EUROFINS ELECTRICAL TESTING SERVICE (SHENZHEN) CO., LTD. RADIO TEST - REPORT FCC Compliance Test Report for Product name: CenterHub FCC ID: 2BU4T-TC0235CC44U Test Report Number: EFGX26060387-IE-11-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Phone: +86-0755-829118671 Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8 Fax: +86-0755-82910749 Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Page 1 of 30 Content 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of applicant 4 1.4 Details of manufacturer 4 1.5 Application details 5 1.6 Test item 5 1.7 Test standards 6 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 7 2.3 Measurement uncertainty 7 2.4 Test mode 8 2.5 Test equipment utilized 9 2.6 Auxiliary equipment used during test 10 2.7 Test software information 10 2.8 Test setup 11 2.9 Test results 13 3 Technical Requirement 14 3.1 Conducted emission AC power port 14 3.2 Duty cycle 15 3.3 6dB bandwidth 16 3.4 99% Occupied Bandwidth 17 3.5 26 dB Bandwidth 18 3.6 Maximum Conducted Output Power 19 3.7 Power spectral density 24 3.8 Transmitter radiated spurious emissionsr 26 4 Test Setup Photos 30 5 External Photo 30 6 Internal Photos 30 7 Appendix 30 Test Report No.: EFGX2606060387-IE-11-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 3 of 30 1 General Information 1.1 Notes The results of this test report relate exclusively to the item tested as specified in chapter “Description of test item” and are not transferable to any other test items. Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. is not responsible for any generalisations and conclusions drawn from this report. Any modification of the test item can lead to invalidity of test results and this test report may therefore be not applicable to the modified test item. The test report may only be reproduced or published in full. Reproducing or publishing extracts of the report requires the prior written approval of the Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. This document is subject to the General Terms and Conditions and the Testing and Certification System of Eurofins Electrical Testing Service (Shenzhen) Co., Ltd., available on request or accessible at www.eurofins.com. Operator: 2026-08-11 Bruce Zheng / Project Engineer Date Eurofins-Lab. Name / Title Signature Technical responsibility for area of testing: 2026-08-11 Albert Xu / Lab Manager Date Eurofins-Lab. Name / Title Signature Test Report No.: EFGX2606060387-IE-11-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 4 of 30 1.2 Testing laboratory Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. 1st Floor, Building 2, Chungu, Meisheng Huigu Science and Technology Park, No. 83 Dabao Road, Bao'an District, Shenzhen. P.R.China. Telephone : +86-755-82911867 Fax : +86-755-82910749 The Laboratory has passed the Accreditation by the American Association for Laboratory Accrediation (A2LA). The Accreditation number is 5376.01 The Laboratory has been listed by industry Canada to perform electromagnetic emission measurements, The CAB identifier is CN0088 1.3 Details of applicant Name : 3Com USA Inc. Address : 2200 LAURELWOOD RD SANTA CLARA, CA 95054 Telephone : ./. Fax : ./. 1.4 Details of manufacturer Name : 3Com USA Inc. Address : 2200 LAURELWOOD RD SANTA CLARA, CA 95054 Telephone : ./. Fax : ./. Test Report No.: EFGX2606060387-IE-11-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86-755-82911867, Fax : +86-755-82910749 Page 5 of 30 1.5 Application details Date of receipt of application : 2026-06-14 Date of receipt of test item : 2026-06-14 Date of test : 2026-06-14 to 2026-08-10 Date of issue : 2026-08-11 1.6 Test item Product type : CenterHub Model name : HUB-16C1, XH-14S38M0-A, HUB-XXXXCXXXX-XXXXXXXX-XXXXXXXX, XH-1XXXXXXXX-XXXXXXXX-XXXXXXXX (where X may be '0-9' 'A-Z' 'a-z' '-' or blank; '-' is option) Brand : 3COM Sample ID : 260720-14-001, 260720-14-002 Serial number : ./. Ratings : DC 12V=3A; USB Output:5V=2A Test voltage : AC 120V, 60Hz for power supply. Hardware Version : B1 Software / Firmware Version : GSHA-B5102.1.7.260813 RadioTechnical data Radio Tech. : WLAN (IEEE 802.11 a/n/ac/ax) Frequency Range : 5 180 MHz ~ 5 240 MHz (U-NII-1 Band) 5 745 MHz ~ 5 825 MHz (U-NII-3 Band) Modulation : OFDM, OFMDA Antenna type : Internal antenna Antenna gain : 3.50 dBi for U-NII-1 Band 3.50 dBi for U-NII-3 Band Additional information : All models are identical except for the model name. Therefore full tests were performed on model HUB-16C1 in this report. 1. Power supply’s information: No. Model Manufacturer Technological data 1 DCT36W120300US-A3 Zhuzhou Dachuan Electronic Technology Co., Ltd Input: 100-240V, 50/60Hz 1.0A Output: 12V,3.0A The above sample(s) and sample information was/were submitted and identified on behalf of the applicant. Eurofins assures objectivity and impartiality of the test, and fulfills the obligation of confidentiality for applicant’s commercial infor- mation and technical documents. Test Report No.: EFGX2606060387-IE-11-E03 Eurofins Electrical Testing Service (Shenzhen) Co., Ltd. Room 20 of 2/F., 1/F., Building 2, Spring Block & Room 102, Building 8, Autumn Block, Meishenghuigu Innovation Park, No.83, Dabao Road…

Text truncated - open the document above for the full version.

EFGX26060387-IE-11-Setup Photos 1 / 2 EFGX26060387-IE-11-Setup Photos 2 / 2

规格承认书 SPECIFICATION FOR APPROVAL 日期 Date 2024/12/05 编号 File No 24120501 版本 Revision 1.0 客户 CUSTOMER: 宇视 客户料号 CUSTOMER NO: homebase 品名 PARTNAME: HomebaseAntenna 供方料号 SUPPLIERNO: YJH01.059.035.301A 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 SUPPLIERNO: YJH01.059.035.301A 送样日期Date: 送样数量Q'TY: 客户确认CUSTOMER APPROVED BY APPROVALCHIEFSUPERVISOR 供方确认SUPPLIER SIGNATURE APPROVALCHECKDESIGN ChenGuoqiangXieLiChenXingyi YJ-RD-F04-A 承认书项目表 NO . 内容 （Contents） 页数 （Number of Page） 页码 （Page Code） 1 承认书封面（Spec Cover） 11 2 承认书项目表（ Spec Item ） 12 3 工程成品图（ Drawing） 13 4 包装图（ Package Drawing） 14 5 天线规格（Antenna Specification） 35 ~ 7 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 5 天线规格（Antenna Specification） 35 ~ 7 6 S参数测试（S Parameter ） 48 ~ 11 7 无源测试（Passive Test ） 512 ~ 16 8 方向图（Radiation Pattern ） 817 ~ 24 9 有源测试（Active Test ） 225 ~ 26 10 天线装配图（Antenna Profile） 227 ~ 28 11 材质证明（Material Certificate ） 3229 ~ 60 12 RoHS报告（RoHSTest Report ） **** 13N/AN/AN/A 天线规格-WiFi2.4G Antenna Specification Electrical Properties Frequency 2.4-2.5GHz Impedance50 Ohm Nominal V.S.W.R2.0 Max Gain WiFi2.4G -1: 3.3 dBi WiFi2.4G -2: 3.1 dBi RadiationOmni-directional 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 PolarizationLinear Physical Properties Connector 1代IPEX Cable TypeO.D.1.13mm Cable Length75mm Cable Color WiFi2.4G -1: Gray WiFi2.4G -2: Black Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity -20 ~ +70 °C/ <70% 天线规格-WiFi5G Antenna Specification Electrical Properties Frequency 5.15-5.85GHz Impedance50 Ohm Nominal V.S.W.R2.0 Max Gain 3.7 dBi RadiationOmni-directional 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 PolarizationLinear Physical Properties Connector 1代IPEX Cable TypeO.D.1.13mm Cable Length75mm Cable Color Black Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity -20 ~ +70 °C/ <70% 天线规格-433MHz Antenna Specification Electrical Properties Frequency 433MHz Impedance50 Ohm Nominal V.S.W.R4.5 Max Gain -5.9 dBi RadiationOmni-directional 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 PolarizationLinear Physical Properties Connector 1代IPEX Cable TypeO.D.1.13mm Cable Length75mm Cable Color Gray Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity -20 ~ +70 °C/ <70% Agilent E5071C S Antenna Performance Test 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 S Parameter Test // WiFi2.4G-1 Antenna Agilent E5071C S 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 S Parameter Test // WiFi2.4G-2 Antenna Agilent E5071C S 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 S Parameter Test // WiFi5G Antenna Agilent E5071C S 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 S Parameter Test // 433MHz Antenna Antenna Passive Test Z Y X 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Y X Z Passive Test For WiFi2.4G-1Antenna Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 2400 58.5 -2.3 2.8 2410 59.4 -2.3 2.3 2420 60.4 -2.2 2.3 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 2430 60.0 -2.2 2.4 2440 59.0 -2.3 2.4 2450 56.5 -2.5 2.0 2460 55.6 -2.6 2.1 2470 56.6 -2.5 2.3 2480 56.5 -2.5 3.0 2490 59.4 -2.3 3.3 2500 58.4 -2.3 3.2 Passive Test For WiFi2.4G-2Antenna Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 2400 61.8 -2.1 2.4 2410 64.1 -1.9 2.3 2420 65.5 -1.8 2.4 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 2430 65.2 -1.9 2.4 2440 64.7 -1.9 2.0 2450 63.0 -2.0 1.6 2460 62.7 -2.0 1.9 2470 63.2 -2.0 2.4 2480 63.3 -2.0 2.4 2490 62.5 -2.0 2.5 2500 62.3 -2.1 3.1 Passive Test For WiFi5GAntenna Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 5150 51.1 -2.9 3.1 5200 52.2 -2.8 3.5 5250 49.8 -3.0 3.4 5300 49.9 -3.0 3.7 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 5350 46.1 -3.4 2.8 5400 53.5 -2.7 3.3 5450 50.7 -3.0 2.4 5500 45.4 -3.4 2.4 5550 52.4 -2.8 2.9 5600 48.1 -3.2 3.1 5650 53.7 -2.7 3.3 5700 51.8 -2.9 3.5 5750 53.6 -2.7 3.5 5800 47.6 -3.2 2.3 5850 50.8 -2.9 3.0 Passive Test For 433MHzAntenna Freq (MHz) Effi (%) Effi (dB) Gain (dBi) 430 7.5 -11.2 -6.0 431 8.0 -10.9 -5.8 432 8.3 -10.8 -5.8 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 433 8.8 -10.5 -5.9 434 9.0 -10.5 -5.9 435 9.6 -10.2 -5.5 436 8.7 -10.6 -5.6 437 8.5 -10.7 -5.6 438 8.4 -10.8 -5.7 439 8.2 -10.8 -5.9 440 8.0 -10.9 -5.9 Radiation Pattern For WiFi2.4G-1 Antenna （ 2450MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi2.4G-2 Antenna （ 2450MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi5G Antenna （ 5550MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For 433MHz Antenna （ 433MHz ） 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Radiation Pattern For WiFi2.4G-1 Antenna Phi 0° 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Phi 90° Theta 90° Radiation Pattern For WiFi2.4G-2 Antenna Phi 0° 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Phi 90° Theta 90° Radiation Pattern For WiFi5G Antenna Phi 0° 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Phi 90° Theta 90° Radiation Pattern For 433MHz Antenna Phi 0° 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Phi 90° Theta 90° Antenna Active Test Z Y X 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Y X Z Active Test For WiFiAntenna BandChannel Data Rate TRP Data Rate TIS WIFI 2.4G-1 802.11b 1 11Mbps 17.0 11Mbps -80.0 -81.6 17.5 6 11 17.9 -83.5 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 WIFI 2.4G-2 802.11b 1 11Mbps 17.2 11Mbps -78.3 -81.5 18.9 6 11 19.6 -85.9 WIFI 5G 802.11a 36 54Mbps 11.7 54Mbps -73.7 100 14.3 -73.4 165 15.1 -72.3 Device 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 Antenna 同轴线需用扎带固定 WiFi5G ANT433MHz ANT 东莞市长安镇沙头社区木鱼路59号Tel:0769-82586086 Fax:0769-82586086 WiFi2.4G-1 ANTWiFi2.4G-2 ANT 化学品安全技术说明书MSDS 第一部分、化学品物品及企业标识Part1IdentificationsofchemicalsandManufacturer 化学品物品名称Chemicalname: 液态感光阻焊油墨YSR-900 Liquidphotosensitivesoldermask YSR-900 生效日期Effectivedate:2022.7.1 企业名称Manufacturername: 肇庆超阳电子科技有限公司 ZhaoqingchaoyangElectronictechnologyCo.,Ltd 地址Address： 肇庆市高要区蚬岗镇工业区 Xian’gangIndustrialZone,Gaoyaodistrict,Zhaoqingcity 电话Tel:0758-8384062 传真Fax:0758-8384063 e…

Text truncated - open the document above for the full version.

EFGX26060387-IE-11-E03 Appendix 140 / 151 Mode: AX20 Channel: 5745 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5700.8750 36.98 51.88 14.90 105.45 53.57 150 40 PK Vertical PASS 2 5724.1250 48.77 63.39 14.62 120.21 56.82 150 21 PK Vertical PASS 3 5730.8750 59.48 74.37 14.89 122.20 47.83 150 93 PK Vertical PASS 4 5769.5000 41.29 55.90 14.61 122.20 66.30 150 121 PK Vertical PASS 5 5775.1250 40.53 55.21 14.68 122.20 66.99 150 21 PK Vertical PASS 6 5832.8750 38.27 52.84 14.57 122.20 69.36 150 193 PK Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 141 / 151 Mode: AX20 Channel: 5745 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5696.7500 38.23 53.07 14.84 102.81 49.74 150 341 PK Horizontal PASS 2 5725.2500 48.61 63.28 14.67 122.20 58.92 150 360 PK Horizontal PASS 3 5730.8750 63.46 78.35 14.89 122.20 43.85 150 18 PK Horizontal PASS 4 5760.8750 57.18 71.91 14.73 122.20 50.29 150 360 PK Horizontal PASS 5 5772.8750 46.36 60.97 14.61 122.20 61.23 150 36 PK Horizontal PASS 6 5800.6250 38.37 52.84 14.47 122.20 69.36 150 331 PK Horizontal PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 142 / 151 Mode: AX20 Channel: 5785 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5684.3750 38.01 52.24 14.23 93.68 41.44 150 161 PK Vertical PASS 2 5759.7500 42.39 57.11 14.72 122.20 65.09 150 273 PK Vertical PASS 3 5768.0000 50.03 64.60 14.57 122.20 57.60 150 232 PK Vertical PASS 4 5809.6250 45.13 59.50 14.37 122.20 62.70 150 0 PK Vertical PASS 5 5834.7500 39.11 53.71 14.60 122.20 68.49 150 90 PK Vertical PASS 6 5862.5000 37.85 52.68 14.83 108.70 56.02 150 232 PK Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 143 / 151 Mode: AX20 Channel: 5785 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5704.2500 38.36 53.19 14.83 106.39 53.20 150 295 PK Horizontal PASS 2 5755.6250 43.55 58.19 14.64 122.20 64.01 150 342 PK Horizontal PASS 3 5769.1250 58.37 72.98 14.61 122.20 49.22 150 4 PK Horizontal PASS 4 5811.8750 45.94 60.43 14.49 122.20 61.77 150 173 PK Horizontal PASS 5 5827.6250 42.07 56.63 14.56 122.20 65.57 150 14 PK Horizontal PASS 6 5848.6250 39.75 54.43 14.68 122.20 67.77 150 58 PK Horizontal PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 144 / 151 Mode: AX20 Channel: 5825 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5720.7500 38.91 53.48 14.57 112.51 59.03 150 251 PK Vertical PASS 2 5787.1250 38.22 52.89 14.67 122.20 69.31 150 98 PK Vertical PASS 3 5811.1250 55.32 69.78 14.46 122.20 52.42 150 24 PK Vertical PASS 4 5846.0000 45.83 60.58 14.75 122.20 61.62 150 122 PK Vertical PASS 5 5857.2500 41.31 56.06 14.75 110.17 54.11 150 345 PK Vertical PASS 6 5896.2500 38.10 53.11 15.01 89.45 36.34 150 134 PK Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 145 / 151 Mode: AX20 Channel: 5825 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5709.5000 37.10 51.54 14.44 107.86 56.32 150 321 PK Horizontal PASS 2 5737.6250 37.81 52.61 14.80 122.20 69.59 150 256 PK Horizontal PASS 3 5804.0000 48.11 62.54 14.43 122.20 59.66 150 299 PK Horizontal PASS 4 5846.0000 49.93 64.68 14.75 122.20 57.52 150 217 PK Horizontal PASS 5 5862.8750 40.92 55.76 14.84 108.59 52.83 150 324 PK Horizontal PASS 6 5884.6250 37.43 52.33 14.90 98.06 45.73 150 96 PK Horizontal PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 146 / 151 Mode: AX40 Channel: 5755 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5670.1250 37.82 52.12 14.30 83.15 31.03 150 281 PK Vertical PASS 2 5710.2500 40.18 54.58 14.40 108.07 53.49 150 8 PK Vertical PASS 3 5720.0000 49.22 63.81 14.59 110.80 46.99 150 8 PK Vertical PASS 4 5786.7500 44.14 58.81 14.67 122.20 63.39 150 310 PK Vertical PASS 5 5802.8750 42.52 56.94 14.42 122.20 65.26 150 292 PK Vertical PASS 6 5838.1250 38.39 53.05 14.66 122.20 69.15 150 76 PK Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 147 / 151 Mode: AX40 Channel: 5755 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5695.6250 42.32 57.11 14.79 101.98 44.87 150 327 PK Horizontal PASS 2 5720.7500 47.79 62.36 14.57 112.51 50.15 150 4 PK Horizontal PASS 3 5734.2500 64.74 79.63 14.89 122.20 42.57 150 21 PK Horizontal PASS 4 5779.2500 54.78 69.44 14.66 122.20 52.76 150 360 PK Horizontal PASS 5 5795.3750 48.70 63.24 14.54 122.20 58.96 150 30 PK Horizontal PASS 6 5818.6250 40.60 55.14 14.54 122.20 67.06 150 4 PK Horizontal PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 148 / 151 Mode: AX40 Channel: 5795 MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 5689.6250 37.53 52.08 14.55 97.56 45.48 150 145 PK Vertical PASS 2 5717.3750 37.49 51.98 14.49 110.07 58.09 150 178 PK Vertical PASS 3 5761.2500 46.58 61.30 14.72 122.20 60.90 …

Text truncated - open the document above for the full version.

EFGX26060387-IE-11-E03 Appendix 94 / 151 Appendix F: Unwant Emissions Test Result Mode: AX Channel: 5180MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 46.4900 32.02 16.04 -15.98 40.00 23.96 150 80 PK Vertical PASS 2 76.9238 32.59 13.00 -19.59 40.00 27.00 150 340 PK Vertical PASS 3 129.7888 36.13 19.22 -16.91 43.50 24.28 150 40 PK Vertical PASS 4 190.1713 38.05 19.54 -18.51 43.50 23.96 150 220 PK Vertical PASS 5 375.0775 44.46 30.30 -14.16 46.00 15.70 150 330 PK Vertical PASS 6 625.0950 37.85 29.27 -8.58 46.00 16.73 150 290 PK Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 95 / 151 Mode: AX Channel: 5180MHz Test Graph Suspected Data List NO. Frequency [MHz] Reading [dBμV/ m] Level [dBμV/m] Factor [dB] Limit [dBμV/m] Margin [dB] Height [cm] Angle [°] Det Polarity Verdict 1 48.4300 30.84 14.80 -16.04 40.00 25.20 150 60 PK Horizontal PASS 2 133.0625 36.83 19.90 -16.93 43.50 23.60 150 20 PK Horizontal PASS 3 307.5413 38.60 23.35 -15.25 46.00 22.65 150 320 PK Horizontal PASS 4 368.0450 39.72 25.30 -14.42 46.00 20.70 150 90 PK Horizontal PASS 5 500.0863 36.02 24.65 -11.37 46.00 21.35 150 50 PK Horizontal PASS 6 625.0950 37.55 28.97 -8.58 46.00 17.03 150 160 PK Horizontal PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 96 / 151 Mode: A Channel: 5180 MHz Test Graph Final Data List NO. Frequency [MHz] Factor [dB] PK Reading [dBμV/ m] PK Value [dBμV/m] PK Limit [dBμV/m] PK Margin [dB] AV Reading [dBμV/ m] AV Value [dBμV/m] AV Limit [dBμV/m] AV Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 1374.4000 -0.35 46.01 45.66 74.00 28.34 43.21 42.86 54.00 11.14 150 61 Vertical PASS 2 3764.8000 8.47 41.37 49.84 74.00 24.16 38.91 47.38 54.00 6.62 150 356 Vertical PASS 3 7999.6600 -7.77 62.38 54.61 68.23 13.62 56.40 48.63 54.00 5.37 150 200 Vertical PASS 4 9599.6900 -4.75 52.36 47.61 68.23 20.62 50.07 45.32 54.00 8.68 150 104 Vertical PASS 5 11199.720 0 -2.44 57.4 54.96 74.00 19.04 52.08 49.64 54.00 4.36 150 226 Vertical PASS 6 15530.110 0 2.17 49.43 51.60 74.00 22.40 42.57 44.74 54.00 9.26 150 4 Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 97 / 151 Mode: A Channel: 5180 MHz Test Graph Final Data List NO. Frequency [MHz] Factor [dB] PK Reading [dBμV/ m] PK Value [dBμV/m] PK Limit [dBμV/m] PK Margin [dB] AV Reading [dBμV/ m] AV Value [dBμV/m] AV Limit [dBμV/m] AV Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 3208.6000 6.56 40.5 47.06 68.23 21.17 35.54 42.10 54.00 11.90 150 143 Horizonta l PASS 2 3828.4000 8.72 41.27 49.99 74.00 24.01 39.48 48.20 54.00 5.80 150 296 Horizonta l PASS 3 7046.8400 -9.30 53.7 44.40 68.23 23.83 51.10 41.80 54.00 12.20 150 168 Horizonta l PASS 4 7999.6600 -7.77 61.42 53.65 68.23 14.58 57.10 49.33 54.00 4.67 150 253 Horizonta l PASS 5 11199.720 0 -2.44 55.87 53.43 74.00 20.57 52.27 49.83 54.00 4.17 150 310 Horizonta l PASS 6 15313.560 0 3.23 47.61 50.84 68.23 17.39 41.67 44.90 54.00 9.10 150 82 Horizonta l PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 98 / 151 Mode: A Channel: 5200 MHz Test Graph Final Data List NO. Frequency [MHz] Factor [dB] PK Reading [dBμV/ m] PK Value [dBμV/m] PK Limit [dBμV/m] PK Margin [dB] AV Reading [dBμV/ m] AV Value [dBμV/m] AV Limit [dBμV/m] AV Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 3162.4000 6.34 40.1 46.44 68.23 21.79 37.67 44.01 54.00 9.99 150 267 Vertical PASS 2 3874.6000 8.97 40.63 49.60 74.00 24.40 38.56 47.53 54.00 6.47 150 338 Vertical PASS 3 6589.3400 -10.11 54.9 44.79 68.23 23.44 49.81 39.70 54.00 14.30 150 146 Vertical PASS 4 7999.6600 -7.77 62.37 54.60 68.23 13.63 57.06 49.29 54.00 4.71 150 199 Vertical PASS 5 11199.720 0 -2.44 57.2 54.76 74.00 19.24 52.21 49.77 54.00 4.23 150 225 Vertical PASS 6 15591.110 0 2.99 48.97 51.96 74.00 22.04 45.99 48.98 54.00 5.02 150 281 Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 99 / 151 Mode: A Channel: 5200 MHz Test Graph Final Data List NO. Frequency [MHz] Factor [dB] PK Reading [dBμV/ m] PK Value [dBμV/m] PK Limit [dBμV/m] PK Margin [dB] AV Reading [dBμV/ m] AV Value [dBμV/m] AV Limit [dBμV/m] AV Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 3731.8000 8.25 40.93 49.18 74.00 24.82 38.69 46.94 54.00 7.06 150 5 Horizonta l PASS 2 4480.6000 11.21 38.71 49.92 68.23 18.31 36.21 47.42 54.00 6.58 150 316 Horizonta l PASS 3 7999.6600 -7.77 61.49 53.72 68.23 14.51 57.50 49.73 54.00 4.27 150 250 Horizonta l PASS 4 9647.8800 -4.34 53.33 48.99 68.23 19.24 50.72 46.38 54.00 7.62 150 166 Horizonta l PASS 5 11199.720 0 -2.44 55.76 53.32 74.00 20.68 52.07 49.63 54.00 4.37 150 312 Horizonta l PASS 6 15600.260 0 3.18 49.7 52.88 74.00 21.12 44.59 47.77 54.00 6.23 150 244 Horizonta l PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 100 / 151 Mode: A Channel: 5240 MHz Test Graph Final Data List NO. Frequency [MHz] Factor [dB] PK Reading [dBμV/ m] PK Value [dBμV/m] PK Limit [dBμV/m] PK Margin [dB] AV Reading [dBμV/ m] AV Value [dBμV/m] AV Limit [dBμV/m] AV Margin [dB] Height [cm] Angle [°] Polarity Verdict 1 3800.8000 8.50 41.68 50.18 74.00 23.82 38.56 47.06 54.00 6.94 150 153 Vertical PASS 2 4720.6000 11.71 39.37 51.08 74.00 22.92 37.58 49.29 54.00 4.71 150 28 Vertical PASS 3 7999.6600 -7.77 61.5 53.73 68.23 14.50 57.66 49.89 54.00 4.11 150 205 Vertical PASS 4 9599.6900 -4.75 51.83 47.08 68.23 21.15 50.32 45.57 54.00 8.43 150 116 Vertical PASS 5 11199.110 0 -2.44 57.14 54.70 74.00 19.30 51.69 49.25 54.00 4.75 150 116 Vertical PASS 6 15725.920 0 2.26 54.35 56.61 74.00 17.39 45.91 48.17 54.00 5.83 150 252 Vertical PASS Note:(1)Level=Reading+Factor (2)Margin=Limit-Level EFGX26060387-IE-11-E03 Appendix 101 / 151 Mode: A Channel: 5240 MH…
