December 7, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT:SANYO ELECTRIC CO., LTD FCC ID: AEZC401SA Part 22 Certification Gentlemen: Attached herewith, on behalf of SANYO ELECTRIC CO., LTD., is an application for Part 22.901(d) Certification of the following Single Mode Cellular CDMA Phone: FCC ID:AEZC401SA TRADE / MODEL(s):SANYO AEZC401SA EUT Classification:Non-Broadcast Transmitter Held to Ear (TNE) Tx Freq. Range:824.70 — 848.31 MHz (CDMA) Rx Freq. Range:869.70 — 893.31 MHz (CDMA) Max. RF Output Power:0.326 W ERP CDMA (25.13 dBm) Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report data and plots, RF Exposure measurement report, FCC ID label and location, test setup photographs, internal and external photographs, block diagrams (confidential), schematic diagrams (confidential), operational description, parts list & tune-up procedure, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Mr. Koichi Takahashi V.P. Marketing SANYO Fisher (USA) Corporation

February 1, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Andy Leimer SUBJECT: SANYO Electric Co., Ltd. FCC ID: AEZC401SA 731 Confirmation No.: EA99464 Correspondence Reference No.: 17849 Request for Tech. Info.: 01/29/2001 Dear Andy: Transmitted herewith, on behalf of Sanyo Electric Co., Ltd., is an amendment provided in response to the request for technical information dated January 29, 2001. 1. Attached is the SAR Report with the correct tabulated body-worn SAR results. 2. Attached is the revised Tune-Up Procedure that indicates a normal test mode output of 24.1 dBm. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: SANYO Electric Co., Ltd.

February 6, 2001 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Andy Leimer SUBJECT: SANYO Electric Co., Ltd. FCC ID: AEZC401SA 731 Confirmation No.: EA99464 Correspondence Reference No.: 18001 Request for Tech. Info.: 02/06/2001 Dear Andy: Transmitted herewith, on behalf of Sanyo Electric Co., Ltd., is an amendment provided in response to the request for technical information dated February 5, 2001. 1. Attached are the TX Limit Adjustments that correspond to the max conducted power of 24.1 dBm used for the SAR test. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact us. cc: SANYO Electric Co., Ltd.

© 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone

© 2000 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) MODEL NO: C401SA FCC ID: AEZC401SA MADE IN JAPAN

© 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone © 2000 PCTEST Lab FCC ID: AEZC401SA (Model(s): C401SA) NVLAP Lab Code: 100431-0 SANYO Single Mode Cellular Phone

For more information about RF exposure, please visit the FCC website at www.fcc.gov FCC RF EXPOSURE INFORMATION In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards. Use only the supplied or an approved antenna. Unauthorized antennas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna. Body-worn Operation This device was tested for typical body-worn operations with the back of the phone kept 1.6 cm. from the body. To maintain compliance with FCC RF exposure guidelines, use only belt-clips, holsters or similar accessories that maintain a 1.6 cm. separation distance between the user’s body and the back of the phone, including the antenna, whether extended or retracted. The use of third-party belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure guidelines, and should be avoided. WARNING! Read this information before using your phone

© 2000 PCTEST Engineering Lab., Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE (SAR EVALUATION) SANYO ELECTRIC CO., LTD. Dates of Tests: Nov. 29-30 & Dec. 1, 2000 c/o Sanyo Sales & Supply (USA) Corp. Test Report S/N: SAR.201129601.AEZ 900 North Arlington Heights Road, Suite 300 Test Site: PCTEST Lab, Columbia, MD USA Itasca, IL 60143-2844 Attn: Mr. Koichi Takahashi, V.P. Engineering SANYO Fisher Company (USA) FCC ID AEZC401SA APPLICANT SANYO Electric Co., Ltd. EUT Type: Single Mode Cellular Phone (CDMA) Tx Frequency: 824.70 – 848.31 MHz (CDMA) Rx Frequency: 869.70 – 893.31 MHz (CDMA) Max. RF Output Power: 0.326 W ERP CDMA (25.13 dBm) Trade Name/Model(s): SANYO C401SA FCC Classification: Non-Broadcast Transmitter Held to Ear (TNE) Application Type: Certification FCC Rule Part(s): §2.1093; ET Docket 96.326 Antenna Model: TOKIN MPA-0008SA-01 Whip Antenna Maximum SAR: 1.4569 W/kg (Brain SAR) 0.8511 W/kg (Body SAR) 1.3350 W/kg Avg. over 10gm (Hand SAR) This wireless portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in ANSI/IEEE Std. C95.3-1992. (See Test Report) I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 201129601.AEZ Test Report S/N: SAR.201129601.AEZ SAR Measurement Report Test Dates: NOV. 29-30 & DEC. 1, 2000 FCC Part 22/24 Certification Table of Contents 1.1 SCOPE....................................................................................................1 2.1 INTRODUCTION......................................................................................2 2.2 SAR Definition.......................................................................................................2 3.1 SAR MEASUREMENT SET-UP................................................................3 4.1 ISOTROPIC E-FIELD PROBE SYSTEM....................................................4 5.1 E-field PROBE CALIBRATION PROCESS................................................5 6.1 PHANTOM AND EQUIVALENT TISSUES.................................................7 7.1 SYSTEM SPECIFICATIONS.....................................................................8 8.1 MEASUREMENT PROCESS....................................................................9 9.1 TEST POSITION OF THE PHONE.........................................................10 10.1 BODY-WORN TEST SETUP................................................................11 11.1 ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS..................................12 12.1 MEASUREMENT UNCERTAINTIES.......................................................13 13.1 SAR TEST DATA SUMMARY...............................................................14 14.1 SAR TEST EQUIPMENT.......................................................................17 15.1 CONCLUSION......................................................................................19 Test Report S/N: SAR.201129601.AEZ SAR Measurement Report Test Dates: Nov. 29-30 & Dec. 1, 2000 FCC Part 22 Certification FCC ID: AEZC401SA (Model(s): C401SA) © 2000 PCTEST Lab SANYO Single Mode Cellular Phone 1 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in simulated human tissues exposed to radiofrequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC) and Industry Canada (IC). 2 Applicant Name: SANYO ELECTRIC CO., LTD. Address: c/o Sanyo Sales & Supply (USA) Corp. 900 North Arlington Heights Road, Suite 300 Itasca, IL 60143-2844 Attention: Mr. Koichi Takahashi, V.P. Engineering SANYO Fisher Company (USA) • EUT Type: Single Mode Cellular Phone (CDMA) • Trade Name: SANYO • Model(s): C401SA • FCC IDENTIFIER: AEZC401SA • Tx Frequency: 824.70 – 848.32 MHz (CDMA) • Rx Frequency: 869.70 – 893.31 MHz (CDMA) • Application Type: Certification • FCC Classification: Non-broadcast Transmitter Held to Ear (TNE) • FCC Rule Part(s): § 2.1093, Docket 96-326 • Modulation(s): CDMA • Max RF. Output Power: 0.326W ERP CDMA (25.13 dBm) • Date(s) of Tests: Nov. 29-30 & Dec. 1, 2000 • Place of Tests: PCTEST Engineering Lab. Columbia, MD, U.S.A. • Report Serial No.: SAR.201129601.AEZ 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET-Docket 93-62. Test Report S/N: SAR.201129601.AEZ SAR Measurement Report Test Dates: Nov. 29-30 & Dec. 1, 2000 FCC Part 22 Certification FCC ID: AEZC401SA (Model(s): C401SA) © 2000 PCTEST Lab SANYO Single Mode Cellular Phone 2 2.1 INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety L…
