ABZ89FC5833Non Broadcast Transmitter

DIMETRA ™ DIMETRA X Core DIMETRA Express DIMETRA IP Scalable (DIPS) DIMETRA IP Compact (DIPC)/Scalable DIMETRA IP (SDIP) DIMETRA IP Micro/DIMETRA IP LiTE MTS LiTE, MTS 2 and MTS 4 Installation, Configuration and Basic Service Manual TBD 2020 © 2020 Motorola Solutions, Inc. All rights reserved *6802800U74* 6802800U74-AN Copyrights 2 Copyrights The Motorola Solutions products described in this document may include copyrighted Motorola Solutions computer programs. Laws in the United States and other countries preserve for Motorola Solutions certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted Motorola Solutions computer programs contained in the Motorola Solutions products described in this document may not be copied or reproduced in any manner without the express written permission of Motorola Solutions. © 2019 Motorola Solutions, Inc. All Rights Reserved No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without the prior written permission of Motorola Solutions, Inc. Furthermore, the purchase of Motorola Solutions products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any license under the copyrights, patents or patent applications of Motorola Solutions, except for the normal non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Disclaimer Please note that certain features, facilities, and capabilities described in this document may not be applicable to or licensed for use on a specific system, or may be dependent upon the characteristics of a specific subscriber unit or configuration of certain parameters. Please refer to your Motorola Solutions contact for further information. Trademarks MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. European Union (EU) Waste of Electrical and Electronic Equipment (WEEE) directive The European Union's WEEE directive requires that products sold into EU countries must have the crossed out trash bin label on the product (or the package in some cases). As defined by the WEEE directive, this cross-out trash bin label means that customers and end users in EU countries should not dispose of electronic and electrical equipment or accessories in household waste. Customers or end users in EU countries should contact their local equipment supplier representative or service centre for information about the waste collection system in their country. 6802800U74-AN Declaration of Conformity 3 Declaration of Conformity The declaration is applicable to the radio only if the radio is labeled with the FCC logo. Declaration of Conformity Per FCC CFR 47 Part 2 Section 2.1077(a) Responsible Party Name: Motorola Solutions, Inc. Address: 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A. Phone Number: 1-800-927-2744 Hereby declares that the product: Model Name: MTS 2, and MTS 4 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d), and section 15.109(a) Class A Digital Device This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1 This device may not cause harmful interference, and 2 This device must accept any interference received, including interference that may cause undesired operation NOTICE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. 4 6802800U74-AN CMM Labeling and Disclosure Table CMM Labeling and Disclosure Table The People’s Republic of China requires that our products comply with China Management Methods (CMM) environmental regulations. (China Management Methods refers to the Regulation Management Methods for Controlling Pollution by Electronic Information Products.) Two items are used to demonstrate compliance; the Label and the Disclosure Table. The label is placed in a customer visible position on the product. The first of the following examples means that the product contains no hazardous substances; the second means that the product contains hazardous substances, and has an Environmental Friendly Use Period (EFUP) of fifty years. The Environmental Friendly Use Period (EFUP) is the period (in years) during which the Toxic and Hazardous Substances (T&HS) contained in the Electronic Information Product (EIP) will not leak or mutate causing environmental pollution, or bodily injury from the use of the EIP. The Disclosure Table, printed in simplified Chinese, is included with each customer order. An example of a Disclosure Table (in Chinese) follows: 5 6802800U74-AN Service Information Service Information EMEA Technical Support Operations (TSO) The EMEA Technical Support Operations (TSO) provides a remote Technical Support Service to help customers …

Text truncated - open the document above for the full version.

MTS LiTE, MTS 2 and MTS 4 Installation, Configuration and Basic Service Manual DIMETRA ™ DIMETRA X Core DIMETRA Express DIMETRA IP Scalable (DIPS) DIMETRA IP Compact (DIPC)/Scalable DIMETRA IP (SDIP) DIMETRA IP Micro/DIMETRA IP LiTE *6802800U74* 6802800U74-AP JUNE 2020 © 2020 Motorola Solutions, Inc. All rights reserved Copyrights The Motorola Solutions products described in this document may include copyrighted Motorola Solutions computer programs. Laws in the United States and other countries preserve for Motorola Solutions certain exclusive rights for copyrighted computer programs. Accordingly, any copyrighted Motorola Solutions computer programs contained in the Motorola Solutions products described in this document may not be copied or reproduced in any manner without the express written permission of Motorola Solutions. © 2020 Motorola Solutions, Inc. All Rights Reserved No part of this document may be reproduced, transmitted, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without the prior written permission of Motorola Solutions, Inc. Furthermore, the purchase of Motorola Solutions products shall not be deemed to grant either directly or by implication, estoppel or otherwise, any license under the copyrights, patents or patent applications of Motorola Solutions, except for the normal non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Disclaimer Please note that certain features, facilities, and capabilities described in this document may not be applicable to or licensed for use on a specific system, or may be dependent upon the characteristics of a specific mobile subscriber unit or configuration of certain parameters. Please refer to your Motorola Solutions contact for further information. Trademarks MOTOROLA, MOTO, MOTOROLA SOLUTIONS, and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. Open Source Content This product contains Open Source software used under license. Refer to the product installation media for full Open Source Legal Notices and Attribution content. European Union (EU) Waste of Electrical and Electronic Equipment (WEEE) directive The European Union's WEEE directive requires that products sold into EU countries must have the crossed out trash bin label on the product (or the package in some cases). As defined by the WEEE directive, this cross-out trash bin label means that customers and end-users in EU countries should not dispose of electronic and electrical equipment or accessories in household waste. Customers or end-users in EU countries should contact their local equipment supplier representative or service centre for information about the waste collection system in their country. 6802800U74-AP Copyrights 2 Declaration of Conformity Declaration of Conformity Per FCC CFR 47 Part 2 Section 2.1077(a) Responsible Party Name: Motorola Solutions, Inc. Address: 1303 East Algonquin Road, Schaumburg, IL 60196-1078, U.S.A. Phone Number: 1-800-927-2744 Hereby declares that the product: Model Name: MTS 2, MTS 4 conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a), 15.107(d), and section 15.109(a) Class A Digital Device This device complies with Part 15 of the FCC. NOTICE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Notice to Users (FCC) This device complies with Part 15 of the FCC rules per the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. • Changes or modifications made to this device, not expressly approved by Motorola Solutions, could void the authority of the user to operate this equipment. 6802800U74-AP Declaration of Conformity 3 CMM Labeling and Disclosure Table The People’s Republic of China requires that our products comply with China Management Methods (CMM) environmental regulations. (China Management Methods refers to the Regulation Management Methods for Controlling Pollution by Electronic Information Products.) Two items are used to demonstrate compliance; the Label and the Disclosure Table. The label is placed in a customer visible position on the product. The first of the following examples means that the product contains no hazardous substances; the second means that the product contains hazardous substances, and has an Environmental Friendly Use Period (EFUP) of fifty years. The Environmental Friendly Use Period (EFUP) is the period (in years) during which the Toxic and Hazardous Substances contained in the Electronic Information Product (EIP) will not leak or mutate causing environmental pollution, or bodily injury from the use of the EIP. The Disclosure Table, printed in simplified Chinese, is included with each customer order. An example of a Disclosure Table (in Chinese) follows: 6802800U74-AP CMM Labeling and Disclosure Table 4 Service Information EMEA Technical Support Operations (TSO) The EMEA Technical Support Operations (TSO) provides a remote Technical Support Service to help customers resolve technical issues and quickly restore networks and systems. This team of highly skilled professionals is available to customers wi…

Text truncated - open the document above for the full version.

3Loosen the all the locking knobs of the MTCC, see the figure below (the design of the MTCC may look slightly different), and turn the tuning knobs counter clock wise as many turns as possible. Figure 159: Tuning Knob and Locking Knob Tuning knob Locking knob BR 1BR 2 4Power up the BTS and let all BRs key up. Observe that the TX LEDs of all BRs shine. 5Connect the service computer to the service port of Base Radio 1 and log on. The service port connector is located on the front panel of the Base Radio module. The default password is motorola. 6At the BR) prompt, type: dekey This command stops all RF transmission. 7Repeat step 5 and 6 for all BRs. 8Observe on the power meter that all BRs have dekeyed and that all TX LEDs are off. 9Connect the service computer to the service port of Base Radio 1. 10At the BR) prompt, type: key. After a while the TX LED of the BR will turn on and the power meter will show the BR output power minus the loss of the MTCC and the duplex filter. 11Slowly turn the tuning knob of the cavity to be tuned, until the power level displayed at the power meter is at its absolute maximum. 12Tighten the locking knob. 13Repeat step 11 and 12 until the power level is still at its absolute maximum with the locking knob firmly tightened. 14Dekey the BR. 15Repeat step 9 to 14 for all remaining BRs connected to the MTCC. 7.4 Expansion Cabinet RFDS The Expansion Cabinet uses a high-power RFDS intended for up to four high power Base Radios in addition to the Base Radios in the MTS 4 Prime cabinet. The RFDS in the Expansion Cabinet is made up of the following: • Up to three RX Splitters – a passive device functioning as an extension for the Receiver Multi Coupler function of the Duplexer/Preselector in MTS 4 to support eight Base Radios. It is connected 6802800U74-AP Chapter 7: Radio Frequency Distribution System 309 to the Exp Cabinet connector on the Duplexer/Preselector present in the MTS 4 Prime Cabinet giving the right signal level for the RX-Splitter. • Cavity Combiners – combining of eight carriers on 1 TX antenna. Table 84: MTS 4 Expansion Cabinet RF Configurations on page 310 lists the RF configurations of the MTS 4 Expansion Cabinet. In the table, Low Power is valid for both 400 MHz and 260 MHz versions of the Expansion Cabinet, while High Power is valid for both 400 MHz and 800 MHz versions of the Expansion Cabinet. Table 84: MTS 4 Expansion Cabinet RF Configurations RF Configura- tion Max Power (W) Cavity Combiner RX Splitter Low PwrHigh Pwr 1 – 2 BRs TX/RX on 2 ant.102512 TX/RX on 2 ant., RX on 1 ant. 102513 TX on 2 ant., RX on 2 ant. 102512 TX on 2 ant., RX on 3 ant. 102513 TX/RX on 1 ant., RX on 1 ant 8201 + phasing harness 2 TX/RX on 1 ant., RX on 2 ant. 8201 + phasing harness 3 TX on 1 ant., RX on 2 ant. 10201 + phasing harness 2 TX on 1 ant., RX on 3 ant. 10201 + phasing harness 3 3 – 4 BRs TX/RX on 2 ant.10252 (comb)2 TX/RX on 2 ant., RX on 1 ant. 10252 (comb)3 TX on 2 ant., RX on 2 ant. 10252 (comb)2 TX on 2 ant., RX on 3 ant. 10252 (comb)3 TX/RX on 1 ant., RX on 1 ant. 8202 (comb) + phasing har- ness 2 TX/RX on 1 ant., RX on 2 ant. 8202 (comb) + phasing har- ness 3 TX on 1 ant., RX on 2 ant. 8202 (comb) + phasing har- ness 2 6802800U74-AP Chapter 7: Radio Frequency Distribution System 310 RF Configura- tion Max Power (W) Cavity Combiner RX Splitter Low PwrHigh Pwr TX on 1 ant., RX on 3 ant. 8202 (comb) + phasing har- ness 3 NOTICE: For 260 MHz version of MTS there are no phasing harness configurations, so please disregard from these in Table 84: MTS 4 Expansion Cabinet RF Configurations on page 310. Figure 160: Expansion Cabinet with Single Diversity FILTER REAR VIEW MTS 4 PRIME CABINET BR1 BR2 BR3 BR4Exp. Cabinet MTS 4 EXPANSION CABINET RX SPLITTER REAR VIEW BR1 BR2 BR3 BR4 Prime Cab 6802800U74-AP Chapter 7: Radio Frequency Distribution System 311 Figure 161: Expansion Cabinet with Dual Diversity FILTER REAR VIEW MTS 4 PRIME CABINET MTS 4 EXPANSION CABINET BR1 BR2 BR3 BR4Exp. Cabinet FILTER REAR VIEW BR1 BR2 BR3 BR4Exp. Cabinet RX SPLITTER REAR VIEW BR1 BR2 BR3 BR4 Prime Cab RX SPLITTER REAR VIEW BR1 BR2 BR3 BR4 Prime Cab 6802800U74-AP Chapter 7: Radio Frequency Distribution System 312 Figure 162: Expansion Cabinet with Triple Diversity FILTER REAR VIEW MTS 4 PRIME CABINET MTS 4 EXPANSION CABINET BR1 BR2 BR3 BR4Exp. Cabinet FILTER REAR VIEW BR1 BR2 BR3 BR4Exp. Cabinet FILTER REAR VIEW BR1 BR2 BR3 BR4Exp. Cabinet RX SPLITTER REAR VIEW BR1 BR2 BR3 BR4 Prime Cab RX SPLITTER REAR VIEW BR1 BR2 BR3 BR4 Prime Cab RX SPLITTER REAR VIEW BR1 BR2 BR3 BR4 Prime Cab 7.4.1 RX Splitter The RX Splitter is a passive device functioning as an extension for the Receiver Multi Coupler function of the Duplexer/Preselector in MTS 4 to support eight Base Radios. It is connected to the Exp Cabinet connector on the Duplexer/Preselector present in the MTS 4 Prime Cabinet giving the right signal level for the RX-Splitter. There are two types of RX splitters covering the 260 MHz range and the 350–825 MHz range. The following figure displays the Expansion Cabinet RX Splitter. 6802800U74-AP Chapter 7: Radio Frequency Distribution System 313 Figure 163: Expansion Cabinet RX Splitter 6802800U74-AP Chapter 7: Radio Frequency Distribution System 314 Figure 164: Schematic Diagram of RX Splitter DC brick Splitter BR6 BR5 BR7 BR8 RX RX RX RX RX Prime Cabinet DC brick DC brick DC brick 7.4.1.1 Replacing the Expansion Cabinet RX Splitter This process outlines the recommended tasks to be performed to replace the Expansion Cabinet RX Splitter. For a list of available FRUs, see Field Replaceable Units (FRUs) on page 478. Process: 1Remove the RX splitter, see Removing the RX Splitter on page 315. 2Reinstall the RX splitter, see Reinstalling the RX Splitter on page 316. 7.4.1.1.1 Removing the RX Splitter This procedure describes how to remove the RX Splitter. Procedure: 1Remove the door of the cabinet completely. 2Remove the four screws holding the front panel. 3Loosen the two screws holding the front se…

Text truncated - open the document above for the full version.

FCC ID: ABZ89FC5833 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot2A, Medan Bayan Lepas, 12 SWD, 11900 Penang, Malaysia EXHIBIT 13A Date: June 2, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: ABZ89FC5833 Dear Sir/Madam, Motorola Solutions Malaysia Sdn Bhd herein submits application for Certification of the subject transmitter. This transmitter is intended for use at fixed base station sites only with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Rated Power FCC Rules Part MTS 4 SQM09SUM0010A 854 – 869 MHz Tetra 1: 4 – 25 W, Max = 30W TEDS: 2.5 – 10 W, Max =12W 90 MTS 4 SQM09SUM0050A 854 – 869 MHz Tetra 1: 4 – 25 W, Max = 30W TEDS: 2.5 – 10 W, Max =12W 90 MTS 2 SQM08SUM0010A 854 – 869 MHz Tetra 1: 4 – 40 W, Max = 48W TEDS: 2.5 – 20 W, Max = 24W 90 We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment and reference to Report & Order FCC 12-114A1 to permit TETRA certification. The transmitter is intended for work related occupational use only under Part 90 of the FCC rules. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at +604 224 0258. Sincerely, Arine Lee FCC/IC Certification Manager E-mail: [email protected]

FCC ID: ABZ89FC5833 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot2A, Medan Bayan Lepas, 12 SWD, 11900 Penang, Malaysia EXHIBIT 13B CONFIDENTIALITY REQUEST June 11, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commision Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request of Transmitter with FCC ID: ABZ89FC5833 Dear Sir / Madam, Motorola Solutions Malaysia Sdn Bhd is requesting that Exhibit 4 (Block Diagram), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions consider the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d). 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any information. Sincerely, Arine Lee FCC/IC Certification Manager E-mail: [email protected]

FCC ID: ABZ89FC5833 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot2A, Medan Bayan Lepas, 12 SWD, 11900 Penang, Malaysia EXHIBIT 13A Date: June 2, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: ABZ89FC5833 Dear Sir/Madam, Motorola Solutions Malaysia Sdn Bhd herein submits application for Certification of the subject transmitter. This transmitter is intended for use at fixed base station sites only with capabilities for clear and coded communications with a variable transmit power operating within the following frequency ranges: Product Name Model Numbers Frequency Rated Power FCC Rules Part MTS 4 SQM09SUM0010A 854 – 869 MHz Tetra 1: 4 – 25 W, Max = 30W TEDS: 2.5 – 10 W, Max =12W 90 MTS 4 SQM09SUM0050A 854 – 869 MHz Tetra 1: 4 – 25 W, Max = 30W TEDS: 2.5 – 10 W, Max =12W 90 MTS 2 SQM08SUM0010A 854 – 869 MHz Tetra 1: 4 – 40 W, Max = 48W TEDS: 2.5 – 20 W, Max = 24W 90 We are requesting certification under Part(s) of the Commission’s Rules listed above to allow operation of this equipment and reference to Report & Order FCC 12-114A1 to permit TETRA certification. The transmitter is intended for work related occupational use only under Part 90 of the FCC rules. The subject transmitter complies with Section 90.203 of the Rules in that the operator cannot directly program transmit frequencies using the unit's normally accessible external controls. A complete Certification application is enclosed. If you require any additional information, please contact me at +604 224 0258. Sincerely, Arine Lee FCC/IC Certification Manager E-mail: [email protected]

FCC ID: ABZ89FC5833 ___________________________________________________________________________________________________________ Motorola Solutions Malaysia Sdn Bhd, Plot2A, Medan Bayan Lepas, 12 SWD, 11900 Penang, Malaysia EXHIBIT 13B CONFIDENTIALITY REQUEST June 11, 2020 Office of Engineering and Technology Laboratory Division Equipment Authorization Branch Federal Communications Commision Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request of Transmitter with FCC ID: ABZ89FC5833 Dear Sir / Madam, Motorola Solutions Malaysia Sdn Bhd is requesting that Exhibit 4 (Block Diagram), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola Solutions consider the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d). 0.459 and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any information. Sincerely, Arine Lee FCC/IC Certification Manager E-mail: [email protected]

Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 1 OF 11 EXHIBIT 3 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View of MTS 4 Base Radio Cabinet 3A 2. Back View of MTS 4 Base Radio Cabinet 3B 3. Side View of MTS 4 Base Radio Cabinet (Left) 3C 4. Side View of MTS 4 Base Radio Cabinet (Right) 3D 5. Top View of MTS 4 Base Radio Cabinet (FCC/IC label location) 3E 6. Front View of MTS 2 Base Radio Cabinet 3F 7. Back View of MTS 2 Base Radio Cabinet 3G 8. Side View of MTS 2 Base Radio Cabinet (Left) 3H 9. Side View of MTS 2 Base Radio Cabinet (Right) 3I 10. Top View of MTS 2 Base Radio Cabinet (FCC/IC label location) 3J Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 2 OF 11 Exhibit 3A – Front View of MTS 4 Base Radio Cabinet Note. The Site Controller will be replace with XHUB for the expansion cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 3 OF 11 Exhibit 3B – Back View of MTS 4 Base Radio Cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 4 OF 11 Exhibit 3C – Side View of MTS 4 Base Radio Cabinet (Left) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 5 OF 11 Exhibit 3D – Side View of MTS 4 Base Radio Cabinet (Right) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 6 OF 11 Exhibit 3E – Top View of MTS 4 Base Radio Cabinet (FCC/IC label location) Location of FCC/IC Identification Label Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 7 OF 11 Exhibit 3F – Front View of MTS 2 Base Radio Cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 8 OF 11 Exhibit 3G – Back View of MTS 2 Base Radio Cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 9 OF 11 Exhibit 3H – Side View of MTS 2 Base Radio Cabinet (Left) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 10 OF 11 Exhibit 3I – Side View of MTS 2 Base Radio Cabinet (Right) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 11 OF 11 Exhibit 3J – Top View of MTS 2 Base Radio Cabinet (FCC/IC label location) Location of FCC/IC Identification Label

Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 1 OF 11 EXHIBIT 3 EXTERNAL PHOTOGRAPHS (Pursuant to FCC Part 2.1033(b)(7) and 2.1033(c)(12) and RSP 100 Annex C) The following photographs are attached. Exhibit 1. Front View of MTS 4 Base Radio Cabinet 3A 2. Back View of MTS 4 Base Radio Cabinet 3B 3. Side View of MTS 4 Base Radio Cabinet (Left) 3C 4. Side View of MTS 4 Base Radio Cabinet (Right) 3D 5. Top View of MTS 4 Base Radio Cabinet (FCC/IC label location) 3E 6. Front View of MTS 2 Base Radio Cabinet 3F 7. Back View of MTS 2 Base Radio Cabinet 3G 8. Side View of MTS 2 Base Radio Cabinet (Left) 3H 9. Side View of MTS 2 Base Radio Cabinet (Right) 3I 10. Top View of MTS 2 Base Radio Cabinet (FCC/IC label location) 3J Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 2 OF 11 Exhibit 3A – Front View of MTS 4 Base Radio Cabinet Note. The Site Controller will be replace with XHUB for the expansion cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 3 OF 11 Exhibit 3B – Back View of MTS 4 Base Radio Cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 4 OF 11 Exhibit 3C – Side View of MTS 4 Base Radio Cabinet (Left) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 5 OF 11 Exhibit 3D – Side View of MTS 4 Base Radio Cabinet (Right) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 6 OF 11 Exhibit 3E – Top View of MTS 4 Base Radio Cabinet (FCC/IC label location) Location of FCC/IC Identification Label Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 7 OF 11 Exhibit 3F – Front View of MTS 2 Base Radio Cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 8 OF 11 Exhibit 3G – Back View of MTS 2 Base Radio Cabinet Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 9 OF 11 Exhibit 3H – Side View of MTS 2 Base Radio Cabinet (Left) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 10 OF 11 Exhibit 3I – Side View of MTS 2 Base Radio Cabinet (Right) Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 3 SHEET 11 OF 11 Exhibit 3J – Top View of MTS 2 Base Radio Cabinet (FCC/IC label location) Location of FCC/IC Identification Label

Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 1 SHEET 1 OF 4 EXHIBIT 1 IDENTIFICATION LABEL (Pursuant to FCC Part 2.1033(c)(11), 2.1033(b)(7) and RSP 100 Annex C and Sec 3) LOCATION See the Attached Photograph or Sketch Bottom of Radio X Top of Radio Back of Radio Back of Radio under Belt Clip TYPE X The label must be made of tamper-evident material; i.e. the label must tear, distort, or otherwise show evidence of having been tampered with when an attempt is made to remove the label from the rack. The printable area is 69.85 mm wide and 50.8 mm MARKINGS (TEXT) X See the Attached Photograph and Exhibit 3 for the actual location of the FCC/IC label on the device. X Label Attached Below. See Attached Drawing. Applicant: Motorola Solutions Inc FCC ID: ABZ89FC5833 / IC: 109AB-5833 EXHIBIT 1 SHEET 2 OF 4 Figure 1: FCC / IC Identification Label, MTS 4 (Model No: SQM09SUM0010A) Applicant: M…

Text truncated - open the document above for the full version.
