A2HRTS7010B1Soundbar with Bluetooth

RTS7010B RTS7110B RTS7630B User manual Manuel de l’utilisateur Manual del Usuario It is important to read this instruction book prior to using your new product for the first time. Il est important de lire ce manuel d’instructions avant d’utiliser l’appareil pour la première fois. Es importante que lea este libro de instrucciones antes de comenzar a usar su nuevo producto. EN FR ES 2 EN SAFETY INSTRUCTIONS pOwER SUpplY FCC INFORmATION This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. wARNING: • Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • The AC adapter is used as disconnect device and it should remain readily operable during intended used. In order to disconnect the unit from the mains completely, the AC adapter should be disconnected from the mains socket outlet completely. • The AC adapter of unit should not be obstructed OR should be easily accessed during intended use. • Minimum 10 cm (4 inches) distances around the unit for sufficient ventilations. • The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains, etc. • No naked flame sources such as lighted candles should be placed on the unit. ON SAFETY • Should any objects or liquids fall into the unit, disconnect the power supply and have the unit checked by qualified personnel before any further operation. • The unit shall not be exposed to dripping or splashing and that no objects filled with liquid, such as vases, shall be placed on the unit. ON USE Never use the unit where it would be subject to: - Heat sources such as radiators or air ducts. - Direct sunlight. FOR CUSTOmERS IN CANAdA This apparatus complies with the Class B limits for radio noise emission set out in radio interference regulations. CAN ICES-3 (B) / NMB-3 (B) This device complies with Industry Canada licence- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. USING ThE AC AdApTER Using an AC adapter other than the one supplied with the unit may damage the unit. Caution: • Before use, ensure the rated voltage of the adapter matches your local voltage. • The included AC adapter is for use with this unit only. Do not use it with other equipment. • If you are not going to use the unit for a long time, disconnect the AC adapter from the wall outlet. • Whenever the AC adapter is plugged in to a wall outlet, the AC adapter will draw some power, even when the Sound Bar is turned off. ACCESSORIES Please locate the included accessories. To order replacement units, visit http://www.RCAav.com Remote control (with battery) ..................x 1 AC power adapter .....................................x 1 Wall Mount Bracket (with screws x 4) ......x 2 3 EN USING ThE REmOTE CONTROl • Point the remote control at the REMOTE SENSOR located on the unit (see Front Panel illustration for precise location). • When there is a strong ambient light source, the perform ance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation. • The recommended effective distance for remote operation is about 16 feet (5 meters). TO ChANGE REmOTE BATTERIES 1. Open the battery door. 2. Insert two AAA batteries. BATTERY REplACEmENT When the batteries become weak, the operating distance of the remote control is greatly reduced and you will need to replace them. Notes: • If the remote control is not going to be used for a long time, remove the batteries to avoid corrosion damage caused by battery leakage. • Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or rechargeable (NICKEL-CADMIUM) batteries. • Always remove batteries as soon as they become weak. • Weak batteries can leak and severely damage the remote control. • WARNING: Do not dispose of batteries in a fire. batteries may explode or leak. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. lOCATION OF CONTROlS 1. MUTE button 2. BLUETOOTH button 3. VOL / button / / button 4. AUX button 5. BASS / button 6. button 7. LINE IN button 8. OPTICAL button 9. TREBLE / button 10 SOURCE / button REmOTE CONTROl REmOTE CONTROl 1. Standby/ON button 2. SOURCE button 3. BLUETOOTH / LEVEL indicator 4. AUX IN / LEVEL indicator 5. OPTICAL IN / LEVEL indicator 6. LINE IN / LEVEL indicator 7. / VOLUME button 8. DC IN jack 9. AUX IN R / L jack 10. LINE IN 3.5mm jack 11. OPTICAL IN jack 12. Remote Sensor SOUNdBASE 4 …

Text truncated - open the document above for the full version.

Electronics Limited A member of the ALCO group 11/F Zung Fu Industrial Building,1067 King’s Road, Quarry Bay, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2597 5201, (852) 2811 1056 Authorization Letter Jun 26, 2014 Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Dear Sir/Madam We, the undersigned, hereby authorize Jeffrey Chen of SGS IECC Limited to act on our behalf in all matter relating to FCC equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS IECC Limited on our behalf shall have the same effect as acts of our own. This authorization is valid for the FCC Certification with FCC ID: A2HRTS7010B1 and expires until further notice. Signature: _________________________________ Name:______Peggy Suen _____________________ Title: ______Secretary, EG Dept._______________

022311 – 6 Electronics Limited A member of the ALCO group 11/F Zung Fu Industrial Building,1067 King’s Road, Quarry Bay, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2597 5201 , (852) 2811 1056 Authority to Act as Agent Date: 23 Apr 2014 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: SGS IECC limited is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: _____until further notice____ By: __________________________ ______Peggy Suen__________ (Signature 1 ) (Print name) Title: __Secretary, E/G Dept.________ On behalf of: ___Alco Electronics Ltd._______ (Company Name) Telephone: ____(852) 2562 6121____________ 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 022311 – 6 Electronics Limited A member of the ALCO group 11/F Zung Fu Industrial Building,1067 King’s Road, Quarry Bay, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2597 5201 , (852) 2811 1056 Request for Confidentiality Date: 23 Apr 2014 Subject: Confidentiality Request for: __FCC ID: A2HRTS7010B1 / IC ID: 9903A-RTS7010B1______ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term a aa a Permanent Block Diagrams Short Term External Photos Short Term Permanent* 2 Internal Photos Short Term a aa a Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term a aa a Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ _Alco Electronics Ltd_ has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 3 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: _______________(Secretary, E/G Dept) __ ______Peggy Suen___________ (Signature/Title 4 ) (Print name) 2 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 3 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 4 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead.

FCC ID: A2HRTS7010B1 External Photo FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1

SBT17010BGE1 Labels for FCC application Jan 24, 2014 Feb 18, 2014 (Rev.01) Feb 19, 2014 (Rev.02) Apr 23, 2014 (Rev.03) Jul 24, 2014 (Add label sizes) Label position spec label CARB label at the bottom of the unit RCA RTS7010B-E1VENTURER SBT17010BGE1 RCA RTS7010BEVENTURER SBT17630B Model: RTS7010BE DC IN 13V 1.8A FCC ID: A2HRTS7010B1 DC IN 13V 1.8A FCC ID: A2HRTS7010B1 Model: SBT17630B Model: RTS7010B-E1 DC IN 13V 1.8A FCC ID: A2HRTS7010B1 DC IN 13V 1.8A FCC ID: A2HRTS7010B1 Model: SBT17010BGE1 100mm 25mm

FCC ID: A2HRTS7010B1 Internal Photo FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1

Report No.: HKES140100023302 Page: 1 of 29 Authorized Signature: CHEN Jian-feng, Jeffrey The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS IECC Limited or testing done by SGS IECC Limited in connection with, distribution or use of the product described in this report must be approved by SGS IECC Limited in writing. This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only . FCC ID: A2HRTS7010B1 Member of the SGS Group (SGS SA) FCC Test Report Application No.: HKES140100023301 Applicant: ALCO ELECTRONICS LTD Address: 11/F, Zung Fu Industrial Building 1067 King's Road, Quarry Bay Hong Kong Product Information: Product Description: Soundbar with Bluetooth Model: SBT17010BGE1, RTS7010B, SBT17110BG2, RTS7110B-22, RTS7010B-E1, SBT17630B, RTS7010BE, SBT17010BGE ♣ ♣ Please refer to section 2 of this report which indicates which item was actually tested and which were electrically identical. Brand Name: VENTURER, RCA Product Class : Low Power Communication Device – Transmitter (2.4 GHz) FCC ID: A2HRTS7010B1 Requirement: CFR 47 FCC PART 15 SUBPART C, 2013 - Intentional Radiators. (Section: 15.249) Date of Receipt: 2014-01-29 Date of Test: 2014-03-04 to 2014-03-11 Date of Issue: 2014-03-21 Test Result : PASS* * In the configuration tested, the EUT complied with the requirements for the relevant clauses of Federal Communications Commission Rules as specified above. Report No.: HKES140100023302 Page: 2 of 29 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only . FCC ID: A2HRTS7010B1 Member of the SGS Group (SGS SA) 2 Test Summary Test Test Requirement Test Method Result Conducted Emission (150KHz to 30MHz) FCC PART 15, SUBPART C: 2013 ANSI C63.4:2003 PASS Radiated Emission (9kMHz to 1GHz) FCC PART 15, SUBPART C: 2013 ANSI C63.4:2003 PASS Radiated Emission above 1 GHz FCC PART 15, SUBPART C: 2013 ANSI C63.4:2003 PASS Band edge / 20 dB Bandwidth FCC PART 15, SUBPART C: 2013 ANSI C63.4:2003 Marker-Detla measurement PASS ♣ Item no.: SBT17010BGE1, RTS7010B, SBT17110BG2, RTS7110B-22, RTS7010B-E1, SBT17630B, RTS7010BE, SBT17010BGE According to the confirmation from the applicant, the above models are identical in all electrical aspects in relating to the circuit design, PCB layout and construction. The difference is the model number for trading purpose. Therefore only the item SBT17010BGE1 was tested in this report. Report No.: HKES140100023302 Page: 3 of 29 This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at www.sgs.com/terms_and_conditions.htm and, for electronic format documents, subject to Terms and Conditions for Electronic Documents at www.sgs.com/terms_e-document.htm . Attention is drawn to the limitation of liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content…

Text truncated - open the document above for the full version.

FCC ID: A2HRTS7010B1 Setup Photo Radiated emission FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 FCC ID: A2HRTS7010B1 Conducted emission
