A2HCN6Q15Notebook Computer

Packaging and Shipping Instruction When you send the product to the AVITA Computer service facility you must use the original carton box and packing material or an equivalent as designated by AVITA Computer. Your Responsibility (1) You must retain the original sale receipt to provide proof of purchase. (2) These warranties are effective only if the product is purchased and operated in the United States or Canada. (3) Warranties extend only to defects in material or workmanship, and do not extend to any product or parts which have been lost or discarded, or damage to product or parts caused by misuse, accident, improper operation or maintenance, or use in violation of instructions provided with the product, or to product which has been altered or modified without authorization of AVITA Computer, or to products or parts thereof which have had the serial number removed or changed. Out of Warranty In the event your product requires repair after the limited warranty period has expired, please contact our Customer Support Center at support.avita-americas.com Important: You are responsible for any transportation, shipping or insurance relative to the return of product to our Product Returns Center. Quick Start Guide Guía de inicio rápido avita-americas.com CN6Q15 Laptop Ordenador portátil AVITA Computer makes the following limited warranty. This limited warranty extend to the original consumer purchaser and is limited to non-commercial use of the product. One Year Parts & Labor Warranty AVITA Computer products purchased in the United States or Canada are warranted to be free from defects in materials or workmanship for a period of one year from the date of their original retail purchase. If the unit fails to conform to this warranty, we will service the product using new or refurbished parts and products, at AVITA Computer’s sole discretion. During a period of one year from the eff ective warranty date, AVITA Computer will provide, when needed, service labor to repair a manufacturing defect at its designated Service Center. To obtain warranty service in the United States or Canada, you must fi rst contact our Customer Support Center atsupport.avita-americas.com. The determination of service will be made by AVITA Computer Customer Support. PLEASE DO NOT RETURN YOUR UNIT TO AVITA COMPUTER WITHOUT PRIOR AUTHORIZATION. New or remanufactured replacements for defective parts or products will be used for repairs by AVITA Computer at its designated Service Center for one year from the eff ective warranty date. Such replacement parts or products are warranted for an additional one year from the date of repair or replacement. The Customer will be required to ship the unit to the Service Center indicated at the time Customer Support is contacted to make the necessary repairs. The customer is responsible for all transportation charges to the service facility. Limited Warranty All warranties implied by state law, including the implied warranties of merchantability and fitness for a particular purpose, are expressly limited to the duration of the limited warranties set forth above. With the exception of any warranties implied by state law as hereby limited, the foregoing warranty is exclusive and in lieu of all other warranties, guarantees, agreements and similar obligations of manufacturer or seller with respect to the repair or replacement of any parts. In no event shall AVITA Computer be liable for consequential or incidental damages. No person, agent, distributor, dealer or company is authorized to change, modify or extend the terms of these warranties in any manner whatsoever. The time within action must be commenced to enforce any obligation of AVITA Computer arising under the warranty or under any statute, or law of the United States or Canada or any state thereof, is hereby limited to one year from the date of purchase. This limitation does not apply to implied warranties arising under state law. This warranty gives you specific legal rights and you may also have other rights, which may vary, from state to state. Some states do not allow limitation on how long an implied warranty lasts, when an action may be brought, or the exclusion or limitation of incidental or consequential damages, so the above provisions may not apply to you. For more information on other products and services, please visit our web site at: support.avita-americas.com Important: Also keep your “Bill of Sale” as proof of purchase. FOR SUPPORT AND SERVICE, PLEASE CONTACT US support.avita-americas.com Product Support and Service To learn more about how to operate your new AVITA laptop, please visit support.avita-americas.com Soporte y Servicio del Product Para obtener más información sobre cómo operar su nueva computadora portátil AVITA, visite support.avita-americas.com Garantía limitada AVITA Computer ofrece la siguiente garantía limitada, la cual se extiende al comprador-consumidor original y está limitada al uso no comercial del producto. Garantía de repuestos y reparaciones por Uno Año Los productos AVITA Computer que se hayan comprado en los Estados Unidos o Canadá tienen una garantía de uno año a partir de la fecha original de compra en caso de presentar defectos en los materiales o en su fabricación. Si la unidad no se encuentra en conformidad a esta garantía, nosotros repararemos el producto usando piezas y productos nuevos y reparados, según lo estime AVITA Computer únicamente. Durante un período de uno año a partir de la fecha efectiva de la garantía, AVITA Computer proporcionará, cuando sea necesario, mano de obra de reparación para reparar defectos de fabricación en su centro de reparaciones designado. Para obtener los servicios de la garantía en los Estados Unidos o Canadá, sírvase contactarse con el Centro de Servicio para el Cliente alsupport.avita-americas.com. La decisión de si bien usted está facultado para recibir estos servicios la tomará la ofi cina de Respaldo al Cliente de AVITA Computer. POR FAVOR NO DEVUEL…

Text truncated - open the document above for the full version.

Electronics Limited A member of the ALCO group 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2811 1056 16 Oct. 2020 To whom it may concern, Multiple Models Confirmation Letter I, the undersigned, hereby confirm that the family models are listed in the following table. These models are identical as follows: √ Electronics/electrical designs, including software & firmware √ Construction design/Physical design/Enclosure √ PCB layout □ (Others, please specify) The only differences between these models are the follows for marketing purpose: □ Color □ Cosmetic details √ Trade name √ Model Number □ (Others, please specify) Item No. New model Model Number Trade Name Remarks 1 √ YES CN6Q15 VENTURER / AVITA 2 √ YES NS15A6 AVITA 3 √ YES CN6QF5 VENTURER / AVITA 4 5 6 The sample being submitted for conformity assessment is CN6Q15 (tested model) of the above list. Best Regards, Alco Electronics Ltd. PEGGY SUEN Secretary, Engineering Dept.

Alco Electronics Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020-10-19 Subject; Request for Long Term Confidentiality FCC ID: A2HCN6Q15 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Peggy Suen Title: Secretary, Engineering Dept.

Alco Electronics Ltd Letter of Authorization Company: Alco Electronics Ltd Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Product Name: Notebook Computer Model Number: CN6Q15, NS15A6, CN6QF5 FCC Identifier: A2HCN6Q15 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Peggy Suen Date: 2020-10-19 Title: Secretary, Engineering Dept.

7.EXTERANAL AND INTERNAL PHOTOS External photos of EUT Model:CN6Q15

ALCO MODEL # : CN6QF5 LABELS ON UNIT (UL VERSION) 22-10-2020 REVISED DATE: SPEC LABEL (P/N 809-6Q1596W010) 34mm 3 mm 3 mm Model : CN6QF5 SAMPLE DC / C.C. 19V 2.1A FCC ID: A2HCN6Q15 Made in China / Fabriqué en Chine PURA LAPTOP Model : CN6Q15 SAMPLE DC / C.C. 19V 2.1A FCC ID: A2HCN6Q15 Made in China / Fabriqué en Chine PURA LAPTOP Model : CN6QF5 SAMPLE DC / C.C. 19V 2.1A FCC ID: A2HCN6Q15 Made in China / Fabriqué en Chine PURA LAPTOP Model : CN6Q15 SAMPLE DC / C.C. 19V 2.1A FCC ID: A2HCN6Q15 Made in China / Fabriqué en Chine PURA LAPTOP AMD R3 LABEL (P/N 809-000AMDW100) (R3) 7.3 mm 1.6 mm 1.2 mm 2.7 mm 1.2 mm Model : NS15A6 SAMPLE DC / C.C. 19V 2.1A FCC ID: A2HCN6Q15 Made in China / Fabriqué en Chine PURA LAPTOP CONFORMS TO UL STD. UL62368-1 CERTIFIED TO CSA STD. C22.2 No. 62368-1 CONFORMS TO UL STD. UL62368-1 CERTIFIED TO CSA STD. C22.2 No. 62368-1 CONFORMS TO UL STD. UL62368-1 CERTIFIED TO CSA STD. C22.2 No. 62368-1 CONFORMS TO UL STD. UL62368-1 CERTIFIED TO CSA STD. C22.2 No. 62368-1 CONFORMS TO UL STD. UL62368-1 CERTIFIED TO CSA STD. C22.2 No. 62368-1

Internal photos of EUT Model:CN6Q15

Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR Lab Date: 9/14/2020 Wifi 2.4G-Body Communication System: UID 0, Generic WIFI (0); Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2412 MHz; σ = 1.684 S/m; ε r = 37.502; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.6°C;Liquid Temperature:22.4°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(7.91, 7.91, 7.91) @ 2412 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 1/Area Scan (71x201x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.0394 W/kg Bottom/CH 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 1.115 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 0.0640 W/kg SAR(1 g) = 0.030 W/kg; SAR(10 g) = 0.014 W/kg Maximum value of SAR (measured) = 0.0504 W/kg 0 dB = 0.0504 W/kg = -12.98 dBW/kg Appendix A: SAR Test Data Plots Plot No.1 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR Lab Date: 9/14/2020 Wifi 5G U-NII-1-Body Communication System: UID 0, Generic WIFI (0); Frequency: 5190 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5190 MHz; σ = 4.475 S/m; ε r = 34.646; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.5°C;Liquid Temperature:22.3°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(5.58, 5.58, 5.58) @ 5190 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 38/Area Scan (81x141x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 0.206 W/kg Bottom/CH 38/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 1.763 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 0.356 W/kg SAR(1 g) = 0.100 W/kg; SAR(10 g) = 0.041 W/kg Maximum value of SAR (measured) = 0.227 W/kg 0 dB = 0.227 W/kg = -6.44 dBW/kg Appendix A: SAR Test Data Plots Plot No.2 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR Lab Date: 9/14/2020 Wifi 5G U-NII-2A-Body Communication System: UID 0, Generic WIFI (0); Frequency: 5280 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5280 MHz; σ = 4.517 S/m; ε r = 34.499; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.3°C;Liquid Temperature:22.1°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(5.58, 5.58, 5.58) @ 5280 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 56/Area Scan (81x141x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 0.295 W/kg Bottom/CH 56/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 1.589 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.533 W/kg SAR(1 g) = 0.120 W/kg; SAR(10 g) = 0.043 W/kg Maximum value of SAR (measured) = 0.314 W/kg 0 dB = 0.314 W/kg = -5.03 dBW/kg Appendix A: SAR Test Data Plots Plot No.3 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 9/15/2020 Wifi 5G U-NII-2C-Body Communication System: UID 0, Generic WIFI (0); Frequency: 5500 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5500 MHz; σ = 4.844 S/m; ε r = 34.127; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.4°C;Liquid Temperature:22.2°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(4.95, 4.95, 4.95) @ 5500 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 100/Area Scan (81x141x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 0.544 W/kg Bottom/CH 100/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 1.488 V/m; Power Drift = -0.13 dB Peak SAR (extrapolated) = 1.06 W/kg SAR(1 g) = 0.233 W/kg; SAR(10 g) = 0.085 W/kg Maximum value of SAR (measured) = 0.597 W/kg 0 dB = 0.597 W/kg = -2.24 dBW/kg Appendix A: SAR Test Data Plots Plot No.4 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR LabDate: 9/15/2020 Wifi 5G U-NII-3-Body Communication System: UID 0, Generic WIFI (0); Frequency: 5745 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 5745 MHz; σ = 5.015 S/m; ε r = 33.686; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.2°C;Liquid Temperature:22.0°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(4.76, 4.76, 4.76) @ 5745 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 149/Area Scan (81x141x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 0.197 W/kg Bottom/CH 149/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 1.613 V/m; Power Drift = -0.19 dB Peak SAR (extrapolated) = 0.317 W/kg SAR(1 g) = 0.071 W/kg; SAR(10 g) = 0.027 W/kg Maximum value of SAR (measured) = 0.194 W/kg 0 dB = 0.194 W/kg = -7.12 dBW/kg Appendix A: SAR Test Data Plots Plot No.5

Appendix B: DAE and Probe Calibration Certificate 1 of 12 1.1. DAE4 Calibration Certificate Appendix B: DAE and Probe Calibration Certificate 2 of 12 Appendix B: DAE and Probe Calibration Certificate 3 of 12 Appendix B: DAE and Probe Calibration Certificate 4 of 12 1.2. Probe Calibration Certificate Appendix B: DAE and Probe Calibration Certificate 5 of 12 Appendix B: DAE and Probe Calibration Certificate 6 of 12 Appendix B: DAE and Probe Calibration Certificate 7 of 12 Appendix B: DAE and Probe Calibration Certificate 8 of 12 Appendix B: DAE and Probe Calibration Certificate 9 of 12 Appendix B: DAE and Probe Calibration Certificate 10 of 12 Appendix B: DAE and Probe Calibration Certificate 11 of 12 Appendix B: DAE and Probe Calibration Certificate 12 of 12

Appendix C: Dipole Calibration Certificate 1 of 26 1.1. D2450V2 Dipole Calibration Certificate Appendix C: Dipole Calibration Certificate 2 of 26 Appendix C: Dipole Calibration Certificate 3 of 26 Appendix C: Dipole Calibration Certificate 4 of 26 Appendix C: Dipole Calibration Certificate 5 of 26 Appendix C: Dipole Calibration Certificate 6 of 26 Appendix C: Dipole Calibration Certificate 7 of 26 Appendix C: Dipole Calibration Certificate 8 of 26 Appendix C: Dipole Calibration Certificate 9 of 26 Extended Dipole Calibrations Referring to KDB865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head-2450 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-05 -27.4 53.8 2.2 2019-02-03 -26.8 2.19% 52.9 0.9 1.9 0.3 2020-01-22 -27.1 1.09% 53.1 0.7 1.8 0.4 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5ohm of prior calibration. Therefore the verification result should support extended calibration. Appendix C: Dipole Calibration Certificate 10 of 26 1.2. D5GHzV2 Dipole Calibration Certificate Appendix C: Dipole Calibration Certificate 11 of 26 Appendix C: Dipole Calibration Certificate 12 of 26 Appendix C: Dipole Calibration Certificate 13 of 26 Appendix C: Dipole Calibration Certificate 14 of 26 Appendix C: Dipole Calibration Certificate 15 of 26 Appendix C: Dipole Calibration Certificate 16 of 26 Appendix C: Dipole Calibration Certificate 17 of 26 Appendix C: Dipole Calibration Certificate 18 of 26 Appendix C: Dipole Calibration Certificate 19 of 26 Appendix C: Dipole Calibration Certificate 20 of 26 Appendix C: Dipole Calibration Certificate 21 of 26 Appendix C: Dipole Calibration Certificate 22 of 26 Appendix C: Dipole Calibration Certificate 23 of 26 Appendix C: Dipole Calibration Certificate 24 of 26 Appendix C: Dipole Calibration Certificate 25 of 26 Appendix C: Dipole Calibration Certificate 26 of 26 Extended Dipole Calibrations Referring to KDB865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head-5200 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -27.9 47.8 -3.3 2019-02-20 -28.5 -2.15% 48.3 0.5 -2.9 0.4 2020-01-22 -28.3 -1.43% 47.5 0.3 -3.1 0.2 Head-5300 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -34.3 48.3 0.8 2019-02-20 -33.9 1.17% 47.7 0.6 0.1 0.7 2020-01-22 -33.7 1.75% 47.5 0.8 0.5 0.3 Head-5500 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -31.2 47.8 1.6 2019-02-20 -31.9 -2.24% 48.2 0.4 2.5 0.9 2020-01-22 -30.7 1.60% 47.5 0.2 2.1 0.5 Head-5600 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -28.7 53.2 2.1 2019-02-20 -28.1 2.09% 52.5 0.7 2.6 0.5 2020-01-22 -27.9 2.79% 52.3 0.9 1.9 0.2 Head-5800 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -27.8 52.5 3.4 2019-02-20 -27.1 2.52% 52.1 0.4 2.9 0.5 2020-01-22 -27.2 2.16% 51.9 0.6 2.7 0.7 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5ohm of prior calibration. Therefore the verification result should support extended calibration.

Page: 1 of 39 TEST REPORT Report No. ...................................... : CHTEW20090105 Report verificaiton: Project No. ...................................... : SHT2008051703EW FCC ID ............................................. : A2HCN6Q15 Applicant’s name ........................... : Alco Electronics Ltd. Address ............................................. : 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Test item description .................... : Notebook Computer Trade Mark ....................................... : Venturer / AVITA Model/Type reference ....................... : CN6Q15 Listed Model(s) ................................. : NS15A6, CN6QF5 Standard ......................................... : FCC 47 CFR Part2.1093 IEEE Std C95.1, 1999 Edition IEEE 1528: 2013 Date of receipt of test sample..........: Aug.20, 2020 Date of testing..............................: Aug.21, 2020- Sep.16, 2020 Date of issue...............................: Sep.17, 2020 Result .................. ........................: PASS Compiled by ( position+printedname+signature) ... : File administrators: Fanghui Zhu Supervised by ( position+printedname+signature) ... : Test Engineer: Patrick Qiu Approved by ( position+printedname+signature) ... : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW20090105 Page: 2 of 39 Issued: 2020-09-17 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. RF Specification Description 6 3.4. Testing Laboratory Information 7 3.5. Environmental conditions 7 4. Equipments Used during the Test 8 5. Measurement Uncertainty 9 6. SAR Measurements System Configuration 10 6.1. SAR Measurement Set-up 10 6.2. DASY5 E-field Probe System 11 6.3. Phantoms 12 6.4. Device Holder 12 7. SAR Test Procedure 13 7.1. Scanning Procedure 13 7.2. Data Storage and Evaluation 15 8. Position of the wireless device in relation to the phantom 17 8.1. Body Exposure conditions 17 9. Dielectric Property Measurements & System Check 18 9.1. Tissue Dielectric Parameters 18 9.2. System Check 19 10. SAR Exposure Limits 26 11. Conducted Power Measurement Results 27 11.1. Wi-Fi 27 11.2. Bluetooth 29 12. Maximum Tune-up Limit 30 13. Antenna Location 34 14. Measured and Reported SAR Results 35 15. SAR Measurement Variability 37 16. Simultaneous Transmission analysis 38 17. TestSetup Photos 39 18. External and Internal Photos of the EUT 39 Report No.: CHTEW20090105 Page: 3 of 39 Issued: 2020-09-17 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) 1. Statement of Compliance Maximum Reported SAR (W/kg @1g) RF Exposure Conditions DTS NII Simultaneous TX Body-worn(Dist.= 0mm) 0.032 0.258 0.519 This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposure limits (1.6 W/kg) specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992, and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2013 and FCC KDB publications. Report No.: CHTEW20090105 Page: 4 of 39 Issued: 2020-09-17 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency radiation exposure evaluation: portable devices. IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. FCC published RF exposure KDB procedures: 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 248227 D01 802 11 Wi-Fi SAR v02r02: SAR Measurement Proceduresfor802.11 a/b/g Transmitters 616217 D04 SAR for laptop and tablets v01r02: describes the SAR evaluation requirements for laptop, notebook, netbook and tablet computers TCB workshop April, 2019; Page 19, Tissue Simulating Liquids (TSL) 2.2. Report version Revision No. Date of issue Description N/A 2020-09-17 Original Report No.: CHTEW20090105 Page: 5 of 39 Issued: 2020-09-17 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) 3. Summary 3.1. Client Information Applicant: Alco Electronics Ltd. Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Manufacturer: Alco Electronics Ltd. Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong 3.2. Product Description Main unit Name of EUT: Notebook …

Text truncated - open the document above for the full version.

Page: 1 of 28 TEST REPORT Report No. ...................................... : CHTEW20090220 Report Verification: Project No.................................： SHT2008051701EW FCC ID ............................................. : A2HCN6Q15 Applicant’s name ........................... : Alco Electronics Ltd Address ............................................. : 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Manufacturer.....................................: Alco Electronics Ltd Address..............................................: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Test item description .................... : Notebook Computer Trade Mark ....................................... : Venturer / AVITA Model/Type reference ....................... : CN6Q15 Listed Model(s) ................................. : NS15A6, CN6QF5 Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: Aug. 20, 2020 Date of testing.............................: Aug. 21, 2020- Sep. 28, 2020 Date of issue...............................: Sep. 29, 2020 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Silvia Li Supervised by (Position+Printed name+Signature): Project Engineer Aaron Fang Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW20090220 Page: 2 of 28 Issued: 2020-09-29 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Test mode 7 4.3. Support unit used in test configuration and system 7 4.4. Testing environmental condition 8 4.5. Measurement uncertainty 8 4.6. Equipment Used during the Test 9 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna Requirement 11 5.2. AC Conducted Emission 12 5.3. Peak Output Power 15 5.4. Power Spectral Density 16 5.5. 6dB bandwidth 17 5.6. 99% Occupied Bandwidth 18 5.7. Duty Cycle 19 5.8. Conducted Band edge and Spurious Emission 20 5.9. Radiated Band edge Emission 21 5.10. Radiated Spurious Emission 23 6. TEST SETUP PHOTOS 27 7. EXTERANAL AND INTERNAL PHOTOS 28 8. APPENDIX REPORT 28 Report No.: CHTEW20090220 Page: 3 of 28 Issued: 2020-09-29 Shenzhen Huatongwei International…

Text truncated - open the document above for the full version.
