ACLAP6H61Microwave Oven

Panasonic Corporation of North America

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Jan 04, 2004
Application Purpose: Original Equipment
Date of Application: Nov 23, 2003
Equipment Note: Microwave Oven
Frequency Range: 2400.00000000 - 2500.00000000
Company: Panasonic Corporation of North America
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

External Photos

Exhibit 2-A Front view NN-S754WFExhibit 2-B Front view, Door open NN-S754WF Exhibit 2-C1 Left Side view NN-S754WFExhibit 2-D1 Right Side view NN-S754WF Exhibit 2-E Rear view NN-S754WFExhibit 2-F1 Top view NN-S754WF Exhibit 2-G Bottom view NN-S754WF

Internal Photos

Exhibit 2-C2 Left side view, Exhibit 2-D2 Right side view, No enclosure NN-S754WFNo enclosure NN-S754WF Exhibit 2-F2 Top view, No enclosure NN-S754WFExhibit 2-I View of Door Choke Const r Exhibit 2-H Magnetron 2M261-M32 Exhibit 2-J View of Control CircuitryExhibit 2-K View of Inverter Circuitry ruction

Schematics

! ! ! ! " # # $ " " " % " ! & !"#" "#" " " " "#" " "#" " " "

Schematics

! ! ! ! " # # $ " " " % " ! & !"#" "#" " " " "#" " "#" " " "

Test Report

APPLICATION FOR CERTIFICATION MODEL FAMILY ACLAP6H61 MODEL NO. FCC ID NN-P794BF/SF/WF ACLAP6H61 NN-T794BF/SF/WF ACLAP6H61 NN-T784BF/SF/WF ACLAP6H61 NN-T774BF/SF/WF ACLAP6H61 NN-T764BF/SF/WF ACLAP6H61 NN-T754BF/SF/WF ACLAP6H61 NN-H764BF/SF/WF ACLAP6H61 NN-S754BF/SF/WF ACLAP6H61 NN-H744BF/SF/WF ACLAP6H61 NN-S744BF/SF/WF ACLAP6H61 NN-H724BF/SF/WF ACLAP6H61 NN-S724BF/SF/WF ACLAP6H61 LIST OF EXHIBITS EXHIBIT 1: TECHNICAL REPORT EXHIBIT 2: PHOTOGRAPHS OF MAGNETRON AND COMPONENTS EXHIBIT 3: SAMPLE AND LOCATION OF FCC ID LABEL EXHIBIT 4: SCHEMATIC DIAGRAM EXHIBIT 5: REPORT OF MEASUREMENTS EXHIBIT 6: LIST OF MEASURING EQUIPMENT AND CALIBRATION EXHIBIT 7: OPERATING INSTRUCTIONS EXHIBIT 8: INSTALLATION INSTRUCTIONS ACLAP6H61 EXHIBIT 1-1A TECHNICAL REPORT 1. DESCRIPTION OF MEASUREMENT FACILITY: The description of the measurement facility is already on file with the FCC laboratory. Please refer to the commission's reference 31010/EQU 4-3-0A. 2. INSTALLATION INSTRUCTIONS: See EXHIBIT 7. 3. OPERATING INSTRUCTIONS: See EXHIBIT 8. 4. APPLICANT: MATSUSHITA HOME APPLIANCE COMPANY, MICROWAVE TECHNICAL LAB.,E-Zip E2J-16 1711 N. Randall Road Elgin, Illinois 60123-7847 5. MANUFACTURER: SHANGHAI MATSUSHITA MICROWAVE OVEN CO. LTD. 868 Long Dong Road Pu Dong, Shanghai 201203 CHINA 6. MEASUREMENT SITE: PANASONIC MAGNETRON LAB. PANASONIC INDUSTRIAL COMPANY 1707 N. Randall Road Elgin, Il 60123-7847 ACLAP6H61 EXHIBIT 1-2 7. EQUIPMENT IDENTIFICATION: Model No. : NN-P794BF, NN-P794SF, NN-P794WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-T794BF, NN-T794SF,NN-T794WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-T784BF, NN-T784SF,NN-T784WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-T774BF, NN-T774SF,NN-T774WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-T764BF, NN-T764SF,NN-T764WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-T754BF, NN-T754SF,NN-T754WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-H764BF, NN-H764SF,NN-H764WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-S754BF, NN-S754SF,NN-S754WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-H744BF, NN-H744SF,NN-H744WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-S744BF, NN-S744SF,NN-S744WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-H724BF, NN-H724SF,NN-H724WF Brand Name : Panasonic FCC ID : ACLAP6H61 Model No. : NN-S724BF, NN-S724SF,NN-S724WF Brand Name : Panasonic FCC ID : ACLAP6H61 ACLAP6H61 EXHIBIT 1A 7. EQUIPMENT SPECIFICATIONS: Electrical Power Requirement: 120V, 60Hz, 12.7A Nominal Operating Frequency: 2450 MHz Maximum RF Energy Generated: 1250 W (IEC 705) Magnetron Type: 2M261-M32 Feed Type and Location: Through the wave guide on the right sidewall of the oven. Stirrer: Turntable Type Cabinet Dimensions: (W) 518 x (H) 301 x (D) 404 (mm) Oven Cavity Dimensions: (W) 375 x (H) 225 x (D) 386 (mm) Door Viewing Area Dimensions: (W) 296 x (H) 153 (mm) Door Seal Type: Slit Choke seal and capacitive seal method 8. DESCRIPTION OF DIFFERENCES Model No. NN-P794 BF/SF/WF NN-T794 BF/SF/WF NN-T784 BF/SF/WF NN-T774 BF/SF/WF NN-T764 BF/SF/WF NN-T754 BF/SF/WF Input Power 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A Output Power 1250W 1250W 1250W 1250W 1250W 1250W Magnetron 2M261-M32) 2M261-M32 2M261-M32 2M261-M32 2M261-M32 2M261-M32 Brand Panasonic Panasonic Panasonic Panasonic Panasonic Panasonic Model No. NN-H764 BF/SF/WF NN-S754 BF/SF/WF NN-H744 BF/SF/WF NN-S744 BF/SF/WF NN-H724 BF/SF/WF NN-S724 BF/SF/WF Input Power 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A 120Vac, 12.7A Output Power 1250W 1250W 1250W 1250W 1200W 1200W Magnetron 2M261-M32 2M261-M32 2M261-M32 2M261-M32 2M261-M32 2M261-M32 Brand Panasonic Panasonic Panasonic Panasonic Panasonic Panasonic ACLAP6H61 EXHIBIT 2 PHOTOGRAPHS OF EQUIPMENT EXHIBIT 2-A: FRONT VIEW OF MODEL NN-S754BF EXHIBIT 2-B: FRONT VIEW DOOR OPEN, MODEL NN-S754BF EXHIBIT 2-C1: LEFT SIDE VIEW OF MODEL NN-S754BF EXHIBIT 2-C2: LEFT SIDE VIEW OF MODEL NN-S754BF WITH ENCLOSURE REMOVED EXHIBIT 2-D1: RIGHT SIDE VIEW OF MODEL NN-S754BF EXHIBIT 2-D2: RIGHT SIDE VIEW OF MODEL NN-S754BF WITH ENCLOSURE REMOVED EXHIBIT 2-E:REAR VIEW OF MODEL NN-S754BF EXHIBIT 2-F1: TOP VIEW OF MODEL NN-S754BF EXHIBIT 2-F1: TOP VIEW OF MODEL NN-S754BF WITH ENCLOSURE REMOVED EXHIBIT 2-G: BOTTOM VIEW OF MODEL NN-S754BF EXHIBIT 2-H: VIEW OF MAGNETRON TYPE 2M261-M32 EXHIBIT 2-I: VIEW OF DOOR CHOKE CONSTRUCTION ILLUSTRATING INTEGRAL CHOKE TYPE. EXHIBIT 2-J: VIEW OF CONTROL CIRCUITRY EXHIBIT 2-K: VIEW OF INVERTER POWER SUPPLY ACLAP6K51 EXHIBIT 5A-1 REPORT OF MEASUREMENTS 1. MODEL NO.: NN-754WF SERIAL NO. PP-0002 MAGNETRON TYPE NO.: 2M261-M32 2. MEASUREMENT DATE: 11/07/03 3. LIST OF MEASURING EQUIPMENT AND CALIBRATION DATA: REFER TO ATTACHED EXHIBIT 6 4. INVESTIGATED FREQUENCY RANGE: 100Mhz to 4th Harmonic 5. DATA SUMMARY: Safety Check : <0.5 MW/cm2 Radiated Field Strength: ( uV/m @ 300m ) Limit Fundamental: 2454 MHz 620.0uv/m N/A 2nd. Harmonic: 4906 MHz 13.03uv/m 36.63 3rd. Harmonic: 7027 MHz 2.43uv/m " 4th. Harmonic: 9811 MHz 1.91uv/m " Spurious: 2572 Mhz 0.62uv/m " Emission Sideband: 2400 MHz 0.59uv/m " Emission Sideband: 2500 MHz 0.26uv/m " Greater than 4th. Harmonic not measurable Maximum Frequency Variation: 2458 to 2460 MHz (96V ~ 150V/ 1500 ml water load) Maximum Frequency Variation: 2458 to 2462 MHz (1500 ml - 300ml water load) Total Power Input to Oven: 2028 watts Power Developed in Dummy Load: 1074 watts Supply Voltage: 120 Volts, 60Hz, 16.9A
