A8TBM70ABCDEFGHBluetooth Module

Preliminary Revision 0.1 12/2015 DS60001372C-Page 53 BM70 Regulatory Compliance Information BM70 Regulatory Compliance Information Revision 0.1 Dec’ 2015 BM70 Regulatory Compliance Information Preliminary Revision 0.1 12/2015 DS60001372C-Page 54 This document covers the Regulatory Compliance information which is part of the BM70 Module datasheet and related documents shared with customers. Preliminary Revision 0.1 12/2015 DS60001372C-Page 55 BM70 Regulatory Compliance Information 1.0 ANTENNA 1.1 Antenna Characteristics 1.1.1 CERAMIC CHIP ANTENNA The BM70 module contains an integral ceramic chip antenna. The Figure 1-1 illustrates the antenna performance of the module. FIGURE 1-1: BM70 ANTENNA RADIATION PATTERN Gain (dBi) 0.0 5.0 -5.0 -10.0 -15.0 -20.0 -25.0 -30.0 -35.0 X - a x i s Y - a x i s Z - a x i s Frequency 2440 MHz Max Gain 1.63 dBi Efficiency 71.55% BM70 Regulatory Compliance Information Preliminary Revision 0.1 12/2015 DS60001372C-Page 54 APPENDIX A: CERTIFICATION NOTICES BM70 module regulatory approval status: • BT SIG/QDID:74246 • United States/FCC ID: A8TBM70ABCDEFGH • Canada/IC ID: 12246A-BM70BLES1F2 • Europe/CE: In Progress • Japan/MIC: 202-SMD069 • Korea/KCC: MSIP-CRM-mcp-BM70BLES1FC2 • Taiwan/NCC No: CCAN15LP0500T1 • China/SRRC: in Progress A.1 REGULATORY APPROVAL This section outlines the regulatory information for the BM70 module for the following countries: • United States • Canada • Europe • Japan • Korea • Taiwan • China A.1.1 UNITED STATES The BM70 module is in progress to receive Federal Communications Commission (FCC) CFR47 Telecom- munications, Part 15 Subpart C "Intentional Radiators" modular approval in accordance with Part 15.212 Mod- ular Transmitter approval. Modular approval allows the end user to integrate the BM70 module into a finished product without obtaining subsequent and separate FCC approvals for intentional radiation, provided no changes or modifications are made to the module cir- cuitry. Changes or modifications could void the user's authority to operate the equipment. The end user must comply with all of the instructions provided by the Grantee, which indicate installation and/or operating conditions necessary for compliance. The finished product is required to comply with all appli- cable FCC equipment authorizations regulations, requirements and equipment functions not associated with the transmitter module portion. For example, com- pliance must be demonstrated to regulations for other transmitter components within the host product; to requirements for unintentional radiators (Part 15 Sub- part B "Unintentional Radiators"), such as digital devices, computer peripherals, radio receivers, etc.; and to additional authorization requirements for the non-transmitter functions on the transmitter module (i.e., Verification, or Declaration of Conformity) (e.g., transmitter modules may also contain digital logic func- tions) as appropriate. A.1.2 LABELING AND USER INFORMATION REQUIREMENTS The BM70 module has been labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the out- side of the finished product into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording as follows: Contains Transmitter Module FCC ID: A8TBM70ABCDEFGH or Contains FCC ID: A8TBM70ABCDEFGH This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation A user's manual for the finished product should include the following statement: Additional information on labeling and user information requirements for Part 15 devices can be found in KDB Publication 784748 available at the FCC Office of Engi- Note: This device has no been auorized as required by the rules of the ederal Com- munications Commission This device is no and may not be, offered or sale or leas or sold or leased, until auorization is obtained is equipment has been tested and found o comply wihe limi for a Class B digil device pursuan o pa 15 of the FCC Rule These limis are designed provide reasonable protection agains haul inerence in a residential insallation. his equip- ment generate uses and can radiate radio fre- quency energy and if no insalled and used in accordance wi h he inruions may cause harmful inerence to radio communicions However ere is no guaranee hat innce will not occur in a par icular inllaion his equipmen does cause harmful innce to radio or television recepiowhich can be determined by urning the equipment of and on, the user is encouraged to ry to corre the inerence by one or more o the follow- ing measures • Reorien or relocae he receiving anenn • ncrease the separation between he equipment and receiver • Connec he equipmen inan outlet on a circui dieren from hat which the receiver is con- need. • Consult he dealer or an experienced radio chnician for help. Preliminary Revision 0.1 12/2015 DS60001372C-Page 55 BM70 Regulatory Compliance Information neering and Technology (OET) Laboratory Division Knowledge Database (KDB) http://apps.fcc.gov/oetcf/kdb/index.cfm. A.1.3 RF EXPOSURE All transmitters regulated by FCC must comply with RF exposure requirements. KDB 447498 General RF Exposure Guidance provides guidance in determining whether proposed or existing transmitting facilities, operations or devices comply with limits for human exposure to Radio Frequency (RF) fields adopted by the Federal Communications Commission (FCC). From the FCC Grant: Output power listed is conducted. This grant is valid only when the module is sold to OEM integrators and must be installed by the OEM or OEM integrators. This transmitter is restricted for use with the specific antenna(s) tested in this application for Certification and must not be co-located or operating in conj…

Text truncated - open the document above for the full version.

Appendix P Photo Documentation Page 1 of 2 10053523 001; 10053524 001; 10053580 001 Product: Brand Name: Bluetooth module Microchip Type Identification: BM70abcSeFC2,RN4870;(for NCC: BM70BLES1FC2, RN4870) 22mm (H) x 12mm (W) x 2.4mm (D) Chip Antenna Appendix P Photo Documentation Page 2 of 2 10053523 001; 10053524 001; 10053580 001 Product: Brand Name: Bluetooth module Microchip Type Identification: BM70abcSeFC2,RN4870;(for NCC: BM70BLES1FC2, RN4870)

Appendix P Photo Documentation Page 1 of 2 10053523 001; 10053524 001; 10053580 001 Product: Brand Name: Bluetooth module Microchip Type Identification: BM70abcSeFC2,RN4870;(for NCC: BM70BLES1FC2, RN4870) 22mm (H) x 12mm (W) x 2.4mm (D) Chip Antenna Appendix P Photo Documentation Page 2 of 2 10053523 001; 10053524 001; 10053580 001 Product: Brand Name: Bluetooth module Microchip Type Identification: BM70abcSeFC2,RN4870;(for NCC: BM70BLES1FC2, RN4870)

Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 27 von 32 Page 27 of 32 6. Safety Human exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT: Passed Test standard : FCC KDB Publication 447498 D01 v05 The maximum peak output power of the transmitter is 1.3677 mW. The separation between hand and antenna is more than 5mm. Hence the EUT is exclueded from SAR evaluation. Please also refer to FCC KDB publication 447498 D01 v05: Mobile Portable RF Exposure

Test Report No.10053523 10053524 001 Appendix D: Radiated and Mains Spurious Emission Data (File: 10053523 10053524AppendixD) Contents Spurious Emissions, Band Edges, 2.35-2.5G ............................................................................................. 2 Spurious Emissions, TX Mode, 1-18G ....................................................................................................... 6 Spurious Emissions, TX Mode, 18-26G ................................................................................................... 12 Spurious Emissions, TX Mode, 30M-1G ................................................................................................. 18 Spurious Emissions, RX Mode, 1-18G .................................................................................................... 20 Spurious Emissions, RX Mode, 18-26G .................................................................................................. 22 Spurious Emissions, RX Mode, 30M-1G ................................................................................................. 24 Spurious Emissions, Mains, 150kHz - 30MHz ......................................................................................... 26 Spurious Emissions, Band Edge, 2.35-2.5G 2 Spurious Emissions, Band Edges, 2.35-2.5G Radiated Bandedge (GFSK) Low Channel (Hor) Spurious Emissions, Band Edge, 2.35-2.5G 3 Low Channel (Ver) Spurious Emissions, Band Edge, 2.35-2.5G 4 Radiated Bandedge (GFSK) High Channel (Hor) Spurious Emissions, Band Edge, 2.35-2.5G 5 High Channel (Ver) Spurious Emissions, TX Mode, 1-18G 6 Spurious Emissions, TX Mode, 1-18G Service No.: 114035791-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2015/11/3 20:38:33 Applicant: Microchip Test Rating: DC 3.3V Product: Bluetooth module Temp.( °C °C°C °C)/Hum.(%): 19.5(°C °C°C °C)/67% Model No.: BM70abcSeFC2,RN4870 Test Engineer: George Yang Test Mode: 2402-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 4804.000 3.60 44.92 48.52 74.00 -25.48 peak 0 2 6168.000 6.21 43.99 50.20 74.00 -23.80 peak 100 349 3 7206.000 5.18 44.28 49.46 74.00 -24.54 peak 0 Tel:+886-2172-7000 fax:+886-2528-0018 11F., No.758, Sec.4 Bade Road. Songshan Dist, Taipei City 105 TUV Taiwan Spurious Emissions, TX Mode, 1-18G 7 Service No.: 114035791-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Vertical Test item: Radiation Emission Test Time: 2015/11/3 20:39:35 Applicant: Microchip Test Rating: DC 3.3V Product: Bluetooth module Temp.(°C °C°C °C)/Hum.(%): 19.5(°C °C°C °C)/67% Model No.: BM70abcSeFC2,RN4870 Test Engineer: George Yang Test Mode: 2402-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 4804.000 3.60 45.15 48.75 74.00 -25.25 peak 2 6185.000 6.22 44.50 50.72 74.00 -23.28 peak 100 201 3 7206.000 5.18 44.39 49.57 74.00 -24.43 peak Tel:+886-2172-7000 fax:+886-2528-0018 11F., No.758, Sec.4 Bade Road. Songshan Dist, Taipei City 105 TUV Taiwan Spurious Emissions, TX Mode, 1-18G 8 Service No.: 114035791-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2015/11/3 20:43:36 Applicant: Microchip Test Rating: DC 3.3V Product: Bluetooth module Temp.(°C °C°C °C)/Hum.(%): 19.5(°C °C°C °C)/67% Model No.: BM70abcSeFC2,RN4870 Test Engineer: George Yang Test Mode: 2440-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 4880.000 3.89 44.68 48.57 74.00 -25.43 peak 2 6678.000 5.94 44.84 50.78 74.00 -23.22 peak 100 293 3 7320.000 5.15 44.35 49.50 74.00 -24.50 peak Tel:+886-2172-7000 fax:+886-2528-0018 11F., No.758, Sec.4 Bade Road. Songshan Dist, Taipei City 105 TUV Taiwan Spurious Emissions, TX Mode, 1-18G 9 Service No.: 114035791-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Vertical Test item: Radiation Emission Test Time: 2015/11/3 20:44:39 Applicant: Microchip Test Rating: DC 3.3V Product: Bluetooth module Temp.(°C °C°C °C)/Hum.(%): 19.5(°C °C°C °C)/67% Model No.: BM70abcSeFC2,RN4870 Test Engineer: George Yang Test Mode: 2440-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 4880.000 3.89 44.01 47.90 74.00 -26.10 peak 2 6185.000 6.22 44.11 50.33 74.00 -23.67 peak 100 89 3 7320.000 5.15 44.19 49.34 74.00 -24.66 peak Tel:+886-2172-7000 fax:+886-2528-0018 11F., No.758, Sec.4 Bade Road. Songshan Dist, Taipei City 105 TUV Taiwan Spurious Emissions, TX Mode, 1-18G 10 Service No.: 114035791-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Horizontal Test item: Radiation Emission Test Time: 2015/11/3 20:48:29 Applicant: Microchip Test Rating: DC 3.3V Product: Bluetooth module Temp.(°C °C°C °C)/Hum.(%): 19.5(°C °C°C °C)/67% Model No.: BM70abcSeFC2,RN4870 Test Engineer: George Yang Test Mode: 2480-TX Remark: No. Frequency (MHz) Factor (dB/m) Reading (dBuV) Level (dBuV/m) Limit (dBuV/m) Margin (dB) Det. Height (cm) Azimuth (。 。。 。) Remark 1 4960.000 4.19 43.85 48.04 74.00 -25.96 peak 2 7440.000 5.10 45.00 50.10 74.00 -23.90 peak 3 8395.000 5.06 46.32 51.38 74.00 -22.62 peak 100 233 Tel:+886-2172-7000 fax:+886-2528-0018 11F., No.758, Sec.4 Bade Road. Songshan Dist, Taipei City 105 TUV Taiwan Spurious Emissions, TX Mode, 1-18G 11 Service No.: 114035791-NCC Test Distance: 3m Test Standard: NCC Above 1G PEAK Ant. Polarization: Vertical Test item: Radiation Emission Test Time: 2015/11/3 20:49:32 Applicant: Microchip Test Rating: DC 3.3V Product: Bluetooth module Temp.(°C °C°C °C)/Hum.(%): 19.5(°C °C°C °C)/67% Model No.: BM70abcSeFC2,RN4870 Test Engineer: George Yang Test Mode: 2480-TX Remark: No. Fre…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 2 von 32 Page 2 of 32 TEST SUMMARY 5.1.1 ANTENNA REQUIREMENT RESULT: Passed 5.1.2 PEAK OUTPUT POWER RESULT: Passed 5.1.3 6DB BANDWIDTH RESULT: Passed 5.1.4 POWER DENSITY RESULT: Passed 5.1.5 CONDUCTED SPURIOUS EMISSIONS AND FREQUENCY BAND EDGE MEASURED IN 100KHZ BANDWIDTH RESULT: Passed 5.1.6 SPURIOUS EMISSION RESULT: Passed 5.2.1 MAINS CONDUCTED EMISSIONS RESULT: Passed 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Passed Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 3 von 32 Page 3 of 32 Contents 1. GENERAL REMARKS ............................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ................................................................................. 4 2. TEST SITES ............................................................................................................ 5 2.1 TEST LABORATORY ................................................................................................ 5 2.2 TEST FACILITY ........................................................................................................ 5 2.3 LIST OF TEST AND MEASUREMENT INSTRUMENTS ...................................................... 6 2.4 TRACEABILITY ........................................................................................................ 7 2.5 CALIBRATION ......................................................................................................... 7 2.6 MEASUREMENT UNCERTAINTY ................................................................................. 7 3. GENERAL PRODUCT INFORMATION ........................................................................... 8 3.1 PRODUCT FUNCTION AND INTENDED USE ................................................................. 8 3.2 SYSTEM DETAILS AND RATINGS ............................................................................... 8 3.3 INDEPENDENT OPERATION MODES ........................................................................... 9 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS .............................................. 9 3.5 SUBMITTED DOCUMENTS ......................................................................................... 9 4. TEST SET-UP AND OPERATION MODES ................................................................... 10 4.1 PRINCIPLE OF CONFIGURATION SELECTION ............................................................ 10 4.2 TEST OPERATION AND TEST SOFTWARE................................................................. 10 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ............................................... 10 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE .............................................. 11 4.5 TEST SETUP DIAGRAM .......................................................................................... 11 5. TEST RESULTS ..................................................................................................... 13 5.1 TRANSMITTER REQUIREMENT & TEST SUITES ......................................................... 13 5.1.1 Antenna Requirement ................................................................................................................ 13 5.1.2 Peak Output Power .................................................................................................................... 14 5.1.3 6dB Bandwidth ........................................................................................................................... 15 5.1.4 Power Density ............................................................................................................................ 18 5.1.5 Conducted spurious emissions and Frequency Band Edge measured in 100kHz Bandwidth ................................................................................................................................... 21 5.1.6 Spurious Emission ..................................................................................................................... 25 5.2 MAINS EMISSIONS................................................................................................. 26 5.2.1 Mains Conducted Emissions ...................................................................................................... 26 6. SAFETY HUMAN EXPOSURE ................................................................................... 27 Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 4 von 32 Page 4 of 32 6.1 RADIO FREQUENCY EXPOSURE COMPLIANCE ......................................................... 27 6.1.1 Electromagnetic Fields ............................................................................................................... 27 7. PHOTOGRAPHS OF THE TEST SET-UP ..................................................................... 28 8. LIST OF TABLES ................................................................................................... 32 9. LIST OF PHOTOGRAPHS......................................................................................... 32 1. General Remarks 1.1 Complementary Materials These attachments are integral parts of this test report: Appendix P: Photo Documentation internal view (File Name: 10053523APPENDIX P) Appendix D: Test Result of Radiated Emissions (File Name: 10053523APPENDIX D) Test Specifications The following standards were applied. Table 1: Applied Standard and Test Levels Radio NCC Low-power Radio-frequency Devices Technical Regulations LP0002(2011)(100年6月28日) FCC CFR47 Part 15: Subpart C Section 15.247 RSS-247 Issue 1 May 2015 RSS-Gen, Issue 4, November 2014 ANSI C63.4:2009, ANSI C63.10:2009 (FCC Part 15) ANSI C63.10:2013 (RSS-Gen) KDB558074 D01 DTS Meas Guidance v02 Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 5 von 32 Page 5 of 32 2. Test Sites 2.1 Test Laboratory TUV Rheinland Taiwan Ltd. Taichung Branch Office No…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 28 von 32 Page 28 of 32 7. Photographs of the Test Set-Up Photograph 1: Set-up for Spurious Emissions (Front View) Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 29 von 32 Page 29 of 32 Photograph 2: Set-up for Spurious Emissions (Back View 1) Photograph 3: Set-up for Spurious Emissions (Back View 2) Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 30 von 32 Page 30 of 32 Photograph 4: Set-up for Spurious Emissions (IC) Photograph 5: Set-up for Spurious Emissions (IC) Produkte Products Prüfbericht - Nr.: Test Report No. 10053523 001 Seite 31 von 32 Page 31 of 32 Photograph 6: Set-up for Conducted testing
