ACLAP7M71Microwave Oven

EXTERNAL PHOTOS Exhibit 2-B: Front View of Model MCEW with door opened Exhibit 2-C1: Left Side View of Model MCEWExhibit 2-D1: Right Side View of Model MCEW Exhibit 2-E1: Top View of Model MCEWExhibit 2-F: Bottom View of Model MCEW Exhibit 2-G: Rear View of Model MCEW ACLAP7M71 EXHIBIT 2 Exhibit 2-A: Front View of Model MCEW

ACLAP7M71 EXHIBIT 3 SAMPLE AND LOCATION OF FCC ID LABEL MHP: Code identifies location of manufacturer MHP denotes: Matsushita Electric Industrial Co. Ltd. Microwave Oven Business Unit Yamatokoriyama Nara, Japan Adhere Label Location

INTERNAL PHOTOS Exhibit 2-C2: Left Side View of Model MCEWExhibit 2-D2: Right Side View of Model MCEW With Enclosure Removed With Enclosure Removed Exhibit 2-E2: Top View of Model MCEWExhibit 2-H: View of Power Inverter With Enclosure Removed Exhibit 2-I: View of Power Line Filter Exhibit 2-J: View of Magnetron Type 2M236-M1 Exhibit 2-K: View of Control ACLAP7M71 EXHIBIT 2

ACLAP7M71 EXHIBIT 4A SCHEMATIC DIAGRAM ACLAP7M71 EXHIBIT 4B SCHEMATIC DIAGRAM ACLAP7M71 EXHIBIT 4C SCHEMATIC DIAGRAM ACLAP7M71 EXHIBIT 4D SCHEMATIC DIAGRAM

ACLAP7M71 APPLICATION FOR CERTIFICATION MODEL NO. BRAND NAME FCC ID MCES Thermador ACLAP7M71 MCEB Thermador “ “ “ MCEW Thermador “ “ “ HMB7050 BOSCH “ “ “ HMB7060 BOSCH “ “ “ HMB7020 BOSCH “ “ “ LIST OF EXHIBITS EXHIBIT 1: TECHNICAL REPORT EXHIBIT 2: PHOTOGRAPHS OF EQUIPTMENT EXHIBIT 3: SAMPLE AND LOCATION OF FCC ID LABEL EXHIBIT 4: SCHEMATIC DIAGRAM EXHIBIT 5: REPORT OF MEASUREMENTS (Radiated and Line Conductance Emissions) EXHIBIT 6: LIST OF MEASURING EQUIPMENT AND CALIBRATION (Radiated and Line Conductance Emissions) EXHIBIT 7: OPERATING INSTRUCTIONS & INSTALLATION INSTRUCTIONS ACLAP7M71 EXHIBIT 1 TECHNICAL REPORT 1. DESCRIPTION OF MEASUREMENT FACILITY: The description of the measurement facility is on file with the FCC laboratory. Please refer to the commission's reference 31040/SIT 1300F2 and 950523A 1300F2 2. OPERATING INSTRUCTIONS & INSTALLATION INSTRUCTIONS: See EXHIBIT 7. 3. APPLICANT: PANASONIC HOME APPLIANCE COMPANY of AMERICA, MICROWAVE TECHNICAL LAB., E-Zip E2J-16 1707 N. Randall Road Elgin, Illinois 60123-7847 4. MANUFACTURER: Matsushita Electric Industrial Co., Ltd. Microwave Oven Business Unit 800 Tsutsui-cho, Yamatokoriyama City, Nara, Japan Zip Code: 639-1188 5. MEASUREMENT SITE: (Radiated and Line Conducted Emissions) Japan Quality Assurance Organization (JQA) Kita-Kansai Testing Center 7-7, Ishimaru 1-Chome, Minoh-shi, Osaka, Japan Zip Code: 562-0027 Japan Quality Assurance Organization (JQA) Kameoka EMC Branch 9-1, Ozaki, Inukanno, Nishibetsuin-Cho,Kameoka-Shi, Kyoto, Japan Zip Code: 621-0126 6. EQUIPTMENT IDENTIFICATION: Model No. MCES MCEB MCEW HMB7050 HMB7060 HMB7020 Brand Name Thermador Thermador Thermador BOSCH BOSCH BOSCH FCC ID. ACLAP7M71 ACLAP7M71 ACLAP7M71ACLAP7M71 ACLAP7M71ACLAP7M71 ACLAP7M71 EXHIBIT 1 7. EQUIPMENT SPECIFICATIONS: Electrical Power Requirement: 120Vac, 60Hz, 12.8A Nominal Operating Frequency: 2450 MHz Maximum RF Energy Generated: 1000 W (IEC 705) Magnetron Type: 2M236-M1 Feed Type and Location: Through the wave guide on the right side of the oven. Stirrer: Turn Table (Ceramic Tray) Cabinet Dimensions: (W) 606 x (H) 376 x (D) 491(mm) Oven Cavity Dimensions: (W) 412 x (H) 242 x (D) 426 (mm) Door Viewing Area Dimensions: (W) 320 x (H) 182 (mm) Door Seal Type: Slit Choke seal and capacitive seal method 8. DESCRIPTION OF DIFFERENCES: Model No. Input Power Output Power (IEC 705) Magnetron Brand Name MCES 120Vac, 12.8A 1000W 2M236-M1 Thermador MCEB 120Vac, 12.8A 1000W 2M236-M1 Thermador MCEW 120Vac, 12.8A 1000W 2M236-M1 Thermador HMB7050 120Vac, 12.8A 1000W 2M236-M1 BOSCH HMB7060 120Vac, 12.8A 1000W 2M236-M1 BOSCH HMB7020 120Vac, 12.8A 1000W 2M236-M1 BOSCH ACLAP7M71 EXHIBIT 2 PHOTOGRAPHS OF EQUIPMENT EXHIBIT 2-A: FRONT VIEW OF MODEL MCEW EXHIBIT 2-B: FRONT VIEW OF MODEL MCEW WITH THE DOOR OPENED EXHIBIT 2-C1: LEFT SIDE VIEW OF MODEL MCEW EXHIBIT 2-C2: LEFT SIDE VIEW OF MODEL MCEW WITH ENCLOSURE REMOVED EXHIBIT 2-D1: RIGHT SIDE VIEW OF MODEL MCEW EXHIBIT 2-D2: RIGHT SIDE VIEW OF MODEL MCEW WITH ENCLOSURE REMOVED EXHIBIT 2-E1: TOP VIEW OF MODEL MCEW EXHIBIT 2-E2: TOP VIEW OF MODEL MCEW WITH ENCLOSURE REMOVED EXHIBIT 2-F: BOTTOM VIEW OF MODEL MCEW EXHIBIT 2-G: REAR VIEW OF MODEL MCEW EXHIBIT 2-H: VIEW OF POWER INVERTER EXHIBIT 2-I: VIEW OF POWER LINE FILTER EXHIBIT 2-J: VIEW OF MAGNETRON TYPE 2M236-M1 EXHIBIT 2-K: VIEW OF CONTROL ACLAP7M71 EXHIBIT 5 REPORT OF MEASUREMENTS (Radiated Emissions) 1. MODEL NUMBER: HMB7050 SERIAL NUMBER: FD 8609 PP09 MAGNETRON TYPE NO.: 2M236-M1 2. MEASUREMENT DATE: From: 5/19/2006 To end of testing: 5/25/2006 3. LIST OF MEASURING EQUIPMENT AND CALIBRATION (Radiated and Line Conductance Emissions) REFER TO EXHIBIT 6 4. INVESTIGATED FREQUENCY RANGE: 0.15MHz to 9th Harmonic 5. DATA SUMMARY: Safety Check : 0.05 MW/cm2 Radiated Field Strength: Frequency ( uV/m @ 300m ) Limit 2nd. Harmonic: 4953.9 MHz 22.5uv/m 30.1 3rd. Harmonic: 7457.2 MHz 14.0uv/m " 4th. Harmonic: 9926.9 MHz 28.2uv/m “ 6th. Harmonic: 14894.3 MHz 26.6uv/m “ 8th. Harmonic: 19860.9 MHz 1.90uv/m “ 9th. Harmonic: 22306.8 MHz 2.10uv/m “ Spurious: 2350.0 MHz 19.8uv/m " Spurious: 2380.5 MHz 19.3uv/m " Emission Sideband: 2387.8 MHz 21.3uv/m " Emission Sideband: 2505.0 MHz 18.1uv/m " Maximum Frequency Variation: 2478.7 to 2499.0 MHz (96V ~ 150V/ 1000 ml water load) Total Power Input to Oven: 1720 watts Power Developed in Dummy Load: 828 watts Supply Voltage: 120 Volts, 60Hz, 14.6A ACLAP7M71 EXHIBIT 5 REPORT OF MEASUREMENTS (Line Conductance) 1. MODEL NO.: HMB7050 SAMPLE NO. FD 8609 PP09 MAGNETRON TYPE NO.: 2M236-M1 2. MEASUREMENT DATE: From: 5/19/2006 To end of testing: 5/25/2006 3. LIST OF MEASURING EQUIPMENT AND CALIBRATION (Radiated and Line Conductance Emissions) REFER TO ATTACHED EXHIBIT 6 4. INVESTIGATED FREQUENCY RANGE: 0.17MHz to 30MHz 5. DATA SUMMARY: Selected Peak Readings Power Line High Side Frequency MHz QP Level dBuV QP Limit dBuV QP Delta dB Ave. Level dBuV Ave. Limit dBuV Ave. Delta dB 0.17 49.2 65.1 15.9 - - 55.1 - - 0.22 49.2 62.7 13.5 - - 52.7 - - 0.45 45.1 56.8 11.7 35.0 46.8 11.8 0.77 41.1 56.0 14.9 - - 46.0 - - 2.28 36.2 56.0 19.8 - - 46.0 - - 12.40 33.6 60.0 26.4 - - 50.0 - - 17.00 47.7 60.0 12.3 - - 50.0 - - 17.70 48.7 60.0 11.3 36.0 50.0 14.0 18.00 36.7 60.0 23.3 - - 50.0 - - 27.00 21.9 60.0 38.1 - - 50.0 - - ACLAP7M71 EXHIBIT 5 Power Line Neutral Side Frequency MHz QP Level dBuV QP Limit dBuV QP Delta dB Ave. Level dBuV Ave. Limit dBuV Ave. Delta dB 0.17 51.2 65.1 13.9 - - 55.1 - - 0.22 52.2 62.7 10.5 40.0 52.7 12.7 0.45 46.1 56.8 10.7 34.0 46.8 12.8 0.77 42.1 56.0 13.9 - - 46.0 - - 2.28 38.2 56.0 17.8 - - 46.0 - - 12.40 29.6 60.0 30.4 - - 50.0 - - 17.00 44.7 60.0 15.3 - - 50.0 - - 17.70 48.7 60.0 11.3 37.0 50.0 13.0 18.00 44.7 60.0 15.3 - - 50.0 - - 27.00 23.9 60.0 36.1 - - 50.0 - -
