20-496 Owner’s Manual Draft Page 1/78 20-496 Owner’s Manual-Draft LOGO PRO-2096 500-Channel Mobile/Desktop Digital Trunking Scanner Catalog # 20-496 OWNER’S MANUAL — Please read before using this equipment. Thank you for purchasing the RadioShack PRO-2096 Mobile/Desktop Digital Scanner. This product is the first of an innovative and exciting new generation of RadioShack scanning receivers capable of receiving Phase 1 APCO-25 C4FM/IMBE digital voice modulation from the newest and most sophisticated conventional and trunked radio networks. Your RadioShack Mobile/Desktop Digital Scanner is ready to receive digital conventional and trunked radio transmissions. No additional hardware or add-on cards are needed. IMPORTANT: If an icon appears at the end of a paragraph, go to the box on that page with the corresponding icon for pertinent information. ! — Warning ! — Important thunder mark — Caution light mark — Hint note mark — Note TABLE OF CONTENTS Features The FCC Wants You to Know Scanning Legally Getting Familiar With Your Scanner About the Keypad Understanding Your Scanner’s Memory Organization Channel Storage Banks Channels Search Banks Understanding Your Scanner’s Channel Receive Modes Preparation Mounting the Scanner in Your Vehicle Powering the Scanner from Vehicle’s Battery Using the Scanner as a Base Station Connecting an Extension Speaker Connecting an Earphone/Headphones 20-496 Owner’s Manual Draft Page 2/78 Listening Safely Connecting an Supplied Antenna Programming Your Scanner Programming Conventional Channels Programming Trunked Systems Programming Motorola Analog, Digital, and APCO-25 Trunking Systems Programming EDACS Trunking Systems Programming Motorola VHF and UHF Trunking Systems Programming Motorola 800 MHz Splinter Systems Talkgroup IDs Programming the Priority Channels Programming Channels for CTCSS and DCS Operation General Programming Notes Operating Your Scanner Initial Preparation Searching and Tuning Searching a Preprogrammed Frequency Range Using Zeromatic Using Seek Search Manually Tuning a Frequency Using Frequency Copy Copying a Frequency into a Specified Channel Copying a Frequency into a Vacant Channel in a Specified Bank Coping a Frequency into the Priority Channel Special Features Listening to the Weather Band Listening to a Weather Channel Using the Delay Function Locking Out Channels or Frequencies Changing the Receive mode Using the Attenuator Turning the Key Tone On and Off Using Dimmer Changing the Display Contrast Working with V-Scanners Using the Digital AGC Function Cloning the Programmed Data Cloning V-Scanner Data Trunking Special Features Trunking Operation Activating ID Lockout While Scanning Trunked Delay Function Clearing Talkgroup IDs 20-496 Owner’s Manual Draft Page 3/78 Digital Operation Updating the DSP Firmware A General Guide To Frequencies Guide To The Action Bands Typical Band Usage (in MHz) Primary Usage Band Allocation Frequency Conversion Troubleshooting Troubleshooting Chart Resetting / Initializing the Scanner Care Service and Repair Specifications Command Quick Reference Guide © 2004 RadioShack Corporation All Rights Reserved. RadioShack, RadioShack.com, Hypersearch, Hyperscan, V-Scanner, and Adaptaplug are trademarks used by RadioShack Corporation. Motorola, Smartnet, ASTRO and Privacy Plus are registered trademarks of Motorola Inc. EDACS is a registered trademark of MA-COM Inc. The IMBE™ voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to decompile, reverse engineer, or disassemble the Object Code, or in any other way convert the Object Code into a human readable form. U.S. Pat. Nos. 5,870,405 and 5,517,511. This device made under license under one or more of the following U.S. Patents: 4,590,473; 4,636,791; 5,148,482; 5,185,796; 5,271,017; 5,377,229 FEATURES Your RadioShack Mobile/Desktop Digital Scanner features Intelligent Adaptive Digital Tracking for optimal reception of digital signals from a variety of digital conventional and trunked radio system types. No special sound quality settings or adjustments are needed for the different digital systems that you monitor. APCO-25 digital voice modulation provides public safety radio users with clear digital voice signals and other features not available in traditional analog systems. Your scanner uses advanced Digital Signal Processing (DSP) technology to receive and decode APCO-25 digital signals from both conventional and trunked radio networks. Additionally, your scanner features automatic detection of digital signals. No 20-496 Owner’s Manual Draft Page 4/78 special scanner programming is required to receive conventional or trunked digital traffic. The DSP module in your scanner features updateable firmware. If DSP improvements become available, you can easily download an update file from the Internet and apply the file to your scanner to obtain the latest DSP firmware version. Your scanner is designed to track Motorola analog and Astro® digital trunking systems using 3600 bps control channel operation, APCO 25 digital trunking systems using 9600 bps control channel operation, and M/A-COM EDACS® trunking systems. The scanner lets you scan conventional transmissions, and is preprogrammed with service search banks for your convenience. By pressing a single button, you can quickly search those frequencies most commonly used by public safety and other agencies. Your RadioShack Mobile/Desktop Digital Scanner features RadioShack’s exciting new 11-in-1 V-Scanner technology. V-Scanner stands for Virtual Scanner. V-Scanner allows you to build and store eleven separate configuration profiles in V-Scanner folder memory. Stored V-Scanners can be recalled, edited and activated at any time, giving yo…
