Tablet Model: CT9E78Q22N PRODUCT GUIDE 1 Introduction Thank you for purchasing the Android tablet. Featuring a fast and responsive quad core processor, this tablet is perfect for accomplishing everyday tasks, streaming music and movies, taking photos, checking emails, and engaging with social media. The tablet offers 16GB of internal storage, Bluetooth connectivity, Micro SD slot for up to 256GB of additional storage. The following information will help you get the most out of your tablet. What You Should Know to Ensure Best Performance: • Charge the battery completely before first use. • While updates download in the background, tablet performance can be affected until completed. • Close unused applications. Open apps that run in the background will affect overall performance. • Battery Consumption: Play times on a fully charged battery will vary depending on your display settings, apps that remain open, and internet use (ie: streaming video content). • Suggest customer use tablet screen protector and tablet case to protect the tablets. 2 Important Safety Instructions 1. Read these instructions - All the safety and operating instructions should be read before this product is operated. 2. Keep these instructions - The safety and operating instructions should be retained for future reference. 3. Heed all warnings - All warning on the appliance and in the operating instructions should be adhered to. 4. Follow all instructions - All operating and use instructions should be followed. 5. Do not use this apparatus near water - The appliance should not be used near water or moisture - for example, in a wet basement or near a swimming pool, and the like. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding plug. Apolarized plug has two blades with one wider than the other. A grounding plug has tow blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet. Consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at the plugs, convenience receptacles, and at the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart or rack is used. Use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug the apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in anyway, such as power supply cord or plug is damaged,liquid has been spilled or objects have fallen into the apparatus has been exposed to moisture, does not operate normally, or has been dropped. 3 15. CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. 16. Do not install this equipment in a confined or building-in space such as a book case or similar unit. And remain a well ventilation conditions at open site. The ventliation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc. 17. WARNING: Only use attachments/accessories specified or provided by the manufacturer (such as the exclusive supply adapter,battery etc). 18. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. 19. WARNING: To reduce the risk of fire or electric, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids. Such as vases, shall not be placed on apparatus. 20. Warning: To reduce the risk of electric shock, do not remove cover (or back)as there are no user-serviceable parts inside. Refer servicing to qualified personnel. 21. WARNING: Please refer the information on exterior bottom enclosure for electrical and safety information before installing or operating the apparatus. Use the devices where the ambient temperature is between 0° and 35° C (32° to 95° F). Low or high temperature conditions might cause the device to change its behavior to regulate its temperature. Using Android device in very cold conditions outside of its operating range might temporarily shorten battery life and could cause the device to turn off. Battery life will return to normal when you bring the device back to higher ambient temperatures. Using an the devices in very hot conditions can permanently shorten battery life. Important Safety Instructions 4 In The Box Tablet USB cable User Manual Charger INPUT: OUTPUT: Check to make sure you have everything below. Tablet Model: CT9E78Q22N PRODUCT GUIDE 5 MicroSD card slot Accepts microSD card (up to 256GB). Reset Reset the tablet (then press and hold the Power button for 4~5 seconds to turn on the unit). Headphones jack Headphones connection for personal listening. Power button Press to enter standby/wake up mode; Press and hold to switch the unit on or off. USB Type-C port Uses to charge the tablet's battery. Connects to a USB storage device or a mouse or a wire keyboard. Front camera Volume +/- Rear camera Speaker Getting to Know Your Tablet 12 3 4 5 6 8 7 9 1 2 3 4 5 6 8 7 9 6 Charging your Tablet 1 2 3 IMPORTANT! Please Read. We recommend fully charging your tablet before using it for the fi rst time. For optimum performance, please connect the provided AC adaptor to y…

Text truncated - open the document above for the full version.

Electronics Ltd A member of the ALCO group 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2811 1056 22 May 2020 To whom it may concern, Multiple Models Confirmation Letter I, the undersigned, hereby confirm that the family models are listed in the following table. These models are identical as follows: √Ele ctronics/electrical designs, including software & firmware √Construction design/Physical design/Enclosure √PCB layout □ (Others, please specify) The only differences between these models are the follows for marketing purpose: □ Color □ Cosmetic details √Trade name √Model Number □ (Others, please specify) Item No. New model Model Number Trade Name Remarks 1 √ YES CT9E78Q22N VENTURER 2 √ YES 100015685 ONN. 3 4 5 6 The sample being submitted for conformity assessment is CT9E78Q22N (tested model) of the above list. Best Regards, Alco Electronics Ltd PEGGY SUEN Secretary, Engineering Dept. (for Peggy Suen)

Alco Electronics Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020-07-17 Subject; Request for Long Term Confidentiality FCC ID: A2HCT9E78O To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Peggy Suen Title: Secretary, E/G Dept. (for Peggy Suen)

Alco Electronics Ltd Letter of Authorization Company: Alco Electronics Ltd Address: 11/F, Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Product Name: Tablet Model Number: CT9E78Q22N, 100015685 FCC Identifier: A2HCT9E78O We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Peggy Suen Date: 2020-07-17 Title: Secretary, E/G Dept. (for Peggy Suen)

External Photos Adapter 1 Adapter 2

Internal Photos

Date: 7/15/2020 Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR Lab WIFI 2.4G Communication System: UID 0, Generic WIFI (0); Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 2412 MHz; σ = 1.839 S/m; ε r = 39.716; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.2°C;Liquid Temperature:22.0°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(7.91, 7.91, 7.91) @ 2412 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Rear/CH 1/Area Scan (111x61x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.535 W/kg Rear/CH 1/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.105 V/m; Power Drift = -0.14 dB Peak SAR (extrapolated) = 0.757 W/kg SAR(1 g) = 0.331 W/kg; SAR(10 g) = 0.163 W/kg Maximum value of SAR (measured) = 0.555 W/kg 0 dB = 0.555 W/kg = -0.85 dBW/kg Appendix A: SAR Test Data Plots Plot No.1 Date: 7/6/2020Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR Lab WIFI 5G U-NII-1 Communication System: UID 0, Generic WIFI (0); Frequency: 5210 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5210 MHz; σ = 4.475 S/m; ε r = 34.846; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.4°C;Liquid Temperature:22.2°C; DASY Configuration: l Probe: EX3DV4 - SN7494; ConvF(5.58, 5.58, 5.58) @ 5210 MHz; Calibrated: 4/1/2020 l Sensor-Surface: 1.4mm (Mechanical Surface Detection) l Electronics: DAE4 Sn1549; Calibrated: 4/4/2020 l Phantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 l DASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 38/Area Scan (31x131x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm= Maximum value of SAR (interpolated) = 2.89 W/kg Bottom/CH 38/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 5.664 V/m; Power Drift = -0.12 dB Peak SAR (extrapolated) = 6.07 W/kg SAR(1 g) = 1.06 W/kg; SAR(10 g) = 0.250 W/kg Maximum value of SAR (measured) = 3.29 W/kg 0 dB = 3.29 W/kg = 5.17 dBW/kg Appendix A: SAR Test Data Plots Plot No.2 Date: 7/6/2020Test Laboratory: Huatongwei International Inspection Co., Ltd.,SAR Lab WIFI 5G U-NII-3 Communication System: UID 0, Generic WIFI (0); Frequency: 5775 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5775 MHz; σ = 5.12 S/m; ε r = 33.815; ρ = 1000 kg/m 3 Phantom section: Flat Section Ambient Temperature:22.3°C;Liquid Temperature:22.1°C; DASY Configuration: lProbe: EX3DV4 - SN7494; ConvF(4.76, 4.76, 4.76) @ 5775 MHz; Calibrated: 4/1/2020 lSensor-Surface: 1.4mm (Mechanical Surface Detection) lElectronics: DAE4 Sn1549; Calibrated: 4/4/2020 lPhantom: ELI V8.0 ; Type: QD OVA 004 AA ; Serial: 2078 lDASY52 52.10.2(1495); SEMCAD X 14.6.12(7450) Bottom/CH 155/Area Scan (31x131x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 2.09 W/kg Bottom/CH 155/Zoom Scan (8x8x7)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=1.4mm Reference Value = 6.827 V/m; Power Drift = -0.19 dB Peak SAR (extrapolated) = 4.16 W/kg SAR(1 g) = 0.769 W/kg; SAR(10 g) = 0.219 W/kg Maximum value of SAR (measured) = 2.12 W/kg 0 dB = 2.12 W/kg = 3.26 dBW/kg Appendix A: SAR Test Data Plots Plot No.3

Appendix B: DAE and Probe Calibration Certificate 1 of 12 1.1. DAE4 Calibration Certificate Appendix B: DAE and Probe Calibration Certificate 2 of 12 Appendix B: DAE and Probe Calibration Certificate 3 of 12 Appendix B: DAE and Probe Calibration Certificate 4 of 12 1.2. Probe Calibration Certificate Appendix B: DAE and Probe Calibration Certificate 5 of 12 Appendix B: DAE and Probe Calibration Certificate 6 of 12 Appendix B: DAE and Probe Calibration Certificate 7 of 12 Appendix B: DAE and Probe Calibration Certificate 8 of 12 Appendix B: DAE and Probe Calibration Certificate 9 of 12 Appendix B: DAE and Probe Calibration Certificate 10 of 12 Appendix B: DAE and Probe Calibration Certificate 11 of 12 Appendix B: DAE and Probe Calibration Certificate 12 of 12

Appendix C: Dipole Calibration Certificate 1 of 26 1.1. D2450V2 Dipole Calibration Certificate Appendix C: Dipole Calibration Certificate 2 of 26 Appendix C: Dipole Calibration Certificate 3 of 26 Appendix C: Dipole Calibration Certificate 4 of 26 Appendix C: Dipole Calibration Certificate 5 of 26 Appendix C: Dipole Calibration Certificate 6 of 26 Appendix C: Dipole Calibration Certificate 7 of 26 Appendix C: Dipole Calibration Certificate 8 of 26 Appendix C: Dipole Calibration Certificate 9 of 26 Extended Dipole Calibrations Referring to KDB865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head-2450 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-05 -27.4 53.8 2.2 2019-02-03 -26.8 2.19% 52.9 0.9 1.9 0.3 2020-01-22 -27.1 1.09% 53.1 0.7 1.8 0.4 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5ohm of prior calibration. Therefore the verification result should support extended calibration. Appendix C: Dipole Calibration Certificate 10 of 26 1.2. D5GHzV2 Dipole Calibration Certificate Appendix C: Dipole Calibration Certificate 11 of 26 Appendix C: Dipole Calibration Certificate 12 of 26 Appendix C: Dipole Calibration Certificate 13 of 26 Appendix C: Dipole Calibration Certificate 14 of 26 Appendix C: Dipole Calibration Certificate 15 of 26 Appendix C: Dipole Calibration Certificate 16 of 26 Appendix C: Dipole Calibration Certificate 17 of 26 Appendix C: Dipole Calibration Certificate 18 of 26 Appendix C: Dipole Calibration Certificate 19 of 26 Appendix C: Dipole Calibration Certificate 20 of 26 Appendix C: Dipole Calibration Certificate 21 of 26 Appendix C: Dipole Calibration Certificate 22 of 26 Appendix C: Dipole Calibration Certificate 23 of 26 Appendix C: Dipole Calibration Certificate 24 of 26 Appendix C: Dipole Calibration Certificate 25 of 26 Appendix C: Dipole Calibration Certificate 26 of 26 Extended Dipole Calibrations Referring to KDB865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. Head-5200 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -27.9 47.8 -3.3 2019-02-20 -28.5 -2.15% 48.3 0.5 -2.9 0.4 2020-01-22 -28.3 -1.43% 47.5 0.3 -3.1 0.2 Head-5300 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -34.3 48.3 0.8 2019-02-20 -33.9 1.17% 47.7 0.6 0.1 0.7 2020-01-22 -33.7 1.75% 47.5 0.8 0.5 0.3 Head-5500 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -31.2 47.8 1.6 2019-02-20 -31.9 -2.24% 48.2 0.4 2.5 0.9 2020-01-22 -30.7 1.60% 47.5 0.2 2.1 0.5 Head-5600 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -28.7 53.2 2.1 2019-02-20 -28.1 2.09% 52.5 0.7 2.6 0.5 2020-01-22 -27.9 2.79% 52.3 0.9 1.9 0.2 Head-5800 Date of measurement Return-loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary impedance (ohm) Delta (ohm) 2018-02-21 -27.8 52.5 3.4 2019-02-20 -27.1 2.52% 52.1 0.4 2.9 0.5 2020-01-22 -27.2 2.16% 51.9 0.6 2.7 0.7 The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5ohm of prior calibration. Therefore the verification result should support extended calibration.

Page: 1 of 35 TEST REPORT Report No. ...................................... : CHTEW20070122 Report verificaiton: Project No. ...................................... : SHT2006103903EW FCC ID ............................................. : A2HCT9E78O Applicant’s name ........................... : Alco Electronics Ltd Address ............................................. : 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Test item description .................... : Tablet Trade Mark ....................................... : , Model/Type reference ....................... : CT9E78Q22N Listed Model(s) ................................. : 100015685 Standard ......................................... : FCC 47 CFR Part2.1093 IEEE Std C95.1, 1999 Edition IEEE 1528: 2013 Date of receipt of test sample..........: Jun.23, 2020 Date of testing..............................: Jun.24, 2020- Jul.15, 2020 Date of issue...............................: Jul.16, 2020 Result .................. ........................: PASS Compiled by ( position+printedname+signature) ... : File administrators: Fanghui Zhu Supervised by ( position+printedname+signature) ... : Test Engineer: Xiaodong Zhao Approved by ( position+printedname+signature) ... : Manager: Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW20070122 Page: 2 of 35 Issued: 2020-07-16 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) Contents 1. Statement of Compliance 3 2. Test Standards and Report version 4 2.1. Test Standards 4 2.2. Report version 4 3. Summary 5 3.1. Client Information 5 3.2. Product Description 5 3.3. RF Specification Description 5 3.4. Testing Laboratory Information 6 3.5. Environmental conditions 6 4. Equipments Used during the Test 7 5. Measurement Uncertainty 8 6. SAR Measurements System Configuration 9 6.1. SAR Measurement Set-up 9 6.2. DASY5 E-field Probe System 10 6.3. Phantoms 11 6.4. Device Holder 11 7. SAR Test Procedure 12 7.1. Scanning Procedure 12 7.2. Data Storage and Evaluation 14 8. Dielectric Property Measurements & System Check 16 8.1. Tissue Dielectric Parameters 16 8.2. System Check 18 9. SAR Exposure Limits 23 10. Conducted Power Measurement Results 24 10.1. Wi-Fi 24 10.2. Bluetooth 25 11. Maximum Tune-up Limit 26 12. RF Exposure Conditions (Test Configurations) 28 12.1. Antenna Location 28 12.2. Standalone SAR test exclusion considerations 29 12.3. Required Test Configurations 29 13. Measured and Reported SAR Results 30 14. SAR Measurement Variability 32 15. Simultaneous Transmission analysis 33 15.1. Simultaneous Transmission 33 16. TestSetup Photos 34 17. External and Internal Photos of the EUT 35 Report No.: CHTEW20070122 Page: 3 of 35 Issued: 2020-07-16 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) 1. Statement of Compliance Maximum Reported SAR (W/kg @1g) RF Exposure Conditions DTS NII Simultaneous Tx Body(Dist.= 0mm) 0.349 1.31 1.496 This device is in compliance with Specific Absorption Rate (SAR) for general population/uncontrolled exposure limits specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992, and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2013 and FCC KDB publications. Report No.: CHTEW20070122 Page: 4 of 35 Issued: 2020-07-16 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) 2. Test Standards and Report version 2.1. Test Standards The tests were performed according to following standards: FCC 47 Part 2.1093: Radiofrequency radiation exposure evaluation: portable devices. IEEE Std C95.1, 1999 Edition: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz IEEE Std 1528™-2013: IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques. FCC published RF exposure KDB procedures: 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04: SAR Measurement Requirements for 100 MHz to 6 GHz 865664 D02 RF Exposure Reporting v01r02: RF Exposure Compliance Reporting and Documentation Considerations 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 248227 D01 802 11 Wi-Fi SAR v02r02: SAR Measurement Proceduresfor802.11 a/b/g Transmitters 616217 D04 SAR for laptop and tablets v01r02: SAR Evaluation Requirements for Laptop, Notebook, Netbook and Tablet Computers TCB workshop April, 2019; Page 19, Tissue Simulating Liquids (TSL) 2.2. Report version Revision No. Date of issue Description N/A 2020-07-16 Original Report No.: CHTEW20070122 Page: 5 of 35 Issued: 2020-07-16 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2020-06) 3. Summary 3.1. Client Information Applicant: Alco Electronics Ltd Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Manufacturer: Alco Electronics Ltd Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong 3.2. Product Description Main unit …
