ADV0602Scanning Receiver

20-107 Owner’s Manual DRAFT RadioShack 20-107 PRO-107 iSCAN Trunking Scanner Thank you for purchasing your iSCAN Trunking Radio Scanner from RadioShack. What’s Included Scanner Antenna PC-USB Cable SD Card Memory (inside the scanner) User’s Guide CD-ROM Please read this user’s guide before installing, setting up, and using your new scanner. www.RadioShack.com WARNING A WARNING symbol is used to indicate possible risk of personal injury or damage to equipment NOTE A NOTE symbol is used to indicate an operational note that relates to the current paragraph of the manual A HINT symbol is used to indicate a usage hint that relates to the current paragraph of the manual HINT IMPORTANT NOTICE: The iSCAN handheld scanner is designed to receive analog transmissions only, and cannot be used to monitor digital or encrypted radio traffic. Please take the time to read this manual completely before using your new scanner. FCC ID TBD This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Motorola, Smartnet, Smartzone, Omnilink, and Privacy Plus are registered trademarks of Motorola Inc. EDACS is a registered trademark of Harris Inc. LTR is a registered trademark of E.F. Johnson, Inc. Copyright © 2009 RadioShack All Rights Reserved Table of Contents Introduction Features The FCC Wants You To Know Scanning Legally Installing the iSCAN PC Application Getting Familiar With Your iSCAN iSCAN Front View Understanding the Keypad POWER/Backlight PLAY/PAUSE/SELECT Key UP Arrow Key DOWN Arrow Key RIGHT Arrow Key LEFT Arrow Key MENU Key SKIP Key WX Key Other Switches and Controls Main Power Off Battery Type Selection Squelch Understanding the Display Display Icons psD Indicators How iSCAN Works Copyright Notice Getting Started Unpacking iSCAN Inserting the batteries Attaching the antenna Turning iSCAN on Battery Charge Indicator Low Battery Warning Listening Safely Traffic Safety Connecting an Optional External Antenna Connecting an Earphone or Headphones Connecting an External Speaker Using AC Power Using Vehicle Battery Power Browsing the Library, Picking Objects and Importing to Playlists Overview Detailed Step by Step Programming Instructions Setting Up Playlists Enabling/Disabling Playlists Renaming Playlists Monitoring Imported Objects Browsing Playlists and Objects Playing Objects Playing While Browsing Scanning Pausing Skipping Scan Resume More iSCAN Features iSCAN PC Application SD Card Inserting and removing the SD Card SD Card contents SD Card error messages iSCAN’s Main Menu Editing Objects Weather Modes Weather Monitor Weather Priority Dedicated SAME Weather Alert Receiver Skywarn Searching Signal Stalker II Service Search Limit Search Troubleshooting Birdie Frequencies Care Service and Repair Appendix A - iSCAN Settings Menu Specifications Limited Warranty Introduction Welcome to iSCAN! iSCAN is an exciting new way to enjoy the hobby of scanning police, fire, EMS, amateur, government and other two-way analog radio communications. iSCAN combines the simplicity and ease of use of a portable media player with the power and sophistication of a state of the art scanning receiver. iSCAN is designed to provide unprecedented ease of use, especially for beginners. Additionally, iSCAN is equipped with the entire USA RadioReference database in a special on-board Library, giving you instant access to the frequencies and systems used by public safety, local government and business all over the United States! Please take a few moments to read this manual carefully before using iSCAN. iSCAN is unlike any other scanner ever produced, and we want you to fully understand how it can maximize your enjoyment of the scanning hobby. Features Easy to Understand Media Player User Interface - A simplified keypad and display with familiar Play, Pause and Navigation controls make it easy for you to use your iSCAN. The Complete USA RadioReference Database On SD Card - The entire USA database from www.radioreference.com is stored on a standard SD Card that is included with iSCAN, giving you access to the most comprehensive radio data available without connecting iSCAN to a computer or the Internet - a RadioShack first! Upgradeable CPU Firmware and Library - Keep your radio’s firmware current with enhancements and updates as they become available with free upgrades from www.radioshack.com ! SKYWARN Storm Spotter Functionality - Instant access to frequencies used by storm spotter networks. You can monitor storm conditions as they occur, and become aware of dangerous conditions before the media or emergency management officials are able to announce them to the general public. SAME and All Hazards Weather Alerting - iSCAN features a Dedicated SAME Weather Alert Receiver mode, alerting you to severe weather and other hazards in the specific area(s) that you select, or, iSCAN can check your local NOAA weather frequency periodically, even while scanning, and alert you when an All Hazards alert occurs. Multi-System Trunking - Scans most common analog trunked radio system signaling formats, including Motorola, EDACS and LTR. Both talkgroup and individual call monitoring are supported. Powerful Signal Stalker II - Quickly sweeps iSCAN’s frequency ranges for transmissions from nearby sources. When a nearby transmission is found, iSCAN automatically tunes to that frequency and receives the traffic. Built-in Service Searches - Predefined service search ranges make it easy to find activity in your area. Audible alarms - Programmable audible alarms can be configured to sound when certain objects are active. Signal Strength Meter – Shows relative strength of received signals. Slim, compact case design with large speaker - Designed for one-handed operation and ease of use. The FCC Wants You To Know This equipment has been tested …

Text truncated - open the document above for the full version.

External Photographs FCC ID: ADV0602

OPEN ADV0602 RATING LABEL LOCATION The §15.19(a)(3) statement is indicated in the user's instruction manual. GENERAL RESEARCH OF ELECTRONICS,INC. FCC ID NO. WARNING RATING LABEL

EMC Report for General Research of Electronics, Inc. on the model 0602 3187216MPK-001 Page 1 of 23 TEST REPORT Report Number: 3187216MPK-001 Project Number: 3187216 September 8, 2009 Testing performed on the Scanner Model Number: 0602 FCC ID: ADV0602 to FCC Part 15, Subpart B Class: B for GRE America Test Performed by: Test Authorized by: Intertek 1365 Adams Court Menlo Park, CA 94025 GRE America 425 Harbor Blvd. Suite B Belmont, CA 94002 Prepared by: Date: September 08, 2009 Arkadi Kaplan Reviewed by: Date: September 08, 2009 Ollie Moyrong This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report for General Research of Electronics, Inc. on the model 0602 3187216MPK-001 Page 2 of 23 VERIFICATION OF COMPLIANCE Report No. 3187216MPK-001 Verification is hereby issued to the named APPLICANT and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below. Equipment Under Test: Hand Held Scanner Trade Name: GRE America Model No.: 0602 Serial No. 000011 Applicant: GRE America Contact: Mr. Teru Takahashi Address: 425 Harbor Blvd. Suite B Belmont, CA 94002 Country USA Tel. number: 650-591-1400 Fax number: 650-591-2001 Applicable Regulation: FCC Part 15, Subpart B Equipment Class: Class B Date of Test: August 11 and September 08, 2009 We attest to the accuracy of this report: Arkadi Kaplan EMC Engineer Ollie Moyrong EMC Manager EMC Report for General Research of Electronics, Inc.on the model ADV0602 3187216MPK-001 Page 3 of 23 TABLE OF CONTENTS 1.0 General Description ........................................................................................................ 4 1.1....... Product Description ........................................................................................................ 4 1.2....... Related Submittal(s) Grants ............................................................................................ 4 1.3....... Test Methodology ........................................................................................................... 4 1.4....... Test Facility .................................................................................................................... 4 1.5....... Summary of Test Results ................................................................................................ 5 2.0 System Test Configuration............................................................................................. 6 2.1....... Justification ..................................................................................................................... 6 2.2....... EUT Exercising Software ............................................................................................... 6 2.3....... Mode of Operation.......................................................................................................... 6 2.4....... Support Equipment List and Description........................................................................ 7 2.5....... Equipment Setup Block Diagram ................................................................................... 7 2.6....... Equipment Modification ................................................................................................. 8 3.0 Emission Test Results ..................................................................................................... 9 3.1....... Field Strength Calculation ............................................................................................ 10 3.2....... Radiated Emission Data................................................................................................ 11 3.3 AC Line Conducted Emission Data ............................................................................... 13 3.3.1.... Test Configuration Photographs .................................................................. 16 3.5....... Antenna Conducted Emission Data .............................................................................. 18 4.0 List of Test Equipment ................................................................................................. 21 Appendix A LO Frequency Calculation................................................................... 22 EMC Report for General Research of Electronics, Inc.on the model ADV0602 3187216MPK-001 Page 4 of 23 1.0 General Description 1.1 Product Description The Equipment under Test (EUT) is an Advanced Digital Scanning Receiver, model 0602. A pre-production version of the sample was received on August 11, 2008 in good condition. As declared by the Applicant, it is identical to production units. 1.2 Related Submittal(s) Grants This is a single application for certification of a scanning receiver. 1.3 Test Methodology Both conducted (if applicable) and radiated emission measurements were performed according to the procedures in ANSI C63.4 (2003). All radiated measurements were performed in a semi-anechoic chamber. Radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated o…

Text truncated - open the document above for the full version.
