ABZ99FT3047CM200 VHF Mobile Radio

Motorola Solutions, Inc.
CM200 VHF Mobile Radio - FCC ID ABZ99FT3047 - Motorola Solutions, Inc.
Click to zoom

Application Details

Equipment Class
TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant
Sep 03, 2003
Application Purpose
Original Equipment
Date of Application
Sep 03, 2003
Equipment Note
CM200 VHF Mobile Radio
Frequency Range
146.00000000 - 174.00000000
Company
Motorola Solutions, Inc.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗
↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Parts List/Tune Up Info

↗

RF Exposure Info

↗
↗

Test Report

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CM200 ™ Commercial SeriesTwo-Way Radio User GuideManuel de l'utilisateurde la radio bidirectionnelle MOTOROLA, the Stylized M Logo, and Radius are registered in the US Patent & Trademark Office.All other product or service names are the property of their respective owners. © Motorola, Inc. 2002. All rights reserved. Printed in U.S.A.MOTOROLA, le logotype au M stylisé et Radius sont enregistrés auprès du Bureau des marques et brevets des États-Unis.Tous les autres noms de produits et de services sont la propriété de leurs titulaires respectifs.© Motorola, Inc. 2002. Tous droits réservés. Imprimé aux États-Unis. *6802966C30*6802966C30-O 66C30-O_cvr.qxd 1/9/2003 11:08 AM Page 1 1 English CONTENTS CONTENTS Computer Software Copyrights . . . . . . . . . . . 2Safety and Warranty . . . . . . . . . . . . . . . . . . 3Product Safety and RF Exposure Compliance . . . . . . . . . . . . . . . . . . . . . . . . . 3 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . 4Radio Overview . . . . . . . . . . . . . . . . . . . . . . 9Parts of the Radio . . . . . . . . . . . . . . . . . . . . . 9 Optional Enhanced Keypad Microphone (RMN5029) . . . . . . . . . . . . . . . . . . . . . 10 On/Off/Volume Knob . . . . . . . . . . . . . . . 11Seven Segment Display. . . . . . . . . . . . . 11Channel Selector Buttons . . . . . . . . . . . 11LED Indicators . . . . . . . . . . . . . . . . . . . . 11Programmable Buttons . . . . . . . . . . . . . 12Push-to-Talk (PTT) Button . . . . . . . . . . . 12Microphone . . . . . . . . . . . . . . . . . . . . . . 12Use with Enhanced Keypad Microphone (RMN5029) . . . . . . . . . . . . . . . . . . . . . 12 Indicator Tones . . . . . . . . . . . . . . . . . . . . . . 14Improved Audio Features . . . . . . . . . . . . . . 14 Companding. . . . . . . . . . . . . . . . . . . . . . 14 Getting Started . . . . . . . . . . . . . . . . . . . . . . 15Turning the Radio On or Off . . . . . . . . . . . . . 15Adjusting the Volume . . . . . . . . . . . . . . . . . . 15Selecting a Radio Channel . . . . . . . . . . . . . . 15Sending a Call . . . . . . . . . . . . . . . . . . . . . . . 16Receiving a Call . . . . . . . . . . . . . . . . . . . . . . 16Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . 16VOX Operation . . . . . . . . . . . . . . . . . . . . . . . 17Radio Calls . . . . . . . . . . . . . . . . . . . . . . . . . 19Selective Radio Inhibit . . . . . . . . . . . . . . . . . 19Repeater or Talkaround Mode . . . . . . . . . . . 19Setting the Power Level . . . . . . . . . . . . . . . . 19Setting Tight or Normal Squelch. . . . . . . . . . 20Receiving a Selective Call . . . . . . . . . . . . . . 20Receiving a Call Alert Page . . . . . . . . . . . . . 20Setting Local or Distance Mode . . . . . . . . . . 20Sending DTMF Tones . . . . . . . . . . . . . . . . . 21Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Starting or Stopping Scan. . . . . . . . . . . . . . . 23Talkback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Deleting a Nuisance Channel . . . . . . . . . . . . 24 Restoring a Channel to the Scan List . . .24 EnglishTOC.fm Page 1 Thursday, December 12, 2002 2:12 PM 2 English CONTENTS Accessories . . . . . . . . . . . . . . . . . . . . . . . .25Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25Alarm and Accessories . . . . . . . . . . . . . . . . .25Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . .25Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . .26Control Station . . . . . . . . . . . . . . . . . . . . . . .26Public Address . . . . . . . . . . . . . . . . . . . . . . .26Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . .27Data - CES . . . . . . . . . . . . . . . . . . . . . . . . . .27 COMPUTER SOFTWARE COPYRIGHTSThe Motorola products described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted computer programs including, but not limited to, the exclusive right to copy or reproduce in any form the copyrighted computer program. Accordingly, any copyrighted Motorola computer programs contained in the Motorola products described in this manual may not be copied, reproduced, modified, reverse-engineered, or distributed in any manner without the express written permission of Motorola. Furthermore, the purchase of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents or patent applications of Motorola, except for the normal non-exclusive license to use that arises by operation of law in the sale of a product. EnglishTOC.fm Page 2 Thursday, December 12, 2002 2:12 PM 3 English SAFETY AND WARRANTY SAFETY AND WARRANTY PRODUCT SAFETY AND RF EXPOSURE COMPLIANCE ATTENTION! This radio is restricted to occupational use only to satisfy FCC RF energy exposure requirements. Before using this product, read the RF energy awareness information and operating instructions in the Product Safety and RF Exposure booklet enclosed with your radio (Motorola Publication part number pending) to ensu re compli ance with RF energy exposure limits. For a list of Motorola-approved antennas, batteries, and other accessories, visit the following web site which lists approved accessories: http://www.motorola.com/cgiss/index.shtml. Before using this product, read the operating instructions for safe usage contained in the Product Safety and RF Exposure booklet enclosed with your radio. ! C a u t i o n 08_SafetyNA.fm Page 3 Tuesday, December 3, 2002 11:25 AM 4 English SAFETY AND WARRANTY LIMITED WARRANTY MOTOROLA COMMUNICATION PRODUCTS I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG: MOTOROLA INC. (“MOTOROLA”) warrants the MOTOROLA manufactured Communication Products listed below (“P roduct”) against de…

Text truncated - open the document above for the full version.

Users Manual

English Product Safety and RF Energy Exposure Booklet for Mobile Two-Way Radios Installed in Vehicles or as Fixed Site Control Stations ATTENTION! The information provided in this document supersedes the general safety information contained in user guides published prior to February 2002. BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL INFORMATION FOR COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN APPLICABLE NATIONAL AND INTERNATIONAL STANDARDS. © Motorola, Inc. 2003 8000 W. Sunrise Blvd., Ft. Lauderdale, FL 33322 Printed in U.S.A. 8/03. *6881095C99* 68P81095C99-A 2 English RF Energy Exposure Awareness and Control Information, and Operational Instructions for FCC Occupational Use Requirements NOTICE: This radio is intended for use in occupational/controlled conditions, where users have full knowledge of their exposure and can exercise control over their exposure to meet FCC limits. This radio device is NOT authorized for general population, consumer, or any other use. This 2-way radio uses electromagnetic energy in the radio frequency (RF) spectrum to provide communications between two or more users over a distance. It uses radio frequency (RF) energy or radio waves to send and receive calls. RF energy is one form of electromagnetic energy. Other forms include, but are not limited to, sunlight and x-rays. RF energy, however, should not be confused with these other forms of electromagnetic energy, which when used improperly, can cause biological damage. Very high levels of x-rays, for example, can damage tissues and genetic material. Experts in science, engineering, medicine, health, and industry work with organizations to develop standards for safe exposure to RF energy. These standards provide recommended levels of RF exposure for both workers and the general public. These recommended RF exposure levels include substantial margins of protection. All Motorola 2-way radios are designed, manufactured, and tested to ensure they meet government-established RF exposure levels. In addition, manufacturers also recommend specific operating instructions to users of 2-way radios. These instructions are important because they inform users about RF energy exposure and provide simple procedures on how to control it. 3 English Please refer to the following Web sites for more information on what RF energy exposure is and how to control your exposure to assure compliance with established RF exposure limits. http://www.fcc.gov/oet/rfsafety/rf-faqs.html http://www.osha.gov/SLTC/radiofrequencyradiation/index.html Federal Communication Commission Regulations The FCC rules require manufacturers to comply with the FCC RF energy exposure limits for mobile 2-way radios before they can be marketed in the U.S. When 2-way radios are used as a consequence of employment, the FCC requires users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure awareness can be facilitated by the use of a label directing users to specific user awareness information. Your Motorola 2-way radio has a RF exposure product label. Also, your Motorola user manual, or separate safety booklet, includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements. Compliance with RF Exposure Standard Your Motorola two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy. This radio complies with the IEEE and ICNIRP exposure limits for occupational/controlled RF exposure environment at duty factors of up to 50% talk-50% listen and is authorized by the FCC for occupational use. In terms of measuring RF energy for compliance with the FCC exposure guidelines, your radio antenna radiates measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in standby mode. 4 English Your Motorola two-way radio complies with the following RF energy exposure standards and guidelines: • United States Federal Communications Commission, Code of Federal Regulations; 47CFR part 2 sub-part J • American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992 • Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999 Edition • International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998 • Ministry of Health (Canada) Safety Code 6. Limits of Human Exposure to Radiofrequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz, 1999 • Australian Communications Authority Radiocommunications (Electromagnetic Radiation - Human Exposure) Standard, 2003 • ANATEL, Brasil Regulatory Authority, Resolution 256 (April 11, 2001) “additional requirements for SMR, cellular, and PCS product certification.” RF Exposure Compliance and Control Guidelines and Operating Instructions To control exposure to yourself and others and to ensure compliance with the RF exposure limits, always adhere to the following procedures. Guidelines: • User awareness instructions should accompany device when transferred to other users. • Do not use this device if the operational requirements described herein are not met. Instructions: •Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting 50% of the time, or less, is important because this radio 5 English generates measurable RF energy exposure only when transmitting (in terms of measuring for standards compliance). •Transmit only when people outside the vehicle are at least the recommended minimum lateral distance away, as shown in Table 1, from the body of a vehicle with a properly installed antenna. This separation distance will ensure that there is sufficient distance f…

Text truncated - open the document above for the full version.

Users Manual

Radius CM200 ™ /CM300 ™ & PM400 ™ Commercial SeriesTwo-Way Radio Installation Guide MOTOROLA, the Stylized M Logo, and Radius are registered in the US Patent & Trademark Office.All other product or service names are the property of their respective owners. © 2002, 2003 Motorola, Inc. All rights reserved. Printed in U.S.A. *6802966C25*68P02966C25-A i Table of Contents Installation Requirements for Compliance with Radio Frequency (RF) Energy Exposure Safety Standards ............ iii Information for Vehicles with Electronic Anti-Lock/Anti-Skid Brakes .......................................iv Installation Warnings .............................................................................................iv Installation Precautions ..........................................................................................iv Braking System Tests ............................................................................................iv Chapter 1Introduction 1.1 General Information ............................................................................................... 1 1.2 Plan the Installation ............................................................................................... 1 Chapter 2DC Power Cable Installation 2.1 Planning the Power Cable Installation ................................................................... 2 2.2 Power Cable Installation Procedure ...................................................................... 2 Chapter 3Trunnion Installation 3.1 Planning the Mounting Trunnion Installation .......................................................... 5 3.2 Trunnion Installation Procedure ............................................................................. 5 Chapter 4Antenna Installation 4.1 Antenna Installation and Compliance with Radio Frequncy (RF) Energy Safety Standards................................................................................ 8 4.2 Selecting an Antenna Site/Location on a Metal Body Vehicle ................................ 8 4.3 Antenna Installation Procedure .............................................................................. 9 4.4 Completing the Installation .................................................................................... 9 Chapter 5Installation Options 5.1 Mobile Dashboard Mounting ................................................................................ 10 5.1.1Installing the Mounting Frame into the Dashboard ................................. 10 ii 5.1.2Inserting the Radio into the Mounting Frame (Figure 5.1)...................... 10 5.1.3Removing the Radio from the Mounting Frame ..................................... 11 5.2 External Speaker Installation ...............................................................................11 5.3 Visor Microphone Installation ...............................................................................12 5.3.1Connecting to the Mobile Radio ............................................................. 12 Chapter 6Accessory Connections 6.1 Accessory Connector Pin Functions ....................................................................13 6.2 Connection Plan for Accessories .........................................................................15 Chapter 7Noise Sources 7.1 Introduction ..........................................................................................................16 7.2 Radiated Noise .....................................................................................................16 7.3 Conducted Noise ..................................................................................................17 7.4 Induced Noise ......................................................................................................17 Chapter 8Operation of a Conventional Ignition System 8.1 Introduction ..........................................................................................................18 8.2 Sources of Ignition Interference ...........................................................................18 Chapter 9Detection of Noise Sources 9.1 Noise Detection Procedure ..................................................................................20 9.2 Sources of Noise ..................................................................................................21 Chapter 10Noise Reduction Techniques 10.1 General ................................................................................................................22 10.2 Ignition System Interference ................................................................................22 10.2.1 Engine Maintenance and Tune-Up......................................................... 22 10.2.2 Available Noise Reduction Kits .............................................................. 22 10.2.3 Ignition Coil Interference ........................................................................ 23 10.2.4 Distributor Interference ........................................................................... 23 10.2.5 Battery Connections ............................................................................... 23 10.3 Alternator ..............................................................................................................24 10.4 Voltage Regulator Noise ......................................................................................25 10.5 Hood and Trunk Lid Noise ...................................................................................25 10.6 Other Electrical Noises .........................................................................................25 10.7 Ground Bonding ...................................................................................................26 Safety-iii INSTALLATION REQUIREMENTS FOR COMPLIANCE WITH RADIO FREQUENCY (RF) ENERGY EXPOSURE SAFETY STANDARDS ATTENTION! This radio is intended for use in occupational/controlled conditions, where users have full knowledge of th…

Text truncated - open the document above for the full version.

Attestation Statements

MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 2 SHEET 1 OF 1 CERTIFICATION OF DATA Pursuant to 47 CFR 2.1517(g) The technical data supplied with this application, having been taken under my supervision, is hereby duly certified. The following is a statement of my qualifications: 1) I have received a BSEE degree in Electrical Engineering from Northwestern University, Evanston, Illinois. 2) I have 31 years experience in developing, testing and certifying Land Mobile Communications Products. NAME: James M. Zima SIGNATURE: DATE: September 3, 2003 POSITION: Principal Staff Engineer I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct: NAME: Vincent Spena SIGNATURE: DATE: September 3, 2003 POSITION: Engineering Manager

Cover Letter(s)

EXHIBIT 13A SHEET 1 OF 1 FCC ID: ABZ99FT3047 Date: September 3, 2003 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: ABZ99FT3047 Dear Sir or Madam: Motorola Inc., 1313 East Algonquin Road, Schaumburg, Illinois, herein submits application for Certification of the equipment identified by FCC ID: ABZ99FT3047. This transmitter is primarily intended for use in mobile radio applications with capabilities for conventional communications, with a conducted transmit power that is adjustable from 25 Watts (+44 dBm) to 54 Watts (+47.3 dBm). The intended use of this transmitter includes applications covered in CFR Title 47, Parts 22, 74, 80 and 90. Model variations include 4 and 32 channel versions with either a mini-UHF or BNC type antenna connector. The subject transmitter complies with CFR Title 47, Section 90.203, in that the operator cannot directly program the transmit frequencies using only the normally accessible external controls of the unit. Enclosed is a complete Certification Application. Please contact me if you require any additional information. Sincerely, Donna Tokarz NPR Coordinator Tel: (847) 576-7245 Fax: (847) 538-4312 E-mail: [email protected]

Cover Letter(s)

EXHIBIT 13B SHEET 1 OF 1 FCC ID: ABZ99FT3047 REQUEST FOR CONFIDENTIALITY Date: September 3, 2003 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of Transmitter with FCC ID: ABZ99FT3047 Dear Sir or Madam: Motorola is requesting that Exhibit 4 (Circuit Descriptions), Exhibit 5 (Schematic Diagrams), Exhibit 10 (Parts List and Tune Up Procedures), and Exhibit 12 (Operational Description) not be made routinely available for public inspection. Motorola considers the information in these exhibits to be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. Please mark Exhibits 4, 5, 10, and 12 as “Confidential.” Please contact me if you require any additional information. Sincerely, Donna Tokarz NPR Coordinator Tel: (847) 576-7245 Fax: (847) 538-4312 E-mail: [email protected]

External Photos

MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 1 OF 7 EXTERNAL PHOTOGRAPHS Pursuant to 47 CFR 2.1033(c)12 GENERAL VIEW, CM200 MODEL FRONT VIEW, CM200 MODEL MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 2 OF 7 REAR VIEW SHOWING ANTENNA CONNECTOR, DC CABLE, AND ACCESSORY CONNECTOR MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 3 OF 7 BOTTOM VIEW SHOWING LOCATION OF FCC ID LABEL MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 4 OF 7 CLOSE-UP VIEW OF FCC ID LABEL MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 5 OF 7 CLOSE-UP VIEWS OF BNC (LEFT) AND MINI-UHF (RIGHT) ANTENNA CONNECTORS MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 6 OF 7 TOP VIEW SHOWING MICROPHONE WITH RF SAFETY LABEL MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 3 SHEET 7 OF 7 CLOSE-UP VIEW OF RF SAFETY LABEL ON MICROPHONE CORD

ID Label/Location Info

MOTOROLA INC FCC ID: ABZ99FT3047 IDENTIFICATION LABEL Pursuant to 47 CFR 2.925(a), 2.1033(c), 2.1065 LOCATION A nameplate of the type presented below will be affixed to every transmitter. It will be placed on the outside of the cast housing at the bottom rear of the unit. Shown below is a photo of the actual label which is affixed to the cast housing of the transmitter. TYPE The label is a paper polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with a minimum peel strength of 40 oz/inch. EXHIBIT 1 SHEET 1 OF 2 MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 1A - GENERAL INFORMATION 1. Production Plans: Quantity production is planned. 2. Application References: TIA/EIA-603 Land Mobile FM or PM Communications Equipment Measurement and Performance Standards Code of Federal Regulations Title 47, Part 2, Section 2.1033-2.1093, and Part 90, Sections 90.210 and 90.214 3. Data Submittal Procedure: Data is supplied in accordance with Part 2, Sub-part J of the Commission’s rules. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Parts 22, 74, 80 and 90. Maximum transmitter power shall not be adjustable by the user. 4. Similar to Currently Certified Transmitter Type: AZ492FT3805 – Motorola CM200 VHF Two-Way Mobile Radio EXHIBIT 1 SHEET 2 OF 2

Internal Photos

MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 1 OF 7 INTERNAL PHOTOGRAPHS Pursuant to 47 CFR 2.1033(c)12 TOP VIEW OF RADIO WITH PLASTIC HOUSING REMOVED MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 2 OF 7 TOP VIEW OF RADIO WITH CHASSIS SHIELD REMOVED MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 3 OF 7 TOP VIEW OF RADIO WITH PA SHIELD REMOVED MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 4 OF 7 TOP VIEW OF CIRCUIT BOARD REMOVED FROM CHASSIS MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 5 OF 7 TOP VIEW OF CIRCUIT BOARD WITH ALL SHIELDS REMOVED MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 6 OF 7 BOTTOM VIEW OF CIRCUIT BOARD REMOVED FROM CHASSIS MOTOROLA INC FCC ID: ABZ99FT3047 EXHIBIT 9 SHEET 7 OF 7 BOTTOM VIEW OF CIRCUIT BOARD WITH ALL SHIELDS REMOVED

Parts List/Tune Up Info

MOTOROLA INC. FCC ID: ABZ99FT3047 EXHIBIT 10 SHEET 1 OF 12 PARTS LIST AND TUNE UP PROCEDURES (CONFIDENTIALITY REQUESTED) This exhibit contains a list of the semiconductor devices used in the transceiver and the test equipment and tuning procedures for maintaining the transceiver. EXHIBIT 10A Function of RF Semiconductors and Other Active Devices EXHIBIT 10B List of Recommended Test Equipment for Servicing EXHIBIT 10C Tune Up Procedure MOTOROLA INC. FCC ID: ABZ99FT3047 EXHIBIT 10 SHEET 2 OF 12 Exhibit 10A – Function of RF Semiconductors and Other Active Devices Pursuant to 47 CFR 2.1033(c)(10) Reference # Part # Circuit Application Operating Freq. Industry Equivalent D100 4813833C02 DC Switch DC MMBD6100 D101 4813833C02 DC Switch DC MMBD6100 D102 4813833C02 DC Switch DC MMBD6100 D103 4802482J02 Antenna Switch 146-174MHz MA4P959 D104 4802482J02 Antenna Switch 146-174MHz MA4P959 D105 4805218N57 Reverse Volt. Peak Detector DC RB715F D106 4805218N57 Reverse Volt. Peak Detector DC RB715F D107 4805218N57 Forward Volt. Peak Detector DC RB715F D108 4805218N57 Forward Volt. Peak Detector DC RB715F D200 4802233J09 Voltage Multiplier 1.05MHz IMN10 D201 4802233J09 Voltage Multiplier 1.05MHz IMN10 D202 4862824C03 Crystal Warp DC 1SV232 D203 4805649Q13 RX VCO Frequency Control 190-220MHz 1SV228 D204 4805649Q13 TX VCO Frequency Control 146-174MHz 1SV228 D205 4862824C01 TX VCO Modulator Audio-174MHz 1SV229 D400 4813833C07 Steering Diode DC MMBD7000 D401 4813833C02 Steering Diode DC MMBD6100 Q100 4886163B01 TX RF Power Amplifier 146-174MHz MRF1550 Q101 4813824A10 DC Switch DC MMBT3904 Q102 4813824A10 DC Switch DC MMBT3904 Q103 4813824A10 DC Switch DC MMBT3904 Q105 4886212B01 TX Driver Stage 146-174MHz MRF1518 Q106 4805128M27 Current Source DC BSR33 Q200 4802245J95 RX Injection Amplifier 190-220MHz BFS540 Q400 4809940E02 DC Switch DC DTC114YE Q403 4809940E02 DC Switch DC DTC114YE Q404 4809940E02 DC Switch DC DTC114YE Q405 4809940E02 DC Switch DC DTC114YE Q406 4809940E02 DC Switch DC DTC114YE Q407 4809940E02 DC Switch DC DTC114YE Q408 4880048M01 DC Switch DC DTC144EKA Q409 4880048M01 DC Switch DC DTC144EKA Q410 4880048M01 DC Switch DC DTC144EKA Q411 4880048M01 DC Switch DC DTC144EKA Q412 4880048M01 DC Switch DC DTC144EKA Q413 4813824A10 DC Switch DC MMBT3904 Q414 4813824A10 DC Switch DC MMBT3904 Q415 4813824A10 DC Switch DC MMBT3904 Q500 4809940E02 DC Switch DC DTC114YE Q502 4809940E02 DC Switch DC DTC114YE Q503 4809940E02 DC Switch DC DTC114YE Q504 4880048M01 DC Switch DC DTC144EKA Q505 4813824A10 DC Switch DC MMBT3904 Q506 4813824A10 DC Switch DC MMBT3904 U100 5180932W01 Power Control DC LM2904 U101 5185130C65 TX Pre-Driver Stage 146-174MHz 30C65 U102 5180932W01 Power Control DC LM2904 MOTOROLA INC. FCC ID: ABZ99FT3047 EXHIBIT 10 SHEET 3 OF 12 U103 5113819A04 Power Control DC MC3303 U200 5185963A27 Frequency Synthesizer 1-220MHz FRACN_63A27 U201 5105750U54 VCO Buffer IC 146-220MHz 50U54 U400 5102463J64 EEPROM 1MHz X25128-2.7 U402 5102463J36 SRAM 3.78MHz SRM2B256 U403 5102226J56 Microprocessor 7.56MHz MC68HC11FL0 U404 5189233U02 FLASH 3.78MHz AT49LV002N_70VI U405 5113805B58 Shift Register DC MC74VHC1GT66 U500 4813833C02 Wired OR DC MMBD6100 U501 5102190C33 Voltage Regulator DC LM2941T U503 5105469E65 Voltage Regulator DC LP2951C U504 5185130C53 Audio and Signaling IC DC 30C53 U508 5113816A30 Voltage Regulator DC MC33269D U510 5104187K94 Voltage Regulator DC LP2986ILDX U511 4813833C02 Wired OR DC MMBD6100 U512 4813833C02 Wired OR DC MMBD6100 U513 4813833C02 Reverse Protection DC MMBD6100 U514 4802393L66 DC Switch DC SI3455ADV VR101 4813830A15 Power Control Loop Protection DC MMBZ5232B VR102 4813830A15 Current Source DC MMBZ5232B VR400 4813830A18 DC Switch DC MMBZ5235B VR401 4813830G12 Overvoltage Protection DC MMSZ4687T1 VR402 4813830A09 DC Switch DC MMBZ5226B VR500 4813832C77 Reverse Protection DC MR2835S VR501 4813830A14 Reverse Protection DC MMBZ5231B VR502 4813830G11 Reverse Protection DC MMSZ4686T1 VR503 4813830G09 Reverse Protection DC MMSZ4684 VR504 4813830G09 Reverse Protection DC MMSZ4684 VR692 4813830A75 ESD Protection DC MMBZ20VAL VR693 4813830A77 ESD Protection DC MMBZ33VAL VR694 4813830A75 ESD Protection DC MMBZ20VAL VR695 4813830A75 ESD Protection DC MMBZ20VAL VR696 4813830A75 ESD Protection DC MMBZ20VAL VR697 4813830A75 ESD Protection DC MMBZ20VAL VR698 4813830A75 ESD Protection DC MMBZ20VAL VR699 4813830A75 ESD Protection DC MMBZ20VAL Y201 4880114R06 16.8MHz Crystal 16.8MHz 114R06 MOTOROLA INC. FCC ID: ABZ99FT3047 EXHIBIT 10 SHEET 4 OF 12 Exhibit 10B – List of Recommended Test Equipment for Servicing Instrument Recommended Type Application RF Signal Generator HP 8656B or equivalent Receiver Measurements Modulation Analyzer HP 8901B or equivalent Frequency and Deviation Measurements Audio Analyzer HP 8903A or equivalent Receiver Measurements Power Meter HP 438A or equivalent Transmitter Power Measurements Power Sensor HP 8428A or equivalent Transmitter Output Power DC Power Supply 0-20 volts at 15 amps Attenuator Pad 75 Watts, 30 dB Transmitter Measurements DC Ammeter 30mA to 20 A Current Drain Measurements Computer IBM PC, PC/XT, or PC/AT Radio Alignment Radio Interface Box RLN4008E Computer Interface to Radio Cable 3080369B72 From RIB to Computer Cable AAPMKN4004 From RIB to Radio Software RVN4191 Radio Alignment MOTOROLA INC. FCC ID: ABZ99FT3047 EXHIBIT 10 SHEET 5 OF 12 Exhibit 10C – Tune Up Information Pursuant to 47 CFR 2.1033(c)(9) All transmitter adjustments are performed by electronic means. The transmitter contains no electromechanical components for the purpose of transmitter tuning or adjustment. The tuning elements that are used for transmitter adjustment are: Location Type of Element Function U403 Microprocessor Supplies data to Audio Filter IC, Fractional-N Synthesizer, Temperature Compensated Crystal Oscillator, and Power Control For Transmitter Modulation, Frequency…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Matthew Nawrocki
[email protected]847-812-5841Fax: 847-576-0903

Technical Contact

MotorolaJames M Zima
[email protected]847-576-3697

1313 East Algonquin Road · Schaumburg, Illinois · United States

Test Firm

Motorola, Inc.William Bily
847-576-2238Fax: 847-538-3905

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
222,74,9146 MHz - 174 MHz54 W16K0F3E2.5 ppm
Confidentiality
Long Term
Grant Notes
Output power is conducted maximum. RF exposure compliance was evaluated at 54 W only using 0 dBd or 3 dBd vehicle-mount antennas only. Qualified end-users of this device must have the knowledge to control the exposure conditions of vehicle passengers, and of bystanders to ensure a minimum separation distance of 60 cm is maintained between the antenna and persons outside of the vehicle for satisfying MPE compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 40 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. This device must be used with a maximum transmitting duty factor not exceeding 50% for satisfying RF exposure compliance. The operation of this transmitter must satisfy the requirements of Occupational/Controlled Exposure Environment, for work related use only. End-users must be provided with specific training instructions for meeting Occupational/Controlled Exposure Environment requirements.
