ACLAP6M61Microwave Oven

Exhibit 2-A Front view NN-G464WFExhibit 2-B Front view,Door O NN-G464WF Exhibit 2-C1 Left side view NN-G464WFExhibit 2-D1 Right side view N Exhibit 2-E1 Rear view NN-G464WFExhibit 2-F1 Top view NN-G46 Exhibit 2-G Bottom view NN-G464WF Open NN-G464WF 64WF

Exhibit 2-C2 Left side view, Exhibit 2-D2 Right side view, No enclosure NN-G464WFNo enclosure NN-G464WF Exhibit 2-F2 Top view, Exhibit 2-H View of Magnetro No enclosure NN-G464WF Exhibit 2-J View of Control CircuitryExhibit 2-K View of Inverter C on 2M261-M32 Circuitry

































             !  !  !          !     "   #
 #

  $   "     "   "   %

      "


  !
 &
















 !"#" "#" " "  "     "#"
"
"#" "
     "   "


ACLAP6M61 APPLICATION FOR CERTIFICATION MODEL NO. FCC ID NN-G464BF ACLAP6M61 NN-G464MF ACLAP6M61 NN-G464WF ACLAP6M61 LIST OF EXHIBITS EXHIBIT 1: TECHNICAL REPORT EXHIBIT 2: PHOTOGRAPHS OF MAGNETRON AND COMPONENTS EXHIBIT 3: SAMPLE AND LOCATION OF FCC ID LABEL EXHIBIT 4: SCHEMATIC DIAGRAM EXHIBIT 5: REPORT OF MEASUREMENTS EXHIBIT 6: LIST OF MEASURING EQUIPMENT AND CALIBRATION EXHIBIT 7: OPERATING INSTRUCTIONS EXHIBIT 8: INSTALLATION INSTRUCTIONS ACLAP6M61 EXHIBIT 1 TECHNICAL REPORT 1. DESCRIPTION OF MEASUREMENT FACILITY: The description of the measurement facility is on file with the FCC laboratory. 2. INSTALLATION INSTRUCTIONS: See EXHIBIT 7. 3. OPERATING INSTRUCTIONS: See EXHIBIT 8. 4. APPLICANT: MATSUSHITA TECHNOLOGY CORPORATION of AMERICA, Microwave Technical Laboratory 1711 N. Randall Road Elgin, Illinois 60123-7847 5. MANUFACTURER: SHANGHAI MATSUSHITA MICROWAVE OVEN COMPANY LTD. 898 Long Dong Road Pu dong Shanghai, 201203 China 6. MEASUREMENT SITE: Panasonic Magnetron Lab. Panasonic Industrial Co. 1707 N. Randall Road Elgin, IL 60123-7847 7. EQUIPMENT IDENTIFICATION: Model No. :NN-G464BF, NN-G464MF, NN-G464WF Brand Name : Panasonic Output Power: 1100W FCC ID : ACLAP6M61 ACLAP6M61 EXHIBIT 1A 7. EQUIPMENT SPECIFICATIONS: Electrical Power Requirement: 120Vac, 60Hz, 11.2A Nominal Operating Frequency: 2450 MHz Maximum RF Energy Generated: 1100 W (IEC 705) Grille Heater Power: 1100W Magnetron Type: 2M261-M32 Feed Type and Location: Through the wave guide on the right side of the oven. Stirrer: Turntable Cabinet Dimensions: (W)510 x (H)305 x (D) 380 (mm) Oven Cavity Dimensions: (W) 359x (H) 217 x (D) 352 (mm) Door Viewing Area Dimensions: (W) 280 x (H) 152 (mm) Door Seal Type: Slit Choke seal and capacitive seal method ACLAP6M61 EXHIBIT 2 PHOTOGRAPHS OF EQUIPMENT EXHIBIT 2-A: FRONT VIEW OF MODEL NN-G464WF EXHIBIT 2-B: FRONT VIEW OF MODEL NN-G464WF WITH THE DOOR OPENED EXHIBIT 2-C1: LEFT SIDE VIEW OF MODEL NN-G464WF EXHIBIT 2-C2: LEFT SIDE VIEW OF MODEL NN-G464WF WITH ENCLOSURE REMOVED EXHIBIT 2-D1: RIGHT SIDE VIEW OF MODEL NN-G464WF EXHIBIT 2-D2: RIGHT SIDE VIEW OF MODEL NN-G464WF WITH ENCLOSURE REMOVED EXHIBIT 2-E1: REAR VIEW OF MODEL NN-G464WF EXHIBIT 2-F1: TOP VIEW OF MODEL NN-G464WF EXHIBIT 2-F2: TOP VIEW OF MODEL NN-G464WF WITH ENCLOSURE REMOVED EXHIBIT 2-G: BOTTOM VIEW OF MODEL NN-G464WF EXHIBIT 2-H: VIEW OF MAGNETRON TYPE 2M261-M32 EXHIBIT 2-J: VIEW OF CONTROL CIRCUITRY EXHIBIT 2-K: VIEW OF INVERTER CIRCUITRY ACLAP6M61 EXHIBIT 5A REPORT OF MEASUREMENTS 1. MODEL NO.: NN-G464WF SERIAL NO. PP-0004 MAGNETRON TYPE NO.: 2M261-M32 2. MEASUREMENT DATE: 1/7/04 3. LIST OF MEASURING EQUIPMENT AND CALIBRATION DATA: REFER TO EXHIBIT 6 4. INVESTIGATED FREQUENCY RANGE: 100Mhz to 10th Harmonic 5. DATA SUMMARY: Safety Check : <0.26 MW/cm² Radiated Field Strength: ( uV/m @ 300m ) Limit Fundamental 2471 MHz 391.19uv/m ------ 2nd. Harmonic 4927 MHz 1.64uv/m 35.31 3rd. Harmonic 7438 MHz 1.93uv/m " 4 th . Harmonic 9828 MHz 1.91uv/m " Spurious 2597 MHz 0.62uv/m “ Emission Sideband 2400 MHz 0.93uv/m " Emission Sideband 2500 MHz 1.29uv/m " Harmonics greater than 4th. Harmonic not measurable-readings below floor of noise level. Maximum Frequency Variation: 2454 to 2458 MHz (96V ~ 150V/ 1500 ml water load) Maximum Frequency Variation: 2454 to 2462 MHz (1500 ml - 300ml water load) Total Power Input to Oven: 1875 watts Power Developed in Dummy Load: 998 watts Supply Voltage: 120 Volts, 60Hz, 16.0A
