. Measurement to be made after keeping at room temperature for 24±2 hrs ※ 200hrs measuring the first data then 300hrs data. No mechanical damage. Electrical specification shall satisfy the descriptions in electrical characteristics at the room temperature. Low temperature IEC 60068-2-1 GB/T2423.1 *Temperature：-40±2°C. *Test duration：500+24/-0 hours Measurement to be made after keeping at room temperature for 24±2 hrs. No mech…
