A2HSBT1739-SWESubwoofer

SUBWOOFER SBT1739-SWE USER ManUal It is important to read this instruction book prior to using your new product for the first time. The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to cause an electric shock. The symbol for Class II (Double Insulation) SaFETY InSTRUCTIOnS On PlaCEMEnT • Do not use the unit in places that are extremely hot, cold, dusty, or humid. • The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains, etc. On SaFETY • When connecting or disconnecting the AC power cord, grip the plug and not the cord itself. Pulling the cord may damage it and create a hazard. • When you are not going to use the unit for a long period of time, disconnect the AC power cord. • No naked flame sources such as lighted candles should be placed on the AC power cord and the unit. • Leave a minimum of 10 cm around the apparatus for ventilation. • Attention should be drawn to the environmental aspects of battery disposal. • Use of apparatus in moderate climates. On COndEnSaTIOn • When left in a heated room where it is warm and damp, water droplets or condensation may form inside the unit. When there is condensation inside the unit, the unit may not function normally. Let the unit stand for 1 to 2 hours before turning the power on, or gradually heat the room and let the unit dry before use. RaTIng PlaTE lOCaTIOn • The rating plate is located at the rear of unit. WARNING: • Should any trouble occur, disconnect the AC power cord and refer servicing to a qualified technician. • Mains plug is used as the disconnect device, it shall remain readily operable and should not be obstructed during intended use. To be completely disconnected the apparatus from supply mains, the mains plug of the apparatus shall be disconnected from the mains socket outlet completely. FCC InFORMaTIOn NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. WARNING: THE APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON APPARATUS. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THE APPLIANCE TO RAIN OR MOISTURE. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE. CAUTION: TO REDUCE THE RISK OF FIRE, DO NOT PLACE ANY HEATING OR COOKING APPARATUS BENEATH THIS UNIT. CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT OF POWER OUTLET, THEN FULLY INSERT. 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type. A polarized power plug has two blades with one wider than the other. A grounding type power plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided power cord does not fit into your AC power outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the AC power cord from being walked on or pinched particularly at the power plug, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13. Unplug this apparatus during lightning storms or when unused for long periods of time. 14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as the AC power cord is damaged, liquid has spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. IMPORTanT SaFETY InSTRUCTIOnS 1. Rear speakers terminal 2. Wireless link button/ Wireless link pairing indicator 3. Power switch 4. Power cord to wall outlet lOCaTIOn OF COnTROlS PlaCEMEnT POSITIOnIng SPEaKERS SUBWOOFER A subwoofer is designed to reproduce powerful low bass effects (explosions, the rumble of spaceships, etc.). It is not recommended to place the subwoofer near the TV set. Place the subwoofer at least 12” away from the TV. REaR SPEaKERS (SURROUnd SPEaKERS) Place Surround speakers to either side of the listening area, not behind it and if space permits, intall Surround speakers 2-3 feet above viewers. This help to minimize localization effects. COnnECTIOnS COn…

Text truncated - open the document above for the full version.

16MbitFLASH 2.4G Wireless Module 16MHz A7125 2.4GHz FSKTransceiver I2S Audio Interface GW 9618 2404.5MHz -2479.5MHz 2404.0MHz -2479.0MHz Y116MHz

Electronics Limited A member of the ALCO group 11/F Zung Fu Industrial Building,1067 King’s Road, Quarry Bay, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2597 5201 , (852) 2811 1056 Letter of Agency "I, an officer of Alco Electronics Ltd., do hereby authorize Intertek Testing Services (Mr. Terry Chan / Koo Wai Ip / Kenneth Wong) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under Part 15 and Part 18 of the FCC Rules until further notice." I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,862. Dated this 2 nd day of March, 2015 By _____________ ____ Signature _ Peggy Suen_____ _ ____ Printed Name _ Secretary, Engineering Dept. __ Title Remark: The person who signs this authorization letter must be the grantee contact of record in the Grantee Code data base.

INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (External)

WIRELESS LINK SLSR WARNING: SHOCK HAZARD - DO NOT OPEN AVERTISSEMENT: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE NE PAS EXPOSER CET APPAREIL À DE LA PLUIE OU DE L’HUMIDITÉ REAR OF SUBWOOFER AVC Multimedia MM/2015 CARB 93120 Compliant for Formaldehyde MM = production month SUBWOOFER AVC Multimedia Markham, Ontario L3R 1E3 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B) / NMB-3 (B) Model : SBT1739-SWE Power Source : 120V 60 Hz Made in China/Fabriqué en Chine/ Fabricado en China Power Consumption : 48W SUBWOOFER Venturer Electronics Inc. Markham, Ontario L3R 1B8 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B) / NMB-3 (B) FCC ID: A2HSBT1739-SWEFCC ID: A2HSBT1739-SWE Model : SBT1739-SWE Power Source : 120V 60 Hz Made in China/Fabriqué en Chine/ Fabricado en China Power Consumption : 48W Letter size 2mm

INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal) INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal) INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal) INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal) INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal) INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal) INTERTEK TESTING SERVICE Report No.: 15071297HKG-001 FCC ID: A2HSBT1739-SWE Equipment Photographs Model: SBT1739-SWE (Internal)

Technical Description The Equipment Under Test (EUT) is the wirless Subwoofer Unit (with two separate surround speakers) of Home Theatre Sound Bar. The audio signal can be sent via the 2.4GHz Digital wireless modules, which are incorporated in both soundbar unit and subwoofer unit. The EUT is powered by 120VAC mains. 2.4GHz Wireless Module: Modulation Type: GFSK Antenna Type: Integral, Internal (PCB Trace) Frequency Range: 2404MHz - 2479MHz, 5MHz channel spacing, 16 channels Antenna Gain: 0dBi Nominal rated field strength: 92.0dBμV/m at 3m Maximum allowed field strength of production tolerance: +/- 3dB The functions of main ICs are mentioned below. 1) XL9618 (U1) acts as I2S audio interface with DSP. 2) The 16MHz crystal (Y1) provides system clock for U1. 3) A7125 (U6) is 2.4GHz FSK transceiver. 4) L2 is antenna matching network. 5) AU1 (2110) is surround speaker amplifiers. 6) AU3 (2110) is subwoofer amplifier. 7) U8 (CE2711) is DAC for surround channels. 8) SIC303 (CE2766) is DAC for subwoofer channel. 2.4GHz wirless module (channel table) ChannelFrequency 12.404GHz 22.409GHz 32.414GHz 42.419GHz 52.424GHz 62.429GHz 72.434GHz 82.439GHz 92.444GHz 102.449GHz 112.454GHz 122.459GHz 132.464GHz 142.469GHz 152.494GHz 162.479GHz ©2008-2013 Gigawit Electronics Ltd. Version 1.01 Page 1 of 13 GWK5NO_SW_TX Datasheet GWK5NO_SW 2.4GHz Wireless Subwoofer Module 1. General Description GWK5NO_SW is the optimized module dedicated for the wireless subwoofer application, it balance well between the cost and performance by utilizing the fact of subwoofer limited frequency response bandwidth. The narrow bandwidth enables GWK5NO_SW to transmit enough redundant data to combat with the 2.4GHz interference thus maintain the good co-existence performance in the 2.4GHz ISM band. Inheriting from its GWK5 family, GWK5NO_SW features both good wireless performance and audio performance. GWK5NO_SW has good RF co-existence and robust link quality, can combat the most interference from the crowded 2.4G ISM band. GWK5NO_SW uses non-compression PCM signal and 24bit high precision thus delivering very low THD audio. By adopting advance forward error correction and error concealment algorithm, GWK5NO_SW can reach <20ms latency, this makes it ideal for the Video synchronization, Home Theater applications. GWK5NO_SW is ideal for the subwoofer application not only by its competitive cost, but also by its flexibility for customized functions. The SW crossover frequency can be adjusted easily by the digital filter, and the general purpose I2C can be used to control customer peripheral unit to eliminate an extra microcontroller. 2. Applications z 5.1 Subwoofer Speaker z 2.1 Subwoofer Speaker z Soundbar Subwoofer z DVD 3. Features z 2.4GHz AFH Solution z 24bit high precision digital audioˈSNR>115dB z Optimized for subwoofer application, 20~250Hz bandwidth z Co-existence: small foot-print(2MHz bandwidth) enabling better 2.4GHz co-existence z Low Power: TX: 36mA/3.3V @ -3dBm RF Output z RF Range: 15m+ indoor z Pairing function to support multi TX/RX operating simultaneously z Optional I2S digital audio interface support most audio ADCs and DACs z Power management function and control for green power policy z General purpose I2C for digital amplifier control zFlexible design, custom functions supported ©2008-2013 Gigawit Electronics Ltd. Version 1.01 Page 2 of 13 GWK5NO_SW_TX Datasheet 4. Electrical Specification Description Min/Typical/Max General Supply voltage TX:3.3V Supply current TX: 36mA Operation temperature -10 ~ +60ć RF RF Frequency 2400 ~ 2483MHZ Modulation GFSK Data rate 2M bps TX Power -3dBm RX Sensitivity -90dBm RF Channels 16 RF Range 15m+ indoor Output/input gain 1:1 Frequency response 20Hz ~ 600Hz (-3dB) Latency 20ms S/N ratio 115dB THD < 0.01% @ 100Hz Dynamic range 90dB Table [1]: Electrical Specification ©2008-2013 Gigawit Electronics Ltd. Version 1.01 Page 3 of 13 GWK5NO_SW_TX Datasheet 5. GWK5NO_SW Pin Assignment Pin # Pin nameTypeDescription 1 GND P Ground 2 3.3V P +3.3V Power Input 3 MFB I/O Power or pairing key input, press long than 3s to turn on or off the module, press long than 10s to enter pairing mode. 4 LED I/O Status LED output 5 MCLK O I2S Master Clock Output, NC when I2S is in slave mode 6 I2SMOSI I/O I2S Data Master Output / Slave Input 7 I2SMISO I/O I2S Data Master Input / Slave Output 8 SCLK I/O I2S Bit Clock Input / Output 9 LRCK I/O I2S Left and Right Clock Input / Output 10 SDA /STANDBY I/O I2C Data or Standby Control, firmware configurable. For Standby mode, A high level will be asserted when no TX signal >5s. When used as I2C, External 4.7K pull-up resister required. 11 SCL /MUTE I/O I2C Clock or MUTE Control, firmware configurable. When used as I2C, External 4.7K pull-up resister required. 12 GND P Ground 13 NC NA Not Connected 14 GP5 P General purpose IO 15 GP4 I/O General purpose IO 16 GP3 I/O General purpose IO 17 GP2 I/O General purpose IO 18 GP8 I/O General purpose IO 19 TXD I/O UART TX 20 RXD I/O UART RX ©2008-2013 Gigawit Electronics Ltd. Version 1.01 Page 4 of 13 GWK5NO_SW_TX Datasheet 21 RST I Reset input, active low 22 KEY I/O Built-in ADC for KEY 23 LR2 NA Not Connected 24 NC NA Not Connected Table [2]. GWK5NO_SW Pin Description ©2008-2013 Gigawit Electronics Ltd. Version 1.01 Page 5 of 13 GWK5NO_SW_TX Datasheet 6. I2S Digital Audio Interface GWK5NO_SW supports 3 digital audio interface modes: Left justify mode, I2S mode and Right justify mode. Figure [1]. Left Justify Mode Figure [2]. Default I2S Mode Figure [3]. Right Justify Mode ©2008-2013 Gigawit Electronics Ltd. Version 1.01 Page 6 of 13 GWK5NO_SW_TX Datasheet GWK5NO_SW I2S interface can work as master or slave mode, the IO pin function is described below. The default configuration is GWK5NO_SW Tx in I2S slave mode, and GWK5NO_SW RX in left justify master mode. Other configurations are available upon customer request. Master ModeSlave Mode MCLK Output, Driving the external DSP or Codec Non fu…

Text truncated - open the document above for the full version.

Analysis Report FCC ID: A2HSBT1739-SWE The Equipment Under Test (EUT) is the wirless Subwoofer Unit (with two separate surround speakers) of Home Theatre Sound Bar. The audio signal can be sent via the 2.4GHz Digital wireless modules, which are incorporated in both soundbar unit and subwoofer unit. The EUT is powered by 120VAC mains. Antenna Type: Internal, integral antenna Antenna Gain: 0dBi Nominal rated field strength: 92.0dBμV/m at 3m Maximum allowed field strength of production tolerance: +/- 3dB According to the KDB 447498: Based on the Maximum allowed field strength of production tolerance was 95.0dBμV/m at 3m in frequency 2.479GHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 0.949mW Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power = 0.949mW. The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.479) mW = 9.53 mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

ALCO CONFIDENTIAL 5 5 4 4 3 3 2 2 1 1 D D C C B B A A Size: Rev: Sheet: of Title:MODEL: COMPANY: ALCO Electronics Limited Date: Data:Date: Drawn:Checked: Approved: LAST SAVED DATE: 1.0 Tuesday, May 26, 2015 1 3 A4 2013-12-04 DS.Tang Checked by Approved by SBT1739WSBLOCK 2013-12-04 2013-12-04 Size: Rev: Sheet: of Title:MODEL: COMPANY: ALCO Electronics Limited Date: Data:Date: Drawn:Checked: Approved: LAST SAVED DATE: 1.0 Tuesday, May 26, 2015 1 3 A4 2013-12-04 DS.Tang Checked by Approved by SBT1739WSBLOCK 2013-12-04 2013-12-04 Size: Rev: Sheet: of Title:MODEL: COMPANY: ALCO Electronics Limited Date: Data:Date: Drawn:Checked: Approved: LAST SAVED DATE: 1.0 Tuesday, May 26, 2015 1 3 A4 2013-12-04 DS.Tang Checked by Approved by SBT1739WSBLOCK 2013-12-04 2013-12-04 Wireless RX 4ohm SUB 8 ohm SR 2110 X 2 8 ohm SL DIGITAL AMP Wireless subwoofer &SR SL 3.3V STB5V +18V POWER DAC 20W 20W 40W CE2766 SBT1739WS BLOCK DIAGRAM ALCO CONFIDENTIAL 55 44 33 22 11 D D C C B B A A Standy5V +12VA +6VA +12VA Standy5V MUTE_CTL +12VA +6VA +6VA +6VA MUTE I2S_LRCKI2S_DATA PAIRING_LED I2S_SCLK WIR_PAIRING SDAI2S_MCLK DAC EN RESTN RESTN EN1 SUB_OUTP SUB_OUTN EN1 EN1 R_OUT L_OUT MUTE I2S_SCLK I2S_MCLK I2S_LRCK I2S_DATA D3.3V D3.3V 3.3V SUB_OUT R_OUT L_OUT DAC EN SUB_OUT I2S_SCLK I2S_MCLK I2S_LRCK I2S_DATA SUB SL SUB MUTE_CTL SCL SR SDA SCL 3.3V 3.3V 3.3V 3.3V PVDD PVDD PVDD PVDD PVDD PVDD PVDD PVDD Standy5V D-GND GND AGND GND AGND AGND D-GND 3.3V Standy5V 3 +12V 3 EN1 MUTE_CTL PVDD 3 SUB_SHUTDOWN 3 Size: Rev: Sheet: of Title:MODEL: COMPANY: ALCO Electronics Limited Date: Data:Date: Drawn:Checked: Approved: LAST SAVED DATE: 1.0 Wednesday, July 15, 2015 2 3 D 2013-10-31 DS.Tang Checked by Approved by SBT1739WS AMP 2013-10-31 2013-10-31 Size: Rev: Sheet: of Title:MODEL: COMPANY: ALCO Electronics Limited Date: Data:Date: Drawn:Checked: Approved: LAST SAVED DATE: 1.0 Wednesday, July 15, 2015 2 3 D 2013-10-31 DS.Tang Checked by Approved by SBT1739WS AMP 2013-10-31 2013-10-31 Size: Rev: Sheet: of Title:MODEL: COMPANY: ALCO Electronics Limited Date: Data:Date: Drawn:Checked: Approved: LAST SAVED DATE: 1.0 Wednesday, July 15, 2015 2 3 D 2013-10-31 DS.Tang Checked by Approved by SBT1739WS AMP 2013-10-31 2013-10-31 VOUT=0.8(R910+R911)/R9110.8(47+15)/15=3.307V Vfb=1.25V OP-OP+ OP+OP- OP-OP+ SLSR SUB_OUT SUB 4 ohm SP 8 ohm SP SR13 2.4KSR13 2.4K AC495 0.1UF AC495 0.1UF AU1 2110 AU1 2110 SDB 1 FAULTB 2 INL+ 3 INL- 4 GAIN0 5 GAIN1 6 NC0 7 AGND 8 AVDD 9 PLIM 10 INR- 11 INR+ 12 NC1 13 PBTL 14 VCCR0 15 VCCR1 16 NC2 17 OUTR+ 18 PGNDR 19 OUTR- 20 NC3 21 NC4 22 OUTL- 23 PGNDL 24 OUTL+ 25 NC5 26 VCCL0 27 VCCL1 28 SC720.1uFSC720.1uF SNC17 NC0805/SMD SNC17 NC0805/SMD SR41 39KSR41 39K 1uF/50V SC70 1uF/50V SC70 SD4 LL4148 SD4 LL4148 1 2 AR436 1KAR436 1K AC434 102PF AC434 102PF SR49 1K SR49 1K AC461 0.22UAC461 0.22U AC516 105 AC516 105 SC83 2.2nF SC83 2.2nF NC3NC3 . 1 SJ6 118-040446W000 SJ6 118-040446W000 1234 SCN3SCN3 12 AR440 10K AR440 10K AC471 0.22U AC471 0.22U SR47 2.4KSR47 2.4K SEC12 1000uF/25V SEC12 1000uF/25V AR512 0R AR512 0R SC826 NC SC826 NC SC40 1U SC40 1U +- SU3A D4558 +- SU3A D4558 32 1 84 SC254 0.1uF SC254 0.1uF AL409 33UH AL409 33UH R328 3K3R328 3K3 SR72 10KSR72 10K BR133 1K BR133 1K + SEC10 10uF/16V + SEC10 10uF/16V MARK4MARK4 . 1 SR8210KSR8210K AC524 470PF AC524 470PF SR33 1K SR33 1K SR98K2SR98K2 SW1 021-KQR901W000 SW1 021-KQR901W000 SR70 100KSR70 100K + BEC132 10U + BEC132 10U + BC104 470U/10V + BC104 470U/10V AC527 470PF AC527 470PF SC79 105 SC79 105 AC535 0.47UF AC535 0.47UF AC5390.47UFAC5390.47UF AC512 105 AC512 105 SC53 1U SC53 1U SNC19 NC0805/SMD SNC19 NC0805/SMD SC76 10uF/10V SC76 10uF/10V SR28 39KSR28 39K SC150.1uFSC150.1uF SR51110KSR51110K AQ7BT3906AQ7BT3906 1 2 3 SQ6BT3904SQ6BT3904 1 23 SNC18 NC0805/SMD SNC18 NC0805/SMD BR132 1K BR132 1K AC497 0.1UF AC497 0.1UF WR602WR602 13579111315 16141210 8624 17 18 19 20 21 22 23 24 SC90 104PF SC90 104PF SR68 3.3K SR68 3.3K SC33 39pFSC33 39pF SC274 0.1uF SC274 0.1uF SR2220KSR2220K SR76 120K_1% SR76 120K_1% AR484 2K7 AR484 2K7 AC459 1UAC459 1U AR495 1KAR495 1K MARK3MARK3 . 1 + AEC428 220UF + AEC428 220UF SR71 0R SR71 0R 0.1U BC110 0.1U BC110 102BC96102BC96 SD5 LL4148 SD5 LL4148 1 2 SC56 1U SC56 1U SC454 220uF/10V SC454 220uF/10V SW602 021-SKQNABW000 SW602 021-SKQNABW000 SC257 0.01uF SC257 0.01uF SR79 NC SR79 NC AL407 22UH AL407 22UH SIC303 CE2766 CE2766 SIC303 CE2766 CE2766 DVDD 1 XCL 2 BCK 3 LRCK 4 DIN1 5 DIN2 6 DIN3 7 GR2 22 AR2 23 AGND 24 AL1 25 GR1 26 AR1 27 AVDD 28 TST 8 RESET 9 NC 10 DGND 11 TSTOUT 12 SDA 13 SCL 14 AVDD 15 VCM 16 AL3 17 GR3 18 AR3 19 AGND 20 AL2 21 SR3115KSR3115K SR84 3K3 SR84 3K3 SC824 NCSC824 NC SC101.2nFSC101.2nF AR423 10R AR423 10R SC3 4.7U SC3 4.7U Q3033904Q3033904 1 23 AR421 10R AR421 10R SJ7 CON4 SJ7 CON4 1234 AC464 102PF AC464 102PF SC260 22UF/6.3V SC260 22UF/6.3V SC828 NC SC828 NC SR69 10K SR69 10K R327 3K3R327 3K3 AC441 0.22UAC441 0.22U SU8 010-246221W000 SU8 010-246221W000 VIN 1 GND 2 EN 3 FB 4 VOUT 5 SC650.1uFSC650.1uF AC479 0.1UF AC479 0.1UF AL406 22UH AL406 22UH SR77 200K_1% SR77 200K_1% AC4991UFAC4991UF AR509 NC AR509 NC AC519 105 AC519 105 AR476 10K AR476 10K SR2 39KSR2 39K SC456 220uF/10V SC456 220uF/10V BR13410RBR13410R + SEC310uF/16V + SEC310uF/16V 102BC97102BC97 0.1uF/50V SC69 0.1uF/50V SC69 AC457 1UAC457 1U AR454 1K AR454 1K AR483 10K AR483 10K AR468 1K AR468 1K SR1015KSR1015K AC458 0.22UAC458 0.22U AR486 1K AR486 1K AR490 0R AR490 0R SC84 2.2nF SC84 2.2nF SC455 220uF/10V SC455 220uF/10V SR88 NC SR88 NC SC290.1uFSC290.1uF AC5051UFAC5051UF AC518 105 AC518 105 Q3063904Q3063904 1 23 AR478 1K AR478 1K AR467 4K7 AR467 4K7 AR488 3K AR488 3K SR75 10K SR75 10K SR74 NCSR74 NC SR18 220RSR18 220R AC426 0.22U AC426 0.22U AR498 NC AR498 NC AL40422UHAL40422UH AR487 0R AR487 0R SD3 LL4148 SD3 LL4148 1 2 SC371.2nFSC371.2nF SC8 39pFSC8 39pF SC640.1uFSC640.1uF AC500 1UF AC500 1UF AC496 1UF AC496 1UF BR130 1K BR130 1K SR86 10RSR86 10R AL408 33UH AL408 33UH AR419 10R AR419 10R SR453 6.8RSR453 6.8R + BEC133 10U + BEC133 10U SR67 4.7K SR67 4.7K + SEC4 10uF/1…

Text truncated - open the document above for the full version.

1 1 2 2 3 3 4 4 DD CC BB AA ** GWK5NO_TX * 2013/7/4 Title: Size: Date: Revision: Sheet:of A4 Cannot open file E:\K4x\template\logonew.jpg Gigawit Electronics Ltd., All Rights Reserved. Designed By:Checked By: 17:21:27 Jeff* Approved By: * 3.3VIN C18 10uF/10V/X7R RF C11 NC ANT1 C13 NC L2 2.7nH C10 10uF/10V/X7R R6 10K VCC33 RSTN 1 2 3 4 6 5 RM1 RFM_K5NO I2SSCLK I2SLRCK I2SMCLK I2SMOSITXD RXD BLED SDA SCL ADCKEY I2SMISO 3.3VIN RSTN MFB GPIO8 GPIO2 GPIO3 GPIO5 GPIO4 1 2 3 4 5 6 7 8 9 10 11 1213 23 22 21 20 19 18 17 16 15 14 24 J1 Header 12X2 PIANT101PIANT102 COANT1 PIC1001 PIC1002 COC10 PIC1101 PIC1102 COC11 PIC1301 PIC1302 COC13 PIC1801 PIC1802 COC18 PIJ101 PIJ102 PIJ103 PIJ104 PIJ105 PIJ106 PIJ107 PIJ108 PIJ109 PIJ1010 PIJ1011 PIJ1012PIJ1013 PIJ1014 PIJ1015 PIJ1016 PIJ1017 PIJ1018 PIJ1019 PIJ1020 PIJ1021 PIJ1022 PIJ1023 PIJ1024 COJ1 PIL201PIL202 COL2 PIR601 PIR602 COR6 PIRM101 PIRM102 PIRM103 PIRM104 PIRM105 PIRM106 CORM1 1 1 2 2 3 3 4 4 DD CC BB AA ** RF_A7125 * 2013/7/4 Title: Size: Date: Revision: Sheet:of A4 Cannot open file E:\K4x\template\logonew.jpg Gigawit Electronics Ltd., All Rights Reserved. Designed By:Checked By: 17:21:27 Jeff* Approved By: * BP_RSSI 1 BP_BG 2 RFI 3 RFO 4 RFC 5 V D D _ V C O 6 C P 7 V D D _ P L L 8 X I 9 X O 1 0 SCS 11 SCK 12 VDD_D 13 SDIO 14 GND 15 G I O 1 1 6 G I O 2 1 7 C K O 1 8 R E G I 1 9 V D D _ A 2 0 PAD 0 U6 A7125 C37 2.2pF C40 1nF/NPO C39 100pF/NPO C38 4.7uF/10V/X7R C46 100pF/NPO C45 0.1uF/X7R C48 0.1uF/X7R C44 100pF/NPO C36 4.7uF/10V/X7R C42 3.9pF/NPO L12 1.8nH L11 2.7nH R14 2.7K C47 180pF/NPO C49 2.2nF SPICSN SPISCK VDD_A VDD_A VDD_A SPISDO 3.3VRF3.3VRF SPISDI RFGIO2 OSCOUT C55 1nF/NPO C57 10pF/NPO RFOSC VDDA Output Internal digal circuit LDO decoupler C41 4.7uF/10V/X7R C24 NC C28 1.2pF/NPO C29 1.2pF/NPO L7 2.7nH L6 2.2nH RF R15 NC PIC2401 PIC2402 COC24 PIC2801 PIC2802 COC28 PIC2901 PIC2902 COC29 PIC3601 PIC3602 COC36 PIC3701 PIC3702 COC37 PIC3801 PIC3802 COC38 PIC3901 PIC3902 COC39 PIC4001 PIC4002 COC40 PIC4101 PIC4102 COC41 PIC4201PIC4202 COC42 PIC4401 PIC4402 COC44 PIC4501 PIC4502 COC45 PIC4601 PIC4602 COC46 PIC4701 PIC4702 COC47 PIC4801 PIC4802 COC48 PIC4901 PIC4902 COC49 PIC5501PIC5502 COC55 PIC5701PIC5702 COC57 PIL601PIL602 COL6 PIL701PIL702 COL7 PIL1101 PIL1102 COL11 PIL1201 PIL1202 COL12 PIR1401 PIR1402 COR14 PIR1501 PIR1502 COR15 PIU600 PIU601 PIU602 PIU603 PIU604 PIU605 PIU606PIU607PIU608PIU609PIU6010 PIU6011 PIU6012 PIU6013 PIU6014 PIU6015 PIU6016PIU6017PIU6018PIU6019PIU6020 COU6 1 1 2 2 3 3 4 4 DD CC BB AA ** XL9618 * 2013/7/4 Title: Size: Date: Revision: Sheet:of A4 Cannot open file E:\K4x\template\logonew.jpg Gigawit Electronics Ltd., All Rights Reserved. Designed By:Checked By: 17:21:27 Jeff* Approved By: * TXD SCL SDARLED BLED P W R E N RSTN VCC33 SPICSN VCC33 C1 4.7uF/10V/X7R C2 1nF/NPO SPISDI SPISCK C3 1 0 u F / 1 0 V / X 7 R 1 2 3 4 5 6 7 8 9 10 11 12 1 3 1 4 1 5 1 6 1 7 1 8 1 9 2 0 2 1 2 2 2 3 2 4 25 26 27 28 29 30 31 32 33 34 35 36 3 7 3 8 3 9 4 0 4 1 4 2 4 3 4 4 4 5 4 6 4 7 4 8 U1 XL9618 I2SSCLK A D C K E Y G P I O 6 M F B A D C B A T I 2 S M C L K I2SMOSI I2SMISO GPIO5 RFCKO G P I O 7 RXD RFGIO2 PA_PWM GPIO4 G P I O 1 SPISDO IRKEY T X _ R X N T X N _ R X G P I O 2 G P I O 3 I2SLRCK G P I O 0 R2 2R2 R1 2R2 VCC33 3.3VRF 3.3VIN GPIO8 I 2 S L R C K P L L _ P W M PWM Assignment PWM0 - Clock PLL PWM1 - PA PWM2 - MCLK PWM3 - LRCK PWM4 - Unused PWM5 - LED1 PWM6 - Capture for LRCK in I2S Slave PWM7 - LED0 A N S W 0 A N S W 1 I 2 S L R C K C5 8.2pF/NPO OSCOUT R3 10K C4 1uF R4 100K 1 2 D1 KDV202E-B C6 330pF X1 1 G 2 G 4 X2 3 Y1 16MHz/10ppm/9pF PIC101 PIC102 COC1 PIC201 PIC202 COC2 PIC301 PIC302 COC3 PIC401 PIC402 COC4 PIC501 PIC502 COC5 PIC601PIC602 COC6 PID101 PID102 COD1 PIR101PIR102 COR1 PIR201PIR202 COR2 PIR301 PIR302 COR3 PIR401PIR402 COR4 PIU101 PIU102 PIU103 PIU104 PIU105 PIU106 PIU107 PIU108 PIU109 PIU1010 PIU1011 PIU1012 PIU1013PIU1014PIU1015PIU1016PIU1017PIU1018PIU1019PIU1020PIU1021PIU1022PIU1023PIU1024 PIU1025 PIU1026 PIU1027 PIU1028 PIU1029 PIU1030 PIU1031 PIU1032 PIU1033 PIU1034 PIU1035 PIU1036 PIU1037PIU1038PIU1039PIU1040PIU1041PIU1042PIU1043PIU1044PIU1045PIU1046PIU1047PIU1048 COU1 PIY101 PIY102 PIY103 PIY104 COY1

- Intertek's standard Terms and Conditions can be obtained at our website http://www.intertek.com/terms/. - This report shall not be reproduced, except in full. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com TEST REPORT Report No.: 15071297HKG-001 Alco Electronics Ltd Application For Certification (Original Grant) (FCC ID: A2HSBT1739-SWE) Transceiver Prepared and Checked by: Approved by: Signed On File Wong Cheuk Ho, Herbert Lead Engineer Wong Kwok Yeung, Kenneth Lead Engineer Date: August 17, 2015 INTERTEK TESTING SERVICES Report No.: 15071297HKG-001 i FCC ID: A2HSBT1739-SWE GENERAL INFORMATION Grantee: Alco Electronics Ltd Grantee Address: 11/F, Zung Fu Industrial Building, 1067 King’s Road, Quarry Bay, Hong Kong. Contact Person: Peggy Suen Tel: (852) 2562 6121 Fax: (852) 2597 5201 e-mail: [email protected] Manufacturer: Alco Electronics (Dongguan) Limited Manufacturer Address: Gong Ye Xi Road, Houjie Technology Industrial Park, Houjie, Dongguan, Guangdong P.R.C. 523960 China Brand Name: VENTURER / RCA Model: SBT1739-SWE Type of EUT: Transceiver Description of EUT: Subwoofer Serial Number: N/A FCC ID: A2HSBT1739-SWE Date of Sample Submitted: July 24, 2015 Date of Test: July 24, 2015 to August 12, 2015 Report No.: 15071297HKG-001 Report Date: August 17, 2015 Environmental Conditions: Temperature: +10 to 40°C Humidity: 10 to 90% INTERTEK TESTING SERVICES Report No.: 15071297HKG-001 ii FCC ID: A2HSBT1739-SWE SUMMARY OF TEST RESULT TEST SPECIFICATION REFERENCE RESULTS Transmitter Power Line Conducted Emissions 15.207 Pass Radiated Emission Radiated Emission on the Bandedge 15.249, 15.209 Pass Radiated Emission in Restricted Bands 15.205 Pass The equipment under test is found to be complying with the following standards: FCC Part 15, October 1, 2014 Edition Note: 1. The EUT uses a permanently attached antenna which, in accordance to section 15.203, is considered sufficient to comply with the pervisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if…

Text truncated - open the document above for the full version.
