AB6BTR2401MBTS 24 GHz Service Transceiver

Avaya Canada Corporation

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Apr 22, 2001
Application Purpose: Original Equipment
Date of Application: Jan 29, 2001
Equipment Note: BTS 24 GHz Service Transceiver
Frequency Range: 24270.00000000 - 24430.00000000
Company: Avaya Canada Corporation
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

NTP #: 411-1333-910 Preliminary 01.01 December 2000 BTR 24-01 GHz MMIC Quick Reference Guide Product Overview The BTR 24-01 GHz MMIC (DSVG11BA) outdoor transceiver is a state-of-the- art broadband microwave transceiver designed to operate at various frequency bands downstream. It is a combined broadband transmitter and receiver deployed in Nortel Networks Reunion point-to-multipoint system. It is compatible with Reunion’s Release 1.2, 1.3 and 1.4 equipment. Figure 1: BTR 31-01M Block Diagram Rx IF Output Tx IF Input Transceiver Lightning Radi o Protector Lightning Protector Rx RF I nput (Test Point ‘B’) (Test Point ‘A’) Tx RF Output Te s t Po r t Rx IF Output Te s t Po r t Lightning Protector BTR 24-01M Transceiver 411-1333-910 Preliminary 01.01 December 2000 2 BTR 24-01 MMIC Specification Table 1: BTR 24-01M Technical Specifications TXIF InputRF Output Frequency Range 24-01M 450-650 MHz24.25 - 24.45 GHz Output Level (P1 dB) ≥27.4 dBm, -40° to +30° C ≥27.2 dBm, +30° to +50° C ≥27.2 dBm, +50° to +60° C Input Impedance 50 Ohms Input/Output Connector N-Type FemaleWR-42 (hole pattern not standard) Input/Output VSWR 1.925:1 (or 10 dB), maximum 2.3:1, max (or 8 dB) Gain (mid-band at room temper- ature not including antenna) 32 ±1.0 dB, minimum Gain Variation ±5.5 dB over all conditions Gain Flatness ±2 dB over 200 MHz BW LO leakage <-43 dBm (outband) Frequency Stability <±4 ppm over all conditions Tx Noise Power -115 dBm/Hz, maximum Tx IF Test Port Coupling -16± 1 dB AntennaBTR Frequency 24.25 - 24.45 GHz Frequency Band 2426 Bore-sight Gain (Azimuth) 15.75±1.25 dBi, 90° Horn 18.9±1.25 dBi, 45° 23.8±1.3 dBi, 15° Wave-guide Interface WR-42 (non-standard hole pattern) Size (Length x Height x Width) 10" x 9" x 2" (90°) Polarity Cross-polarized (co-polarized avialable) Sectorized Angle Available 15°, 45°, and 90° BTR 24-01 GHz MMIC Quick Reference Guide 3 RXRF Input IF Output Frequency Range 31-01M25.05 - 25.25 GHz150 - 350 MHz Input/Output Connector WR-42 (hole pattern not standard) N-Type female Input P1 dB -18 dBm Output Impedance N/A50 Ohms Input/Output VSWR 2.3:1, max (or 8 dB)2.1:1, max (or 9 dB) Gain (mid-band at room tem- perature not including antenna) 28 ±1.0 dB Gain Flatness ±2.0 dB over bandwidth Gain Variation ±5.5 dB over all conditions Frequency Stability <±4 ppm over all conditions Tx IF Test Port Coupling-14± 1 dB Noise Figure < 6.0 dB, -40° to +30° C < 6.5 dB, +30° to +50° C < 6.5 dB, +50° to +55° C Power RequirementsBTR Input Voltage-48 VDC Input Inrush Current <4.5A max Input Power 66 Watts, maximum EnvironmentalBTR Humidity100% condensing Altitude 3000 meters Operating Wind Resistance 50m/second on all surfaces Operating Temperature -40° to +60°C Storage Temperature Range -45° to +70°C (packaged) Solar Loading ETS 300 019 class 4.1 1120W/m 2 , 50°C max. MechanicalBTR Size (Length x Height x Width)19.2" x 10.3" x 6.7" (49 x 26 x 17 cm) Weight without brackets 35 lbs. (16KG) Information is subject to change without notice. Nortel reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. © 2000 Northern Telecom Ltd. Converted Frequency Formula Use the following formula to calculate the converted frequency: TX: ƒ RF OUT (GHz) = 24.9 - ƒ IF IN (GHz) RX: ƒ IF OUT (GHz) = ƒ RF IN (GHz) - 24.9 Note: Vent holes are covered with a Goretex TM patch. Note: The transceiver mounts to a vertical pole of 2.5” to 4.5” outside diame- ter. It has a range of motion of 90° over and -60° under horizon. The bases of the antenna mount can rotate ±180°. Technical Assistance Contact Information In case additional technical assistance is required, or the transceiver unit is damaged upon receipt, contact Nortel Networks. Nortel Networks Broadband Wireless Access (BWA) provides 24-hour customer service and technical support to ensure your service operation is trouble-free. If you have questions or need technical support, contact Nortel Networks Broadband Wireless Access at the following telephone numbers: • In the USA and Canada, call 972-BWA-ETAS/972-292-3827

Cover Letter(s)

C-MAC Engineering 21 Richardson Side rd Kanata ON K2K 2C1 ∙ Canada Tel613 763 7847 Fax613 763 8091 www.cmac.com January 25, 2001 Denis Lalonde Radio Compliance Specialist Federal Communicatio ns Co mmission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, Maryland, 21046 Re: AB6BTR2401M Dear Sir or Madam: This is a FCC Part 101 application for Nortel Network’s iBWA 5100 24-01M BTS LMDS transceiver. The FCCID of this equipment is AB6BTR2401M. Two test reports are submitted. The main report demonstrate compliance of the LMDS BTS transceiver while it transmits signal described by the following emission designators: 7M92D9W and 37M9D9W. An addendum report is also submitted to demonstrate compliance of the product while it transmits a 6M0D9W and 26M8D9W signal The power levels listed on Form 731 and recorded in the test reports are composite power levels. EmissionChannel SpacingCompositeSub-carrier Comment Designator (MHz) Power (dBm) Power (dBm) 6M0D9W7.021.421.41 carrier 7M92D9W10.024.424.41 carrier 26M8D9W28.017.911.94 x 7 MHz carriers 37M9D9W40.020.914.94 x 10 MHz carriers Page 2 of 2 Nortel Networks requests, pursuant to 47 CFR 0.457 and 0.459 of the commission's rules, that the following items be held CONFIDENTIAL due to their proprietary nature. Nortel Networks considers this leading edge technology developed by Nortel and its partners and being new technology, would not want to make this information available to its competitors. Exhibit Type File name of Exhibit 1. Schematics advg11ba-am-08.pdf 2. Parts list 24-01M_BTR_Generic_Parts_List.doc 3. Parts list 24-01M_BTR_Unique_Parts_List.doc 4. Block Diagram 24-01M_ BTR_Block Diag.doc Please call me or write if you have any questions or comments. Regards, Denis Lalonde Product Integrity email:[email protected] C-MAC Engineering

Operational Description

Test Report

Master: ktlPT101SubC.doc Date: April 12, 2000 KTL Test Report:1R03491 Applicant:Nortel Networks 21 Richardson Side Road Kanata, Ontario K2K 2C1 Equipment Under Test:BTR 24-01M (E.U.T.)NTVG11BA 66 NNTM532H45HD In Accordance With:FCC Part 101, Subpart C Tested By:KTL Ottawa Inc. 3325 River Road, R.R. 5 Ottawa, Ontario K1V 1H2 Authorized By: R. Grant, Wireless Manager Date:January 24, 2001 Total Number of Pages:43 Authorized Copy:Soft Copy KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 2 of 40 Table of Contents Section 1. Summary of Test Results......................................................................................3 Section 2. General Equipment Specification........................................................................5 Section 3. RF Power Output..................................................................................................7 Section 4. Occupied Bandwidth............................................................................................8 Section 5. Spurious Emissions at Antenna Terminals........................................................34 Section 6. Field Strength of Spurious Emissions................................................................38 Section 7. Frequency Stability.............................................................................................39 Section 8. Test Equipment List...........................................................................................40 Annex A Test Diagrams....................................................................................................A1 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 3 of 40 Section 1.Summary of Test Results General All measurements are traceable to national standards. These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with FCC Part 101, Subpart C. New SubmissionProduction Unit Class II Permissive ChangePre-Production Unit TNB Equipment Code THIS TEST REPORT RELATES ONLY TO THE ITEM(S) TESTED. THE FOLLOWING DEVIATIONS FROM, ADDITIONS TO, OR EXCLUSIONS FROM THE TEST SPECIFICATIONS HAVE BEEN MADE. See “ Summary of Test Data”. NVLAP LAB CODE: 100351-0 TESTED BY: DATE: January 24, 2001 Glen Westwell, Technologist KTL Ottawa Inc. authorizes the above named company to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. KTL Ottawa Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. This report applies only to the items tested. KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 4 of 40 Summary Of Test Data Name Of TestPara. No.Result RF Power Output101.113Complies Occupied Bandwidth101.111Complies Spurious Emissions at Antenna Terminals101.111Complies Field Strength of Spurious Emissions101.111Complies Frequency Stability101.107Complies Footnotes For N/A’s: Test Conditions: IndoorTemperature:24 °C Humidity:42 % OutdoorTemperature:N/A Humidity:N/A . KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 5 of 40 Section 2.General Equipment Specification Manufacturer: Nortel Networks Model No.: BTR 24-01M, SW Version 1.2 NTVG11BA 66 Serial No.: NNTM532H45HD Date Received In Laboratory: October 23, 2000 KTL Identification No.: Item #2 Transmitter Supply Voltage Input: -48 Vdc Frequency Range: Tx 24.255 GHz to 24.445 GHz Tunable Bands: Item #1 Types of Modulation: 4, 16, 64 QAM @ 7.488 Msps FDMA Data Rate(s): 7.488 Msps Internal/External Data Source: External Emission Designator: 7M92D9W 37M9D9W Output Impedance: 50Ω RF Power Output (rated): 14.75dBm to 24.4dBm Channel Spacing(s): 10 MHz Operator Selection of Operating Frequency: None Power Output Adjustment Capability: 0-31 dBm Attenuation KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 6 of 40 Equipment Under Test (1)BTR 24-01M NTVG11BA 66 NNTM532H45HD (6)SMM 5010C x QTY 04 NTVH06AA – NNTM5337THA2 NTVH06AB19 – NNTM5353P C9P NTVH06AB03 – NNTM5334XA7R NTVH06AB03 – NNTM532NV8B7 (2)RPE 9000 (Telemetry Box) NTVH24AA 25 NNTM532GD728 (7)CIM5000C NTVH25AA 15 NNTM5324MWH9 (3)RSM 9016 NTVH13BA 62 NNTM532G9F7H (8)AWM5010B NTVH04AA AD NNTM535L30ML (4)RSM 9116 NTVH20BA 16 NNTM53219QEJ (9)SDM5002C NTV07AB27 NNTM83004BRE (5)PSM5148 x QTY 05 NTVH10AC 03 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 7 of 40 Section 3.RF Power Output Para. No.: 1.1046 Test Performed By: Glen WestwellDate of Test: November 3, 2000 Minimum Standard:101.113 (a) Test Results:Complies. The RF output power is within 1 dBm of the rated power. Measurement Data: Rated (dBm)Measured (dBm) 24.424.7 21.421.5 1 Carrier 18.418.4 20.7420.8 17.7418.7 4 Carriers 14.7415.2 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 8 of 40 Section 4.Occupied Bandwidth Para. No.: 2.1049 Test Performed By: Glen WestwellDate of Test: November 7, 2000 Minimum Standard:101.111 (a)(2)(ii) Test Results:Complies. Test Data:See attached graph(s). Note:In plots where the RBW has been reduced to 100 kHz, the limit has been decreased by another 10 dB. KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 9 of 40 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 10 of 40 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 11 of 40 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 12 of 40 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 13 of 40 KTL OttawaFCC PART 101, SUBPART C PROJECT NO.: 1R03491 EQUIPMENT: BTR 24-01M Page 14 of 40 KTL OttawaFCC PART…

Text truncated - open the document above for the full version.

Test Report

CERTIFICATE OF COMPLIANCE Product Name:iBWA System 5100 24-01M BTR Model Identifier: NTVG11BA On the basis of measurements here reported on January 22, 2001, the above referenced equipment is verified as meeting the requirements of FCC Part 101 (Fixed Microwave Services), and FCC Part 2 requirements. The Test data included in this report applies to the product titled herein manufactured by Nortel Networks. Certified by: Denis Lalonde C-MAC Engineering, Inc. 21 Richardson Side Road Kanata, Ontario K2K 2C1 Canada Report Number: 10000122Nortel Networks iBWA System 5100 24-01M BTR Issue: 1.0Radio Compatibility Test Report January 22, 2001Security status: Proprietary ii Report Number: 10000122Nortel Networks iBWA System 5100 24-01M BTR Issue: 1.0Radio Compatibility Test Report January 22, 2001Security status: Proprietary iii Table of Contents 1.TEST AND RESULTS SUMMARY............................................................................... 1 2.REFERENCE DOCUMENTATION............................................................................... 2 2.1. S PECIFICAT IONS ......................................................................................................... 2 2.2. S TANDARDS ............................................................................................................... 2 2.3. O THER R EFERENCE D OCUMENTATION ....................................................................... 2 2.4. G LOSSARY OF A CRONYMS ......................................................................................... 2 3.PRODUCT DESCRIPTION.......................................................................................... 4 3.1. P RODUCT I DENT IFICAT ION .......................................................................................... 4 3.2. F UNCTIONAL D ESCRIPTION ......................................................................................... 4 3.3. P RODUCT C ONFIGURATION (E QUIPMENT U NDER T EST )............................................... 6 4.GENERAL TEST CONDITIONS.................................................................................. 8 4.1. T EST F ACILIT Y ........................................................................................................... 8 4.2. C LIMATIC C ONDITIONS ................................................................................................ 8 4.3. M EASUREMENT I NSTRUMENTATION ............................................................................ 8 5.TEST RESULTS........................................................................................................ 9 5.1. M AXIMUM T RANSMIT P OWER T EST .............................................................................. 9 5.2. O CCUPIED B ANDWIDTH T EST ................................................................................... 10 5.3. RF S PECTRUM M ASK T EST ...................................................................................... 11 5.4. T RANSMITTER C ONDUCTED S PURIOUS E MISSIONS T EST ........................................... 12 6.TEST EQUIPMENT.................................................................................................. 13 6.1. T EST C ONFIGURATION ............................................................................................. 13 6.2. T EST E QUIPMENT L IST ............................................................................................. 14 ANNEX A: NORTEL IBWA SYSTEM 5100 24-01M BTR TEST PLOTS................................... 15 ANNEX B: NORTEL IBWA SYSTEM 5100 24-01M BTR TEST PLAN ERROR! BOOKMARK NOT DEFINED. Report Number: 10000122Nortel Networks iBWA System 5100 24-01M BTR Issue: 1.0Radio Compatibility Test Report January 22, 2001Security status: Proprietary iv List of Tables Table 1-1: Test Case Summary ............................................................................................... 1 Table 3-1: Hardware descriptions ............................................................................................ 6 Table 6-1: Test equipment used............................................................................................. 14 List of Figures Figure 3-1: Nortel Networks Reunion TDMA system.................................................................. 3 Figure 5-1: Spectrum mask limit............................................................................................... 8 Figure 6-1: Test configuration for Tx output power, Tx nominal output power ............................. 10 Figure 6-2: Test config. for occ. bandwidth, sp. mask and Tx conducted spurious emissions ...... 10 Figure A-1 (99% Occupied Bandwidth, 1 carrier)..................................................................... 12 Figure A-2 (99% Occupied Bandwidth, 4 carriers) ................................................................... 12 Figure A-3 (Spectrum Mask, channel B, 1 carrier) ................................................................... 13 Figure A-4 (Spectrum Mask, channel T, 1 carrier) ................................................................... 13 Figure A-5 (Spectrum Mask, channel B, 4 carriers) ................................................................. 14 Figure A-6 (Spectrum Mask, channel T, 4 carriers).................................................................. 14 Figure A-7 (Conducted Spurious Emissions, 1 carrier, 30MHz - 10GHz) .................................... 15 Figure A-8 (Conducted Spurious Emissions, 1 carrier, 10 - 24.17GHz)...................................... 15 Figure A-9 (Conducted Spurious Emissions, 1 carrier, 24.53 - 40GHz)...................................... 16 Figure A-10 (Conducted Spurious Emissions, …
