AEZM220Microwave Oven

A-011-00-C Page 1 of 11 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Designated by Ministry of International Trade and Industry KANSAI ELECTRONIC INDUSTRY DEVELOPMENT CENTER HEAD OFFICE IKOMA TESTING LABORATORY 6-8-7 NISHITENMA 12128 TAKAYAMA-CHO KITA-KU OSAKA 530-0047 JAPAN IKOMA-CITY NARA 630-0101 JAPAN Corporate Juridical Person TEST REPORT Report No.A-011-00-CDate: 31 March 2000 This test report is to certify that the tested device properly complies with the requirements of: FCC Rules and Regulations Part 18 Subpart C. The tests necessary to show compliance to the requirements were performed and these results met the specifications of requirement. The results of this report should not be construed to imply compliance of equipment other than that, which was tested. Unless the laboratory permission, this report should not be copied in part. 1. Applicant Company Name:SANYO Electric Co., Ltd. Laundry & Cooking Appliances Division Mailing Address:1-1, Seta 1-chome, Otsu City, Shiga, 520-2198 Japan 2. Identification of Tested Device Type of Device:INDUSTRIAL, SCIENTIFIC, AND MEDICAL EQUIPMENT Kind of Equipment Authorization:: DoC : Certification: Verification FCC ID:AEZM220 Device Name:Microwave Oven Trade Name: SANYO Model Number: EM-V3405SW Serial Number:No.1 : Prototype : Pre-production: Production Date of Manufacture:March, 2000 3. Test Items and Procedure : AC Power Line Conducted Emission Measurement : Radiated Emission Measurement (30MHz−1000MHz) Above all tests were performed under: FCC/OET MP-5(1985) : without deviation, : with deviation(details are found inside of this report) 4. Date of Test Receipt of Test Sample:7 March 2000 Test Completed on: 28 March 2000 Eizo Hariya General Manager of Ikoma Testing Laboratory A-011-00-C Page 2 of 11 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan Table of Contents 1. GENERAL INFORMATION-----------------------------------------------------------3 1.1 Product Description----------------------------------------------------------------------------------------------------------------------3 1.2 Description for Equipment Authorization--------------------------------------------------------------------------------------3 1.3 Test Facility---------------------------------------------------------------------------------------------------------------------------------4 1.TESTED SYSTEM-------------------------------------------------------------------5 1.1Test Mode-------------------------------------------------------------------------------------------------------------------------------5 1.2Operaton of EUT System---------------------------------------------------------------------------------------------------------5 2.3 Block Diagram of EUT System-----------------------------------------------------------------------------------------------------6 3. MEASUREMENT OF ELECTRIC FIELD STRENGTH (30 MHz TO 1000 MHz)--------7 3.1 Reference Rule and Specification-------------------------------------------------------------------------------------------------7 3.2 Test Procedure------------------------------------------------------------------------------------------------------------------------------7 3.3 Test Arrangement-------------------------------------------------------------------------------------------------------------------------8 3.4 Photographs of EUT System Configuration-----------------------------------------------------------------------------------9 3.5 Test Results--------------------------------------------------------------------------------------------------------------------------------10 4. LIST OF TEST INSTRUMENTS-----------------------------------------------------11 A-011-00-C Page 3 of 11 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 1. GENERAL INFORMATION 1.1 Product Description The SANYO Model No. EM-V3405SW(refered to as the EUT in this engineering test report) is a Household Microwave Oven. (1) Special Feature Magnetron Frequency : 2450 MHz ± 50 MHz RF Power : 1200 W (2) Rated Power Supply AC 120 V, 60 Hz Protection Class 1(with ground connector) (3) Contained Oscillator 4.0 ± 0.4 MHz(Main PCB) 1.2 Description for Equipment Authorization (1) Category:Class AClass B Not Applicable (2) Reference Rule and Specification:FCC Rule Part 18 Section 18.305 (a), (b) (3) Type of device:Personal Computer & Peripherals Other Digital Device ISM Device (4) Kind of Equipment Authorization:DoC CertificationVerification (5)Procedure of Application:Original Equipment Modification (6)Highest Frequency used in the Device:2.45 GHz (7)Upper Frequency of Radiated Emission Measurement Range :1000 MHz2000 MHz 5000 MHz The Tenth Harmonic A-011-00-C Page 4 of 11 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 1.3 Test Facility All tests described in this report were performed by: Name:KANSAI ELECTRONIC INDUSTRY DEVELOPMENT CENTER (KEC) IKOMA TESTING LABORATORY Open Area Test Site No.1 No.2 No.3 No.4 EMC M.C. Anechoic Chamber No.1 Shielded Room No.2 No.4 EMC M.C. Shielded Room Address:12128, Takayama-cho Ikoma-city, Nara, 630-0101 Japan These test facilities have been filed with the FCC under the criteria of ANSI C63.4-1992. The Open Area Test Site No.4, EMC M.C. Anechoic Chamber No.1, Shielded Room No.4 and EMC M.C. Shielded Room have been accredited by the NVLAP (Lab. Code: 200207-0) based on ISO/IEC Guide 25. Also the laboratory has been authorized by ITI (Interference Technology International, (UK), TUV Product Service (GER) and TUV Rheinland (GER) based on their criteria for testing laboratory (EN45001). A-011-00-C Page 5 of 11 KEC Ikoma Testing Laboratory 12128 Takayama-cho Ikoma-city Nara 630-0101 Japan 1. TESTED SYSTEM 1.1 Test Mode The compliance tests were performed under following operation mode. Maximum Output Power Operation 1.2 Operaton of EUT System (1) Open the door of EUT. (2) Set the load as follows in EUT. …
