RLN5381 Option Board with Bluetooth™ Wireless Technology for the Professional Portable Radio Series 6880309L69-O TABLE OF CONTENTS Safety and General Information ........................................ 1 Guidelines on Interference and Lost Links ...................... 1 Regulatory ....................................................................... 2 Range .............................................................................. 2 Electromagnetic Interference/Compatibility .................... 3 2.4 GHz Equipment Compatibility ................................... 3 Facilities .......................................................................... 3 Aircraft ............................................................................. 3 Medical Devices .............................................................. 3 Installation and Programming ........................................... 5 Bluetooth Radio Overview ................................................. 6 Connecting for the First Time .......................................... 7 Verifying Connection ....................................................... 8 Receiving a Call .............................................................. 8 Sending a Call ................................................................. 9 Resolving a Lost Link ...................................................... 9 Channel Change ........................................................... 10 Ending a Connection ..................................................... 10 Connecting to Last Device(s) ........................................ 10 Connecting to Different Device(s) ................................. 11 Turning Radio Off .......................................................... 12 Tone Description ........................................................... 13 Troubleshooting............................................................. 13 Service .......................................................................... 13 Warranty ........................................................................ 13 Replacement Parts ........................................................ 14 1 SAFETY AND GENERAL INFORMATION IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFORMATION BEFORE USING YOUR MOTOROLA OPTION BOARD WITH BLUETOOTH WIRELESS TECHNOLOGY. Guidelines on Interference and Lost Links This device operates in the unlicensed ISM frequency band (2.402-2.480 GHz). Devices operating in an unlicensed frequency band are subject to interference from other devices. Interference effects range in severity from poor or garbled audio to a complete loss of communication between a Motorola two-way radio with Bluetooth wireless technology and a corresponding Motorola accessory with Bluetooth wireless technology. The latter effect is referred to as a “lost link” and results in the inability to use the accessory with Bluetooth wireless technology. ALWAYS KEEP YOUR TWO-WAY RADIO READILY AVAILABLE FOR USE IN THE EVENT THE BLUETOOTH WIRELESS LINK IS LOST. Examples of potential interference sources operating in the ISM band include 802.11b wireless local area networks (LANs), Home RF residential wireless LANs, microwave ovens, computers, and 2.4 GHz wireless phones. 2 Regulatory Users are not permitted to make changes or modify the device in any way. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the device. See 47 CFR Sec. 15.21. This device complies with Part 15 of the U.S. FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3). This device operates in the 2.402 - 2.480 GHz frequency range. Some countries have restrictions against using devices in this range. Please check your local regulations. Range This Bluetooth wireless device has a Class 2 transmitter operating at a nominal 0 dBm (1 mW) power level. In ideal line-of-sight conditions, the range between a Motorola two-way radio with Bluetooth wireless technology and a corresponding accessory with Bluetooth wireless technology is up to 10 meters (approximately 30 feet). Actual range varies depending on environmental conditions and position of the portable radio with respect to the accessory. 3 ELECTROMAGNETIC INTERFERENCE/ COMPATIBILITY 2.4 GHz Equipment Compatibility Bluetooth wireless devices may cause disruption in operation of other 2.4 GHz equipment, especially wireless LANs. Facilities To avoid electromagnetic interference and/or compatibility conflicts, turn off your device in any facility where posted notices instruct you to do so. Hospitals or health care facilities may be using equipment that is sensitive to external RF energy. Aircraft When instructed to do so, turn off your device when on board an aircraft. Any use of your device must be in accordance with applicable regulations per airline crew instructions. Medical Devices Pacemakers The Health Industry Manufacturers Association recommends that a minimum separation of 6 inches (15 centimeters) be maintained between a wireless device and a pacemaker. These recommendations are consistent with the recommendations of the Food and Drug Administration. 4 Persons with pacemakers should: • ALWAYS keep the wireless device more than 6 inches (15 centimeters) from their pacemaker when the device is turned ON. • NOT carry the device in the breast pocket. • Use the ear opposite the pacemaker to minimize the potential for interference. • Turn the device OFF immediately if there is any reason to suspect that interference is taking place. Hearing Aids Some digital wireless radios may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer to discuss alternatives. Other Medical Dev…

Text truncated - open the document above for the full version.

FCC ID: ABZ99FT7005 Request for Confidentiality In accordance with 47 C.F.R. Section 0.459, we, Motorola, Inc., hereby request confidentiality for the block diagram, schematic and product description for certification. In support of the Request for Confidentiality, the following is stated: Enclosed within this application is technical information that we deem to be trade secrets and proprietary. If made public, the information might be used to our disadvantage. To assist in assuring that we receive the full value of our product and protect its competitive posture, we respectfully request this grant of confidentiality. David Brongiel Engineering Section Manager Motorola, Inc. Accessories and Peripheral Solutions GTDG (847) 576-7475
