A4RGXCA6Wireless Device

Get started in three simple steps: 1. Plug the power cable into the device. 2. Plug the power adapter into a wall outlet. 3. Please download and run the APP on a phone or tablet. 4. Finish setting up the device through the APP. Regulatory Information: United States FCC Regulatory Compliance Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the manufacture could void your authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: 1. These devices may not cause harmful interference. 2. These devices must accept any interference received, including interference that may cause undesired operation. Responsible party – U.S. contact information Google LLC, 1600 Amphitheatre Parkway, Mountain View, CA 94043. Contact : https://g.co/nest/contact Radio Frequency Exposure This device meets the U.S. Federal Communications Commission's (FCC) requirements for exposure to radio waves and is designed and manufactured not to exceed the FCC's emission limits for exposure to radio frequency (RF) energy. To comply with FCC RF exposure compliance requirements, a distance of at least 20 cm should be maintained between the antenna of this device and persons during device operation. This device must not be co-located or operating in conjunction with any other antenna or transmitter.

1 1600 Amphitheatre Parkway Mountain View, CA 94043 USA Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 March 20th, 2020 Subject: Request for Confidentiality FCC ID: A4RGXCA6 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 C.F.R. §§ 0.457, 0.459), we request that the Commission withhold the following attachments as confidential documents from public disclosure indefinitely. ● Schematic Diagram ● Block Diagram ● Theory of Operation (Operational and Technical Descriptions) ● SW Security Description In support of this request, we provide the following information: 1. Identification of the specific information for which confidential treatment is sought (§ 0.459(b)(1)): We request that all of the information contained in the above-referenced exhibits to the certification application be withheld from routine public disclosure. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission (§ 0.459(b)(2)): The material is being submitted in connection with our certification application for the above-captioned FCC ID. 3. Explanation of the degree to which the information is commercial, or financial or contains a trade secret or is privileged (§ 0.459(b)(3)): The market for the technology that is the subject of the certification application is highly competitive, with numerous companies competing for the business of potential customers. Were competitors to become aware of the facts set forth in the above-referenced exhibits to the application at this time, it could have an adverse impact on our competitive standing and deprive us of the marketplace benefit we otherwise might achieve by virtue of having the product available before other competitors. If any of the information for which confidential treatment is sought was made publicly available, competitors could reasonably determine the scope and status of our activities. 4. Explanation of the degree to which the information concerns a service that is competitive (§ 0.459(b)(4)): The technology that is the subject of the certification application is subject to intense competition from other manufacturers and service providers that are developing competing services and technology. 5. Explanation of how disclosure of the information could result in substantial competitive harm (§ 0.459(b)(5)): As noted above, were our competitors to become aware of the facts set forth in the above- 2 referenced exhibits to the application, it could have an adverse impact on our competitive standing and deprive us of the marketplace benefit we otherwise would achieve by virtue of having the product available before other providers. 6. Identification of any measures taken by the requesting party to prevent unauthorized disclosure (§ 0.459(b)(6)): The information contained in the above-referenced exhibits to the certification application has been strictly controlled by us, with distribution limited to internal use only and for the specific purpose of conducting research, development, and testing of the technology. 7. Identification of whether the information is available to the public and the extent of any previous disclosures of the information to any third parties (§ 0.459(b)(7)): The information that we request be maintained as confidential is not available publicly. The information has been protected and kept confidential by limiting external contacts to privileged and confidential communications. 8. Justification of the period during which the submitting party asserts that material should not be available for public disclosure (§ 0.459(b)(8)): Given the competitive nature of the marketplace, any disclosure that we have developed the technology discussed in the above-referenced exhibits to the certification application would harm our competitive position. The information subject to this request for confidentiality should not be made available for public disclosure at any time. In addition, pursuant to Public Notice DA 04-1705, and in order to comply with the marketing regulations in 47 C.F.R. §2.803 and the importation rules in 47 C.F.R. §2.1204 while ensuring that business-sensitive information remains confidential until the actual marketing of newly authorized devices, we also request that the Commission grant temporary confidential treatment and not release the following attachments for routine public disclosure until 180 days after the grant date. ● External Photos ● Internal Photos ● Test Setup Photos ● User Manual It is our understanding that test measurement reports and correspondence during the certification review process cannot be granted confidential treatment, and such information will be available for public review once the grant of equipment authorization is issued. Sincerely yours, ___________________________ Kevin Li Regulatory Compliance Program Manager Google LLC 1600 Amphitheatre Parkway Mountain View, CA 94043 T: 650-253-0000 E: [email protected]

1600 Amphitheatre Parkway Mountain View, CA 94043 USA 1 Date: March 20th, 2020 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: A4RGXCA6 To Whom It May Concern: I, the undersigned, hereby authorize Sporton International Inc. (Sporton) to act on Google LLC’s (Google) behalf in all manners relating to the above-captioned application for equipment authorization, including signing of all documents relating to this matter. Any and all acts carried out by Sporton on Google’s behalf shall have the same effect as acts of Google’s own. I, the undersigned, hereby certify that Google is not subject to a denial of federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 853(a). In authorizing Sporton as Google’s representative, Google recognizes that it is still responsible for: a) complying with the relevant provisions of the certification program; b) making all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) making claims regarding certification only in respect of the scope for which certification has been granted; d) not using the product certification in such a manner as to bring Sporton into disrepute and not making any statement regarding the product certification that Sporton may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinuing the use of all advertising matter that contains any reference thereto and return any certification documents as required by Sporton; f) using the certification only to indicate that the products are certified as being in conformity with specified standards; 1600 Amphitheatre Parkway Mountain View, CA 94043 USA 2 g) endeavoring to ensure that no certificate or report or any part thereof is used in a misleading manner; h) ensuring that any reference to the product certification in communication media such as documents, brochures, or advertising, complies with Sporton’s requirements; i) keeping a record of all complaints made known to Google relating to the product’s compliance with the requirements of the relevant standard and making these records available to the applicable authorities when requested; j) taking appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; and k) documenting the actions taken. This authorization is valid until further written notice from Google. Sincerely Yours, _____________________________ Kevin Li Regulatory Compliance Program Manager Google LLC 1600 Amphitheatre Parkway Mountain View, CA 94043 T: 650-253-0000 E: [email protected]

PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 1 of 6 FAX : 886-3-328-4978 Issued Date : May 26, 2020 Report Version : 01 External Photograph of EUT PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 2 of 6 FAX : 886-3-328-4978 Issued Date : May 26, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 3 of 6 FAX : 886-3-328-4978 Issued Date : May 26, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 4 of 6 FAX : 886-3-328-4978 Issued Date : May 26, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 5 of 6 FAX : 886-3-328-4978 Issued Date : May 26, 2020 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 6 of 6 FAX : 886-3-328-4978 Issued Date : May 26, 2020 Report Version : 01 ─────THE END──── 720510

FCC ID: A4RGXCA6 Model No: GXCA6 MADE IN CHINA Label will be printed at the bottom of the device

PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 1 of 5 FAX : 886-3-328-4978 Issued Date : Jun. 01, 2020 Report Version : 02 Internal Photograph of EUT PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 2 of 5 FAX : 886-3-328-4978 Issued Date : Jun. 01, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 3 of 5 FAX : 886-3-328-4978 Issued Date : Jun. 01, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 4 of 5 FAX : 886-3-328-4978 Issued Date : Jun. 01, 2020 Report Version : 02 PHOTOGRAPHS OF EUT Report No.: EP990608-02 Model Name: GXCA6 TEL : 886-3-327-3456 Page Number : 5 of 5 FAX : 886-3-328-4978 Issued Date : Jun. 01, 2020 Report Version : 02 ─────THE END──── 720510

TEL : 886-3-327-3456 Page : 1 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B RF EXPOSURE EVALUATION REPORT FCC ID : A4RGXCA6 Equipment : Wireless Device Model Name : GXCA6 Applicant : Google LLC 1600 Amphitheatre Parkway, Mountain View, California, 94043 USA Standard : 47 CFR Part 2.1091 We, SPORTON INTERNATIONAL INC has been evaluated this product in accordance with 47 CFR Part 2.1091 and it complies with applicable limit. The results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory, the test report shall not be reproduced except in full. Sporton Lab is accredited to ISO 17025 by Taiwan Accreditation Foundation (TAF code: 1190) and the FCC designation No. TW1190 under the FCC 2.948(e) by Mutual Recognition Agreement (MRA) in FCC evaluation. SPORTON INTERNATIONAL INC. EMC & Wireless Communications Laboratory No. 52, Huaya 1st Rd., Guishan Dist., Taoyuan City, Taiwan (R.O.C.) Approved by: Cona Huang / Deputy Manager TEL : 886-3-327-3456 Page : 2 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B Table of Contents 1. DESCRIPTION OF EQUIPMENT UNDER TEST (EUT) ............................................................................. 4 2. MAXIMUM RF AVERAGE OUTPUT POWER AMONG PRODUCTION UNITS ........................................ 4 3. RF EXPOSURE LIMIT INTRODUCTION .................................................................................................... 5 4. RADIO FREQUENCY RADIATION EXPOSURE EVALUATION ............................................................... 6 4.1. Standalone Power Density Calculation ............................................................................................. 6 4.2. Collocated Power Density Calculation ............................................................................................... 7 TEL : 886-3-327-3456 Page : 3 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B History of this test report Report No. Version Description Issued Date FA990608-02B Rev. 01 Initial issue of report May 12, 2020 TEL : 886-3-327-3456 Page : 4 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B 1. Description of Equipment Under Test (EUT) Product Feature & Specification EUT Type Wireless Device Model Name GXCA6 FCC ID A4RGXCA6 Wireless Technology and Frequency Range WLAN 2.4GHz Band: 2400 MHz ~ 2483.5 MHz WLAN 5.2GHz Band: 5150 MHz ~ 5250 MHz WLAN 5.3GHz Band: 5250 MHz ~ 5350 MHz WLAN 5.6GHz Band: 5470 MHz ~ 5725 MHz WLAN 5.8GHz Band: 5725 MHz ~ 5825 MHz Bluetooth: 2400 MHz ~ 2483.5 MHz Mode WLAN: 802.11a/b/g/n/ac HT20/HT40/VHT20/VHT40/VHT80 Bluetooth BR/EDR/LE Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. Reviewed by: Jason Wang Report Producer: Wan Liu 2. Maximum RF average output power among production units Mode Maximum Average Power (dBm) 2.4GHz WLAN 802.11b 17 802.11g 17 802.11n-HT20 17 802.11n-HT40 16 5GHz WLAN 802.11a 16 802.11n-HT20 16 802.11n-HT40 15 802.11ac-VHT20 16 802.11ac-VHT40 15 802.11ac-VHT80 12 Bluetooth BR/EDR 7 Bluetooth LE 7 TEL : 886-3-327-3456 Page : 5 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B 3. RF Exposure Limit Introduction According to ANSI/IEEE C95.1-1992, the criteria listed in Table 1 shall be used to evaluate the environmental impact of human exposure to radio frequency (RF) radiation as specified in §1.1310. The MPE was calculated at 20 cm to show compliance with the power density limit. The following formula was used to calculate the Power Density: 퐒= 퐏퐆 ퟒ훑퐑 ퟐ Where: S = Power Density P = Output Power at Antenna Terminals G = Gain of Transmit Antenna (linear gain) R = Distance from Transmitting Antenna TEL : 886-3-327-3456 Page : 6 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B 4. Radio Frequency Radiation Exposure Evaluation 4.1. Standalone Power Density Calculation <Ant 1> Band Antenna Gain (dBi) Maximum Power (dBm) Maximum EIRP (dBm) Maximum EIRP (W) Average EIRP (mW) Power Density at 20cm (mW/cm^2) Limit (mW/cm^2) Power Density / Limit 2.4GHz WLAN 3.80 17.00 20.800 0.120 120.226 0.024 1.000 0.024 5GHz WLAN 7.60 16.00 23.600 0.229 229.087 0.046 1.000 0.046 Bluetooth 3.80 7.00 10.800 0.012 12.023 0.002 1.000 0.002 Note: For conservativeness, the lowest frequency of each band is used to determine the MPE limit of that band <Ant 2> Band Antenna Gain (dBi) Maximum Power (dBm) Maximum EIRP (dBm) Maximum EIRP (W) Average EIRP (mW) Power Density at 20cm (mW/cm^2) Limit (mW/cm^2) Power Density / Limit 2.4GHz WLAN 3.90 17.00 20.900 0.123 123.027 0.024 1.000 0.024 5GHz WLAN 7.70 16.00 23.700 0.234 234.423 0.047 1.000 0.047 Bluetooth 3.90 7.00 10.900 0.012 12.303 0.002 1.000 0.002 Note: For conservativeness, the lowest frequency of each band is used to determine the MPE limit of that band TEL : 886-3-327-3456 Page : 7 of 7 FAX : 886-3-328-4978 Issued Date : May 12, 2020 Form version: 200414 RF EXPOSURE EVALUATION REPORT Report No. : FA990608-02B 4.2. Collocated Power Density Calculation Co-location 1 ANT1_BT+ANT2_2.4g 2 ANT1_BT+ANT2_5G 3 ANT1_BLE+ANT2_5G 4 ANT1_BLE+ANT2_2.4G 5 ANT2_BT+ANT1_2.4g 6 ANT2_BT+ANT1_5G 7 ANT2_BLE+ANT1_5G 8 ANT2_BLE+ANT1_2.4G Ant 1_2.4GHz/5GHz WLAN Power Density / Limit Ant 2_Bluetooth Power Density / Limit Σ(Power Density / Limit) of Ant 1 + Ant 2 0.046 0.002 0.048 Ant 1_Bluetooth Power Density / Limit Ant 2_2.4GHz/5GHz WLAN Power Density / Limit Σ(Power Density / Limit) of Ant 1 + Ant 2 0.002 0.047 0…
