Canopy TM Backhaul Module USER MANUAL BH02-UM-en Draft for Regulatory Review December 2003 © 2003 Motorola, Inc. All rights reserved. Printed in the U.S.A Backhaul User Manual Draft for Regulatory Review Pa ge 2 of 56 NOTICES Important Note on Modifications Intentional or unintentional changes or modifications to the equipment must not be made unless under the express consent of the party responsible for compliance. Any such modifications could void the user’s authority to operate the equipment and will void the manufacturer’s warranty. U.S. Federal Communication Commision (FCC) and Industry Canada (IC) Notification This device complies with part 15 of the U. S. FCC Rules and Regulations and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. In Canada, users should be cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250 – 5350 MHz and 5650 – 5850 MHz and these radars could cause interference and/or damage to license-exempt local area networks (LELAN). This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the U.S. FCC Rules and with RSS-210 of Industry Canada. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with these instructions, may cause harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to correct the interference by one or more of the following measures:
Increase the separation between the affected equipment and the unit;
Connect the affected equipment to a power outlet on a different circuit from that which the receiver is connected to;
Consult the dealer and/or experienced radio/TV technician for help. FCC IDs and Industry Canada Certification Numbers are listed in the following table: Module Types Frequency Band Range Maximum Transmitter Power ReflectorFCC IDIndustry Canada Cert Number SM AP BHISM 2400-2483.5 MHz 340mWAllowed on SM and BHABZ89FC5808109W-2400 SM AP BHU-NII 5250-5350 MHz 200mWNot AllowedABZ89FC3789109W-5200 SM BHU-NII 5250-5350 MHz3.2mWRecommendedABZ89FC5807109W-5210 SM AP BHU-NII 5725-5825 MHz 200mWAllowed on SM and BHABZ89FC4816109W-5700 SM AP BHISM 5725-5850 MHz200mWAllowed on SM and BHABZ89FC5804109W-5700 The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. European Community Notification Notification of Intended Purpose of Product Uses This product is a two-way radio transceiver suitable for use in Broadband RLAN systems. It uses operating frequencies which are not harmonized through the EC. All licenses must be obtained before using the product in any EC country. Declaration of conformity: Motorola declares the GHz radio types listed below comply with the essential requirements and other relevant provisions of Directive1999/5/EC. Relevant Specification EN 301 893 or similar - radio spectrum EN301489-17 - EMC EN60950 – safety Product Details for Products Tested for Compliance with Relevant EC Directives Module TypeFrequency Band Range Maximum Transmitter Power Effective Isotropic Radiated Power (EIRP) Modulation Type Operating Channels Non- overlapping Channel Spacing Access Point5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Subscriber Module 5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Subscriber Module with Reflector 5.725 to 5.825 GHz 200mW RMS 63 Watts EIRPHigh Index 2-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Backhaul User Manual Draft for Regulatory Review Pa ge 3 of 56 Backhaul5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level or 4-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Backhaul with Reflector 5.725 to 5.825 GHz 200mW RMS 63 Watts EIRPHigh Index 2-level or 4-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Canopy can be configured to operate at a range of frequencies, but at this time, only channels from 5745 MHz through 5805 MHz of the 5.7 GHz product have been tested for compliance with relevant EC directives. Before configuring equipment to operate outside this range, please check with your regulator. Exposure Note A Canopy module must be installed to provide a separation distance of at least 20 cm (7.9 in) from all persons. When adding the Canopy reflector dish, the reflector dish must be installed to provide a separation distance of at least 1.5m (59.1 in) from all persons. When so installed, the module’s RF field is within Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website http://www.hc-sc.gc.ca/rpb. In both configurations the maximum RMS power does not exceed 340mW. The applicable power density exposure limit is 10 Watt/m 2 , according to the FCC OET Bulletin 65, the ICNIRP guidelines, and the Health Canada Safety Code 6. The corresponding compliance distances referenced above have been determined by assuming worst-case scenarios. The peak power density (S) in the far-field of a radio-frequency source with rms transmit power P and antenna gain G at a distance d is 2 4d GP S π ⋅ = In the case of the Canopy SM without reflector, the gain is 8 dBi (a factor of 6.3), so the peak power density equals the exposure limit at a distance of 13 cm for 2.4 GHz product and 10 cm for 5.2 and 5.7 GHz product. A power compliance margin of over 2 is artificially introduced by setting the distance t…

Text truncated - open the document above for the full version.

Canopy TM Subscriber Module USER MANUAL SM02-UM-en Draft for Regulatory Review December 2003 © 2003 Motorola, Inc. All rights reserved. Printed in the U.S.A SM User Manual Draft for Regulatory ReviewPage 2 of 34 NOTICES Important Note on Modifications Intentional or unintentional changes or modifications to the equipment must not be made unless under the express consent of the party responsible for compliance. Any such modifications could void the user’s authority to operate the equipment and will void the manufacturer’s warranty. U.S. Federal Communication Commision (FCC) and Industry Canada (IC) Notification This device complies with part 15 of the U. S. FCC Rules and Regulations and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. In Canada, users should be cautioned to take note that high power radars are allocated as primary users (meaning they have priority) of 5250 – 5350 MHz and 5650 – 5850 MHz and these radars could cause interference and/or damage to license-exempt local area networks (LELAN). This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the U.S. FCC Rules and with RSS-210 of Industry Canada. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with these instructions, may cause harmful interference to radio communications. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to correct the interference by one or more of the following measures:
Increase the separation between the affected equipment and the unit;
Connect the affected equipment to a power outlet on a different circuit from that which the receiver is connected to;
Consult the dealer and/or experienced radio/TV technician for help. FCC IDs and Industry Canada Certification Numbers are listed in the following table: Module Types Frequency Band RangeMaximum Transmitter Power ReflectorFCC IDIndustry Canada Cert Number SM AP BHISM 2400-2483.5 MHz340mWAllowed on SM and BH ABZ89FC5808109W-2400 SM AP BHU-NII 5250-5350 MHz200mWNot AllowedABZ89FC3789109W-5200 SM BHU-NII 5250-5350 MHz3.2mWRecommendedABZ89FC5807109W-5210 SM AP BHU-NII 5725-5825 MHz200mWAllowed on SM and BH ABZ89FC4816109W-5700 SM AP BHISM 5725-5850 MHz200mWAllowed on SM and BH ABZ89FC5804109W-5700 The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. European Community Notification Notification of Intended Purpose of Product Uses This product is a two-way radio transceiver suitable for use in Broadband RLAN systems. It uses operating frequencies which are not harmonized through the EC. All licenses must be obtained before using the product in any EC country. Declaration of conformity: Motorola declares the GHz radio types listed below comply with the essential requirements and other relevant provisions of Directive1999/5/EC. Relevant Specification EN 301 893 or similar - radio spectrum EN301489-17 - EMC EN60950 - safety Product Details for Products Tested for Compliance with Relevant EC Directives Module TypeFrequency Band Range Maximum Transmitter Power Effective Isotropic Radiated Power (EIRP) Modulation Type Operating Channels Non- overlapping Channel Spacing Access Point5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Subscriber Module 5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Subscriber Module with Reflector 5.725 to 5.825 GHz 200mW RMS 63 Watts EIRPHigh Index 2-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Backhaul5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level or 4-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Backhaul with Reflector 5.725 to 5.825 GHz 200mW RMS 63 Watts EIRPHigh Index 2-level or 4-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz SM User Manual Draft for Regulatory ReviewPage 3 of 34 Canopy can be configured to operate at a range of frequencies, but at this time, only channels from 5745 MHz through 5805 MHz of the 5.7 GHz product have been tested for compliance with relevant EC directives. Before configuring equipment to operate outside this range, please check with your regulator. Exposure Note A Canopy module must be installed to provide a separation distance of at least 20 cm (7.9 in) from all persons. When adding the Canopy reflector dish, the reflector dish must be installed to provide a separation distance of at least 1.5m (59.1 in) from all persons. When so installed, the module’s RF field is within Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website http://www.hc-sc.gc.ca/rpb. In both configurations the maximum RMS power does not exceed 340mW. The applicable power density exposure limit is 10 Watt/m 2 , according to the FCC OET Bulletin 65, the ICNIRP guidelines, and the Health Canada Safety Code 6. The corresponding compliance distances referenced above have been determined by assuming worst-case scenarios. The peak power density (S) in the far-field of a radio-frequency source with rms transmit power P and antenna gain G at a distance d is 2 4d GP S π ⋅ = In the case of the Canopy module without reflector, the gain is 8 dBi (a factor of 6.3), so the peak power density equals the exposure limit at a distance of 13 cm for 2.4 GHz product and 10 cm for 5.2 and 5.7 GHz product. A power compliance margin of over 2 is artificially introduced by setting the distance to a consist…

Text truncated - open the document above for the full version.

FCC ID: ABZ89FC5807 Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, Motorola Inc., hereby request confidentiality for the block diagram, schematic and product description presented for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information which we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. Motorola Inc.

22 Side View Serial #: 0A003E0063EC 23 Front view Serial #: 0A003E0063EC

20 Canopy Model 5210 unit Serial #: 0A003E0063EC, Component Side: 21 Canopy Model 5210 Unit Serial #: 0A003E0063EC, Solder Side:

Backhaul User Manual Draft for Regulatory Review Pa ge 3 of 56 Backhaul5.725 to 5.825 GHz 200mW RMS 1 Watt EIRPHigh Index 2-level or 4-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Backhaul with Reflector 5.725 to 5.825 GHz 200mW RMS 63 Watts EIRPHigh Index 2-level or 4-level FSK 5745 to 5805 MHz in 5 MHz increments 20 MHz Canopy can be configured to operate at a range of frequencies, but at this time, only channels from 5745 MHz through 5805 MHz of the 5.7 GHz product have been tested for compliance with relevant EC directives. Before configuring equipment to operate outside this range, please check with your regulator. Exposure Note A Canopy module must be installed to provide a separation distance of at least 20 cm (7.9 in) from all persons. When adding the Canopy reflector dish, the reflector dish must be installed to provide a separation distance of at least 1.5m (59.1 in) from all persons. When so installed, the module’s RF field is within Health Canada limits for the general population; consult Safety Code 6, obtainable from Health Canada’s website http://www.hc-sc.gc.ca/rpb. In both configurations the maximum RMS power does not exceed 340mW. The applicable power density exposure limit is 10 Watt/m 2 , according to the FCC OET Bulletin 65, the ICNIRP guidelines, and the Health Canada Safety Code 6. The corresponding compliance distances referenced above have been determined by assuming worst-case scenarios. The peak power density (S) in the far-field of a radio-frequency source with rms transmit power P and antenna gain G at a distance d is 2 4d GP S π ⋅ = In the case of the Canopy SM without reflector, the gain is 8 dBi (a factor of 6.3), so the peak power density equals the exposure limit at a distance of 13 cm for 2.4 GHz product and 10 cm for 5.2 and 5.7 GHz product. A power compliance margin of over 2 is artificially introduced by setting the distance to a consistent 20 cm across all modules, giving a power compliance margin of x2.4 for 2.4 GHz modules and x4 for 5.2 and 5.7 GHz modules. In the case of the Canopy SM with reflector, the gain depends on frequency and ranges from 19 dBi (a factor of 80) for 2.4 GHz modules to 26 dBi (a factor of 400) for 5.2 GHz Extended Range and 5.7 GHz modules, so the peak power density equals the exposure limit at a distance of 10 to 80 cm. A power compliance margin is artificially introduced by defining a consistent compliance distance of 1.5 m across all modules with reflectors, giving a power compliance margin of x10 for 2.4 GHz modules, x220 for 5.2 GHz Extended Range modules, and x3.5 for 5.7 GHz modules. The compliance distance is greatly overestimated in this case because the far-field equation neglects the physical dimension of the antenna, which is modeled as a point-source. Software License Terms and Conditions ONLY OPEN THE PACKAGE, OR USE THE SOFTWARE AND RELATED PRODUCT IF YOU ACCEPT THE TERMS OF THIS LICENSE. BY BREAKING THE SEAL ON THIS DISK KIT / CDROM, OR IF YOU USE THE SOFTWARE OR RELATED PRODUCT, YOU ACCEPT THE TERMS OF THIS LICENSE AGREEMENT. IF YOU DO NOT AGREE TO THESE TERMS, DO NOT USE THE SOFTWARE OR RELATED PRODUCT; INSTEAD, RETURN THE SOFTWARE TO PLACE OF PURCHASE FOR A FULL REFUND. THE FOLLOWING AGREEMENT IS A LEGAL AGREEMENT BETWEEN YOU (EITHER AN INDIVIDUAL OR ENTITY), AND MOTOROLA, INC. (FOR ITSELF AND ITS LICENSORS). THE RIGHT TO USE THIS PRODUCT IS LICENSED ONLY ON THE CONDITION THAT YOU AGREE TO THE FOLLOWING TERMS. Now, therefore, in consideration of the promises and mutual obligations contained herein, and for other good and valuable consideration, the receipt and sufficiency of which are hereby mutually acknowledged, you and Motorola agree as follows: Grant of License. Subject to the following terms and conditions, Motorola, Inc., grants to you a personal, revocable, non-assignable, non-transferable, non-exclusive and limited license to use on a single piece of equipment only one copy of the software contained on this disk (which may have been pre-loaded on the equipment)(Software). You may make two copies of the Software, but only for backup, archival, or disaster recovery purposes. On any copy you make of the Software, you must reproduce and include the copyright and other proprietary rights notice contained on the copy we have furnished you of the Software. Ownership. Motorola (or its supplier) retains all title, ownership and intellectual property rights to the Software and any copies, including translations, compilations, derivative works (including images) partial copies and portions of updated works. The Software is Motorola’s (or its supplier's) confidential proprietary information. This Software License Agreement does not convey to you any interest in or to the Software, but only a limited right of use. You agree not to disclose it or make it available to anyone without Motorola’s written authorization. You will exercise no less than reasonable care to protect the Software from unauthorized disclosure. You agree not to disassemble, decompile or reverse engineer, or create derivative works of the Software, except and only to the extent that such activity is expressly permitted by applicable law. Termination. This License is effective until terminated. This License will terminate immediately without notice from Motorola or judicial resolution if you fail to comply with any provision of this License. Upon such termination you must destroy the Software, all accompanying written materials and all copies thereof, and the sections entitled Limited Warranty, Limitation of Remedies and Damages, and General will survive any termination. Limited Warranty. Motorola warrants for a period of ninety (90) days from Motorola’s or its customer’s shipment of the Software to you that (i) the disk(s) on which the Software is recorded will be free from defects in materials and workmanship under normal use and (ii) the Software, under normal use, will perform substantially in accordance with Motorola’s published…

Text truncated - open the document above for the full version.

5 6 The test setup diagram is as follows: Radio Under Test Reference Antenna 3 or 7 Meters Spectrum Analyzer IBM PC Ethernet Connection
