20-427 Owner’s Manual Draft RadioShack 20-427 PRO-2054 300 Channel Mobile/Base Scanner Please read this user’s guide before installing, setting up and using your new product www.radioshack.com Thank you for purchasing your Pro-2054 300 channel Mobile/Base scanner from RadioShack. You can mount your scanner in a fixed position and use it as a base scanner or you can use it as a mobile scanner by mounting it in a vehicle. This scanner lets you scan conventional transmissions, and is preprogrammed with search banks for convenience. By pressing a one touch search key, you can quickly search those frequencies most commonly used by public service and other agencies without tedious and complicated programming. what’s included user’s guide quick start guide preloaded data addendum Scanner Antenna DC cable w/fuse AC adapter DIN sleeve and keys (2) Mounting bracket Knob (2) Rubber washer (2) Lock washer (2) Screw (2) Rubber foot (3) contents will add © 2005 RadioShack Corporation. All Rights Reserved. RadioShack, RadioShack.com, Hypersearch, Hyperscan, and Adaptaplug are trademarks used by RadioShack Corporation. Page 1 of 36 20-427 Owner’s Manual Draft your scanner’s keypad WX (Weather)/(skywarn) – scans through the seven preprogrammed weather channels, or jumps to a Skywarn channel you programmed (300 CH). MAR (Marine) – lets you search the scanner’s preprogrammed marine band. F/P (Fire/Police) – lets you search the scanner’s preprogrammed fire/police band. AIR (Aircraft) – lets you search the scanner’s preprogrammed aircraft band. HAM (Amateur radio) – lets you search the scanner’s preprogrammed amateur radio band. FUNC (Function) – lets you use various functions by pressing this key in combination with other keys. PRI (Priority) – sets and turns the priority function on or off. ATT (Attenuate) – turns attenuation on to reduce the scanner’s sensitivity and block extremely strong signals, or turns it off to return the sensitivity to normal. TUNE – press TUNE, PAUSE to tune to a frequency. PAUSE – pauses search or tune operation. SCAN/(stalker) – scans through the programmed channels, or activates the Signal Stalker II function. MAN (Manual) – stops scanning and lets you directly enter a channel number. /¥ or ¥/ – selects the scan or search direction. Number keys – press to enter a number or a character (in text mode). /DELAY – enters a decimal point (necessary when programming frequencies), or programs delay time for the selected channel/search bank. ENT (Enter) – completes the entry of frequencies. DIM (Dimmer) – adjusts the backlight level (Light, Dark, or OFF). L/OUT (Lock Out) – lets you lock out a selected channel, skip a specified frequency during search, or lock out a selected ID code. CLEAR – clears an incorrect entry. PROG (Program) – programs frequencies in channels PWR/VOL/SQ – long knob turns OFF/ON, and controls volume. Short knob controls Page 2 of 36 20-427 Owner’s Manual Draft squelch. PC/IF – connect an optional PC interface cable here to use the scanner with your computer. Headphone Symbol – attach headphones with 1/8” jack here. your scanner’s rear view ANT – connect the supplied antenna or an external antenna here. SCREW HOLE – use to mount the scanner in a car with some hardware (screw not supplied). RESET – press to reset your scanner. DC 13.8V – connect a power source here. EXT SP – connect an external speaker here. your scanner’s display will add install your scanner You can mount your scanner in your vehicle, install it for mobility, or install it as a base station. mounting your scanner in your dashboard If you are unsure about how to install your scanner in your vehicle, consult your automobile manufacturer, dealer, or a qualified installer. Before installing, confirm your scanner fits in the desired mounting area and you have all the necessary materials. Your scanner requires a 2 x 7 1/8 x 5 5/16 inch (50 x 180 x 135 mm) mounting area. 1. Remove the four rear screws and pull off the black case before installing your scanner. 2. Install the DIN sleeve into the opening in your dashboard, lip facing out. Page 3 of 36 20-427 Owner’s Manual Draft 3. Push out the top and bottom tabs to hold the sleeve firmly in place. 4. Slide the scanner into the sleeve until it locks in place. Notes: To remove your scanner from the DIN sleeve, insert the two keys straight into the scanner’s front panel. Then, remove the scanner by pulling front panel. When mounting in your dashboard, you will need to connect an external antenna and an external speaker. mobile mounting in your vehicle You can mount your scanner under the dashboard, or on top of it, using the mounting bracket. 1. Attach the three protective rubber feet to the mounting bracket when you use the scanner on a flat surface. Do not use them when you mount the bracket with screws. 2. Use the supplied mounting bracket as a template to mark positions for the two mounting screws. 3. At the marked positions, drill holes slightly smaller than the screws. 4. Remove the paper backing from each washer and stick one inside of each bracket’s ear, aligning the washer’s hole with the bracket’s hole. 5. Attach the mounting bracket to your vehicle’s surface using the supplied screws and lockwashers. 6. Slide the scanner into the bracket, aligning the scanner’s holes with the holes in the bracket, and then screw the mounting knobs into the scanner. Page 4 of 36 20-427 Owner’s Manual Draft Note: When drilling holes, be sure to avoid obstructions behind the mounting surface. Consult a qualified installer if in doubt. using your scanner as a base station You can place your scanner on a desk, shelf, or table to use it as a base station. Since the speaker is on the bottom of the scanner, you may want to use the mounting bracket to elevate your scanner off the surface for better sound. Follow the mobile vehicle mounting instructions above to affix your scanner to a desk, shelf, table or other flat surface (except that the bracket will be below the sca…

Text truncated - open the document above for the full version.

From: Ollie Moyrong ES-Mpk Sent: Thursday, May 05, 2005 1:06 PM To: David Chernomordik ES-Mpk Cc: TCB_Admin ES-Crt Subject: RE: Review ADV2000427 David, The "cable loss" values listed in the data table of the report are correct. The comment at the bottom of the data table referencing a 3dB pad is incorrect. A 3dB pad was not installed during the measurements. A revised report is attached. Regards, Ollie -----Original Message----- From: David Chernomordik ES-Mpk Sent: Wednesday, May 04, 2005 5:03 PM To: Ollie Moyrong ES-Mpk Cc: TCB_Admin ES-Crt Subject: Review ADV2000427 Ollie, By reviewing the application, I have the following comment: The cable loss in the data table (page 12 of the test report) seems to be unreasonable low (taking into account the external attenuator) . Please verify. Thanks David

External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427 External Photos FCC ID: ADV2000427

EMC Report for General Research of Electronics, Inc. on the model PRO-2054 File: 30760821 Page 1 of 22 TEST REPORT Report Number: 30760821 Project Number: 3076082 April 25, 2005 Testing performed on the Multi Trunk-Tracking Scanner Model Number: PRO-2054 FCC ID: ADV2000427 to FCC Part 15, Subpart B ICES 003 Class: B For General Research of Electronics, Inc. A2LA Certificate Number: 1755-01 Test Performed by: Test Authorized by: Intertek 1365 Adams Court Menlo Park, CA 94025 General Research of Electronics, Inc. 425 Harbor Blvd. Suit B Belmont, CA 94002 Prepared by: Date: April 28, 2005 Bruce Gordon Reviewed by: Date: April 28, 2005 Ollie Moyrong This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report for General Research of Electronics, Inc. on the model PRO-2054 File: 30760821 Page 2 of 22 VERIFICATION OF COMPLIANCE Report No. 30760821 Verification is hereby issued to the named APPLICANT and is VALID ONLY for the equipment identified hereon for use under the rules and regulations listed below. Equipment Under Test: Multi Trunk-Tracking Scanner Trade Name: General Research of Electronics, Inc. Model No.: PRO-2054 Applicant: General Research of Electronics, Inc. Contact: Mr. Teru Takahashi Address: 425 Harbor Blvd. Suite B Belmont, CA 94002 Country USA Tel. number: 650-591-1400 Fax number: 650-591-2001 Applicable Regulation: FCC Part 15, Subpart B Industry Canada ICES-003 Equipment Class: Class B Date of Test: April 25 to 27, 2005 We attest to the accuracy of this report: Bruce Gordon Test Engineer Ollie Moyrong EMC Department Manager EMC Report for General Research of Electronics, Inc.on the model PRO-2054 File: 30760821 Page 3 of 22 TABLE OF CONTENTS 1.0 General Description ........................................................................................................ 4 1.1....... Product Description ........................................................................................................ 4 1.2....... Related Submittal(s) Grants ............................................................................................ 4 1.3....... Test Methodology ........................................................................................................... 4 1.4....... Test Facility .................................................................................................................... 4 1.5....... Summary of Test Results ................................................................................................ 5 2.0 System Test Configuration............................................................................................. 6 2.1....... Justification ..................................................................................................................... 6 2.2....... EUT Exercising Software ............................................................................................... 6 2.3....... Mode of Operation.......................................................................................................... 6 2.4....... Support Equipment List and Description........................................................................ 7 2.5....... Equipment Setup Block Diagram ................................................................................... 7 2.6....... Equipment Modification ................................................................................................. 8 3.0 Emission Test Results ..................................................................................................... 9 3.1....... Field Strength Calculation ............................................................................................ 10 3.2....... Radiated Emission Data ................................................................................................ 11 3.3....... AC Line Conducted Emission Data .............................................................................. 13 3.4....... Antenna Conducted Emission Data .............................................................................. 16 4.0 List of Test Equipment ................................................................................................. 19 Appendix A – EUT Specification............................................................................................. 20 Appendix B – Local Oscillator Frequency calculation .......................................................... 21 Appendix C – Antenna Drawing ............................................................................................. 22 EMC Report for General Research of Electronics, Inc.on the model PRO-2054 File: 30760821 Page 4 of 22 1.0 General Description 1.1 Product Description The Equipment under Test (EUT) is Multi Trunk-Tracking Scanning Receiver, model PRO-2054 Please refer to the attached specifications sheets in Appendix A for more details. A pre-production version of the sample was received on April 25, 2005 in good condition. As declared by the Applicant, it is identical to product…
