A29-REWCASEVRECEIVER FOR AIRCHOC WIRELESS APPLICATION

NOTREW-US.doc 1 December 6th, 2012 Produced on: December 6th, 2012 By: DESIGN OFFICE Checked on: By: BOISLEUX.M Signature: USER MANUEL Revision Level: F1 NOTREW-US Date: December 6th, 2012 HEAD OFFICE- Standard Industrie : 139-141 rue du Luxembourg-BP50207 59054 ROUBAIX CEDEX 1- FRANCE +33 (0)3 20 28 32 32 / @ : [email protected] NOTREW-US.doc 2 December 6th, 2012 CONTENTS 1 Principle of Airchoc Wireless page 3 2 Receiver unit characteristics page 4 2-1 Explanation of the symbol on the label Page 4 3 Receiver unit Batteries page 4 3-1 Recommandation page 4 3-2 Device Recycling (environment) page 4 4 Warranty page 4 5 Wireless AIRCHOC receiver unit start-up page 5 6 Instructions page 7 NOTREW-US.doc 3 December 6th, 2012 1- Principle of Airchoc Wireless NOTREW-US.doc 4 December 6th, 2012 2- Receiver unit characteristics Material : ABS V0 + Aluminum Dimensions : 100 x 114 x 83 mm Weight: 195 g without batteries Supply voltage: 2 x 3,6Vdc Service temperature : - 20 to +70°C Humidity : no more than 80% Max altitude : e.g up to 2000 m Pollution degree : 3 Equipped with an 915 MHz RF module 2-1 Explanation of the symbol on the label : Direct current This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 3-Receiver Unit Batteries You must use only our batteries, Standard Industrie reference: BATACW Voltage : 7.2V-13Ah (2 x 3.6Vdc) Type : Lithium-ion non rechargeable Service temperature : - 20 to +85°C Max. storage temperature: 30°C Weight : 240 g for both 3-1.Recommendation Do not recharge, short-circuit, dispose of in fire, expose to temperatures greater than 100°C, immerse, or alter its shape. Any one of these actions may damage the battery, or cause it to combust or explode. Store in a dry place at constant temperature. Attention : it is forbidden to clean the receiver in the high-pressure water. The protection is impaired if equipment is used in a manner not specified by the manufacturer. 3-2. Device Recycling (environment) 4. Warranty The warranty does not cover damage caused by external factors such as lightning, flooding, and fire. No warranty shall apply if the device was repaired or modified by the purchaser or if its serial number has been modified, removed, or rendered illegible. Comply with the instructions for use contained in the manual. At the end of the batteries’, receiver units’, or Control panel’s service life, you must not dispose of these produces with ordinary household waste. They must be disposed of at an electrical and electronic device recycling point. Comply with applicable regulations in your country. NOTREW-US.doc 5 December 6th, 2012 5- WIRELESS AIRCHOC RECEIVER UNIT START-UP Use a flat screwdriver with a max. blade thickness of 0.5. Press on the connectors until you hear a click *The MAC address will be used when registering the Airchoc and for communications between the Control panel and the receiver unit CONNECT THE BATTERIES CLOSE THE COVER 3 Remove the screw Open the cover 1 2 Attach the battery connectors to the device. Direction is unimportant. The batteries must be identical. 4 5 Find the MAC* address 4 characters NOTREW-US.doc 6 December 6th, 2012 The housing must abut the base Ensure than the manual solenoid valve control is correctly positioned in relation to the oblong hole 6 7 8 ATTACH THE RECEIVER UNIT HOUSING TO THE SOLENOID VALVE TIGHTEN THE HOUSING TO THE SOLENOID VALVE Compress the cover until you are in front of the screw hole. The screw will tighten the housing through the solenoid valve 9 NOTREW-US.doc 7 December 6th, 2012 6 – Instructions Changes or modifications not expressly approved by Standard Industrie could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC’s radiation exposure limits set forth for an uncontrolled environment under the following conditions : 1. This equipment should be installed and operated such that a minimum separation distance of 20cm is maintained between the radiator (antenna) and user’s/nearby person’s body at all times. 2. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
