AB6IP1150EBluetooth IP Phone

Nortel Communication Server 1000 Nortel IP Phone 1150E User Guide Title page Revision history 3 Revision history November 2005 Standard 1.01. This document is issued to support Nortel Communication Server 1000 Release 4.5 software. Revision history 4 Contents 5 Contents About the Nortel IP Phone 1150E . . . . . . . . . . . . . . . . . . . . 11 Basic features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Telephone controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Telephone display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Call features and Flexible Feature Codes . . . . . . . . . . . . . . . 21 Security features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Entering and editing text . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Entering text using the telephone dialpad . . . . . . . . . . . . . . . 25 Entering text using the USB keyboard . . . . . . . . . . . . . . . . . . 26 Editing text using the soft keys . . . . . . . . . . . . . . . . . . . . . . . . 26 Connecting the components . . . . . . . . . . . . . . . . . . . . . . . . 29 Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Connecting the components of the phone . . . . . . . . . . . . . . . 30 Connecting a Bluetooth headset . . . . . . . . . . . . . . . . . . . . . . 35 Interaction between Bluetooth headset and wired headset . . 35 Configuring Telephone Options . . . . . . . . . . . . . . . . . . . . . 37 Using the Telephone Options menu . . . . . . . . . . . . . . . . . . . . 39 To use the Telephone Options menu: . . . . . . . . . . . . . . . 40 Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 Adjusting the display screen contrast . . . . . . . . . . . . . . . . 41 Selecting a language . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Selecting date and time format . . . . . . . . . . . . . . . . . . . . 43 Accessing display diagnostics . . . . . . . . . . . . . . . . . . . . . 44 Choosing a local dialpad tone . . . . . . . . . . . . . . . . . . . . . 44 Viewing telephone information . . . . . . . . . . . . . . . . . . . . . 45 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Contents 6 Configuring call log options . . . . . . . . . . . . . . . . . . . . . . . 46 Choosing a ring type . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Enabling or disabling Call Timer . . . . . . . . . . . . . . . . . . . 52 Enabling OnHook Default Path . . . . . . . . . . . . . . . . . . . . 52 Changing feature key labels . . . . . . . . . . . . . . . . . . . . . . . 53 Configuring the name display format . . . . . . . . . . . . . . . . 55 Using the call indication light . . . . . . . . . . . . . . . . . . . . . . 56 Selecting a headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Call Center Agent/Supervisor Features . . . . . . . . . . . . . . . 57 Headset interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Agent login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Correct errors during the login procedure . . . . . . . . . . . . . . . . 60 Default login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Agent logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Call Center Agent features . . . . . . . . . . . . . . . . . . . . . . . . . 63 Use Activity Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Answering Call Center calls . . . . . . . . . . . . . . . . . . . . . . . . . . 63 Call Forcing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64 Use the Emergency Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Use Not Ready . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Activate Make Set Busy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 Answer or make non-ACD calls . . . . . . . . . . . . . . . . . . . . . . . 67 Contact your supervisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67 Use Walkaway and Return from Walkaway . . . . . . . . . . . . . . 69 Call Center Supervisor features . . . . . . . . . . . . . . . . . . . . . 71 Agent Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Answer Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71 Answer Emergency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Contents 7 Call Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Use the Supervisor Observe and Supervisor Headset Jack . 73 Observe Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Interflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74 Night Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 Viewing queue status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 The ACD Calls Waiting status indicator . . . . . . . . . . . . . . . . . 77 Display Queue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77 Display agent status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78 Your telephone’s non-ACD call features . . . . . . . . . . . . . . 81 Make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 Use the Predial feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 Auto Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83 Ring Again . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84 Redial last number called . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 Use Speed Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

AdhesiveAdhesiveLinerLiner ProductType/Thickness 2 Color, Type,Caliper 3 / NumberColor 1 (mils, mm)PrintLiner Release 4 3M™ Adhesive Transfer200MP/2.3 milsTan, 58#, Polycoated Kraft,4.2 mils Tape 467MPClear(0.06 mm)“3M 467MP50 grams/inch 200MP Adhesive” 3M™ Adhesive Transfer200MP/5.2 milsTan, 58#, Polycoated Kraft,4.2 mils Tape 468MPClear(0.13 mm)“3M 468MP50 grams/inch 200MP Adhesive” 3M™ Adhesive Transfer200MP/2.3 milsClear, Polyester (PET),2.0 mils Tape 467MPFClear(0.06 mm)No Print20 grams/inch 3M™ Adhesive Transfer200MP/5.2 milsClear, Polyester,2.0 mils Tape 468MPFClear(0.13 mm)No Print20 grams/inch 3M™ Adhesive Transfer200MP/2.3 milsWhite, polycoated glassine paper3.5 mils Tape 467MPRClear(0.06 mm)printed with white 3M logo55 grams/inch 3M™ Adhesive Transfer200MP/5.2 milsWhite, polycoated glassine paper3.5 mils Tape 468MPRClear(0.13 mm)printed with white 3M logo55 grams/inch 3M™ Adhesive Transfer200MP/2.3 mils1) Tan, 58#, Polycoated Kraft,1) 4.2 mils Tape 7952MPClear(0.06 mm)“3M 200MP”50 grams/inch 2) Tan, 58# PCK2) 4.2 mils 12 grams/inch Constructions 3 High Performance Adhesive Transfer Tapes with Adhesive 200MP 467MP • 468MP • 467MPF • 468MPF • 467MPR • 468MPR • 7952MP • 7955MP 7962MP • 7965MP • 9172MP • 9172PT • 9185MP • 9188 • 9667MP • 9668MP • 9676 Product Description 3M™ Adhesive 200MP is a popular choice for graphic attachment and membrane switch applications because it has excellent quality, consistency and durability. In addition, as a result of 3M’s innovative, proprietary process, 3M adhesive 200MP also offers the following excellent performance characteristics. Clarity (virtually free of vapor inclusions that are commonly found in adhesives produced by the traditional solvent coating technique). Excellent high temperature performance as well as excellent shear strength (that minimizes edge lifting and slippage of parts). Excellent resistance to harsh environments; this adhesive can withstand splashes of organic solvents, weak acids and bases and salt water, cleaning solutions, germicidals, disinfectants, oils, etc. In addition, it performs well after exposure to humidity and hot/cold cycles. Provides some initial repositionability when bonding to plastic parts (not metal) which allows graphic parts to be lifted and repositioned if initial alignment is incorrect. Finally, this adhesive family is provided with a variety of liner configurations to help ensure excellent process flexibility. Technical DataOctober, 2003 3M ™ High Performance Adhesive Transfer Tapes with Adhesive 200MP 467MP • 468MP • 467MPF • 468MPF • 467MPR • 468MPR • 7952MP • 7955MP 7962MP • 7965MP • 9172MP • 9172PT • 9185MP • 9188 • 9667MP • 9668MP • 9676 - 2 - 1 The adhesive color is transparent with a very slight yellow cast. The yellow cast is not typically visible in a single adhesive layer. 2 The thickness listed is based on a calculation from manufacturing controlled adhesive coat weights using a density of 1.012 g/cc. While past data pages have listed nominal thicknesses of 2 and 5 mils, the coat weight (and theoretical caliper) has not changed. 3 Where two liners are listed (double-linered products, useful for selective die-cutting), liner 1) is the primary (stays with the die-cut part); liner 2) is the secondary (removed first). The polycoat on one side of the heavy linered products (83#) was changed to balance the liner. This balanced sheet will provide an improvement to the flatness of products made using the heavy liner. 4 Typical liner release value, in grams/inch, tested at 90 ipm. For additional double coated product constructions (adhesive/carrier/adhesive) using 3M™ Adhesive 200MP, please refer to the data page for 3M™ Membrane Switch Spacers (70-0707-1195-0) and the data page for Double Coated Tapes with 3M™ Adhesive 200MP (70-0709-3792-8). Constructions (continued) AdhesiveAdhesiveLinerLiner ProductType/Thickness 2 Color, Type,Caliper 3 / NumberColor 1 (mils, mm)PrintLiner Release 4 3M™ Adhesive Transfer200MP/5.2 mils1) Tan, 58#, Polycoated Kraft,1) 4.2 mils Tape 7955MPClear(0.13 mm)“3M 200MP”50 grams/inch 2) Tan, 58# PCK2) 4.2 mils 12 grams/inch 3M™ Adhesive Transfer200MP/2.3 mils1) Tan, 83#, Polycoated Kraft,1) 6.2 mils printed Tape 7962MPClear(0.06 mm)“3M 200MP”50 grams/inch 2) Tan, 58# PCK2) 4.2 mils 12 grams/inch 3M™ Adhesive Transfer200MP/5.2 mils1) Tan, 83#, Polycoated Kraft,1) 6.2 mils printed Tape 7965MPClear(0.13 mm)“3M 200MP”50 grams/inch 2) Tan, 58# PCK2) 4.2 mils 12 grams/inch 3M™ Adhesive Transfer200MP/2.3 mils1) Clear HDPE Film, No Print1) 3.0 mils Tape 9172MPClear(0.06 mm)2) Tan, 58# Polycoated Kraft,50 grams/inch No Print2) 4.2 mils 7 grams/inch 3M™ Adhesive Transfer200MP/2.3 mils1) Clear PET Film, No Print1) 2.0 mils Tape 9172PTClear(0.06 mm)2) Tan, 58# Polycoated Kraft,40 grams/inch No Print2) 4.2 mils 7 grams/inch 3M™ Adhesive Transfer200MP/5.2 mils1) Clear HDPE Film, No Print1) 3.0 mils Tape 9185MPClear(0.13 mm)2) Tan, 58# Polycoated Kraft,70 grams/inch No Print2) 4.2 mils 7 grams/inch 3M™ Adhesive Transfer200MP/5.2 mils1) Clear HDPE Film, No Print1) 3.0 mils Tape 9188Clear(0.1m)2) Tan, 83# Polycoated Kraft,50 grams/inch No Print2) 6.2 mils 20 grams/inch 3M™ Adhesive Transfer200MP/2.3 milsTan, 83#, Polycoated Kraft6.2 mils Tape 9667MPClear(0.06 mm)“3M 200MP”60 grams/inch 3M™ Adhesive Transfer200MP/5.2 milsTan, 83#, Polycoated Kraft6.2 mils Tape 9668MPClear(0.13 mm)“3M 200MP”70 grams/inch 3M™ Adhesive Transfer200MP/2.3 mils1) White Polypropylene (PP),1) 3.5 mils Tape 9676Clear(0.06 mm)No Print45 grams/inch 2) Tan, 58# Polycoated Kraft,2) 4.2 mils No Print20 grams/inch - 3 - Constructions (continued) Liner Configuration Guide: General purpose steel rule die-cutting58# polycoated kraft (PCK) Steel rule cutting nested or multi-up nameplates on common sheet83# PCK Kiss cutting, steel rule83# PCK Rotary die-cuttingpolyester (PET) and polycoated glassine (PCG) Selective die-cutting (cut adhesive before laminate)double-linered ThermoformingHDPE, white PP Part inspectionHDPE, …

Text truncated - open the document above for the full version.

Exemption from SAR evaluation Worst case emission from device = 101.7 dBμV/m at 2402 MHz Electric field strength is related to transmitter power by the following formula: 30 eirp 22 rE P t == Where E is the electric field strength (V/m) of EUT emissions measured at the test antenna, and r is the separation of the EUT and test antenna. Using units of dB μV/m for field strength, and dBm for EIRP, the above formula becomes: 810420 10 .log−+=rEP (dBm) for a measurement distance of r = 3m, 395.−=EP (dBm) P = 101.7-95.3 dBm = 6.4 dBm = 4.4 mW The power threshold above which SAR testing is required is equal 60/f (GHz) mW. For the worst-case frequency in the 2.4 GHz band (2.4835 GHz) this threshold is equates to 24 mW. Therefore the device is exempt from SAR evaluation.

Total number of pages : 43 grepbl.doc Ver: g01/10 "4H8379GUS1" KTL EMC Test Report:4H8379GUS1 Applicant:Flextronics SA Apparatus:Nortel IP Phone IP1150E Authorised by : K J Anderson, Principal EMC and Radio Group Engineer Issue Date: 25 th August 2006 Authorised Copy Number: PDF KTL EMC Test Report: 4H8379GUS1 2 Contents Section 1:Introduction3 1.1General3 1.2Tests Requested By4 1.3Manufacturer4 1.4Apparatus Assessed4 1.5Test Result Summary5 1.6Notes Relating To The Assessment6 1.7Deviations from Test Standards7 Section 2:Measurement Uncertainty8 2.1Introduction8 2.2Application of Measurement Uncertainty8 2.3Measurement Uncertainty Values8 Section 3:Modifications9 3.1Modifications Performed During Assessment9 Appendix A:Formal Emission Test Results10 A1Radiated Electric Field Emissions11 A2Power Line Conducted Emissions14 A320 dB Bandwidth and Channel Spacing16 A4Conducted carrier power17 A5Hopping frequencies18 A6Channel Occupancy19 Appendix B:Supporting Graphical Data20 Appendix C:Additional Test and Sample Details31 Appendix D:Additional Information37 Appendix E:Photographs and Figures39 Appendix F:MPE Calculation43 KTL EMC Test Report: 4H8379GUS1 3 Section 1:Introduction 1.1General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed by:KTL Saxon Way Priory Park West Hull HU13 9PB United Kingdom Telephone:+44 (0) 1482 801801 Fax:+44 (0) 1482 801806 Email:[email protected] Web site:www.ktl.com Tests performed by: ,K J Anderson, Principal EMC and Radio Group Engineer Report author:. M E Leach, Senior EMC and Radio Group Engineer This report must not be reproduced except in full without prior written permission from KTL. KTL EMC Test Report: 4H8379GUS1 4 1.2Tests Requested By This testing in this report was requested by: Flextronics SA 260 Surrey Avenue Ferndale Randburg 2194 South Africa 1.3Manufacturer Flextronics Technology (Shanghai) Co. Ltd No. 77 Yong Sheng Road Malu Jiading Shanghai 210801 China 1.4Apparatus Assessed The following apparatus was assessed between 21 st and 22 nd August 2006: Nortel IP Phone IP1150E The above equipment was an IP phone incorporating a Bluetooth radio module KTL EMC Test Report: 4H8379GUS1 5 1.5Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test TypeRegulationMeasurement standardResult REFE Title 47 of the CFR: 2004, Part 15 Subpart (c) 15.247 ANSI C63.4: 2003PASS AC Power conducted emissions Title 47 of the CFR: 2004, Part 15 Subpart (c) 15.207 ANSI C63.4: 2003PASS 20dB Bandwidth and Channel Spacing Title 47 of the CFR :2004, Part 15 Subpart (c) 15.247(a)(1)(i) Public Notice DA 00-705 March 30, 2000 PASS Conducted Carrier Power Title 47 of the CFR :2004, Part 15 Subpart(c) 15.247(b)(2) Public Notice DA 00-705 March 30, 2000 PASS Hopping Frequencies Title 47 of the CFR :2004, Part 15 Subpart (c) 15.247(a)(1) Public Notice DA 00-705 March 30, 2000 PASS Channel Occupancy Title 47 of the CFR :2004, Part 15 Subpart (c) 15.247(a)(1)(i) Public Notice DA 00-705 March 30, 2000 PASS Abbreviations used in the above table: Mod: Modification CFR: Code of Federal RegulationsANSI: American National Standards Institution REFE: Radiated Electric Field Emissions KTL EMC Test Report: 4H8379GUS1 6 1.6Notes Relating To The Assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature: 17 to 23 ÄC Humidity : 45 to 75 % Barometric Pressure: 86 to 106 kPa All dates used in this report are in the format dd/mm/yy. This assessment has been performed in accordance with the requirements of ISO/IEC 17025. KTL Hull is a listed electromagnetic compatibility Conformance Assessment Body (CAB) for EC access to the US market. (Decision No 3/2000 of the Joint Committee established under the Agreement on Mutual Recognition between the European Community and the United States of America. This decision was effective from 16 th January 2001). FCC Facility Registration number (3m semi anechoic chamber) : 90743 KTL EMC Test Report: 4H8379GUS1 7 1.7Deviations from Test Standards There were no deviations from the standards tested to. KTL EMC Test Report: 4H8379GUS1 8 Section 2:Measurement Uncertainty 2.1Introduction The standard ISO/IEC 17025 used for laboratory accreditation requires laboratories to estimate measurement uncertainty using accepted methods of analysis. Where required, the reported expanded uncertainty is based on a standard uncertainty providing a confidence level of approximately 95%. Measurement uncertainty is calculated using the methods defined in the UKAS document…
