A2HSPS3911Undercabinet Docking Tablet

Under Cabinet Speaker Dock SPS3911 User manual It is important to read this instruction book prior to using your new product for the first time. Il est important de lire ce manuel d’instructions avant d’utiliser l’appareil pour la première fois. Es importante que lea este libro de instrucciones antes de comenzar a usar su nuevo producto. 2 SAFETY INSTRUCTIONS FCC INFORMATION This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. WARNING: • Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. • The AC adapter is used as disconnect device and it should remain readily operable during intended used. In order to disconnect the unit from the mains completely, the AC adapter should be disconnected from the mains socket outlet completely. • The AC adapter of unit should not be obstructed OR should be easily accessed during intended use. • Minimum 10 cm (4 inches) distances around the unit for sufficient ventilations. • The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains, etc. • No naked flame sources such as lighted candles should be placed on the unit. ON SAFETY • Should any objects or liquids fall into the unit, disconnect the power supply and have the unit checked by qualified personnel before any further operation. • The unit shall not be exposed to dripping or splashing and that no objects filled with liquid, such as vases, shall be placed on the unit. ON USE Never use the unit where it would be subject to: - Heat sources such as radiators or air ducts. - Direct sunlight. The device has been evaluated to meet general RF exposure requirement. To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. FOR CUSTOMERS IN CANADA This apparatus complies with the Class B limits for radio noise emission set out in radio interference regulations. CAN ICES-3 (B) / NMB-3 (B) This device complies with Industry Canada licence- exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 3 POWER SUPPLY USING THE AC ADAPTER Using an AC adapter other than the one supplied with the unit may damage the unit. Caution: • Before use, ensure the rated voltage of the adapter matches your local voltage. • The included AC adapter is for use with this unit only. Do not use it with other equipment. • If you are not going to use the unit for a long time, disconnect the AC adapter from the wall outlet. • Whenever the AC adapter is plugged in to a wall outlet, the AC adapter will draw some power, even when the Sound Bar is turned off. USING THE REMOTE CONTROL • Point the remote control at the REMOTE SENSOR located on the unit (see Front Panel illustration for precise location). • When there is a strong ambient light source, the perform ance of the infrared REMOTE SENSOR may be degraded, causing unreliable operation. • The recommended effective distance for remote operation is about 16 feet (5 meters). BATTERY REPLACEMENT When the batteries become weak, the operating distance of the remote control is greatly reduced and you will need to replace them. Notes: • If the remote control is not going to be used for a long time, remove the batteries to avoid corrosion damage caused by battery leakage. • Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or rechargeable (NICKEL-CADMIUM) batteries. • Always remove batteries as soon as they become weak. • Weak batteries can leak and severely damage the remote control. • WARNING: Do not dispose of batteries in a fire. batteries may explode or leak. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. REMOTE CONTROL TO CHANGE REMOTE BATTERIES 1. Open the battery door. 2. Insert two AAA batteries. 4 LOCATION OF CONTROLS 1. button 2. VOL / button / / button 3. BLUETOOTH button 4. SOUCE button 5. MUTE button 6 LIGHT button REMOTE CONTROL 1. Standby/ON button 2. LED INDICATOR GREEN indicator - illuminate when docking to a tablet, will turn off in 30 seconds after docked. RED indicator - standby mode BLUE indicator - flash when bluetooth pairing, solid when connected to a bluetooth device. 3. BLUETOOTH button 4. Light button Turn the left and right light strip to on and off. 5. Remote Sensor 6. / VOLUME button 7. Left and Right Light strip 8. Tablet support …

Text truncated - open the document above for the full version.

Electronics Limited A member of the ALCO group 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Tel: (852) 2562 6121, Fax: (852) 2811 1056 7 May 2020 To whom it may concern, Multiple Models Confirmation Letter I, the undersigned, hereby confirm that the family models are listed in the following table. These models are identical as follows: √ Electronics/electrical designs, including software & firmware √ Construction design/Physical design/Enclosure √ PCB layout □ (Others, please specify) The only differences between these models are the follows for marketing purpose: □ Color □ Cosmetic details √ Trade name √ Model Number □ (Others, please specify) Item No. New model Model Number Trade Name Remarks 1 √ YES KLR19113 VENTURER 2 √ YES SPS3911 RCA 3 4 5 6 The sample being submitted for conformity assessment is KLR19113 (tested model) of the above list. Best Regards, Alco Electronics Ltd. PEGGY SUEN Secretary, Engineering Dept. (for Peggy Suen)

2020-05-22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: A2HSPS3911 Product Name: Undercabinet Docking Tablet Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name : Peggy Suen Title: Secretary, E/G Dept. Applicant Company: Alco Electronics Ltd (for Peggy Suen)

2020-05-22 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Huatongwei International Inspection Co., Ltd./ 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China / Hans Hu , to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Alco Electronics Ltd / 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Signature: Name : Peggy Suen Title: Secretary, E/G Dept. Applicant Company: Alco Electronics Ltd (for Peggy Suen)

External Photos

RCA SPS3911 Venturer KLR19113 - FCC application 04-May-2020

Internal Photos

FCC ID: A2HSPS3911 RF Exposure Evaluation LIMIT The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 )6 30–300 61.4 0.163 1.0 6 300–1500 - - f/300 6 1500–100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 )30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 Note: f = frequency in MHz EVALUATION METHOD Transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW, G = gain of antenna in linear scale; Pi = 3.1416, R = distance between observation point and center of the radiator in cm TEST RESULT Passed Not Applicable Type Conducted Peak Power (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result BT-EDR 3.05 0.0006 1.0000 Pass Note: 1)The maximum antenna gain is 1.5dBi 2)The exposure evaluation safety distance is 20cm.

Page: 1 of 40 TEST REPORT Report No. ...................................... : CHTEW20050070 Report Verification: Project No.................................： SHT2004144301EW FCC ID ............................................. : A2HSPS3911 Applicant’s name ........................... : Alco Electronics Ltd Address ............................................. : 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Manufacturer.....................................: Alco Electronics Ltd Address..............................................: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Test item description .................... : Undercabinet Docking Tablet Trade Mark ....................................... : Venturer / RCA Model/Type reference ....................... : KLR19113 Listed Model(s) ................................. : SPS3911 Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: May 06, 2020 Date of testing.............................: May 07, 2020- May 18, 2020 Date of issue...............................: May 19, 2020 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Fanghui Zhu Supervised by (Position+Printed name+Signature): Project Engineer Cheng Xiao Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW20050070 Page: 2 of 40 Issued: 2020-05-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) Contents 1. TEST S T AN D AR D S A N D R E P O R T V E R S I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Test mode 7 4.4. Support unit used in test configuration and system 8 4.5. Testing environmental condition 8 4.6. Measurement uncertainty 8 4.7. Equipment Used during the Test 9 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna Requirement 11 5.2. AC Conducted Emission 12 5.3. Peak Output Power 15 5.4. 20 dB Bandwidth 16 5.5. 99% Occupied Bandwidth 17 5.6. Carrier Frequencies Separation 18 5.7. Hopping Channel Number 19 5.8. Dwell Time 20 5.9. Duty Cycle Correction Factor (DCCF) 21 5.10. Pseudorandom Frequency Hopping Sequence 22 5.11. Conducted Band edge and Spurious Emission 23 5.12. Radiated Band edge Emission 25 5.13. Radiated Spurious Emission 28 6. TEST SETUP PHOTOS 33 7. EXTERANAL AND INTERNAL PHOTOS 35 8. APPENDIX REPORT 40 Report No.: CHTEW20050070 Page: 3 of 40 Issued: 2020-05-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2013: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2020-05-19 Original Report No.: CHTEW20050070 Page: 4 of 40 Issued: 2020-05-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result 5.1 Antenna Requirement 15.203/15.247 (c) PASS 5.2 AC Conducted Emission 15.207 PASS 5.3 Peak Output Power 15.247 (b)(1) PASS 5.4 20 dB Bandwidth 15.247 (a)(1) PASS 5.5 99% Occupied Bandwidth - PASS *1 5.6 Carrier Frequency Separation 15.247 (a)(1) PASS 5.7 Hopping Channel Number 15.247 (a)(1) PASS 5.8 Dwell Time 15.247 (a)(1) PASS 5.9 Duty Cycle Correction Factor - PASS *1 5.10 Pseudorandom Frequency Hopping Sequence 15.247(b)(4) PASS 5.11 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS 5.12 Radiated Band Edge Emission 15.205/15.209 PASS 5.13 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW20050070 Page: 5 of 40 Issued: 2020-05-19 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V02 (2019-10) 3. SUMMARY 3.1. Client Information Applicant: Alco Electronics Ltd Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong Manufacturer: Alco Electronics Ltd Address: 11/F Metropole Square, 2 On Yiu Street, Sha Tin, New Territories, Hong Kong 3.2. Product Description Name of EUT: Undercabinet Docking Tablet Trade Mark: Venturer / RCA Model No.: KLR19113 Listed Model(s): SPS3911 Power supply: DC 13V Hardware version: V1.0 Software version: …
