AB6BTR2401M0BTS 24 GHz Service Transceiver

Avaya Canada Corporation

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Apr 23, 2001
Application Purpose: Original Equipment
Date of Application: Jan 29, 2001
Equipment Note: BTS 24 GHz Service Transceiver
Frequency Range: 24270.00000000 - 24430.00000000
Company: Avaya Canada Corporation
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

NTP#: 411-1333-928 Draft 01.01 July 2000 BTR 24-01MO GHz Quick Reference Guide Product Overview The BTR 24-01MO (NTVG11BC) outdoor transceiver is a state-of-the-art broad- band microwave transceiver designed to operate at various frequency bands downstream. It is a combined broadband transmitter and receiver deployed in Nortel Networks Reunion point-to-multipoint system. It is compatible with Reunion’s Release 1.2, 1.3 and 1.4 equipment. Figure 1: BTR 24-01MO Block Diagram LO Rx IF Output DC/DC Telemetry Tx IF/DC Input DC Extractor Transceiver Lightening Section Protector Lightening Protector Telemetry Signals Rx RF Input (Test Point ‘B’) (Test Point ‘A’) Tx RF Output Modem (Baseband) Converter DC/ RF DC -48V RF DC Supplies BTR 24-01MO Transceiver 411-1333-928 Draft 01.01 July 2000 2 BTR 24-01MO Specification Table 1: BTR 24-01MO Technical Specifications TXIF InputRF Output Frequency Range 24-01MO 450-650 MHz24.25-24.45 GHz Output Level (P1 dB) ≥27.0 dBm, -40° to +30° C ≥26.5 dBm, +31° to +55° C Output Level (IP3) >35 dBm, -40° to +30° C >34.5 dBm, 30° to +55° C Input Impedance 50 Ohms Input/Output Connector N-Type FemaleWR-42 (non-standard hole pattern) Input/Output VSWR 1.9:1, maximum (10 dB return loss) 2.3:1, max (or 8 dB) Gain (not including antenna) 33 dBm, minimum Gain vs. Temperature ±2.0/-3.0 dB, (-40° to +55° C) Gain Flatness ±2.0 dB over bandwidth LO leakage <-43 dBm (outband) Frequency Stability <±2 ppm, (-40° to +55° C) AntennaBTR Frequency 24.25-26.50 GHz Bore-sight Gain (Azimuth) 15.75±1.25 dBi, 90° Horn 18.9 ±1.25 dBi, 45° 23.8 ±1.3 dBi, 15° Wave-guide Interface WR-42 (non-standard hole pattern) Size (Length x Height x Width) 10" x 9" x 2" (90°) Polarization Vertical or Horizontal Sectorized Angle Available 15°, 45°, and 90° Cross-Polarization Discrimination 26 dB Minimum BTR 24-01MO GHz Quick Reference Guide 3 RXRF Input IF Output Frequency Range 24-01MO25.05-25.25 GHz150-350 MHz Input/Output Connector WR-42 (non- standard hole pattern) N-Type female Input P1 dB -18 dBm Output Impedance 50 Ohms Input/Output VSWR 2.3:1, max (or 8 dB return loss) 2.1:1, maximum (or 9 dB return loss) Gain (not including antenna) 28.0 dB ±1.0 dB Gain Flatness ±2.0 dB over bandwidth Gain Stability +2.0/-3.0 dB over temperature Frequency Stability <±4 ppm, (-40° to +55° C) Noise Figure 7.0 dB, -40° to +55° C Power RequirementsBTR Input Voltage-48 VDC (diplexed with TX cable) Inrush Current 4.5 A, maximum Input Power 66 Watts, maximum EnvironmentalBTR Humidity100% condensing Altitude 10,000 feet (3,000 meters) Operating Wind Resistance 50m/second on all surfaces Operating Temperature -40° to +55°C Storage Temperature Range -45° to +70°C (packaged) Solar Loading ETS 300 019 class 4.1 1120W/m 2 , 50°C max. MechanicalBTR Size (Length x Height x Width)19.1" x 10.3" x 5.8" (47.75 x 26 x 14.5 cm) Weight without brackets 40 lbs. (17.8 KG) Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. © 2000 Nortel Networks Converted Frequency Formula Use the following formula to calculate the converted frequency: TX: ƒ RF OUT (GHz) = 24.9 - ƒ IF IN (GHz) RX: ƒ IF OUT (GHz) = ƒ RF IN (GHz) - 24.9 Note: The antenna has an option of a hydrophobic coating that can help to reduce ice build-up effect. Note: Vent holes are covered with a Goretex TM patch. Note: The transceiver mounts to a vertical pole of 2.5” to 4.5” outside diame- ter. It has a range of motion of 90° over and -60° under horizon. The bases of the antenna mount can rotate ±180°. Technical Assistance Contact Information In case additional technical assistance is required, or the transceiver unit is damaged upon receipt, contact Nortel Networks. Nortel Networks Broadband Wireless Access (BWA) provides 24-hour customer service and technical support to ensure your service operation is trouble-free. If you have questions or need technical support, contact Nortel Networks Broadband Wireless Access at the following telephone numbers: • In the USA and Canada, call 972-BWA-ETAS/972-292-3827
