2BG9T-SCALEV1STCL Smart Scale

Read this manual before using and save for future reference Model：TCL Smart Scale V1 SE TCL Smart Scale Cont ents 3. Before You Begin3 4. Troubleshooting6 5. Battery Advice7 6. Disposal7 1. What's included2 2. Product Overview2 1 •DO NOT use the scale if you have implanted medical devices such as pace- makers. •DO NOT stand on the edge of the scale or jump on it. •DO NOT overload the scale (Max 396lb/180kg/28st). •DO NOT drop the scale or drop objects on it as this may damage the sensors. •DO NOT immerse the scale in water or use chemical cleaning agents. Clean the scale with a slightly damp cloth. •Always place the scale on a hard, dry and flat surface before measurement. •Make sure your feet are dry before stepping on the scale. •DO NOT use the device if damaged. The continuous use of a damaged unit may cause injury or improper results. •Please check the device before each use. •Be careful when using on the wet and slippery surface. WARNING 2 1.What's included 2.Product Overview Smart body scaleManualBatteries ×2 3 Sensor feetBattery coverUnit switch LED screen 3 Note: Read this User guide carefully and completely and retain for future reference. 3.Before You Begin 1.Carefully remove the scale and the batteries from the packaging. Verifythat the included items are present. 2.Check the scale for any visible damage or defects. 3. Read and follow all instructions carefully in this user guide before using your Smart Body Scale. Failure to adhere to these precautions may result in inaccurate readings, damage to the device, or injury. Product Specification: Product Size26 x 26 x 2.4 cm Weight Unitlb / kg Weight Limit11 l b - 396 lb / 5 kg - 180 kg Weight Division0.1 lb / 0.05 kg Power Supply2 AAA Batte ries Operating Temperature5-35 °C Operating Humidity40%-80% RH Inserting the batteries 4 1.Turn the scale over and place it on a smooth, level, clean and flat surface. 2. Open the battery compartment cover by pressing it down and sliding it upward. 3.Insert the 2 AAA batteries, ensuring the positive (+) and negative (-) ends match the polarity markings inside the battery compartment. 4.Close the battery compartment cover and wait until the "0.00" digits are shown on the display. Weight-Only measurement You can also use this scale as a conventional weight-measuring device. Simply step on it to measure your weight without connecting to the Fitdays app. Installing the Fitdays app and pairing 5 This Smart Body Fat Scale pairs with the Fitdays App. Follow the instructions below to set up and connect your scale: 1. Search for"Fitdays"in the App Store or Google Play, or scan the QR code below to download and install the app on your device. 4. At the bott om of the screen,go to Account page and select De vice. Ensure your device meets the following requirements: •iPhone/iPad requires iOS 12.0 or above •Android devices require version 7.0 or above. 2. Enable bluetooth on your smartphone or tablet. 3. Open the Fitdays app then log in or register. Note: When registering, complete your personal information such as gender, birthday, and height to ensure accurate measurements. 5. Tap + Add Device at the bott om of the screen. 6. St ep on the scale briefly to wake it up, then wait until the display shows " 0.00". 7. Select the Bo dy F at Scale icon and follow the on-screen instruc- tions to pair the scale with your device. 6 4.Troubleshooting IssuePossible C auseSolution Display Screen shows Lo Low batte ry Replace the batte ries. Note : Replace all batte ries at the same time. DO N OT mix old and new batte ries. Display Screen shows Err Overloading Ensure the total weight on the scale DOES NOT exceed the maximum weight capacity specified in the user manual. Display Screen shows C Unstable measuring Place and use the scale on a hard, flat, level and clean surface. DO NOT u se the scale on carpets or uneven surfaces. Inaccurate weighing The scale is not placed on a har d, flat and level surface Place and use the scale on a hard, flat and level surface. DO NOT u se the scale on carpets or uneven surfaces. The scale is not calibrate d before weighing. Before each use, ensure the scale is calibrate d to avoid inconsiste nt readings. To calibrate , gently ste p on the scale with one foot until t he readings appear on the display, then ste p off and wait until t he screen shows "0.00" i ndicating the calibration is complete . Standing on the scale unevenly Stand still and evenly bal ance your weight between both feet while on the scale. Failure with app connection Bluetooth is not enabled on your smartphone. Enable Bluetooth in your smartphone settings. The scale is not within the required range for Bluetooth connection. Move your smartphone closer t o the scale to ensure it is within the Bluetooth connection range. The scale is not turned on Ensure the scale is turned on and has sufficient batte ry power. 7 5.Battery Advice 6.Disposal * If the scale is not to be used for long periods, it's recom- mended to remove the battery to avoid damage to the scale due to possiblebattery leakage. * Keep the battery out of reach of children. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local Authority or retailer for recyacling advice. * Waste batteries should not disposed of with household waste. * Please check with your local authority for battery recycling advice. * Do not mix old and new batteries, with different compositions or of different brands in order to prevent possible leakage, explosion. * Do not heat or deform the batteries or expose to fire. The packaging material is recyclable. Please dispose of it in an environmentally friendly manner and take it to a recycling centre. Dispose of the device in an environmentally friendly manner. Dispose of it at a recycling centre for used electrical and electronic devices.You can obtain more information from your local authorities. The batteries should be removed prior to disposal of the devi…

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT External Photos External Photos Page 1 / 3 External Photos Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT External Photos External Photos Page 2 / 3 Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT External Photos External Photos Page 3 / 3 ***** END *****

Label Label location

Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT Internal Photos Internal Photos Page 1 / 4 Internal Photos Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT Internal Photos Internal Photos Page 2 / 4 Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT Internal Photos Internal Photos Page 3 / 4 Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF EUT Internal Photos Internal Photos Page 4 / 4 ANT ***** END *****

Note: This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA, or any agency of the Federal Government. The information marked “#” is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included but no need marked. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. Floor 1, KuMaKe Building, Dongzhou Community, Guangming Street, Guangming District, Shenzhen, Guangdong, China. Tel: +86 755-26503290 Web: www.atc-lab.com Rev:A/4.0(2024/11/01) Page 1 of 6 TR-4-E-R063 TEST REPORT Applicant Name: Shenzhen TCL Smart Home Technology Co., Ltd. Address 702, Building G1, TCL International E City, Shuguang Community, Xili Street, Nanshan District, Shenzhen, China Report Number: 2604S20100E-RF FCC ID: 2BG9T-SCALEV1S Test Standard (s) 47 CFR §2.1093 Sample Description Product Name: TCL Smart Scale Model No.: TCL Smart Scale V1 SE Trade Mark: TCL Date Received: 2026-04-24 Report Date: 2026-05-06 Test Result: The EUT complied with the standards above. Prepared and Checked By: Approved By: Roger Ling Bob.Liao EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: 2604S20100E-RF Rev:A/4.0(2024/11/01) Page 2 of 6 TR-4-E-R051 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ................................................................................................................ 3 GENERAL INFORMATION ............................................................................................................................ 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................ 4 OBJECTIVE ................................................................................................................................................... 4 TEST FACILITY .............................................................................................................................................. 4 RF EXPOSURE .............................................................................................................................................. 5 APPLICABLE STANDARD ................................................................................................................................. 5 RESULT ........................................................................................................................................................ 5 EXHIBIT A-EUT PHOTOGRAPHS ................................................................................................................ 6 Shenzhen Accurate Technology Co., Ltd. Report No.: 2604S20100E-RF Rev:A/4.0(2024/11/01) Page 3 of 6 TR-4-E-R051 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision Rev.00 2604S20100E-RF Original Report 2026-05-06 Shenzhen Accurate Technology Co., Ltd. Report No.: 2604S20100E-RF Rev:A/4.0(2024/11/01) Page 4 of 6 TR-4-E-R051 GENERAL INFORMATION Product Description for Equipment under Test (EUT) Product Name TCL Smart Scale Tested Model TCL Smart Scale V1 SE Voltage Range # DC 3V from battery (2 AAA Alkaline Batteries) Frequency Range BLE 1M: 2402-2480MHz Maximum Conducted Output Power(Peak) (actual test result) -0.66 dBm Antenna Specification # Internal Antenna, Gain: -2.17 dBi (It is provided by the manufacturer.) Sample/EUT Status Good condition Objective This test report is in accordance with Part 2-Subpart J, Radiofrequency Radiation Exposure of the Federal Communication Commission rules. The tests were performed in order to determine compliance with FCC §2.1093 rules. Test Facility The test site used by Shenzhen Accurate Technology Co., Ltd. to collect test data is located on the Floor 1, KuMaKe Building, Dongzhou Community, Guangming Street, Guangming District, Shenzhen, Guangdong, China. Accredited by American Association for Laboratory Accreditation (A2LA).The Certificate Number is 4297.01. Shenzhen Accurate Technology Co., Ltd. Report No.: 2604S20100E-RF Rev:A/4.0(2024/11/01) Page 5 of 6 TR-4-E-R051 RF EXPOSURE Applicable Standard According to FCC §2.1093, systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. According to KDB 447498 D01 General RF Exposure Guidance v06, The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where 1. f(GHz) is the RF channel transmit frequency in GHz. 2. Power and distance are rounded to the nearest mW and mm before calculation. 3. The result is rounded to one decimal place for comparison. 4. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test Exclusion. Result For worst case: Frequency (MHz) Tune-Up Conducted Output Power # (dBm) Tune-Up Conducted Output Power # (mW) Distance (mm) Calculated Value Threshold (1-g SAR) SAR Test Exclusion 2402-2480 -0.5 0.89 5 0.3 3 Yes Note: The tune-up conducted power is declared by the applicant. Result: No SAR test is required. Shenzhen Accurate Technology Co., Ltd. Report No.: 2604S20100E-RF Rev:A/4.0(2024/11/01) Page 6 of 6 TR-4-E-R051 EXHIBIT A-EUT PHOTOGRAPHS Please refer to the Attachment No.1 2604S20100E-RF EUT External Photos and Attachment No.…

Text truncated - open the document above for the full version.

Client： Guangdong Welland Technology Co., Ltd. Project： FG2317WB Antenna standard： BT Manufacturer：Shenzhen DBT Communications Equipment Co.,Ltd. Address：8th Building, Phase 2 of Nanshan Cloud Valley, Taoyuan Street, Nanshan District, Shenzhen, China Antenna Testing Report OTA-800 Brand：ETS Frequency range：370MHz-8.5GHz Features：passive、active test；G net、C net、 2G/3G/4G，WIFI and BT， TRP、TIS test. 5071C Brand：Agilent Frequency range：9KHz-8.5GHz Features：2G/3G/4G/BT/WIFI antenna comprehensive passive test。 8960 Brand：Agilent Frequency range：292MHz-2700GHz Features：2G/3G avtive test。 CMW500 Brand：Rohde & Schwarz Frequency range：70KHz-6GHz Features：2G/3G/4G/BT/WIFI/NB-Lot antenna comprehensive passive test。 Antenna RF Module E1 E2 E3 E4 ElementMAINGPS/WIFI /BT AUX E1(0201)N/A E2(0201)1.2pF E3(0201)10pF E4(0201)0Ω antenna position antenna position Electrical Parameter Frequency Range (MHz)2400~2500 VSWR≤7.0 Input Impedance(Ω)50 Gain(dBi)-2.17 Polarization(°)vertical Max power(W)10 Antenna TypePCB Antenna Working Temperature(°C)-40~+80

Note: This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA, or any agency of the Federal Government. The information marked “#” is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included but no need marked. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. Floor 1, KuMaKe Building, Dongzhou Community, Guangming Street, Guangming District, Shenzhen, Guangdong, China. Tel: +86 755-26503290 Web: www.atc-lab.com Rev:A/4.0(2024/11/01) Page 1 of 48 TR-4-E-R015 TEST REPORT Applicant Name: Shenzhen TCL Smart Home Technology Co., Ltd. Address: 702, Building G1, TCL International E City, Shuguang Community, Xili Street, Nanshan District, Shenzhen, China Report Number: 2604S20100E-RF-00A FCC ID: 2BG9T-SCALEV1S Test Standard (s) FCC PART 15.247 Sample Description Product Name: TCL Smart Scale Model No.: TCL Smart Scale V1 SE Trade Mark: TCL Date Received: 2026-04-24 Report Date: 2026-05-06 Test Result: The EUT complied with the standards above. Prepared and Checked By: Approved By: Roger Ling Bob.Liao EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: 2604S20100E-RF-00A Rev:A/4.0(2024/11/01) Page 2 of 48 TR-4-E-R015 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ................................................................................................................ 4 GENERAL INFORMATION ............................................................................................................................ 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ........................................................................ 5 OBJECTIVE ................................................................................................................................................... 6 TEST METHODOLOGY .................................................................................................................................... 6 TEST FACILITY .............................................................................................................................................. 6 MEASUREMENT UNCERTAINTY ....................................................................................................................... 6 SYSTEM TEST CONFIGURATION ............................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ......................................................................................................... 7 EUT EXERCISE SOFTWARE AND POWER LEVEL # ............................................................................................ 7 SPECIAL ACCESSORIES AND EQUIPMENT MODIFICATIONS ............................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS ....................................................................................................... 7 EXTERNAL I/O CABLE .................................................................................................................................... 7 BLOCK DIAGRAM OF TEST SETUP .................................................................................................................. 8 SUMMARY OF TEST RESULTS ................................................................................................................... 9 TEST EQUIPMENT LIST ............................................................................................................................. 10 ANTENNA REQUIREMENT ........................................................................................................................ 11 APPLICABLE STANDARD ............................................................................................................................... 11 ANTENNA CONNECTOR CONSTRUCTION ....................................................................................................... 11 RADIATED SPURIOUS EMISSIONS .......................................................................................................... 12 APPLICABLE STANDARD ............................................................................................................................... 12 EUT SETUP ................................................................................................................................................ 12 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .................................................................................. 13 TEST PROCEDURE ...................................................................................................................................... 14 CALCULATION ............................................................................................................................................. 14 TEST DATA ................................................................................................................................................. 15 6 dB EMISSION BANDWIDTH & OCCUPIED BANDWIDTH ..................................................................... 33 APPLICABLE STANDARD ............................................................................................................................... 33 TEST PROCEDURE ...................................................................................................................................... 33 TEST DATA .......................................................…

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF Test Photos Test Photos Page 1 / 2 Radiated Spurious Emissions Test View (9kHz-30MHz) Radiated Spurious Emissions Test View (30MHz- 1GHz) Shenzhen Accurate Technology Co., Ltd. No.: 2604S20100E-RF Test Photos Test Photos Page 2 / 2 Radiated Spurious Emissions Test View (1GHz-18GHz) Radiated Spurious Emissions Test View (18GHz-25GHz) ***** END *****
